ADENDORFF MAC AFRIC SMIXER-001 User manual

GENERAL POWER TOOL SAFETY WARNINGS
(For All Power Tools)
WARNING! Read and understand all instructions. Failure to follow all
instructions listed below may result in electric shock, fire and/or serious
personal injury.
Save all warnings and instructions for future reference.
The term “power tool” in the warnings refers to your mains-operated (corded) power tool
or battery-operated (cordless) power tool.
Work Area Safety
1. Keep work area clean and well lit. Cluttered or dark areas invite accidents.
2. Do not operate power tools in explosive atmospheres, such as in the presence of
flammable liquids, gases, or dust.
Power tools create sparks which may ignite the
dust or fumes.
3. Keep children and bystanders away while operating a power tool.
Distractions can
cause you to lose control.
Electrical Safety
4. Power tool plugs must match the outlet. Never modify the plug in anyway. Do not use
any adapter plugs with earthed (grounded) power tools.
Unmodified plugs and
matching outlets will reduce risk of electric shock.
5. Avoid body contact with earthed or grounded surfaces, such as pipes, radiators,
ranges and refrigerators.
There is an increased risk o electric shock if your body is
earthed or grounded.
6. Do not expose power tools to rain or wet conditions.
Water entering a power tool will
increase the risk of electric shock.
7. Do not abuse the cord. Never use the cord for carrying, pulling or unplugging the
power tool. Keep cord away from heat, oil, sharp edges or moving parts.
Damaged or
entangled cords increase the risk of electric shock.
8. When operating a power tool outdoors, use an extension cord suitable for outdoor use.
Use of
a cord suitable for outdoor use reduces the risk of electric shock.
9. If operating a power in a damp location is unavoidable, use a residual current device (RCD)
protected supply. Use of an RCD reduces the risk of electric shock.
NOTE: The term “residual current device (RCD)” may be replaced by the term “ground fault
circuit interrupter (GFCI)” or “earth leakage circuit breaker (ELCB)”.
Personal Safety
10. Stay alert, watch what you are doing and use common sense when operating a power tool.
Do not use a power tool while you are tired or under the influence of drugs, alcohol, or
medication. A moment of inattention while operating power tools may result in serious
personal injury.
11. Use personal protective equipment. Always wear eye protection. Protective equipment such
as dust mask, non-skid safety shoes, hard hat, or hearing protection used for appropriate
conditions will reduce personal injuries.
12. Prevent unintentional starting. Ensure the switch is in the off-position before connecting to
power source and /or battery pack, picking up or carrying the tool.
Carrying power tools
with your finger on the switch or energising power tools that have the switch on invites
accidents.
13. Remove any adjusting key or wrench before turning the tool on.
A wrench or a key left
attached to a rotating part of the power tool may result in personal injury.
14. Do not overreach. Keep proper footing and balance at all times.
This enables better control
of the power tool in unexpected situations.
15. Dress properly. Do not wear loose clothing or jewellery. Keep your hair, clothing, and gloves
away from moving parts.
Loose clothes, jewellery or long hair can be caught in moving
parts.
16. If devices are provided for the connection of dust extraction and collection facilities, ensure
these are connected and properly used.
Use of dust collection can reduce dust-related
hazards.
Power Tool Use and Care
17. Do not force the power tool. Use the correct power tool for your application. The
correct power tool will do the job better and safer at the rate for which it was
designed.
18. Do not use tool if switch does not turn it on or off. Any power tool that cannot be

controlled with the switch is dangerous and must be repaired.
19. Disconnect the plug from the power source and/or the battery pack from the power
tool before making any adjustments, changing accessories, or storing power tools.
Such preventive safety measures reduce the risk of starting the power tool
accidentally.
20. Store idle power tools out of the reach of children and do not allow persons
unfamiliar with the power tool or these instructions to operate the power tool.
Power
tools are dangerous in the hands of untrained users.
21. Maintain power tools. Check for misalignment or binding of moving parts, breakage
of parts and any other condition that may affect the power tool’s operation. If
damaged, have the power tool repaired before use. Many accidents are caused by
poorly maintained power tools.
22. Keep cutting tools sharp and clean.
Properly maintained cutting tools with sharp
cutting edges are less likely to bind and are easier to control.
23. Use the power tool, accessories and tool bits etc. in accordance with these
instructions, taking into account the working conditions and the work to be
performed. Use of the power tool for operations different from those intended could
result in a hazardous situation.
Service
24. Have your power tool serviced by a qualified repair person using only identical
replacement parts.
This will ensure that the safety of the power tool is maintained .
VOLTAGE WARNING:
Before connecting the machine to a power source (receptacle, outlet, etc.), be sure the
voltage supplied is the same as that specified on the nameplate of the machine. A power
source with voltage greater than that specified for the machine can result in SERIOUS
INJURY to the user, as well as damage to the machine. If in doubt, DO NOT PLUG IN THE
MACHINE. Using a power source with voltage less than nameplate rating is harmful to the
motor.
SPECIFICATIONS
Model SMIXER-001 Q1U-FF02-160B
Rated Power Input 800 W 1010 W
No-Load Speed 680 r/min 620 r/min
Net Weight 2.4 Kg 3.5 Kg
※Due to the continuing program of research and development, the specifications herein are
subject to change without prior notice.
ADDITIONAL SAFETY RULES
1. Always hold the tool firmly and provide for a secure stance. The power tool is guided
more secure with both hands.
2. Make sure the stirring paddle is mounted securely before starting operation.
3. Always wait until the tool has come to a complete stop before placing it down or
changing the direction of its rotation.
4. Keep hands away from rotating parts.
5. Do not use for explosive materials (e. g. easily inflammable solvent). Power tools produce
sparks which could ignite developing vapours.
6. Do not use a tool with a damaged mains cable. Do not touch the damaged cable and pull
the mains plug when the cable s damaged while working. Damaged cables increase the
risk of an electric shock.
7. In case the tool should fall into the material to be stirred, pull the mains plug immediately
and have the tool checked by an after-sales service agent. Material that has penetrated
the tool can cause damage and lead to an electric shock.
8. Always use the auxiliary handle supplied with the tool. Loss of control can cause
personal injury.
SAVE THESE INSTRUCTIONS.
WARNING! MISUSE or failure to follow the safety rules stated in this instruction manual may
cause serious personal injury.

