ACU-RITE 06006 User manual

Instruction Manual
Display for 5-in-1 Weather Sensor
model 06006
Package Contents
1. Display with Tabletop Stand
2. Power Adapter
3. USB Cable
4. Instruction Manual
This product requires an AcuRite 5-in-1 Weather Sensor
(sold separately) to be operational.
PRODUCT MUST BE REGISTERED
IMPORTANT TO RECEIVE WARRANTY SERVICE
PRODUCT REGISTRATION
Register online to receive 1 year warranty protection
www.AcuRite.com
Questions? Contact Customer Support at
www.AcuRite.com.
SAVE THIS MANUAL FOR FUTURE REFERENCE.

2
Features & Benets
Display
2
1 3 4 4
41
40
39
35
37
38
36
32
33
28
29
34
5
7
6
8
10
9
12
11
13
14
18
20
19
15
17
16
26 27 26 23 25 24 23 22
30
31
21

3
X
1. Current Wind Direction
2. Touch Activated Backlight
Momentary during battery power,
always on/off for power adapter.
3. Current Wind Speed
4. Previous 2 Wind Directions
5. Current Outdoor Temperature
Arrow icon indicates direction
temperature is trending.
6. Outdoor Temperature Alarm On
Indicator
7. Current Outdoor Humidity
Arrow icon indicates direction
humidity is trending.
8. Outdoor Humidity Alarm On
Indicator
9. Current Rainfall
Accumulates data during rainfall.
10. Rainfall Alarm On Indicator
11. 12 to 24 Hour Weather Forecast
Self-Calibrating Forecasting pulls
data from your 5-in-1 sensor to
generate your personal forecast.
12. All-Time Rainfall
13. Current Month Total Rainfall
14. Date
15. Clock
16. Display Low Battery Indicator
17. Selectable Category
18. Record High
Shown for current category selected
on the display (#17).
19. Record Low
Shown for current category selected
on the display (#17).
20. Weather Ticker™
21. Button
Press for all-time low and date
recorded for current category
selected on display (#17). Press twice
for all-time high and date recorded.
22. Button
Activates current Weather Ticker
message during ticker customization
mode.
23. ▲ & ▼ Buttons
Press to select category (#17)
adjust settings.
24. Button
Press to manually advance through
Weather Ticker messages.
25. Button
For setup preferences.
26. Button
Activate alarm; press and hold to
adjust alarm values.
27. Button
Deactivates current Weather Ticker
message during ticker customization
mode.
28. Indicates Deactivated Weather
Ticker Message
During ticker customization mode.
29. Indicates Active Weather Ticker
Message
During ticker customization mode.
30. Programmable Alarm Settings
31. Alarm On/Off Indicator
For Selectable Category (#17).
32. Sensor Low Battery Indicator
33. 5-in-1 Sensor Signal Strength
34. Learning Mode Icon
Disappears after weather forecast
self-calibration is complete.
35. Weather Select Button
Press to change the Weather Select
category data being displayed.
36. Current Barometric Pressure
Arrow icon indicates direction
pressure is trending.
37. Weather Select (top to bottom)
Heat index, dew point, wind chill,
indoor temperature / humidity,
rainfall rate (in/mm per hour).
38. Storm Alert Alarm On Indicator
39. Average Wind Speed
of all speeds from past 2 minutes.
40. Wind Speed Alarm On Indicator
41. Peak Wind Speed
Highest speed from past 60 minutes.

4
     
Back of Display 123 4
10
11
6
7
8
9
5
BACK OF DISPLAY
1. Plug-in for Power Adapter
2. Plug-in for USB Cable
3. Integrated Hang Hole
For easy wall mounting.
4. DEVICE ID
12 digit unique ID required for
online connectivity functions.
5. Backup Battery Compartment
6. A-B-C Switch
ID code that must match 5-in-1
sensor’s A-B-C switch to ensure
units synchronize.
7. CLEAR TODAY
Clears data recorded since
12:00am.
8. CLEAR ALL
Clears all recorded data without
having to reset time and date.
9. RESET
Full reset to factory defaults.
10. Power Adapter
11. USB Cable for PC Connection
12. Battery Compartment Cover
(not shown)

