ActiveProducts RCP-C65B User manual

OWNER’S MANUAL
MODEL NO: RCP-C65B
KEEP THE ORIGINAL BOX, PACKAGING AND RECEIPT. BEFORE OPERATING THIS UNIT,
READ THE MANUAL THOROUGHLY AND RETAIN IT FOR FUTURE REFERENCE.
[ACT 050] Manual E 4/4/06 4:34 PM Page 1
INFLATION STATION
Cordless

1
HIGH-PRESSURE
APPLICATIONS
•Car tires
•Bicycle tires
•Basketball
•Sporting equipment
•Party balloons
HIGH-VOLUME
APPLICATIONS
•Air mattresses
•Rafts
•Inflatable toys
•Pool toys
[ACT 050] Manual E 4/4/06 4:34 PM Page 2
INFLATION STATION
Cordless

www.activeproducts.com 2
PARTS LIST
ITEM NO. QTY DESCRIPTION
1 1 High-pressure air compressor
2 1 High-volume air inflator
3 1 Digital tire gauge
4 1 Ni-Cd rechargable battery
5 1 Ni-Cd rechargable battery
6 1 12V cigarette lighter adapter pack
7 1 Charger station
8 1 Stand
9 1 Pressure gauge hose
ITEM NO. QTY DESCRIPTION
10 1 Large adapter
11 1 Medium adapter
12 1 Inflatable connector
13 1 Ball adapter
14 1 Small adapter
15 1 Balloon adapter
16 1 AC charger
[ACT 050] Manual E 4/4/06 4:34 PM Page 3
15
14
13
12
11
10
1 23 4
5 6 7 8 9
16
Accessories include:

[ACT 050] Manual E 4/4/06 4:34 PM Page 4
DIGITAL TIRE GAUGE
USER INSTRUCTION:
1. Press ON/OFF button once to
switch on.
2. To choose desired pressure format
PSI, BAR, press the ON/OFF button.
3. Press nozzle on tire’s valve stem.
4. Hold until pressure reading
is displayed on LCD display.
5. Press button and hold for 5 second
to switch off.
6. To take another pressure reading,
simply repeat steps 3 to 4.
7. 1 x 3V Lithium button cell, CR2032.
Note: Digital gauge accurate to
± 1 PSI
3
LCD
display
ON/OFF
switch
LED light
LED light
switch

INSTALLATION PROCEDURE
1
2
Seat the charger station on a flat surface.
Connect the AC charger and return all com-
ponents back onto the charger station.
DESKTOP PLACEMENT
[ACT 050] Manual E 4/4/06 4:34 PM Page 5
Red LED Indicator
AC Charging Port
Pull out the bracket as shown on the
back of the charger station.
www.activeproducts.com 4

POWER SOURCE
Both the air compressor and air inflator can
be powered by both the Ni-Cd rechargeable
battery and the 12V cigarette lighter adapter.
RECHARGEABLE BATTERIES
The Inflation Station comes with two 9.6V
1,000 mAh Ni-Cd rechargeable battery. The
battery can be charged either on the charger
station, or from the AC charger port on
the battery.
CHARGING BATTERY
ON THE CHARGER STATION
Before initial use, place one of the batteries on
the charger station for an initial charge time
of 15 to 18 hours. Repeat charging times are
approximately 20-22 hours, if batteries
are depleted.
Warning! Failure to fully charge the battery will
result in shorter life, compromised perform-
ance and will void battery warranty. To keep
the battery fully charged at all times, place
charged at all times, place the battery on the
charger station whenever they are not in use.
The charger station red LED indicator will be
“ON” once the battery has been properly
on the station. The charger station will control
battery charging to ensure optimal battery
charge. We recommend that if the inflation
station is not going to be used for an extended
period of time (i.e. 4 months or more), the unit
should be unplugged and stored indoors. When
the inflation station is removed from storage,
please re-charge for 20 to 22 hours before use.
CHARGING FROM THE AC CHARGER
PORT ON THE BATTERY
Remove the battery from the air compres-
sor/inflator by gripping the end of the battery
and pulling it out.The same AC charger can be
used to charge the battery directly by con-
necting the AC charger to AC charger port on
the battery and plugging the AC charger to an
110V-120V power source. The red LED indica-
tor will be “ON” when the battery is charging.
When charging directly from the AC charger
port on the battery, the charging time must
not exceed 24 hours. Repeat charging times
are approximately 18 -20 hours, if the battery
is depleted.
AC Charger Port
STEP 1
STEP 2
5
[ACT 050] Manual E 4/4/06 4:34 PM Page 6

