Introduction
The Adaptec SCSI Card 39320A enables you to connect up to 30
SCSI devices—such as very large arrays of high-performance hard
disk drives, external storage subsystems, Ultra320/160 hard disk
drives, scanners, and CD-ROM drives—to any Intel-based
computer with 64- or 32-bit PCI/PCI-X expansion slots.
The Adaptec SCSI Card 39320A has two independent SCSI
channels with a maximum throughput of 320 MB/sec per SCSI
channel. SCSI Channel A (marked CH A on the card) has one
internal 68-pin Low Voltage Differential/Single-Ended (LVD/SE)
connector and one external 68-pin very high-density cable
interconnect (VHDCI) connector. SCSI Channel B (marked CH B on
the card) has one internal 68-pin LVD/SE connector and one
external 68-pin VHDCI connector.
You can connect Ultra320/160 and Ultra2 SCSI devices to the
68-pin LVD connectors on both SCSI channels. When connecting
these newer devices along with older legacy SCSI devices, Adaptec
recommends that you dedicate them as separate channels. See
Support for Older SCSI Devices on page 2 for more information.
Although the Adaptec SCSI Card 39320A is a 64-bit PCI/PCI-X
card, it also works in a 32-bit PCI slot. When installed in a 32-bit
PCI slot, the card automatically runs in the slower 32-bit mode.
68-pin external
LVD/SEVHDCIconnector
Channel A
68-pin internal LVD/SE
connector ChannelA 68-pin internal LVD/SE
connector Channel B
68-pinexternal
LVD/SE VHDCI connector
Channel B
ASC-39320A IG.fm Page 1 Tuesday, July 29, 2003 3:17 PM

2
This installation guide explains how to:
■Install the Adaptec SCSI Card 39320A
■Set up SCSI devices
■Connect SCSI devices
Support for Older SCSI Devices
If you have single-ended Ultra SCSI and earlier SCSI devices,
Adaptec recommends that you connect them together on one
channel of the Adaptec SCSI Card 39320A and that you connect
newer Ultra320/160 SCSI and Ultra2 devices to the other channel.
This allows the Adaptec SCSI Card 39320A to dedicate one SCSI
channel to support a slower transfer rate for the Ultra (legacy)
devices, while the second SCSI channel can support LVD devices in
Ultra320, Ultra 160, or Ultra2 speeds. It also allows you to use
longer cable lengths for the newer SCSI devices.
Note: If you connect Wide Ultra/Ultra SCSI devices to the
same SCSI channel as Ultra320/160 and Ultra2 SCSI devices,
the data transfer rate for the Ultra320/160 and Ultra2 SCSI
devices will drop to Ultra SCSI performance levels. To achieve
maximum data transfer rates for the newer SCSI devices, be
sure to connect them on their own SCSI channel.
Installing the Adaptec SCSI Card 39320A
1Discharge any static electricity build-up before handling your
SCSI card by touching a grounded metal object (like the
exposed metal parts on the back of your computer).
Warning: Turn OFF power to the computer and disconnect
the power cord.
ASC-39320A IG.fm Page 2 Tuesday, July 29, 2003 3:17 PM

3
2After you turn off your computer and unplug the power cord,
remove the cover from the computer.
3Locate an unused 64-bit PCI/PCI-X expansion slot and remove
the expansion slot cover. If the computer does not have a 64-bit
slot, you can install the card in a 32-bit PCI slot. The Adaptec
SCSI Card 39320A supports both 5V and 3.3V 64-bit slots. (The
expansion slot must be compliant with PCI Rev. 2.1 or PCI-X
Rev. 1.0 and must support Bus Mastering.) Save the slot cover
screw for use in Step 4.
Computers may have vertical or horizontal expansion slots.
Refer to your computer manual to locate the PCI/PCI-X slots. If
your computer is a tower model, lay it on its side to allow for
easier installation of the Adaptec SCSI Card 39320A.
Slot cover screw
Expansion slot
cover
64-bit PCI slot
32-bit PCI slot
ASC-39320A IG.fm Page 3 Tuesday, July 29, 2003 3:17 PM

4
Warning: Be careful when inserting the Adaptec SCSI Card
39320A in a PCI slot. Some 32-bit slots will not
accommodate it, and the card may break if you force it into
the slot.
4Insert the Adaptec SCSI Card 39320A in the 64-bit (or 32-bit)
PCI or PCI-X expansion slot; press down firmly until the card
clicks into place, then replace the slot cover screw. When
installed properly, the card should appear level with the
expansion slot, as shown below.
Setting Up SCSI Devices
There are several things you may need to do to your SCSI devices
before you connect them to the Adaptec SCSI Card 39320A:
■Check the SCSI IDs
■Set the termination
■Connect the power cables
Since setup can vary from device to device, always refer to the
device’s documentation for specific instructions.
ASC-39320A IG.fm Page 4 Tuesday, July 29, 2003 3:17 PM

