VEVOR KR-17 User manual

Technical Support and E-Warranty Certificate www.vevor.com/support
CURB RAMP
USER MANUAL
We continue to be committed to provide you tools with competitive price.
"Save Half", "Half Price" or any other similar expressions used by us only represents an
estimate of savings you might benefit from buying certain tools with us compared to the
major top brands and doses not necessarily mean to cover all categories of tools offered by
us. You are kindly reminded to verify carefully when you are placing an order with us if you
are actually saving half in comparison with the top major brands.

- 1 -
Have product questions? Need technical support? Please feel free to
contact us:
[e-mail]
NEED HELP? CONTACT US!
This is the original instruction, please read all manual instructions
carefully before operating. VEVOR reserves a clear interpretation of our
user manual. The appearance of the product shall be subject to the
product you received. Please forgive us that we won't inform you again if
there are any technology or software updates on our product.
TYPE A TYPE B TYPE C TYPE D
CURB RAMP

- 2 -
INSTRUCTIONS
• For your information, please read these installation instructions before
using your curb ramp; Please keep all instructions and refer to them when
necessary. It is normal the product has a slight smell. we recommended
ventilating before use to avoid the smell.
WARNINGS
Incorrect installation can cause debris to collect, impeding water flow.
Used in curbs, steps, and uneven pavement.
1. Read and understand manual.And SAVE THESE INSTRUCTIONS.
2. Inspect before every use; do not use if parts loose or damaged.
3. Clean dirt, oil and debris off ramps and allow ramps to dry.
4. Set up only on solid, level, dry surface.
5. Be aware of dynamic loading! Sudden load movement may
briefly create excess load, causing product failure.
6. Use as intended only.
7. Clean ramps. Prior to each use, clean dirt, oil, or any debris off ramps.
8. This product is not a toy. Do not allow children to play with or near this
item.
9. All persons not involved in the loading process must stand clear of the
loading ramps. Keep children away. Children must not be allowed in the
work area.
10. Store idle equipment. When not in use, store ramps in a dry location to
inhibit rust.
11. The warnings, cautions, and instructions discussed in this instruction
manual cannot cover all possible conditions and situations that may occur.
It must be understood by the operator that common sense and caution are
factors which cannot be built into this product, but must be supplied by the
operator.

- 3 -
PARAMETER
Curb ramp - Parameter
TYPE Picture ITEM Model Ramp
Height Product size/mm Packaging Size/mm
G.W.
kg
Ramp
Quantity
Load
Limit
Water
Proof
groove
A
SKU1 KR-17 2.6inch 1220×410×65 1230×420×90 1pc21.5 s 15
tons Y
SKU2 KR-17 2.6inch 1220×410×65 1240×424×155 2pc43 s 15
tons Y
SKU3 KR-17 2.6inch 1220×410×65 1240×425×210 3pc64 s 15
tons Y
B
SKU4 KR-03 1000×250×93.7inch 0 1010×260×100 14.5 1pcs 15
tons Y
SKU5 KR-04 4.25inch 500×300×105 510×310×120 9 1pcs 15
tons Y
SKU6 KR-05 6inch 491×370×152 510×390×185 1pc14.3 s 15
tons Y
SKU7 KR-06 4.3inch 500×320×110 19.510×330×150 5 2pcs 15
tons Y
SKU8 KR-07 5inch 482.6×330×127 500×340×180 2pc19.5 s 15
tons Y
SKU9 KR-05 6inch 510×390×250 2pc27.5 s 15
tons Y
C
SKU10 KR-09 1inch 4
491×370×152
1130×241.3×25. 1140×250×50 6 1pcs 15
tons Y
SKU11 KR-10 1100×320×31.5inch 8 1110×330×50 1pc10.8 s 15
tons Y
SKU12 KR-11 1110×406.4×50 1120×417×62inch 0 1pc13 s 15
tons Y
SKU13 KR-12 3inch 901.7×457.2×76.
2912×468×87 1pc15.8 s 15 tons Y
SKU14 KR-13 3.5inch 901.7×533.4×88.
91pc21.912×544×100 5 s 15 tons Y
SKU15 KR-14 4inch 901.7×619.8×10
1.6 910×640×136 1pc26.3 s 15 tons Y
D
SKU16 KR-15 1.2inch 900×200×30 920×220×60 5.2 1pcs 15
tons N
SKU17 KR-16 1.6inch 900×200×40 923×232×64 1pc6.2 s 15
tons N

