Adaptec GameBridge AVC-1400 User manual

GameBridge
USB 2.0 Edition
AVC-1400
User’s Guide

ii
Copyright
© 2005 Adaptec, Inc. All rights reserved. No part of this publication may be
reproduced, stored in a retrieval system, or transmitted in any form or by any
means, electronic, mechanical, photocopying, recording or otherwise, without the
prior written consent of Adaptec, Inc., 691 South Milpitas Blvd., Milpitas, CA 95035.
Trademarks
Adaptec, the Adaptec logo, and GameBridge are trademarks of Adaptec, Inc., which
may be registered in some jurisdictions.
Windows 2000, Windows XP, and Xbox are trademarks of Microsoft Corporation in
the US and other countries, used under license.
PlayStation 2 is a trademark of Sony Computer Entertainment, Inc.
GameCube is a trademark of Nintendo.
InterVideo Home Theater is a registered trademarks of InterVideo in the U.S. and
other countries, used under license.
All other trademarks are the property of their respective owners.
Changes
The material in this document is for information only and is subject to change
without notice. While reasonable efforts have been made in the preparation of this
document to assure its accuracy, Adaptec, Inc. assumes no liability resulting from
errors or omissions in this document, or from the use of the information contained
herein.
Adaptec reserves the right to make changes in the product design without
reservation and without notification to its users.
Disclaimer
IF THIS PRODUCT DIRECTS YOU TO COPY MATERIALS, YOU MUST HAVE
PERMISSION FROM THE COPYRIGHT OWNER OF THE MATERIALS TO AVOID
VIOLATING THE LAW WHICH COULD RESULT IN DAMAGES OR OTHER
REMEDIES.

iii
Adaptec Customer Support
If you have questions about installing or using your Adaptec product, check this
document first—you will find answers to most of your questions here. If you need
further assistance, use the support options listed below.
Technical Support Identification (TSID) Number
■Before contacting Technical Support, you need your unique 12-digit TSID
number. The TSID number identifies your product and support status.
■The TSID number is included on two white, bar-coded labels, like the example
below.
Support Options
■Search the Adaptec Support Knowledgebase (ASK) at ask.adaptec.com for
articles, troubleshooting tips, and frequently asked questions for your product.
■For support via Email, submit your question to Adaptec's Technical Support
Specialists at ask.adaptec.com.
■To order Adaptec products, including accessories and cables, call +1 408-957-
7274. Or, you can order cables online at www.adaptec.com/buy-cables.
Europe
■Visit our Web site at www.adaptec-europe.com.
■German and English: Search the Adaptec Support Knowledgebase (ASK) at
ask-de.adaptec.com for articles, troubleshooting tips, and frequently asked
questions for your product.
For support via e-mail, submit your question to Adaptec's Technical Support
Specialists at ask-de.adaptec.com.
■French: Search the Adaptec Support Knowledgebase (ASK) at ask-fr.adaptec.com
for articles, troubleshooting tips, and frequently asked questions for your
product.
For support via e-mail, submit your question to Adaptec's Technical Support
Specialists at ask-fr.adaptec.com.
■To order Adaptec products, including accessories and cables, go to
www.adaptec.com/buy-cables.
Japan
■Search the Adaptec Support Knowledgebase (ASK) at ask.adaptec.co.jp
■Visit our Web site at www.adaptec.co.jp.