www.activeproducts.com
TYPICAL RUN-TIME*
*EMIT-NURLACIPYTECIVED
Air Compressor 10-15 minutes
Air Inflator 15-20 minutes
* REMARK:
1. Typical run-time will vary depending on
the battery level, pressure load during use,
and the operating conditions.
2. High-pressure loading, or excessive back
pressure will result in a shorter run-time
than indicated above.
3. Cold temperature conditions will reduce
battery run-time. We recommend
using the 12V cigarette lighter adapter
pack during cold temperature
operating conditions.
When the operating period per charge is
significantly reduced, it indicates the
battery is worn-out and should be replaced.
To order a replacement battery,
please visit us at www.activeproducts.com
12V CIGARETTE LIGHTER ADAPTER PACK
Switching between the battery and 12V ciga-
rette lighter adapter pack
•Roll out the 12V cord before use.
•Remove the battery from the
air compressor/inflator by gripping the
end of the battery and pulling it out.
•Slide the 12V adapter pack into the
air compressor/inflator until clicks into
place. Make sure that the cord runs
through the small hole at the base of
the cable pack.
•Connect the 12V car cigarette lighter
adapter to the cigarette lighter socket in
your car.
6
[ACT 050] Manual E 4/4/06 4:34 PM Page 7

Balloon adapter
Ball adapter
Pressure gauge hose
INFLATION INSTRUCTION
HIGH-PRESSURE AIR COMPRESSOR
The Air Compressor has been specially
designed for simple and fast inflation of car
tires, bicycle tires, basketball, sporting equip-
ment, and party balloons.The air compressor
provides a small quantity of air at a relatively
high pressure.
INFLATING A CAR TIRE AND BICYCLE TIRE
1. Loosen the union valve from the air nozzle.
2. Insert the pressure gauge hose into
the air nozzle and tighten the union valve.
3. Screw the thread connector onto tire’s
valve stem.
4. Press the trigger once for continuous
inflation.
5. Operate the air compressor until the
desired pressure is reached.
6. Pressure the trigger twice to stop inflation.
7. Remove the thread connector from the tire.
Note: To avoid over-inflation of tires, please
check the recommended car tire pressure in
the vehicle’s owner’s manual. For bicycle tire,
please check the tire marking.
INFLATING SPORTING EQUIPMENT
(I.E. BASKETBALL) OR PARTY BALLOONS
1. Loosen the union valve from the air nozzle.
2. Insert the ball/balloon adapter into the air
nozzle and tighten the union valve.
3. Insert the ball/balloon adapter into valve of
the object to be inflated.
4. Operate the air compressor until the object
is fully inflated.
5. Remove ball/balloon adapter from the
inflated object’s valve.
Note: If a pressure reading is required during
inflation, use the pressure gauge hose provided.
CAUTION
•Do not run the air compressor continuously for more than 15 minutes.
After each 15 minutes, allow it to cool for a minimum of 15 minutes.
•Do not leave the air compressor unattended while in operation.
Keep out of reach of children.
•Do not exceed maximum pressure of 150 psi.
•The pressure gauge will provide an estimated reading only.
Please use a digital pressure gauge for more accuracy pressure information.
7
[ACT 050] Manual E 4/4/06 4:34 PM Page 8
A
B
Loosen
A
BTighten
(counterclockwise)
(clockwise)

