ACTi R12CP-30 User manual

Reader & Controller
Installation Guide
R12CP-30
2019/01/15

www.acti.com
Installation Guide
2
Table of Contents
Precautions.............................................................4
Safety Instructions .................................................................................... 5
Introduction.............................................................6
Package Contents...................................................................................... 6
Additional Requirement for Installation................................................... 6
Physical Description ................................................................................. 7
The Device.............................................................................................. 7
Front Panel ............................................................................................. 7
Connectors.............................................................................................. 8
Installation Procedure..........................................10
Step 1: Install the Mounting Plate .......................................................... 10
Mounting Directly on the Surface.......................................................... 10
Embedding into the Wall ....................................................................... 10
Step 2: Do the Wiring ...............................................................................11
Step 3: Install the Device ........................................................................ 12
Step 4: Connect to Power Source.......................................................... 12
Wiring Diagram .....................................................13
Connect to Door Contact ........................................................................ 13
Connect to Electric Bolt.......................................................................... 13
Connect to Magnetic Lock...................................................................... 14
Connect to Reader................................................................................... 14
Connect to Electric Strike....................................................................... 15
Connect to Relay Output Module for Added Security .......................... 15

www.acti.com
Installation Guide
3
Wiegand Mode ......................................................................................... 16
Quick Setup...........................................................17
Enter Setup Mode.................................................................................... 17
Initial Setup .............................................................................................. 17
Change the Language .......................................................................... 17
Configure the IPAddress...................................................................... 17
Useful Shortcuts...................................................................................... 18
How to Exit the Menu............................................................................ 18
How to Change the Master Code.......................................................... 18
How to Lock and Unlock the Keypad .................................................... 18
Accessing the Device...........................................19
Web Interface........................................................................................... 19

www.acti.com
Installation Guide
4
Precautions
Read these instructions
You should read all the safety and operating instructions before using this product.
Heed all warnings
You must adhere to all the warnings on the product and in the instruction manual. Failure to follow
the safety instruction given may directly endanger people, cause damage to the system or to
other equipment.
Servicing
Do not attempt to service this video device yourself as opening or removing covers may expose
you to dangerous voltage or other hazards. Refer all servicing to qualified service personnel.
Trademarks
All names used in this manual are probably registered trademarks of respective companies.
Liability
Every reasonable care has been taken during the writing of this manual. Please inform your local
office if you find any inaccuracies or omissions. We cannot be held responsible for any
typographical or technical errors and reserve the right to make changes to the product and
manuals without prior notice.

www.acti.com
Installation Guide
5
Safety Instructions
Cleaning
Disconnect this product from the power supply before cleaning.
Attachments
Do not use attachments not recommended by the product manufacturer as they may cause
hazards.
Do not use accessories not recommended by the manufacturer
Install this device in a dry place protected from varying weather conditions.
Servicing
Do not attempt to service this product yourself. Refer all servicing to qualified service personnel.
Damage Requiring service
Disconnect this product from the power supply immediately and refer servicing to qualified
service personnel under the following conditions.
1) When the power-supply cord or plug is damaged
2) If liquid has been spilled, or objects have fallen into the product.
3) If the inner parts of product have been directly exposed to rain or water.
4) If the product does not operate normally by following the operating Instructions in this manual.
Adjust only those controls that are covered by the instruction manual, as an improper
adjustment of other controls may result in damage, and will often require extensive work by a
qualified technician to restore the product to its normal operation.
Safety Check
Upon completion of any service or repairs to this product, ask the service technician to perform
safety checks to determine if the product is in proper operating condition.

www.acti.com
Installation Guide
6
Introduction
Package Contents
1. Reader and Controller Unit
2. Ethernet Terminal Cable
3. Terminal Cables (x 5)
4. Terminal block strip (x 3)
5. Screw Pack
6. Waterproof Rubber Strip
NOTE: Actual items may slightly vary.
Additional Requirement for Installation
The following items are not included in the package. Installers must prepare these items to do the
installation.
1. DC 10~24V Power adapter
2. Ethernet cable
3. Allen wrench

www.acti.com
Installation Guide
7
Physical Description
The Device
Front Panel
Below are the detailed descriptions of the front panel indicators and keypad.
Press to enter SETUP mode
In SETUP menu, press to go
back a previous screen.
ESC / Quit
Press to “Enter” or select

www.acti.com
Installation Guide
8
Connectors
This section shows the connectors at the back of the device and its pin mapping definition. For
wiring examples, see Wiring Diagram on page 13.

www.acti.com
Installation Guide
9

www.acti.com
Installation Guide
10
Installation Procedure
This section describes the procedures in installing the camera on the wall.
Step 1: Install the Mounting Plate
The device can be mounted on the wall either by mounting directly on the surface or flushed into
the wall where only the device front panel can be seen on the surface. First, determine how you
want to mount the device then install the mounting plate on the wall.
Mounting Directly on the Surface
1. Drill the hole where the cables will pass through
the wall using the mounting plate as template.
2. Mark or drill the screw holes, if necessary.
3. Install the mounting plate by securing
four (4) screws as marked on the illustration.
Embedding into the Wall
The device can be flushed or embedded into the wall so only the edge of the mounting plate and
the device front panel can be seen on the surface.
1. Drill a hole with dimensions of 128 mm x 108 mm. This is where the device will be
embedded.
2. Drill the hole where the cables will pass through
on the wall, use the mounting plate as template
for its location.
3. Flush the mounting plate into the wall.
4. Drill the holes and attach the four (4) screws
to secure the plate as marked on the illustration.
Cable hole
Cable hole