iv
Limited 1-Year Hardware Warranty
1. Adaptec, Inc. (“Adaptec”) warrants to the purchaser of this product that it will be free from
defects in material and workmanship for a period of one (1) year from the date of purchase.
If the product should become defective within the warranty period, Adaptec, at its option,
will repair or replace the product, or refund the purchaser’s purchase price for the product,
provided it is delivered at the purchaser’s expense to an authorized Adaptec service facility
or to Adaptec.
2. Repair or replacement parts or products will be furnished on an exchange basis and will
either be new or reconditioned. All replaced parts or products shall become the property of
Adaptec. This warranty shall not apply if the product has been damaged by accident,
misuse, abuse or as a result of unauthorized service or parts.
3. Warranty service is available to the purchaser by delivering the product during the warranty
period to an authorized Adaptec service facility or to Adaptec and providing proof of
purchase price and date. The purchaser shall bear all shipping, packing and insurance costs
and all other costs, excluding labor and parts, necessary to effectuate repair, replacement or
refund under this warranty.
4. For more information on how to obtain warranty service, write or telephone Adaptec at 691
South Milpitas Boulevard, Milpitas, CA 95035, [phone].
5. THIS LIMITED WARRANTY DOES NOT EXTEND TO ANY PRODUCT WHICH HAS
BEEN DAMAGED AS A RESULT OF ACCIDENT, MISUSE, ABUSE, OR AS A RESULT OF
UNAUTHORIZED SERVICE OR PARTS.
6. THIS WARRANTY IS IN LIEU OF ALL OTHER EXPRESS WARRANTIES WHICH NOW
OR HEREAFTER MIGHT OTHERWISE ARISE RESPECT TO THIS PRODUCT. IMPLIED
WARRANTIES, INCLUDING THOSE OF MERCHANTABILITY, FITNESS FOR A
PARTICULAR PURPOSE AND NON-INFRINGEMENT SHALL (A) HAVE NO GREATER
DURATION THAN 1 YEAR FROM THE DATE OF PURCHASE, (B) TERMINATE
AUTOMATICALLY AT THE EXPIRATION OF SUCH PERIOD AND (C) TO THE EXTENT
PERMITTED BY LAW BE EXCLUDED. IN THE EVENT THIS PRODUCT BECOMES
DEFECTIVE DURING THE WARRANTY PERIOD, THE PURCHASER’S EXCLUSIVE
REMEDY SHALL BE REPAIR, REPLACEMENT OR REFUND AS PROVIDED ABOVE.
INCIDENTAL OR CONSEQUENTIAL DAMAGES, INCLUDING WITHOUT LIMITATION
LOSS OF DATA, ARISING FROM BREACH OF ANY EXPRESS OR IMPLIED WARRANTY
ARE NOT THE RESPONSIBILITY OF ADAPTEC AND, TO THE EXTENT PERMITTED BY
LAW, ARE HEREBY EXCLUDED BOTH FOR PROPERTY DAMAGE, AND TO THE
EXTENT NOT UNCONSCIONABLE, FOR PERSONAL INJURY DAMAGE.
7. SOME STATES DO NOT ALLOW THE EXCLUSION OR LIMITATION OF INCIDENTAL
OR CONSEQUENTIAL DAMAGES FOR CONSUMER PRODUCTS, AND SOME STATES
DO NOT ALLOW LIMITATIONS ON HOW LONG AN IMPLIED WARRANTY LASTS, SO
THE ABOVE LIMITATION OR EXCLUSIONS MAY NOT APPLY TO YOU.
8. This warranty gives you specific legal rights, and you may also have other rights which vary
from state to state.