INSTRUCTIONS FOR OPERATION
Installing or Removing Stirring Paddle
CAUTION:
Always be sure that the tool is switched off and
unplugged before installing or removing stirring
paddle.
To install the stirring paddle, screw the stirrer
into the drive spindle and tighten the lock nut
securely. (Fig. 1)
To remove the stirring paddle, follow the
installation procedures in reverse.
Switch Action
To start the tool, simply pull the switch trigger,
release the switch trigger to stop the tool. (Fig. 2)
For continuous operation, press the trigger switch
and then push in the lock button. To stop the tool
from the locked position, pull the trigger fully
then release it. (Fig. 2)
CAUTION:
Before plugging in the tool, always check to see
that the switch trigger actuates properly and
returns to the “OFF” position when released.
Change the direction of rotation only when the
tool comes to a complete stop. Changing it
before the tool stops may damage the tool.
Auxiliary Handle
Screw the auxiliary handle to the tool securely. (Fig. 3)
CAUTION: Always use auxiliary handle for safe operation.
Stirring Operation
When start stirring operation, put the stirring paddle into the material to be stirred firstly before
switching on the tool; And when stop operation, switch off the tool firstly and wait until the tool
has come to a complete stop before pulling the stirring paddle out.
CAUTION:
Change the stirring operation only when the tool has come to a complete stop.
Move the tool up and down while stirring.
Clean the stirring paddle after use.
MAINTENANCE AND INSPECTION
CAUTION:
Always be sure that the tool is switched off and unplugged before attempting to perform
inspection or maintenance.
1. Inspecting the Mounting Screws
Regularly inspect all mounting screws and ensure that they are properly tightened. Should
any of the screws be loose, retighten them immediately. Failure to do so could result in
serious hazard.
2. Maintenance of the Motor
The motor unit winding is the very “heart” of the power tool. Exercise due care to ensure
the winding does not become damaged and /or wet with oil or water.
3. Inspecting and replacing the carbon brushes

Remove and check the carbon brushes
regularly. Replace when they wear down to
the limit mark (Fig. 4). Keep the carbon
brushes clean and free to slip in the holders.
Both carbon brushes should be replaced at
the same time. Use only identical carbon
brushes.
Use a screwdriver to remove the brush holder
caps. Take out the worn carbon brushes,
insert the new ones and secure the brush
holder caps. (Fig. 5)
※Damaged cord must be replaced by a special
cord purchased from authorized service center.
※To maintain product SAFETY and RELIABILITY, repairs, any other maintenance or
adjustment should be performed by authorized service centers, always using original
replacement parts.

EXPLANATION OF GENERAL VIEW
1 Stirring Paddle and Stirrer Assembly 29 Baffle Plate
3 Drive Spindle 30 Stator Assembly
4 Flat Key 31 Trigger Switch
5 Bearing Retainer 32 Left –half Handle
6 Ball Bearing 33 Pan Head Tapping Screw
7 Gear Housing Cover 34 Capacitor
8 Needle Bearing 35 Pan Head Tapping Screw
9 Fiber Washer 36 Right-half Handle
10 Gear(Small) 37 Pan Head Tapping Screw
11 Drive Shaft 38 Strain Relief
12 Ball Bearing 39 Cord Guard
13 Rubber Pin 40 Cord
14 Gear Housing 42 Motor Housing
15 Pan Head Tapping Screw 43 Carbon Brush Holder
16 Spacer Ring 44 Nameplate
17 Gear (Large) 45 Carbon Brush
18 Circlip for Shaft 46 Brush Holder Cap
19 Needle Bearing 47 Auxiliary Handle
22 Ball Bearing 48
Carrying Handle
23 Insulation Washer 49
24 Armature Assembly 50 Pan Head Tapping Screw
25 Rubber Washer 51 Terminal Block
26 Ball Bearing 52 Steel Ball
27 Rubber Pin
28 Pan Head Tapping Screw
