ACTi ACM-3601 User manual

Megapixel IP Dome
ACM-3401
Megapixel Day&Night IP Dome
ACM-3411
Ver. 080130
Quick Installation Guide
IP Mini Dome
ACM-360x series
Ver. 090518
Quick Installation Guide

0-1
0Getting Started
1.1 PACKAGE CONTENTS
ACM-3601/ACM-3603 Product CD
Warranty Card Drill Template
Mount Screws Allen/Hex Key
RJ45 Field Installable Feed M12 Field Installable Feed
Through Adaptor (ACM-3601 Only) Through Adaptor (ACM-3603 Only)
1

0-2
1.2 PHYSICAL DESCRIPTION
ACM-3601 ACM-3603
1. The LED will indicate ethernet speed and active states after IP
camera has connected completely.
Ethernet Indicator LED
2. The LED will light up after IP camera has successfully completed
the boot process
Power LED
3. Step 1: Switch off IP device by disconnecting the power cable
Step 2: Press and continue to hold the Reset Button. Reconnect
the power cable while continuing to hold the reset button.
Step 3: Keep holding the reset button depressed around 16
seconds, release the reset button. The unit will start up with
factory default settings.
Reset Button

0-3
Model
ACM-3601
ACM-3603
Type
Rugged RJ-45 Connector
Rugged M12 Connector
1. The IP device connects to the Ethernet via a female RJ-45
industrial connector(ACM-3601) or a male M12 D-code Ethernet
connector(ACM-3603)
The Ethernet port supporting Power over Ethernet.
Ethernet Port
Supporting NWAY, this IP device can auto detect the speed of
local network segment (10Base-T/100Base-TX Ethernet).

1-1
1.3 BASIC CONNECTIONS
Follow the procedures below to connect the IP device to the respective
apparatuses.
1. Connect this IP device’s ethernet port to an Ethernet (RJ45/ M12
connector). IP device has only PoE built-in, you must regard it as a PD and
connect it directly to a PSE device like PoE switch.
2. Connect a PC to the Ethernet hub
1Quick Tour
NOTE: You may find a support package for help you getting familiar
with PoE. Please visit our web site, and get the support document
TS-00040.
2

1-2
This section guides you with a quick tour on this IP device.
2.1 Configure this IP Device
2.1.1 Make sure network environment
Default IP of this IP device is 192.168.0.100. Please make sure this IP device and
your PC are on the same network segment before running the installation.
2.1.2 Open Internal Explorer with IP address
Please set the settings as below.
IP address: 192.168. 0.xxx
Subnet mask: 255.255.255. 0
(NOTE: xxx should be a number
from 1 to 254, but 100 is
excepted.)

1-3
NOTE: If your web browser is earlier than IE6, then download IE6 is
recommended.
NOTE: This IP device default IP address is set to 192.168.0.100
2.1.3 Login with default administrator’s account & password
NOTE: Default administrator account is set to Admin, password is set to
123456, and click button.
2.1.4 Preview the video

1-4
2.1.5 Set the new IP address
*IP Address : The default IP address is 192.168.0.100.

1-5
*Subnet Mask : The default subnet mask is 255.255.255.0
*Click button
NOTE: In your Client PC, please make sure the setting of Network
Connections Type is set to Auto Negotation, since this IP device follows
MII standard. Otherwise, you might not see the live image.
IMPORTANT:After the IP address is changed, please record this IP
address. There’s no way to connect to the IP device if user forgets the
new IP address.
2.1.6 Check Default Video Setting
2.1.7 Click Save Reboot
to restore all settings and please wait about 30 seconds
for system reboot.
