FUNCTIONS
The LINK is a pivoting and lowering seat base that uses your vehicle’s original seat which affords comfort and freedom.
The user-friendly functions of the LINK make it a breeze to operate.
POWER
Use the POWER button on top of the pendant to activate it. A blue light will
indicate that the pendant is active and will allow you to use your LINK. This light
will flash during movements. If the pendant is not used for ten (10) seconds, the
light will go off and the pendant will no longer be active. Simply press the power
button on the top of the pendant again to activate.
IN
Use the button to move the LINK into the vehicle.
OUT
Use the button to move the LINK out of the vehicle.
Watch the short video by scanning here:

3
LINK
SEAT ADJUSTMENTS
Use the button to move the seat forward.
Use the button to move the seat backward.
Use the button to tilt the seat of the seat upward.
Use the button to tilt the seat of the seat downward.
PLEASE NOTE: The seat adjustments will only be available to you once the LINK is
completely inside the vehicle and the cycle of the LINK is complete. If you have
pushed the POWER button, the blue light is on and the seat adjustment buttons do
not work, make sure the LINK has completed its full cycle and is fully ‘IN’. Use the
button until the LINK and seat no longer move to ensure the cycle is completed.

4
LINK
LIFT UP FEATURE
The LINK system can be equipped with a LIFT UP feature.
This innovative feature offers you the possibility of having the LINK assist you in standingonce you have exited the vehicle.
It can also make transferring onto the LINK easier, by adjusting the tilt angle of the seat to fit your needs.
This feature is incorporated into the LINK’s programming by your mobility service provider – where you purchased the
LINK. Please make sure you understand clearly how this feature can be of benefit to you. If you will be using the LINK
simply to level transfer, your mobility service provider will simply omit the option in your LINK’s programming.
This feature cannot be added or modified by you.
It is only available through a certified Adapt Solutions mobility service provider.

5
USER GUIDE
ENTERING YOUR VEHICLE
Follow the next few steps:
•After opening the door, retrieve the hand held pendant.
•Push the POWER button on the top of the pendant to activate it. The light in the top corner will turn blue. This light will
flash during movements. If the pendant is not used for ten (10) seconds, the light will go off and the pendant will no
longer be active. Simply press the power button on the top of the pendant again to activate.
•Press and hold the button until the LINK has reached a desired height for your transfer.
•Once you are comfortably positioned on the LINK, press and hold the button until the LINK has completed its
cycle and is inside the vehicle. At any time throughout the movements you may release the button and the LINK will
stop, allowing you to reposition. Once you are ready to continue, simply press and hold the button to resume
your ascent into the vehicle.
•Close your vehicle door and replace the hand held pendant.
•Use the steps outlined on page 3 to adjust your seated position for appropriate legroom, space, positioning and
comfort inside your vehicle.

6
USER GUIDE
EXITING YOUR VEHICLE
Follow the next few steps:
•Start by removing your seat belt and opening the door.
•Locate the hand held pendant.
•Push the POWER button on the top of the pendant to activate it. The light in the top corner will turn blue. This light
will flash during movements. If the pendant is not used for ten (10) seconds, the light will go off and the pendant
will no longer be active. Simply press the power button on the top of the pendant again to activate.
•Press and hold the button until the LINK has reached a desired height for your transfer. At any time you
may release the button and the LINK will stop moving allowing you to reposition. Once you are ready to continue,
simply press and hold the button to resume your descent out of the vehicle.
•Once you have transferred out of the seat, press and hold the button until the LINK has returned
completely inside the vehicle.
•Replace the hand held pendant and close your vehicle door.
WARNING
NEVER TRY TO OPERATE THE LINK WHILE THE VEHICLE DOOR IS CLOSED OR IF THE VEHICLE IS IN MOTION.

7
MANUAL BACKUP
Your new LINK is equipped with a manual backup system. If you were to encounter a power failure or other functional
problem, this backup system will allow your seat to be returned to the inside of your vehicle.
IMPORTANT: This feature cannot be used with a passenger seated on the unit and will require physical effort.
Please look through the following pages for the steps to followand details on how to use this feature. For further instruction
on how to use the manual backup, a short video can be found by scanning the QR code below.
Please contact your dealer for full diagnostics and needed repairs.
If your LINK will not run and the seat is outside of the vehicle. Follow the steps outlined in the next few pagesto manually
return the seat into the vehicle. (Note: If your LINK has the LIFT UP feature, two additional steps must be done first, found
on page13.)