www.acti.com
Installation Guide
11
Step 2: Do the Wiring
Determine the devices that you will connect to the reader/controller.
1. The reader/controller comes with terminal blocks to easily connect devices to the unit. Once
you determine the devices to connect, cut off the needed terminal blocks and connect to the
corresponding terminal cable wires. Below is an example of connecting the wires to the
supplied terminal block.
TIP: For the most basic operation, the terminal cables for Ethernet, CN4 (for power adapter
and lock relay, etc.), CN5 (for wiegand connections) are commonly used.
2. Route the cables such as the power source and other devices (such as door lock, sensor,
etc.) that will be connected to the reader/controller through the hole on the wall and the
mounting plate.
3. Then connect the devices to the supplied terminal block. Below is an example of connecting
a DC 12V power adapter. Note that the RED wire connects to the DC 12V wire of the power
adapter (cable with white lines) while the BLACK wire connects to the ground wire of the
power adapter.
4. Continue to connect other devices, as needed. Refer to Wiring Diagram on page 13.
White stripe: Connects to 12V Pin
Connects to GND Pin

www.acti.com
Installation Guide
12
5. When all wirings are ready, connect the terminal cables to the corresponding connectors on
the reader/controller.
Step 3: Install the Device
Align the top part of the reader/controller to the mounting plate and attach the two (2) supplied
screws.
Step 4: Connect to Power Source
When the unit is connected to the power source, the unit will initialize. Once complete, the LCD
will display “Ready”.

www.acti.com
Installation Guide
13
Wiring Diagram
This section shows the wiring options you can do with the reader/controller.
Connect to Door Contact
Connect to Electric Bolt

www.acti.com
Installation Guide
14
Connect to Magnetic Lock
Connect to Reader

www.acti.com
Installation Guide
15
Connect to Electric Strike
Connect to Relay Output Module for Added Security

www.acti.com
Installation Guide
16
Wiegand Mode
It is possible to use the unit as a reader and connect it to another unit which can be the controller.
To do this, connect the units by Wiegand. Below is the wiring diagram.

www.acti.com
Installation Guide
17
Quick Setup
Enter Setup Mode
Enter Setup mode if you need to change any of the settings or add users to the device.
To enter setup mode, press 1 2 3 4 5 6 . 123456 is the default master code; to
modify the master code, see How to Change the Master Code on page 18.
Initial Setup
Change the Language
The default device interface language is English, to change the language:
1. Press 1 2 3 4 5 6
2. Press 5[Tools] 1[Language]
3. Press either 0[English] or 1[Chinese]
Configure the IP Address
The default IP address of the device is: 192.168.0.100
You can modify the static IP address or enable DHCP mode to obtain automatically obtain an IP
address if it is connected to a DHCP server.
Modify the IP Address
To modify the static IP address, do the following:
1. Press 1 2 3 4 5 6
2. Press 3 [Parameters (1)] 1 [Node ID]
3. Press four (4) times to scroll through the submenu option until you see ENABLE
DHCP on the screen.
4. On the ENABLE DHCP screen, press 0 to select static address.
5. Press the keypad to enter the preferred IP address.
TIP: Press to enter or copy the existing value shown on the screen.
6. Continue to enter the Net Mask, and Gateway.
7. When done, press to exit the configuration menu.

www.acti.com
Installation Guide
18
Automatically Obtain an IP Address
To automatically obtain an IP address, do the following:
1. Press 1 2 3 4 5 6
2. Press 3 [Parameters (1)] 1 [Node ID]
3. Press four (4) times to scroll through the submenu option until you see ENABLE
DHCP on the screen.
4. On the ENABLE DHCP screen, press 1 to select Enable DCHP. The device will
automatically restart and obtain an IP address from the connected server.
How to Check the IP Address
When the device has obtained an IP address automatically, you may need to check and know
what that IP address is. To check for the IP address, do the following:
1. Press 1 2 3 4 5 6
2. Press 3 [Parameters (1)] 1 [Node ID]
3. Press four (4) times to scroll through the submenu option until you see ENABLE
DHCP on the screen. This screen also shows the current IP address of the device.
4. Press 2 to exit the submenu, then press repeatedly to go back the previous
submenu screens.
5. Press 6 to Quit or close the menu.
Useful Shortcuts
How to Exit the Menu
Press repeatedly or select the corresponding number of QUIT as shown on some of the
screens.
How to Change the Master Code
1. Press 1 2 3 4 5 6
2. Press 5 [Tools] 2 [Master Code]
3. Press the keypad to enter the new 6-digit master code.
4. The screen will automatically show SUCCEEDED after pressing the last digit of the code.
How to Lock and Unlock the Keypad
Press and at the same time to lock or unlock the keypad.

www.acti.com
Installation Guide
19
Accessing the Device
Web Interface
In order to be able to communicate with the device from your PC, both the device and the PC
have to be within the same network segment. In most cases, it means that they both should have
very similar IP addresses, where only the last number of the IP address is different from each
other.
The default IP address is 192.168.0.100. If the device is connected to a DHCP server, then you
have to check what the device IP address is in order to type it on the PC web browser. See How
to Check the IP Address on page 18 to identify the IP address of the device.
1. Open a web browser and type the IP address on the address bar.
2. If prompted to login, type the User Name “admin”and leave the Password empty.
3. After a successful login, the user interface will be shown.

Copyright © 2019, ACTi Corporation All Rights Reserved
7F, No. 1, Alley 20, Lane 407, Sec. 2, Ti-Ding Blvd., Neihu District, Taipei, Taiwan 114, R.O.C.
TEL : [phone] FAX : [phone]
Email: [e-mail]