5
• •
•
• •
• •
SETUP
Display Setup
1 Set the A-B-C Switch
The A-B-C switch is located inside
the battery compartment. It can
be set to A, B or C. However, you
must select the same letter choices
for both the 5-in-1 Sensor and the
display in order for the units to
3
A B C
sensor
synchronize.
2 Plug Power Adapter into
Electric Outlet
1 A-B-C Switch
set to match
3
4
Write Down
DEVICE ID
12 digit number
Write Down the DEVICE ID
12 digit unique ID needed for
online connectivity functions.
24 C8 6E
Install or Replace Backup
Batteries (optional)
Insert 6 x AA alkaline batteries into
the battery compartment, as shown.
Follow the polarity (+/-) diagram in
the battery compartment.
4 Install Backup
Batteries
6 AA Batteries
(optional)
2 Plug in Power
Adapter IMPORTANT: Batteries are a backup
power source to preserve records
in the event of a power outage.
Power adapter is the recommended
primary power source to enjoy the full
functionality of this product.
PLEASE DISPOSE OF OLD OR DEFECTIVE BATTERIES IN AN ENVIRONMENTALLY SAFE
WAY AND IN ACCORDANCE WITH YOUR LOCAL LAWS AND REGULATIONS.
BATTERY SAFETY: Clean the battery contacts and also those of the device prior to battery installation. Remove batteries from equipment which is not to be
used for an extended period of time. Follow the polarity (+/-) diagram in the battery compartment. Promptly remove dead batteries from the device. Dispose of used
batteries properly. Only batteries of the same or equivalent type as recommended are to be used. DO NOT incinerate used batteries. DO NOT dispose of batteries in fire,
as batteries may explode or leak. DO NOT mix old and new batteries or types of batteries (alkaline/standard). DO NOT use rechargeable batteries. DO NOT recharge
non-rechargeable batteries. DO NOT short-circuit the supply terminals.

6
      
        
      
      
        
l.?=OOAM
..
SET
r1 nrk7
LLUL ox
. •
T 15x A ox
12=38PM ox
6 ox A
I? f
ox
12:38PM
..
SET ox
]RTE?
. .
T 15x A ox
12/0 I ox
6 ox A
Set the Time & Date
The clock and calendar are utilized to time stamp history records and other
data, so it is important to set the time and date soon after you power on the
display.
Set the Time
1. Press the “ ▲ “ or “ ▼ “ buttons until
“SET CLOCK?” is displayed on the
Selectable Category part of the display.
2. Press the “ ” button to set the clock.
3. Press the “ ▲ “ or “ ▼ “ buttons to adjust the
hour. Note the “AM” and “PM” indicators.
4. Press the “”button to conrm hour
selection.
5. Press the “ ▲ “ or “ ▼ “ buttons to adjust
minutes.
6. Press the “”button to conrm minute
selection.
The clock is now set.
Set the Date
Note: The “ ” stays in
Selectable Categories, 1. Press the “
▲ “ or “ ▼ “ buttons until
even after setup. “SET DATE?” is displayed on the Selectable
Category part of the display.
2. Press the “ ” button to set the date.
3. Press the “ ▲ “ or “ ▼ “ buttons to adjust the
month.
4. Press the “”button to conrm month
selection.
5. Press the “ ▲ “ or “ ▼ “ buttons to adjust the
day.
6. Press the “”button to conrm day
selection.
7. Press the “ ▲ “ or “ ▼ “ buttons to adjust the
year.
8. Press the “”button to conrm year
selection.
The date is now set.

7
       
       
       
ox
ox
ox
ox
ox
12=38PM
SET
UNIT57
. .
...ox .....
12=38PM
WI~~]
mPH
...ox .....
Select Measurement Units
To select between standard units (mph, ºF, etc.) or
metric units (kph, ºC, etc.):
1. Press the “ ▲ “ or “ ▼ “ buttons until “SET UNITS?” is
displayed on the Selectable Category part of the display.
2. Press the “ ” button to set the unit preference.
3. Press the “ ▲ “ or “ ▼ “ buttons to select “STAND” for
standard or “METRIC” for metric units.
4. Press the “”button to conrm your selection.
5. Next, you will see “WIND MPH”. Press the “ ▲ “ or
“ ▼ “ buttons to select MPH, KPH, or KNOTS for wind
speed units.
6. Press the “”button to conrm your selection.
Units are now set.
Set Language
To select between English (default) or French for the display language:
1. Press the “ ▲ “ or “ ▼ “ buttons until “SET LANG?” is displayed on the
Selectable Category part of the display.
2. Press the “ ” button to set the language preference.
3. Press the “ ▲ “ or “ ▼ “ buttons to select the desired language.
4. Press the “”button to conrm your selection.
Language is now set.
Note: Display reverts to English language when display runs out of power or is reset.
Placement for Maximum Accuracy
AcuRite sensors are sensitive to surrounding environmental conditions. Proper
placement of both the display and the sensor are critical to the accuracy and
performance of this product.
Display Placement
Place the display in a dry area free of dirt and dust. To ensure
accurate temperature measurement, place out of direct sunlight and
away from heat sources or vents. Display stands upright for tabletop
use or is wall-mountable.
Important Placement Guidelines
Display and sensor must be within 330 feet (100 m) of each other.
MAXIMIZE WIRELESS RANGE
Place units away from large metallic items, thick walls, metal surfaces, or other
objects that may limit wireless communication.
PREVENT WIRELESS INTERFERENCE
Place both units at least 3 feet (.9 m) away from electronic devices (TV, computer,
microwave, radio, etc.).

