ActiV POLIBOX 120888 User manual

ONLY BY SDS

83,0 lt
50 mm
50 gr/lt
6725 gr
1
8
2 x GN 1/1
65 mm
1 x GN 1/1
100 mm
1 x GN 1/1
150 mm
2 x GN 1/1
200 mm 4 x GN 1/1 100 mm
610
500
480
650
540
330
Item code 120888PORTER
GN ACTIV
L
O
W
E
N
E
R
G
Y
P
R
O
D
U
C
T
250W
230V 50/60Hz
0
PPE
EPP
go to the site www.polibox.com go to Manual of use and maintenance
Certifications.
The Polibox® products present the following
certifications obtained at the Experimental Station
of Industry for canned food in Parma (SSICA):
• Cold-hot decay
• Decay under freezing
Obtained from Pack Co Srl:
• Overall migration testing OM6
TÜV certified
product
Dimensions.
Stackable..........................
Colour ...............................
Colored lid.......................
Capacity ...........................
Wall thickness ...............
Material density...........
Vacuum weight ...........
Pieces per package....
Pieces per pallet..........
Weight and dimensions
have a tolerance of +/-10%
Product description. The isothermal box Polibox®, made of polypropylene foam (PPE), is suitable to protect food
against thermal stresses due to the insulating properties of polymer foam, which has a coefficient of resistivity
(Lambda) of 0,039 W/mk, which guarantees a thermal loss according to standard UNI EN 12571:1999.
Technical features. The polypropylene is expanded with CO2, without CFC and HCFC and doesn’t have residual
expansion agents. It has a closed-cell structure, which gives excellent energy dissipation characteristics with shock and
specific thermal resistance.
Polypropylene foam has an excellent environmental balance and doesn’t cause environmental damages either due to
production effect or as raw material, because:
- it consists mainly of air (with regard to the density it can reach 98% air) and only 2% of pure structural hydrocarbon
material.
- it is 100% recyclable and at infinite cycles without the release of waste into the environment or loss of physical-
chemical characteristics.
- it is a stable plastic polymer of hydrogen and carbon.
- Operating temperature -40° + 120°C
capacity
12 x GN
trays
90° C
(resistance)

ONLY BY SDS
Manual of use and maintenance.
The correct application of the following standards of use is necessary to hold the thermal functioning
of the product, both for operators’ safety as well as for the environments where it is used.
STANDARDS FOR ELECTRICAL SAFETY
Porter Activ is an electric appliance and for its use it is necessary to observe some basic precautions
concerning safety. Therefore it is necessary to read carefully the following instructions of use.
• Introduce the supply cable outlet to the box, ensuring that the connection plug is
completely dry.
• Connect the plug to an earth connected current outlet.
• The green led and the red led are switched on:
Red led > current supply,
Green led > supply to the resistance (when the resistance reaches the temperature, the
green led switches off).
NOTE: call technical assistance, if the green led doesn’t switch on when connecting the feeder cable.
• Don’t touch the hot parts of the box (wall opposite the opening one).
• Be extremely careful when there is oil or other boiling liquids inside the box.
• Don’t use the box for uses different from the original one.
• Don’t immerse the cable, the plug or the box in water or other liquid in order to be protected against
electric shocks; avoid the use of water splashes when connected to the network.
• Avoid the use of accessories, not recommended by SDS
• In order to reduce the risk of personal injuries, disconnect the cable from the feeding net when:
- the box isn’t used
- during handling operations
- during cleaning, maintenance, repair operations
• The feeder cable has always to be whole, may not come in contact with hot parts or with oil, may not
be connected on the edge of a table or touch boiling surfaces.
• Don’t place the appliance on or near an electric, gas or hot oven.
• If the feeder cable of this unit is damaged, it should be replaced by the manufacturer, by an authorized
centre or by qualified staff.
IMPORTANT: if the capsuled plug is damaged, replace it immediately. It is not possible to
introduce new cables in the plug and this could cause electric discharges if introduced in an
outlet.
TERMS OF USE
The isothermal box Porter Activ should be used
to keep products at a controlled temperature,
and it is easily transportable. The isothermal box
should not be used directly in ovens or cookers.
Heat-sensitive and thermal perishable products
in special packages or hygienic pre-wrapped,
trays or welded plates, gastronorm dishes of steel,
polycarbonate or polypropylene can be placed in
the box.
Regarding the “hot bond” it is recommended to
supply the box electrically for at least 30 minutes
before its use and to keep it supplied till the
moment of transport.
Before using the Porter Activ for the first time,
wash the box, including the lid, according to
the procedure noted in paragraph Cleaning
instruction. It is recommended to place it on a
clean flat surface. The heat-sensitive and thermal
perishable products have to be placed in special
cases, which allow the closure in order to prevent
spillage or leakage of substances. Place the
special cartons in the Polibox®, taking care to fill
the entire base area and to distribute the weight
evenly; close the Polibox® with the appropriate
lid. In order to ensure the correct thermal seal
function, it is necessary that the Polibox® remains
closed with the proper lid from the packaging
until product delivery.
go to Next pagego to the site www.polibox.com
back to Technical Data

