TROUBLESHOOT1NG No.lb20 (AND 1006)
,.‘..,’
TROUBLE: I .
A.
B.
TROUBLE: 2.
A.
B.
C.
D.
E.
EXCESSIVE DRAIN OF PROTECTIVE CIRCUIT POWER SUPPLY OR REPEATED RE-
PLACEMENT OF PROTECTIVE CIRCUIT BATTERY. (See also Part I, Section HI.
PROBABLE CAUSE
Short circuit in protective circuit A. Repair or replace defective wir-
wiring (remove wires from terminals ing (check for pierced insulation
A and B and from termina I s C and D;
remove wires from protective circuit inprotective circuit wiring
caused by tacks, s-tap les or-
power source; see Part I, Sect ion H pinching. Check where wires go
for finding short circuits). through walls or around pipes).
Short circuit in sensitive relay coil B.
(located uppermost above terminals
5 and 6).
REMEDY
Replace sensitive relay if
resistance check indicates too
low’s value (see Part I, Section
HI.
NOTE: I. When using separate power sources as shown in Diagram B, DO NOT
cut black jumper between terminals B and 3 on terminal board.
2. When using a common power source as shown in Diagrams A and C,
CUT black jumper between terminals B and 3’on terminal board.
BELL(S) OR OTHER SOUNDING DEVICES DO NOT GIVE FULL SOUND.
PROBABLE CAUSE
Low bell battery or power supply volt- A.
age ( in the case of a rechargeable
power supply, be sure that the batteries
are fully charged - charge batter i es for
24 hours wlthout a load).
Bell line run does not conform to B.
specified procedures (see note at
the end of this section: see also.
-
Part I, Section G).
Improper bell mounting has caused
clapper to jam. C.
Short circuit in bell wires (see Part D.
I, Section G for troubleshooting bell
connection).
Defective bell (if possible, test E.
system with new bell).
REMEDY
Replace battery if voltage mea-
sures substantially less than 6
volts,while the bell is operating.
Allow rechargeable batteries to
charge ful ly.
Makechanges.in bel I wiring.
Inspect mounting and bell dome
position. Correct any binding or
jamming.
Replace wires to bell, being care-
ful to avoid conditions that will
cause short circuits.
Replace bell if necessary.
159