www.activeproducts.com
Inflation outlet
Deflation outlet
Large adapter
Medium adapter
Small adapter
Inflatable
connector
HIGH-VOLUME AIR INFLATOR
The Air Inflator is designed for quick and easy
inflation and deflation of high air volume
objects such as air mattresses, rafts, inflatable
toys and pool toys.
BEFORE INFLATING
Choose the appropriate inflatable adapter.
There are four inflatable adapters provided
for high-volume inflation/deflation.The small
and medium adapters must be used with the
inflatable connector provided. The inflatable
connector and large adapter can be directly
attached to the inflation air outlet.
INFLATING PROCEDURE
1. Insert the appropriate inflatable adapter
into inflation outlet.
2. Insert adapter into the air valve of the
object to be inflated.
3. Press the trigger once for continuous
inflation.
4. Operate the air inflator until the desired
firmness is reached.
5. Pressure the trigger twice to stop inflation.
6. Remove adapter from the inflated object
valve and close the valve cap.
DEFLATING PROCEDURE
1. Insert the inflatable adapter into
deflation outlet.
2. Insert adapter into the valve of the object
to be deflated.
3. Press the trigger once for continuous
deflation.
4. Operate the air inflator until desired
deflation is reached.
5. Pressure the trigger twice to stop deflation.
6. Remove adapter from the deflated
object valve.
Note: Make sure the stop valve or resisted
valve is opened, before inflation or deflation.
INFLATION TIPS FOR LARGE OBJECTS:
The performance of an air inflator depends on
air flow rate, size of adapter and the valve of the
inflatable object. The smaller the valve and/
or adapter used, the lower the air flow rate.
Therefore, always buy inflatable objects with
the largest possible valves.Typically, air mat-
tresses or large inflatable objects may have
two sizes of air valve, always inflate from the
largest valve to get maximum performance.
CAUTION
•Do not run the air inflator for continuously for more than 15 minutes. After each
15 minutes, allow it to cool for a minimum of 15 minutes.
•Do not leave the air inflator unattended while in operation. Keep out of reach of children.
•Make sure the stop valve or resisted valve is opened, before inflation or deflation.
8
[ACT 050] Manual E 4/4/06 4:34 PM Page 9

GENERAL SAFETY MEASURES AND
PRECAUTIONS THAT APPLY TO THE
USE OF AIR COMPRESSOR/INFLATOR.
The following instructions apply to both the
air compressor and air inflator.
Safe operation of the air compressor and
inflator require that you read the instructions
and safety precautions carefully and follow
all instructions before using the air compres-
sor or inflator.
1. The air compressor and inflator are
designed for occasional use. Inflation
over a long period will overheat the
air compressor or air inflator and may
cause damage.
2. The air compressor and inflator must not
operate for more than 15 minutes
at a time, after which it must be switched
off and set aside to cool for at least
15 minutes before restarting.
3. If the air compressor or inflator emits
abnormal sounds or overheats,
turn it off immediately and let it cool
off for minimum 30 minutes.
4. Inspect air compressor, inflator and
batteries before use. If cracked, broken
or damaged parts are found, qualified
technicians should repair damaged parts.
5. Incorrect use of air compressor/inflator
may result in personal injury and/or
property damage.
6. Never expose the air compressor, inflator
or battery to rain, frost or temperatures
above 50 ºC (122 ºF). Never charge the
battery in humid or wet locations.
7. Never use the air compressor or inflator
near flammable fluids or gases. Make
sure your working area is well-lit.
8. Protect yourself against electric shock.
Avoid physical contact with grounded
surfaces such as pipes, radiators, electric
stoves, refrigerators, etc.
9. Never allow children to connect/disconnect
the air compressor or inflator to/from
power sources. Never leave children
unattended with the air compressor or
inflator and never allow them to play with
the accessories.
10. Never allow anyone to pump air into
mouth, ears, nose, etc of people,
or animals.The air compressor/inflator
is not a toy.
11. Store air compressor and inflator
in a secure location. If the air
compressor/inflator for long periods
of time, it should be stored in a
dry space inaccessible to children.
12. Regularly check the charger cord.
Never carry the charger by the cord and
never pull the plug out of the outlet
by jerking the cord. Make sure the cord
is not exposed to hot objects, oil or
sharp edges.
13. Keep the air compressor and inflator
clean to maintain maximum output and
safety. Examine the plug, charger and
cable pack at regular intervals and have
them repaired by qualified technicians if
they are damaged.
14. Unplug the 12V car cigarette lighter
adapter from the cigarette lighter socket
in your car when is not in use.
15. Unplug the AC charger from the battery
when the charger is not in use.
16. Never charge the battery outdoors.
Do not open the battery. Protect it against
impact.The battery should be stored in a
dry, frost-free place.
17. The battery and charger are designed
for each other. Only an Active Products
charger should be used.
18. Protect the battery against heat and fire
to prevent danger due to explosion!
19. Do not place the battery on a heater and
do not expose it to solar radiation for a
prolonged period. Exposing battery to
temperatures above 50 ºC (122 ºF) will
damage the battery. Allow batteries to
cool off completely before charging.
20. Do not directly connect the positive (+)
and the negative (-) terminals.
This will result in a short-circuit caused
by metallic arcing.
21. Stay alert. Always pay attention to what
you are doing when working with the air
compressor, inflator, charger and battery.
22. Warning! For your own safety, you
should only use accessories and
parts specified in the instructions,
or recommended for use by the
manufacturer. Use of accessories
and other parts that are not mentioned
in the instructions may entail
an increased risk for the user of
the air compressor and inflator.
9
[ACT 050] Manual E 4/4/06 4:34 PM Page 10