8
MANUAL BACKUP
(MOTOR LOCATION)
Remove the plastic trim stamped with the word
LINK on it at the very front of the unit. It is simply
fastened with Velcro tabs on either side. (Note:
The trim underneath it does not need to be
removed.)
There are four (4) holes
under the trim on the
front of the unit. The two
outer holes move the
TRAVEL motor and the
two inner holes move
the TILT motor.
The third motor is the PIVOT and it can be found at
the back of the LINK. (Shown far right: The backup
tool has been designed to curve for the pivot
motor, in case your vehicle is equipped with a
center console.)

9
MANUAL BACKUP
(BACK UP TOOLS)
To move these motors manually, you have been supplied with backup tools that can be found in a pouch, next to this
user manual. The three pieces below require assembly as follows:
Grasp the first two pieces by their respective handles and insert the nut into the slot, then slide it to lock it in place. Next,
take the long, spring like piece and slide it into the assembled tool so that the two gears meet up and lie flush. Then, simply
tighten thumb screw.

10
MANUAL BACKUP
(CONTINUED)
1) Our first step requires this assembled tool. It attaches to the end of the PIVOT motor of the LINK. Insert the split end
socket into this opening and fit it onto the end of the pivot motor. Turn the handle of the tool CLOCKWISE to make the
LINK pivot into the vehicle. Turn until the LINK is at a 90 degree angle with the vehicle. It will likely be touching the door
of the vehicle.
2) Next, we need to move the TRAVEL motor until the seat is almost touching the steering wheel. To do this, use the ¼ inch
hex tool (ratchet) in the outer hole and turn CLOCKWISE. Check periodically how close you are to the steering wheel as
you do not want to force the seat and risk it getting jammed. 3) Then, use the lever on the side of the seat (or button if
equipped with power recline) to tilt the seatback as far forward as possible. This will give you more space to clear the
steering wheel.
2
1
3

11
MANUAL BACKUP
(CONTINUED)
4) Now we will move TILT motor using the inner hole and turning our ¼ inch hex tool (ratchet) COUNTER CLOCKWISE. Tilt
the seat down until it is just touching the steering wheel by turning the tool COUNTER CLOCKWISE.
5) We now return to the PIVOT motor and turn CLOCKWISE until the seatback has just cleared the steering wheel.
6) Next, we move the TILT motor until the seat becomes completely level. Use the inner hole andturn COUNTER CLOCKWISE
until the seat is parallel with the floor of the vehicle.
7) Our last step is to PIVOT until the seat is completely inside the vehicle. Turn the PIVOT tool CLOCKWISE until the seat is
returned to its original position in the vehicle.
5
4
6
7

12
MANUAL BACKUP
(LIFT UP FEATURE)
If your LINK is equipped with the LIFT UP feature, there are two (2) additional steps that must be done first:

13
MANUAL BACKUP
(LIFT UP FEATURE)
I. Using the ¼ inch hex tool (ratchet) in the inner hole; turn CLOCKWISE. Turn and TILT until the unit is almost touching the
ground. (Note: Even though the visual indicator on the front of the unit says to turn counter clockwise, you must turn clockwise at this
step)
II. Then TRAVEL the seat back using the ¼ inch hex tool (ratchet) in the outer hole and turn CLOCKWISE until the seat is
level. Then simply follow the aforementioned steps.
*NOTE: Be careful not to disconnect or constrict the wires when manually moving the LINK.
Once the problem is resolved, do not forget to return your back up tools to where you found them.
Please contact your dealer for full diagnostics and needed repairs.

14
RECOMMENDED MAINTENANCE
To keep your LINK running properly for many years to come, please follow the recommended maintenance:
Once a year or every 1000 cycles, whichever occurs first, have your Mobility Service Provider perform a visual inspection
of all moving parts. Moving parts should be cleaned and greased using petroleum based liquid spray grease.
IMPORTANT: DO NOT EVER GREASE THE GREEN NYLON SLIDES OR THE LINEAR ACTUATOR SCREWS.