5
Following are some guidelines for setting SCSI IDs and termination
on your devices.
Check the SCSI IDs
The Adaptec SCSI Card 39320A and each device you connect to it
must have a unique SCSI ID number ranging from 0 to 15 on each
channel. No two devices on the same SCSI channel can have the
same SCSI ID.
The Adaptec SCSI Card 39320A is preset to ID 7 for each channel
and should not be changed. If you boot from a SCSI hard disk,
make sure the hard disk SCSI ID is set to 0. (Most SCSI hard disks
are preset to SCSI ID 0 at the factory.) The SCSI IDs for internal
devices are usually set with jumpers; SCSI IDs for external devices
are usually set with a switch on the back of the device.
Terminate the Ends
To ensure reliable communication on the SCSI bus, the device at the
end of each cable, or the end of the cable itself, must have a
terminator installed (or enabled). Terminators must be removed, or
termination must be disabled, on devices between the ends of each
cable.
Note: When connecting Ultra320/160 or Ultra2 SCSI devices,
the SCSI bus must be terminated either on the end of the cable
(with a permanent terminator) or with a separate terminating
connector. Ultra SCSI and earlier single-ended devices can
terminate the bus directly from the device. If you use an Ultra
SCSI terminator on an LVD Ultra320/160 and Ultra2 SCSI
bus, the SCSI devices will not operate properly. For this
reason be sure that you have the necessary Ultra320/160 or
Ultra2 cable and terminator before installing the Ultra320/160
SCSI devices.
Connecting SCSI Devices
You can connect a total of 30 SCSI devices to the Adaptec SCSI
Card 39320A, with up to 15 devices on each SCSI channel. Before
connecting devices, be sure to review Setting Up SCSI Devices on
page 4.
ASC-39320A IG.fm Page 5 Tuesday, July 29, 2003 3:17 PM

6
Connecting Internal Ultra320/160 and Ultra2 Devices
A special 68-pin internal LVD cable is needed to connect internal
Ultra320/160 or Ultra2 SCSI devices. If your cables are not marked,
you can identify most LVD cables as having twisted pairs of the flat
ribbon cable between the device connectors. Some cables are
laminated so that they lay flat. Internal LVD cables usually have a
terminator built into the end of the cable.
The Adaptec SCSI Card 39320A has two separate Ultra320/160
SCSI channels, as shown in the figure on page 1. Both channels
have an internal LVD/SE connector to which you can connect
internal SCSI devices.
Note: Adaptec recommends that you keep your Ultra320/160
and Ultra2 SCSI devices separate from your Ultra SCSI
devices. This allows the Ultra320/160 and Ultra2 SCSI
devices to transfer data at their maximum speed.
Follow these steps to connect your internal Ultra320/160 and
Ultra2 devices:
1Locate a 68-pin internal LVD SCSI cable, which may have either
twisted wires or flat wires, shown as follows.
ASC-39320A IG.fm Page 6 Tuesday, July 29, 2003 3:17 PM

7
2Plug the nonterminated end of the cable(s) to one of the internal
LVD/SE connectors.
3Plug the internal Ultra320/160 and Ultra2 SCSI devices to the
other cable connectors, starting with the connector at the
terminated end of the cable.
Note: Internal Ultra320/160 and Ultra2 SCSI devices come
from the factory with termination disabled and cannot be
changed. Proper termination is provided by the terminator
at the end of the LVD SCSI cable.
4Connect a power cable from your computer’s internal power
supply to each internal SCSI device.
Ultra320/160 or Ultra2
SCSI devices
Built-in terminator on cable
Plug first device to
this connector
ASC-39320A IG.fm Page 7 Tuesday, July 29, 2003 3:17 PM

8
Connecting External SCSI Devices
You can connect external Ultra320/160 and Ultra2 SCSI devices to
the 68-pin external LVD/SE VHDCI SCSI connectors. Each external
device will require a 68-pin VHDCI external LVD SCSI cable.
Note: We recommend that you do not combine older SCSI
devices with the newer Ultra320/160 and Ultra2 SCSI devices
on the same SCSI channel of the Adaptec SCSI Card 39320A.
Follow these steps to connect your external SCSI devices:
1Connect one end of an external SCSI cable to one of the external
Ultra320/160 connectors on the Adaptec SCSI Card 39320A.
2Connect the other end of the cable to a SCSI connector on the
back of an external device. If you are installing only one
external device, terminate the device and skip to Step 4.
VHDCI External LVD SCSI
cable
68-pin external LVD/SE VHDCI
SCSI connectors
4
4
SCSI terminator
ASC-39320A IG.fm Page 8 Tuesday, July 29, 2003 3:17 PM

9
3Connect the other external SCSI devices by linking each device
to the previous one, as shown below. Terminate only the device
at the end of the chain.
4Connect power cables to all external device(s) and to the
computer.
More Information About Termination
The last SCSI device on the end of each SCSI bus cable must be
terminated, and termination must be disabled for all other devices
in the middle of the cables. Ultra320/160 and Ultra2 SCSI devices
are automatically unterminated, but Ultra SCSI and Fast/Wide
SCSI devices do have termination that you must check. For more
information, refer to the documentation for each SCSI device.
If you are using external Ultra2 or Ultra320/160 devices, be sure to
use an LVD terminator to terminate the last device in the chain. If
you use a single-ended, active terminator (sometimes called an
Ultra terminator) the SCSI devices will not operate properly.
