w w w . a d c . c o m • + 1 - 9 5 2 - 9 3 8 - 8 0 8 0 • 1 - 8 0 0 - 3 6 6 - 3 8 9 1
DSX-4R (RZX3) 4 High Rear Modular
Cross-Connect Product Line
24-, 32- and 36-Position Chassis, 3-,4- and 6-Port Modules
ADC sets the standards the industry follows. No one packs more jacks,
performance, flexibility, and durability into DSX than ADC’s RZX-3. With 504
midsize jacks ports in a 7-foot rack, the RZX-3 has more capacity than any
other midsize DSX. It is also the only solution available with modular pre-
termination, setting a new standard.
Description Ordering Number
Chassis
24-Position chassis with front and rear LEDs DSX4R-D24
32-Position chassis with front and rear LEDs DSX4R-D32
36-Position chassis with front and rear LEDs DSX4R-D36
8-position chassis DSX4R-E08
Module Configurations
4-port midsize-BNC odd numbered module DSX-4R-MB140
4-port midsize-BNC even numbered module DSX-4R-MB240
6-port midsize-BNC odd numbered module DSX-4R-MB160
6-port midsize-BNC even numbered module DSX-4R-MB260
Ordering Information
Web Site: www.adc.com
From North America, Call Toll Free: 1-800-366-3891 • Outside of North America: +1-952-938-8080
Fax: +1-952-917-3237 • For a listing of ADC’s global sales office locations, please refer to our web site.
ADC Telecommunications, Inc., P.O. Box 1101, Minneapolis, Minnesota USA 55440-1101
Specifications published here are current as of the date of publication of this document. Because we are continuously
improving our products, ADC reserves the right to change specifications without prior notice. At any time, you may verify
product specifications by contacting our headquarters office in Minneapolis. ADC Telecommunications, Inc. views its patent
portfolio as an important corporate asset and vigorously enforces its patents. Products orfeatures contained herein may be
covered by one or more U.S. or foreign patents. An Equal Opportunity Employer
103876AE 11/06 Original © 2006 ADC Telecommunications, Inc. All Rights Reserved
Accessories
Quality patch cords and cross-connect cables in various configurations and lengths
Description Ordering Number
Patch Cord Start-up Kits
9’ Midsize to midsize patch cord-RG59 Cable PCH-MMXB-009D
3’ Midsize to midsize patch cord -RG59 Cable PCH-MMXB-003
6’ Midsize to midsize patch cord -RG59 Cable PCH-MMXB-006
10’ Midsize to midsize patch cord -RG59 Cable PCH-MMXB-010
3’ BNC to BNC cross-connect cable-dual 735 cable XCC-BBXD-003
6’ BNC to BNC cross-connect cable-dual 735 cable XCC-BBXD-006
12’ BNC to BNC cross-connect cable-dual 735 cable XCC-BBXD-012
15’ BNC to BNC cross-connect cable-dual 735 cable XCC-BBXD-015
20’ BNC to BNC BNC to BNC cross-connect cable-dual 735 cable XCC-BBXD-020
25’ BNC to BNC cross-connect cable-dual 735 cable XCC-BBCD-025
75 OHM midsize termination plug CP150IN
25 Pack red ground circuit plugs CJP-M-Red
75 OHN BNC termination plug BNC-3
BNC insertion/removal tool BT2000
BNC installation kit BNC-TOOL-1
Bulk Equipment Cable
Bulk cable-735 single 3AC-BB
Bulk cable-735 dual 3AC-2BB
Bulk cable-735 6 pack 3AC-6BB
Bulk cable-735 12 pack 3AC-12BB
Ordering Information