15
HAND PENDANS L.E.D. LIGHT
REFERENCE
•BLUE: Normal. Ready for use.
•YELLOW: Reduced Power Mode. (see below)
•RED: Problem detected. Do not use the LINK.
Contact your Mobility Equipment Dealer.
•GREEN: No response or 12 volt power supply failure.
YELLOW: REDUCED POWER MODE
In the unlikely
event that the vehicle’s battery (12V) is disconnected or fully
drained at the same time as the 9V battery (LINK
memory back up) is
disconnected or fully drained, the LINK will go into Reduced Power Mode
to
prevent damage to the vehicle and to itself.
How to exit Reduced Power Mode
The LINK
must run a full cycle. Use this time to visually inspect each movement.
NOTE: It is possible that the LINK
will stop through its cycle as it is running on
reduced power. Visually confirm nothing is impeding the movements and then
simply press the IN or OUT button again to continue the cycle.

16
LINK AUDIBLE WARNINGS
Audible Signal Meaning Description
BEEEEEP Overload
Protection
A safeguard against the application of excessive force on
the mechanical components of the LINK. The overload
protection prevents damage to the unit.
BEEP-BEEP Obstruction
Something is impeding the LINK from moving. The LINK has
detected an obstruction.
BEEP-BEEP-BEEP 12v Power
Fluctuation
A problem with the 12 volt power supply. It could be a low
car battery or a faulty power supply connection.
BEEP-BEEP
BEEP-BEEP 9v Battery The LINK's memory back up battery (9 volt) is low or dead.
Please replace battery as soon as possible.
Please contact your dealer for full diagnostics, maintenance and needed repairs.

17
WARNING
Read and understand the operating instructions before using the unit. Failure to follow the operating instructions could
result in bodily injury or damage to the unit.
MAXIMUM WEIGHT CAPACITY: 350 lbs.
POSSIBLE INJURY: The LINK seat requires space for operation. Tilt head as necessary to avoid contact with “A” pillar.
COMPONENTS IN MOVEMENT: Pinching Risk – Keep your hands and fingers away from moving components.
POSSIBLE BODILY INJURY OR DAMAGE TO THE LINK.
•Do not step on the cover.
•Do not recline seat back during operation.
•Stored items could become entangled in the LINK unit. Store items away from the unit.
•The LINK seat requires space for operation. Park in spaces with ample room to the side of the vehicle. Check for
sufficient clearance prior to operating the LINK.
WARNING: This product can expose you to chemicals including benzene, which is known to the State of California
to cause cancer and birth defects or other reproductive harm. For more information, go to www.P65Warnings.ca.gov.

18
3 YEAR LIMITED WARRANTY
LINK
Adapt Solutions # 1 Ltd. (Adapt Solutions), warrants to the original purchaser of a LINK that the equipment is free from
defects in material and workmanship for a period of three years from date of purchase.
During the first year of the warranty, Adapt Solutions will supply the replacement parts as well as a pre-set monetary
amount (determined by Adapt Solutions) for the repair if a defect in materiel or workmanship is discovered. After the initial
year of this warranty, only parts and components are covered. This warranty does not cover labour and other services
after the initial year. Freight and other related repair charges will be the responsibility of the original purchaser.
The only remedy for a defect in one of Adapt Solutions products (LINK; XL-BASE; XL-SEAT; HI-LIFT; SPEEDY-LIFT;
XL-BOARD; POWER-PULL) shall be the repair or the replacement, at the discretion of Adapt Solutions, of the
defective part or component. If repair or replacement is not commercially practical or cannot be timely made, Adapt
Solutions may decide to refund the purchase price of the equipment instead of repairing or replacing the original
equipment.
In no event shall Adapt Solutions be responsible for indirect, incidental or consequential damages, whether such damages
arise from claims based on contract, warranty, tort (including negligence), strict liability or product liability.
All implied warranties, including any warranty of merchantability or fitness for a particular purpose, are limited in their
duration to the length of the warranty stated above for the affected component.
This warranty is to the original purchaser only, and excludes product damage due to installation error, product misuse,
product abuse, accidents, physical damage, damage in shipment, modifications not made by Adapt Solutions, or
repairs undertaken by anyone other than authorized distributors.