www.activeproducts.com
BATTERIES AND THE ENVIRONMENT
The accompanying batteries can be recharged
at least 500 times, when it is time to replace the
batteries, please consider the environment.
The EPA certified RBRC®Battery Recycling
Seal on the nickel-cadmium (Ni-Cd) battery
indicates that Active Products is voluntarily
participating in an industry program to collect
and recycle these batteries at the end of their
useful life, when taken out of service in the
United States or Canada.The RBRC®program
provides a convenient alternative to placing
used Ni-Cd batteries into trash or the munici-
pal waste stream. Please call 1-800-822-8837
for information on Ni-Cd battery recycling and
disposal bans/restrictions in your area. Active
Products’ involvement in this program is part
of our commitment to preserving our environ-
ment and conserving our natural resources.
WARRANTY
This Active Products equipment carries a one
(1) year limited warranty against defects in man
ufacturing workmanship, and a one-year limited
warranty on the batteries and accessories.
This Limited Warranty shall be limited to the
repair or replacement of parts which prove
defective under normal use and service and
which on examination shall indicate, to Active
Product’s satisfaction, they are defective. Active
Products reserves the right to request the
return of defective parts. Shipping charges may
apply. Before returning any parts, contact us
by visiting www.activeproducts.com. If
Active Products confirms the defect and
approves the claim, Active Products will elect to
replace such parts without charge.
The foregoing warranty does not apply to
defects resulting from faulty installation, oper-
ation, disassembly, alterations or remodeling,
or misuse, misapplication, neglect, abuse, acci-
dent, tornado, hurricane, and earthquake; or
lack of proper maintenance, cleaning and care.
Warranty will not apply if this product is used
for commercial or rental purposes. This war-
ranty shall not extend to anyone other than
the original purchaser of this product.
Should this product become defective within
the stated warranty period, do not return to store,
but contact us at www.activeproducts.com
The warranty card is not a replacement for the
proof of purchase. Please keep your proof of
purchase in a secure place.
10
[ACT 050] Manual E 4/4/06 4:34 PM Page 11

Made in China
0306
[ACT 050] Manual E 4/4/06 4:34 PM Page 12
Imported by:
Active Products Inc.
Toronto, Ontario, Canada M3B 2M3
www.activeproducts.com
INFLATION STATION
Cordless