ONLY BY SDS
back to Previous page
Temperature: the products placed
inside the Porter Activ shouldn’t have a
higher temperature than 100 °C. A digital
thermometer (optional) can be applied to the
Polibox® for temperature control. Observe the
requirements of standard UNI EN 12571:1999
for the correct temperature maintenance.
Handling and transport: due to the
type and thickness of the material, the box
is lightweight, without sharp edges and
protrusions, both to protect the safety of the
operators during handling and transport,
as well as to avoid accumulation of dirt in
the corners. However, it is recommended to
use proper hand trolleys; it is possible to use
the optional trolley. In general you should
observe the company procedures for the
correct handling of loads.
Food safety: polypropylene is a material,
suitable for contact with food substances. It
doesn’t release either smell, or taste to foods
and it can be easily washed and sanitized after
use. The boxes Porter Activ are suitable to
protect the food against thermal stresses, due
to the insulating properties of the polymer
foam, which has a coefficient of resistivity
(lambda) of 0.039 W / mk and ensures a
thermal loss according to standard UNI EN
12571:1999.
Cleaning instructions:
ATTENTION:
Disconnect the product from
the network before cleaning
the plate and
close the socket
protector.
Don’t clean the hot plate under running water
or pour a liquid product on it, but use a wet
cloth, both for the inner and outer box surface.
The isothermal box can be washed and
sanitized in a dishwasher, in industrial cleaning
centres,withdirectwaterjet,withhigh-pressure
machines, with steam machines (up to 100°C)
or by hand. All detergents and disinfectants
can be used for the cleaning provided they
don’t contain products derived from petrol
and trichloroethylene. It is recommended to
wash the box both internally and externally in
order to ensure a perfect hygiene level. Very
important: the box has to be completely dry
after washing; the drying has to be carried out
with overturned and open box.
Reaction to fire: the isothermal box has a
1 class fire reaction and has to be kept away
from open fire. It cannot be exposed to higher
temperatures than 100°C.
Recycling.
The boxes, once separated from the metallic and electric part, can be collected at recycling plants
and milled. The boxes can be collected in recycling plants and be grounded. The resulting product
is normally used to produce new packaging or products that are used in the building industry like
lightening components. The box is 100% recyclable.
Disposal.
The metallic part and the electric cabling have to be separated from the polypropylene for
disposal. The plate is disposed with metal, the electric part with the electric-electronic ones. The
boxes are disposed in the plastic. Polypropylene incinerated at higher temperatures than 900 ° C,
has carbon dioxide (CO2) and water (H2O) as residues released into the atmosphere. The product
is chemically inert, it doesn’t pollute either the air or groundwater.
Warranty on manufacturing defects.
With the exclusion of any legal claim, SDS Ltd. provides free of charge repair or replacement within
the warranty period of the law to all the defect found parts, provided it is shown, that the defect is
not derived from uses different from the ones described in this manual, from overuse or from use
contrary to the detailed instructions in the preceding paragraphs. The warranty is strictly limited
to the repair or replacement of parts supplied by us and doesn’t accept any claims based on
damages to people, property or loss of production.