v
Adaptec Software License Agreement
PLEASE READ CAREFULLY: THE USE OF THIS SOFTWARE IS SUBJECT TO THE SOFTWARE
LICENSE TERMS OF ADAPTEC, INC. AND OTHER LICENSORS WHOSE SOFTWARE MAY
BE BUNDLED WITH THIS PRODUCT.
BY YOUR USE OF THE SOFTWARE INCLUDED WITH THIS PRODUCT YOU AGREE TO THE
LICENSE TERMS REQUIRED BY THE LICENSOR OF THAT SOFTWARE, AS SET FORTH
DURING THE INSTALLATION PROCESS. IF YOU DO NOT AGREE TO THE LICENSE
TERMS APPLICABLE TO THE SOFTWARE, YOU MAY RETURN THE ENTIRE UNUSED
PRODUCT FOR A FULL REFUND.
In return for acquiring a license to use the Adaptec software, which may include software from
third party licensors and patches made available by Adaptec (“Software”), and the related
documentation, you agree to the following terms and conditions:
1. License. This Agreement grants you, the Licensee, a license to:
a. Use the Software on a single computer system, which is not intended for use by more
than five (5) users; and:
b. Make one copy of the Software in machine readable form solely for back-up purposes,
provided you reproduce Adaptec's copyright proprietary legends. Notwithstanding the
foregoing, the Software may be used on the home, laptop or other secondary computer
of the principal user of the Software, and an additional copy of the Software may be
made to support such use. As used in this license, the Software is “in use” when it is
either loaded into RAM or installed on a hard disk or other permanent memory device.
The Software may be “in use” on only one computer at any given time. (Different license
terms and fees are applicable for networked or multiple user applications.) As a specific
condition of this license, you agree to use the Software in compliance with all applicable
laws, including copyright laws, and that you will not copy, transmit, perform or
distribute any audio or other content using the Software without obtaining all necessary
licenses or permissions from the owner of the content.
2. Restrictions. You may not distribute copies of the Software to others or electronically
transfer the Software from one computer to another over a network. You may not post or
otherwise make available the Software, or any portion thereof, in any form, on the Internet.
You may not use the Software in a computer service business, including in time sharing
applications. The Software contains trade secrets and, in order to protect them, you may not
decompile, reverse engineer, disassemble, or otherwise reduce the Software to a human-
perceivable form. YOU MAY NOT MODIFY, ADAPT, TRANSLATE, RENT, LEASE, LOAN,
RESELL FOR PROFIT, DISTRIBUTE, NETWORK OR CREATE DERIVATIVE WORKS
BASED UPON THE SOFTWARE OR ANY PART THEREOF.
3. Ownership of Software. As Licensee, you own the media upon which the software is
recorded or fixed, but Adaptec and its licensors retain title and ownership of the Software
recorded on the original media and all subsequent copies of the Software, regardless of the
form or media in which or on which the original and other copies may exist. This license is
not a sale of the Software or any copy.
4. Confidentiality. You agree to maintain the Software in confidence and that you will not
disclose the Software to any third party without the express written consent of Adaptec. You
further agree to take all reasonable precautions to preclude access of unauthorized persons
to the Software.
5. Term. This license is effective until January 1, 2045, unless terminated earlier. You may
terminate the license at any time by destroying the Software (including the related
documentation) together with all copies or modifications in any form. Adaptec will have the
right to terminate our license immediately if you fail to comply with any term or condition
of this Agreement. Upon any termination, including termination by you, you must destroy
the Software (including the related documentation), together with all copies or
modifications in any form.
6. Special Terms Applicable to Databases. Where a database is included with the Software, you
acknowledge that it is licensed only in connection with the use of the Software to perform
disc creation, and that the database and all data derived therefrom must be maintained in
confidence in accordance with the provisions of Section 4. This license does not grant you
any rights to distribute or disclose such database or data.