8
       
     
            
           
                  
         
ox
ox
PC Connect
PC Connect works with PCs to provide access to your Weather Center data in the
following ways:
• Data File: The display logs (or stores) data so that you can download it to a
CSV (comma separated values) data le on your PC.
• Web Browser or Smartphone:Monitor sensor data remotely using AcuRite’s
free AcuRite online software, or from a mobile device using the free AcuRite
app, available from the Apple App Store or Google Play Store.
• Weather Underground: This weather station is compatible for streaming data
to the Weather Underground Personal Weather Station Network. For more
information, navigate to: www.acurite.com > Support > Downloads
USB Mode
To set up PC Connect, you must rst select mode 3on your display to gain access to all
functionality. Modes 1, 2 and 4 are not used for the PC Connect software.
1. Press the “ ▲ “ or “ ▼ “ buttons until “SET USB MODE?” is displayed on the
Selectable Category part of the display.
2. Press the “ ” button to set the mode preference.
3. Press the “ ▲ “ or “ ▼ “ buttons to select USB mode #3.
4. Press the “ ”button to conrm your selection. PC Connect USB Mode
is now set.
Download the Software
The PC Connect software is available online as a free download. A manual (PDF) is
included with the software download.
Before setting up the PC Connect software, verify that the display
is ON with the power adapter plugged in. Next,
connect the mini-USB (small end of the cable) into the
USB port on the display, located inside the battery
compartment.
Download PC Connect software to your computer by visiting:
1 www.acurite.com > Support > Downloads
Open the le that was downloaded in step 1and follow the on-screen
2 instructions to install the software.
After PC Connect is installed on the computer, the initial conguration will
3 begin automatically. Select where to save weather data downloaded from the
display. By default, this will create a folder on the computer.
When prompted by the software to plug in the display, connect the
4 USB (larger end of the cable) into a USB port on the computer.
PC Connect is installed and ready for use.
Follow the instructions within the PC Connect app
to complete setup and begin using the software.
(PC)

9
       
~
~
<Z2, D
I 1, 1, 1, I
o~+
'ft ◄
~if
ill
1'/0
D D
.... .,.,.,.,
.... ,.,.,.,.
OPERATION
Using the Professional Weather Center
Learning Mode
Self-Calibrating Forecasting use a unique algorithm to analyze changes in
pressure over a time period (called Learning Mode) to determine your altitude.
After 14 days, the Learning Mode icon disappears from the display screen. At
this point, the self-calibrated pressure is tuned in to your location and the unit is
ready for superior weather prediction.
Weather Forecast
AcuRite’s patented Self-Calibrating Forecasting provides your personal forecast
of weather conditions for the next 12 to 24 hours by collecting data from
the sensor in your backyard. It generates a forecast with pinpoint accuracy -
personalized for your exact location.
STORM
LIKELY
PARTLY
CLOUDY CLOUDY
RAIN
LIKELY
SNOW
LIKELY
CHANCE OF MIXED
RAIN & SNOW
View the complete list of icons at www.AcuRite.com/acurite-icons
Weather Select = Heat Index
Features weather data groups
shown at right. To change = Dew Point
“Weather Select” category,
press the selection arrow = Wind Chill
button just to the left of the = Indoor Conditions
weather select display area.
= Rainfall Rate (in./hour)
Rainfall Event
The rainfall feature tracks rain accumulation over all-time, the current month,
and current rainfall event. Current event clears when no rain registers for
8 hours OR no rain registers for 1 hour and pressure rises by .03inhg or more.

10
v
Barometric Pressure
Subtle variations in barometric pressure greatly affect the weather. This
weather center displays the current pressure with an arrow icon to indicate the
direction the pressure is trending (FALLING, STEADY, or RISING).
Weather Ticker™
The Weather Ticker automatically streams your real-time weather information
and alerts as scrolling text in the lower part of the display screen.
You can manually cycle through all the available messages by pressing “
button.
Default WEATHER TICKER messages are pre-loaded as follows:
”
FORECAST 12 to 24 hour future weather forecast
MOON PHASE Current moon phase
INDOOR COMFORT Dry, OK or humid comfort level
IT FEELS LIKE __ OUTSIDE Calculates what temperature it feels like outdoors
(based on temperature, humidity and wind speed)
OUTDOOR TEMP THIS
WEEK HIGH Highest temperature recorded this calendar week
OUTDOOR TEMP THIS
WEEK LOW Lowest temperature recorded this calendar week
OUTDOOR TEMP THIS
MONTH HIGH Highest temperature recorded this calendar month
OUTDOOR TEMP THIS
MONTH LOW Lowest temperature recorded this calendar month
Additional Messages Include:
NEW HIGH TEMPERATURE RECORD
NEW LOW TEMPERATURE RECORD
NEW WIND SPEED RECORD TODAY
CURRENT RAINFALL RATE
CURRENT RAIN EVENT STARTED
NO RAIN RECORDED SINCE ____
WEATHER ALARM MESSAGES
SENSOR BATTERIES LOW
SENSOR SIGNAL LOST
