OmniReach®NCX-1000s
Distribution Intercept Cross-Connect for CoolPed™ Cabinets
www.adc.com • [phone] • 1-800-366-3891
Spec Sheet
The NCX-1000s service delivery cross connect is designed for customers who use the Emerson
CoolPed™cabinet for hardend DSLAM applications. The NCX-1000s utilizes ADC’s patented
Distribution Intercept (DI) broadband service delivery cross-connect and mounts inside the
CoolPed cabinet offering the same streamlined broadband service delivery as found in ADC's
family of NCX-1000 cabinets. The NCX-1000s combined with the CoolPed allows you to
strategically place the cabinet anywhere in the network to achieve the required loop lengths
for optimum bandwidth. Simple straight splicing to the outside plant cable is all that is needed
to begin turning up customers.
ADC’s OmniReach®FTTX Solutions are the industry’s first infrastructure solutions designed
from the ground up to meet the unique requirements of FTTX networks. Designed for operational
efficiency and scalability, OmniReach solutions simplify FTTX network installation, maintenance
and management from the central office/headend to the outside plant.
Features
NCX-1000s and mounting brackets for•
CoolPed cabinet installation, OSP cable
stubs 12’ for easy splicing into DSLAMs
and network
Works with existing feeder/distribution•
cross box or can replace it
Sized from 48 DSLAM ports and 100 OSP•
intercept pairs to 144 DSLAM ports and
600 OSP intercept pairs
Able to groom all existing xDSL shelves into•
a single format and provide cross-connect
capability in addition to pair-bonding
Provides a consistent interface•
for technicians

6/08•104982AE OmniReach® NCX-1000s
OmniReach®NCX-1000s
Distribution Intercept Cross-Connect for CoolPed™ Cabinets
2
www.adc.com • [phone] • 1-800-366-3891
NCX-1000s enables centralized broadband service
delivery from CoolPed cabinets.
Green activation plugs in cross–connect
distribution field provide visual indication
of active xDSL customers.
Distribution Intercept
The heart of the NCX-1000s is ADC’s patented Distribution Intercept (DI) cross-connect using LSA-PLUS®
Series 2 IDC connectivity.
 • BrownSeries2switchingblocksroutePOTSintotheDSLAMandpresentthecombinedDSLAM
output of POTS/xDSL signals.
 • WhiteSeries2disconnectblocksprovideOSPinputandoutputterminations.
Once the DI is spliced onto either feeder or distribution outside plant cable, broadband service activation
occurs with a simple 2 pair jumper between brown and white blocks and insertion of a green activation
plug. Existing voice service is immediately available upon splicing the DI onto outside plant cable due to
normally closed contacts on Series 2 white blocks.
The high performance LSA-PLUS Series 2 IDC blocks are far superior to standard 66- and 110-type
IDC blocks. Contacts angled at 45 degrees offer a larger, stronger cross section of wire and a gas tight
seal. Silver-plated contacts resist corrosion much more effectively than standard tin-plated contacts.
Combined with integral clamping ribs for extraordinary grip, LSA-PLUS blocks offer exceptional electrical
performance and contribute to reduced failure frequency rates in the network.

6/08•104982AE OmniReach® NCX-1000s
OmniReach®NCX-1000s
Distribution Intercept Cross-Connect for CoolPed™ Cabinets
3
www.adc.com • [phone] • 1-800-366-3891
Benefits
Can be deployed in feeder or distribution•
outside plant cable, the most flexible
solution available
Fastest to deploy, only straight splicing•
activities to OSP required
Unique look-both-ways test capability without•
lifting wires reduces time for technicians to
isolate network problems
Distribution Intercept (DI) offers the most•
streamlined approach to xDSL delivery
Cross BoxDLC Remote Cabinet
CoolPed Cabinet
NCX-1000s cross connect in CoolPed•
Central location for xDSL service delivery•
LSA-PLUS IDC for distribution intercept•
“Look both ways” testing•
DLC Remote Cabinet CrossBox
Specifications
GENERAL SPECIFICATIONS
Mounting:  BracketincludedforCoolPed™cabinet
with mounting rails
DSLAM Ports In/Out: 48 to 144
OSP Intercept Pairs In/Out: 100 to 600 pairs
Cabling: OSP gel filled direct bury cable with raw
ended stubs 12 ft in length
Accessories: Includes Insertion Tool and LSA-PLUS Series 2
green plugs for xDSL activation
MECHANICAL SPECIFICATIONS
OSP Input/Output: LSA-PLUS Series 2 disconnect block (white)
DSLAM Input/Output: LSA-PLUS Series 2 switching block (brown)
Contact Resistance: < 1 m Ω
Insulation Resistance: > 5 x 104 MΩ
Contact Material: Copper Alloy
Contact Plating: Silver
Number of Test Cord Insertions: > 750
IDC Reterminations: > 200
Cross Connect Wire Requirements: 24 AWG solid, tinned cross connect wire
for all terminations

Website: www.adc.com
FromNorthAmerica,CallTollFree:1-800-366-3891•OutsideofNorthAmerica:[phone]
Fax:[phone]•ForalistingofADC’sglobalsalesofficelocations,pleaserefertoourwebsite.
ADCTelecommunications,Inc.,P.O.Box1101,Minneapolis,Minnesota USA 55440-1101
Specificationspublishedherearecurrentasofthedateofpublicationofthisdocument.Becausewearecontinuously
improving our products, ADC reserves the right to change specifications without prior notice. At any time, you may
verify product specifications by contacting our headquarters office in Minneapolis. ADC Telecommunications, Inc.
views its patent portfolio as an important corporate asset and vigorously enforces its patents. Products or features
contained herein may be covered by one or more U.S. or foreign patents. An Equal Opportunity Employer
104982AE 6/08 Revision © 2008, 2007 ADC Telecommunications, Inc. All Rights Reserved
Spec Sheet
Description Catalog Number
Distribution intercept cross connect for mounting in CoolPed cabinet.
Includes mounting bracket, Insertion Tool and LSA-PLUS Series 2 green activation plugs.
48 DSLAM ports in/out, 100 OSP intercept pairs NIB-048100N12S
96DSLAMportsin/out,200OSPinterceptpairs NIB-096200N12S
144 DSLAM ports in/out, 600 OSP intercept pairs NIB-144600N12S
Accessories
Insertion Tool 6417 2 055-01
Look-both-ways test cord for LSA-PLUS Series 2 66472900-01
LSA-PLUS Series 2 green plugs for xDSL activation
Quantity: 1 (order in multiples of 100)
60893055-02
Ordering Information