vi
7. Limited Warranty. Adaptec and its Licensor warrant only that the media upon which the
Software is furnished will be free from defects in material or workmanship under normal
use and service for a period of thirty (30) days from the date of delivery to you. ADAPTEC
AND ITS LICENSORS DO NOT AND CANNOT WARRANT THE PERFORMANCE OR
RESULTS YOU MAY OBTAIN BY USING THE SOFTWARE OR DOCUMENTATION. THE
FOREGOING STATES THE SOLE AND EXCLUSIVE REMEDIES ADAPTEC AND ITS
LICENSORS WILL PROVIDE FOR BREACH OF WARRANTY. EXCEPT FOR THE
FOREGOING LIMITED WARRANTY, ADAPTEC AND ITS LICENSORS MAKE NO
WARRANTIES, EXPRESSED OR IMPLIED, INCLUDING, BUT NOT LIMITED, AS TO
NON-INFRINGEMENT OF THIRD PARTY RIGHTS, MERCHANTABILITY OR FITNESS
FOR A PARTICULAR PURPOSE. Some states do not allow the exclusion of implied
warranties or limitations on how long an implied warranty may last, so the above
limitations may not apply to you. This warranty gives you specific legal rights and you may
also have other rights which vary from state to state.
8. The entire liability of Adaptec and its licensors, and your exclusive remedy for a breach of
this warranty, shall be:
a. The replacement of any media not meeting the above limited warranty which is
returned to Adaptec; or:
b. if Adaptec or its distributor is unable to deliver replacement media which is free from
defects in materials or workmanship, you may terminate this Agreement by returning
the Software and your money will be refunded.
9. Limitation of Liability. IN NO EVENT WILL ADAPTEC OR ITS LICENSORS BE LIABLE TO
YOU FOR ANY INCIDENTAL, CONSEQUENTIAL OR INDIRECT DAMAGES,
INCLUDING ANY LOST PROFITS, LOST SAVINGS, OR LOSS OF DATA, EVEN IF
ADAPTEC OR A LICENSOR HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH
DAMAGES, OR FOR ANY CLAIM BY ANY OTHER PARTY. Some states do not allow the
exclusion or limitation of special, incidental, or consequential damages, so the above
limitation or exclusion may not apply to you.
10. Export. You acknowledge that the laws and regulations of the United States and other
countries may restrict the export and re-export of the Software. You agree that you will not
export or re-export the Software or documentation in any form in violation of applicable
United States and foreign law.
11. Government Restricted Rights. The Software is subject to restricted rights as follows. If the
Software is acquired under the terms of a GSA contract: use, reproduction or disclosure is
subject to the restrictions set forth in the applicable ADP Schedule contract. If the Software is
acquired under the terms of a DoD or civilian agency contract, use, duplication or disclosure
by the Government is subject to the restrictions of this Agreement in accordance with 48
C.F.R. 12.212 of the Federal Acquisition Regulations and its successors and 49 C.F.R.
227.7202-1 of the DoD FAR Supplement and its successors.
12. General. You acknowledge that you have read this Agreement, understand it, and that by
using the Software you agree to be bound by its terms and conditions. You further agree that
it is the complete and exclusive statement of the agreement between Adaptec and you, and
supersedes any proposal or prior agreement, oral or written, and any other communication
between Adaptec and you relating to the subject matter of this Agreement. No additional or
any different terms will be enforceable against Adaptec unless Adaptec gives its express
consent, including an express waiver of the terms of this Agreement, in writing signed by an
officer of Adaptec. You assume full responsibility for the use of the Software and agree to
use the Software legally and responsibly. This Agreement shall be governed by California
law, except as to copyright matters, which are covered by Federal law. This Agreement is
deemed entered into at Milpitas, California by both parties. Should any provision of this
Agreement be declared unenforceable in any jurisdiction, then such provision shall be
deemed severable from this Agreement and shall not affect the remainder hereof. All rights
in the Software not specifically granted in this Agreement are reserved by Adaptec.
Should you have any questions concerning this Agreement, contact Adaptec by writing to:
Adaptec, Inc.
Legal Department
691 South Milpitas Boulevard
Milpitas, California 95035