- 4 -
INSTALLATION STEPS FOR TYPE A(SKU1~SKU3)
STEP 01 select the dimension
The sizes of the type A curb ramps are listed in parameter table. The load
limit is 15 tons. Please choose the size that matches the ramp .
STEP 02 Align ramp sections
Facing your house, ensure that the ramp sections are in the correct
order,paying attention to the angle of the ends.
STEP 03 Flip ramp into street
Turn the ramp sections over into the street so that they are flat side down.
If you have additional center sections, the hardware from one side of that
ramp must be removed. To remove excess hardware from one side,
strike underneath the bolt head with the claw portion of your hammer and
extract.

- 5 -
M8*10 Expansion Bolts need to be fixed for installation. The groove can
be used for drain water or protect cables. the blind holes in the ramp need
to be drilled through to allow the screw to pass through the ramp and lock
into the ground
STEP 01 Select the dimension
The sizes of the type B curb ramps are listed in parameter table. The load
limit is 15 tons. Please choose the size that matches the ramp .
STEP 02 Align ramp sections
Facing your house, ensure that the ramp sections are in the correct
INSTALLATION STEPS FOR TYPE B(SKU4~SKU9)
order,paying attention to the angle of the ends.
STEP 03 Sighten the screws
M8*10 Expansion Bolts need to be fixed for installation.the blind holes in
the ramp need to be drilled through to allow the screw to pass through the
STEP 04 Tighten the screws

- 6 -
ramp and lock into the ground.
INSTALLATION STEPS FOR TYPE C(SKU10~SKU15)
STEP 01 Select the dimension
The sizes of the type C curb ramps are listed in parameter table. The load
limit is 15 tons. Please choose the size that matches the ramp.
STEP 02 Tighten the screws
M8*10 Expansion Bolts need to be fixed for installation.the blind holes in
the ramp need to be drilled through to allow the screw to pass through the
ramp and lock into the ground.

- 7 -
INSTALLATION STEPS FOR TYPE D(SKU16~SKU17)
STEP 01 Dimension select
The sizes of the type D curb ramps are listed in parameter table. The load
limit is 15 tons. Please choose the size that matches the ramp.
STEP 02 Use the adhesive tape
Use double-sided tape to secure to the ground.
How to Keep Ramp From Moving Out of Place
Don't enter the driveway at an angle. If you can drive out to the street
with both tires impacting the ramps at the same time, the ramps will stay
put.
How to Adjust Position of A Curb Ramp Set
Straddle the ramp at the center.Pick up the ramp and lean back in the
direction you want it to go.

- 8 -
How to Clean Beneath The Ramp
Clean out underneath the ramp 2 ~3 times a year or more frequently if you
have a lot of gutter build-up. To turn the ramp over, start at one end, pull
the top of the ramp up and out toward the street. Use a hose to clean the
ramp's underside and the gutter. To return in place, simply start at one
end and flip back toward curb as you walk along the ramp.
How to Take A Curb Ramp Apart
Turn ramp over into the street, so the flat side is down. Put a flat head
screwdriver between the waterway rubber and bolt. Pry up toward the
waterway lifting the bolt up enough to remove the nuts. Using a hammer
and screwdriver as a punch, drive the bolt back through the adjoining
section. Be careful not to damage the bolt threads.
How to Add Another Ramp Section (only for type A)
After removing the nut, using a screwdriver as a punch, hammer the bolt
back through the adjoining section. Be careful not to damage the bolt
threads.

- 9 -
Importer: WAITCHX
Address: 250 bis boulevard Saint-Germain 75007 Paris
Importer: FREE MOOD LTD
Address: 2 Holywell Lane, London, England, EC2A 3ET
Manufacturer: Zhejiang Luba Traffic Technology Co.,Ltd
Address: No.300 West Guangming Road, Sanmen, Zhejiang, China
Made In China
REP
UK
EUREP UK LTD
UNIT 2264, 100 OCK STREET, ABINGDON
OXFORDSHIRE ENGLAND OX14 5DH
REP
EC
EUREP GmbH
Unterlettenweg 1a, 85051
Ingolstadt, Germany