vii
Regulatory Compliance Statements
Federal Communications Commission Radio Frequency Interference Statement
WARNING: Changes or modifications to this unit not expressly approved by the party
responsible for compliance could void the user’s authority to operate the equipment.
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates, uses, and
can radiate radio frequency energy, and if not installed and used in accordance with the
instruction manual, may cause harmful interference to radio communications. However, there is
no guarantee that interference will not occur in a particular installation. However, if this
equipment does cause interference to radio or television equipment reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
■Reorient or relocate the receiving antenna.
■Increase the separation between equipment and receiver.
■Connect the equipment to an outlet on a circuit different from that to which the receiver is
connected.
■Consult the dealer or an experienced radio/television technician for help.
■Use a shielded and properly grounded I/O cable and power cable to ensure compliance of
this unit to the specified limits of the rules.
This device complies with part 15 of the FCC rules. Operation is subject to the following two
conditions: (1) this device may not cause harmful interference and (2) this device must accept
any interference received, including interference that may cause undesired operation.
European Union Compliance Statement
This Information Technology Equipment has been tested and found to comply with
EMC Directive 89/336/EEC, as amended by 92/31/EEC and 93/68/EEC, in
accordance with:
■EN55013
■EN55020
■EN55022 (1998) Emissions
■EN55024 (1998) Immunity:
➐EN61000-4-2 (1998) Electrostatic discharge: ±4 kV contact, ±8 kV air
➐EN61000-4-3 (1998) Radiated immunity
➐EN61000-4-4 (1995) Electrical fast transients/burst: ±1 kV AC, ±0.5 kV I/O
➐EN61000-4-5 (1995) Surges ±1 kV differential mode, ±2 kV common mode
➐EN61000-4-6 (1996) Conducted immunity: 3 V
➐EN61000-4-11 (1994) Supply dips and variation: 30% and 100%
In addition, all equipment requiring U.L. listing has been found to comply with EMC
Directive 73/23/EEC as amended by 93/68/EEC in accordance with EN60950 with
amendments A1, A2, A3, A4, A11.
Japanese Compliance (Voluntary Control Council Initiative)
This equipment complies to class B Information Technology equipment based on
VCCI (Voluntary Control Council for Interface). This equipment is designed for home
use but it may causes radio frequency interference problem if used too near to a
television or radio. Please handle it correctly per this documentation.
Adaptec, Inc. AVC-1400
Tested to Comply
With FCC Standards
FOR HOME OR OFFICE USE

1
In this Guide
Introduction 2
Installing GameBridge 5
Configuring InterVideo Home Theater 17
Navigating InterVideo Home Theater 19
Playing and Recording Console Games on Your PC 20
Recording Videos 25
Getting Help 26
Technical Specifications 30

2
Introduction
Introduction
Thank you for purchasing the Adaptec GameBridge™ AVC-1400
USB 2.0 Edition. This product allows you to connect and play
console games on your computer in real time. You can record and
save your best moves and gaming highlights and play them back to
your friends. You can also use GameBridge to convert your home
videos to video CDs.
The GameBridge kit includes a complete suite of software that you
can use to:
■Connect your game console to a PC or Notebook
■Play console games on your computer, maximizing your
gaming environment and enhancing the quality of your game
graphics
■Record games as you play them
■Share the videos of your games with friends, proving your
superior gaming skills
■Capture video from camcorders and VHS tapes
■Burn games and videos to VCDs

3
Introduction
What’s in the Kit
In addition to the carrying pouch, your Adaptec GameBridge kit
includes:
System Requirements
To use GameBridge, you need a PC-compatible computer with:
■Intel Pentium®IV, Celeron®, or AMD® Athlon processor at 1.3
GHz (or faster)
■Windows®2000 SP4, or Windows XP SP2
■256 MB RAM (512 MB recommended)
■250 MB free disk space for applications
■110–480 MB free disk space per 10 minutes of captured video,
depending on resolution and capture quality (see the table on
page 29 for more information)
■DirectX 9 compatible graphic accelerator and sound card
■Available USB 2.0 port
■CD-R/W drive
GameBridge Unit
6-ft USB Cable with
mini Type B connector
Adaptec GameBridge CD, including
drivers, software, and user’s guide
4-in-1 Audio Video Adapter Cable Quick Start Guide

4
Introduction
Your GameBridge Unit
Power LED Status
The LED on the top of GameBridge lights up to indicate the status
of operation:
LED Color Condition Description
Off - Device is off.
Green Steady Device is ready to use.
Green Blinking Data is being transferred.
4-in-1 Audio/Video Connector
LED
Mini USB Port

5
Installing GameBridge
Installing GameBridge
This section steps you through the process of installing
GameBridge, the device driver, and InterVideo Home Theater
software. The installation program checks your computer to ensure
that the minimum hardware requirements are met.
Installing GameBridge is easy--the installation CD guides you
through the process. After prompting you to install the
GameBridge hardware, it installs the device drivers using a two-
step process (first installing the USB loader, then the device driver),
and then it installs the InterVideo Home Theater software.
Follow the complete set of instructions provided for your operating
system to ensure that all GameBridge components are properly
installed.
Note: If a version of InterVideo Home Theater is already installed
on your system, uninstall it before installing this version.
■For Windows XP, see this page.
■For Windows 2000 SP4, see page 11.
Windows XP
To install GameBridge, follow these steps:
1Turn on your computer.
2Insert the GameBridge Installation CD. The GameBridge
installation window is displayed.

6
Installing GameBridge
3Click Install GameBridge.
If the following message pops up, make sure GameBridge is not
plugged into your computer, then click Continue.
Note: If you click Cancel in this window, you must restart the
installation process.

7
Installing GameBridge
4The Install GameBridge window opens, alerting you to connect
GameBridge to your computer’s USB 2.0 port. At this time, you
will connect all the equipment.
5Connect GameBridge to your computer using the provided USB
cable.
Note: To operate properly, GameBridge requires USB 2.0. If you
plug GameBridge into a USB 1.1 port, you’ll see the following
message during driver installation indicating that GameBridge
will run at a reduced (USB 1.1) speed:
A hi-speed USB device is plugged into a non-hi-speed USB hub.

8
Installing GameBridge
6 Connect GameBridge to your game console using the provided 4-
in-1 Audio Video cable
. GameBridge can be connected to
PlayStation®2, Xbox®, or GameCube®consoles.
Note: To record videos, connect GameBridge to a camcorder or
VHS the same way .
7When the Found New Hardware Wizard opens, select No, not
at this time and click Next.
Connect yellow video
plug to yellow video port.
Connect white audio plug
to white audio port and
red audio plug to red
audio port.
Connect gray S-video
plug to analog video
input port (if available).

9
Installing GameBridge
At this time, the following message may be displayed. Click
Continue Anyway.
Note: Adaptec drivers are fully tested and certified to work with
GameBridge.
8Select Install the Software Automatically (default) and click
Next.
Your computer detects the new hardware.
9Click Finish to complete the USB Loader installation.

10
Installing GameBridge
10 The Found New Hardware Wizard opens again, repeat Step 7
through Step 9 to install the device drivers
Note: To check if the driver is installed properly, see Need Help
Installing Your Device Drivers? on page 26.
11 The InterVideo Home Theater software installer launches
automatically. Follow the on-screen instructions.

11
Installing GameBridge
12 After the installation is complete, click Yes, I want to restart my
computer now.
13 After the computer restarts, you are ready to set up InterVideo
Home Theater and then play and record games. See Configuring
InterVideo Home Theater on page 17.
Windows 2000 SP4
To install GameBridge, follow these steps:
1Turn on your computer.
2Insert the GameBridge Installation CD. The GameBridge
installation window is displayed.

12
Installing GameBridge
3Click Install GameBridge.
If the following message pops up, make sure GameBridge is
unplugged from the computer, then click Continue.
Note: If you click Cancel in the following window, you must
restart the installation process.
If your computer does not have DirectX 9.0 installed, the
following window opens. Click OK to continue and follow the
on-screen instructions. Your computer reboots after DirectX 9.0
has been installed.

13
Installing GameBridge
4The Install GameBridge window opens, alerting you to connect
GameBridge to your computer’s USB 2.0 port. At this time, you
will connect all the equipment.
5Connect GameBridge to your computer using the provided USB
cable.
