Declaration of Conformity
Manufacturer’s name : ADEUNIS R.F.
Manufacturer’s address : Parc Technologique PRE ROUX IV
283 rue Louis NEEL
38920 CROLLES - FRANCE
declares that the product if used and installed according to the user guide available on
our web site www.adeunis-rf.com
Product Name : ARF37
Product Number(s) : ARF7483A / ARF7484A / ARF7483B / ARF7484B
Product options :
complies with the RTTE Directive 99/5/EC :
EMC : conformity is proven by compliance to the harmonized standard
EN 301-489
Safety : conformity to the standard EN 60950-1/2001
Radio : conformity is proven by compliance to harmonized standard EN
300-220 covering essential radio requirements of the RTTE
directive.
Exposure to radio frequency signals : regarding the 1999/519/EC recommendation,
when using the device, keep the product at least 3,2 cm from your body.
Notes : - Conformity has been evaluated according to the procedure
described in Annex III of the RTTE directive.
- Receiver class (if applicable): 3.
Crolles, November 6th, 2007
VINCENT Hervé / Quality manager
Download of the user guide
Thank you for having chosen the ADEUNIS RF products.
User guides can be uploaded directly on our web site www.adeunis-rf.com :
Index Products
Paragraph Long range audio transmissions
Print version available upon request
9Tel : [phone]
9Email : [e-mail]

A
RF37 User Guide
Ref. 07-10-V3-psn p 3
Introducing the A
RF37
The A
RF37
allows you to establish a conference communication, using up to 6
wireless devices in a team.
Having set the conference parameters, you can use the devices, speak and
hear the other users.
Product Description
The A
RF37
devices are delivered with the following options :
Audio conference devices with a 3.7 V 1000 mA/h battery
Dimensions : 120 mm x 60 mm x 25 mm
Weight : 150 g
Battery reload : 2 hours
Battery autonomy : 8 hours
Ref. with a standard jack connector ARF7483A
Ref. with a waterproof locking connector ARF7484A
Audio conference devices with a 3.7 V 2000 mA/h battery
Dimensions : 120mm x 60mm x 30mm
Weight : 170 g
Battery reload : 3 hours
Battery autonomy : 16 hours
Ref. with a standard jack connector ARF7483B
Ref. with a waterproof locking connector ARF7484B

A
RF37 User Guide
Ref. 07-10-V3-psn p 4
Accessories
To complete the communication system, the following accessories are
available :
Standard headset kit with a Jack connector
Ref. 7
38
2-
A
–
M
Ø5
Standard headset kit with waterproof locking connector
Ref. 7
38
2-
A
–
M
Ø
4
Customized headset kit with waterproof locking connector
Ref. 7382-
A
–
M
Ø
8
Belt Ref. CEINT
U
RE 11
0
Harness Ref. 7382-A - MØ9
Armband Ref. 206105

A
RF37 User Guide
Ref. 07-10-V3-psn p 5
3.7 V 1000 mA/h battery Ref. EASYPACK 1000
3.7 V 2000 mA/h battery Ref. EASYPACK 2000
5-slot battery rack for reloading the batteries Ref.
A
RF7418A
Clip Ref. CL1-N
Case Ref. NOVA 4 AW
Push-to-talk button (only available for locking connector)
Ref. 7382-
A
-M1Ø

A
RF37 User Guide
Ref. 07-10-V3-psn p 6
Getting Started
Keyboard Description
The keyboard allows you to select the functions and their options. This is a
capacitive keyboard. It will be more efficient when pressing the button on the
sign.
The available keys are as follows :
Keys Description
Power On/Off
Key active during parameters setting
Menu
Access to the device settings menu
Option selection
In the device settings menu, the buttons allow
you to adjust the parameters.
When you are not in the device settings menu, the
buttons give you direct access to volume settings.
Validation
Allows you to validate the selected option or to
exit the device settings menu.
OK
NOTE
Each time you press a button, the device displays a *and produces a
"beep".

A
RF37 User Guide
Ref. 07-10-V3-psn p 7
Function Usage
To use a function, make sure you press the corresponding key for 2 seconds.
To turn the device on, press the ON/OFF button for 2 seconds.
To turn the device off, press the ON/OFF button for 2 seconds.
Using the Screen and Keyboard
Each device is composed of a screen which displays information and a
keyboard for entering the different settings.
Screen Description
When powered on, the screen provides you with information on :
ythe device online status,
ythe battery level,
ythe device settings.

A
RF37 User Guide
Ref. 07-10-V3-psn p 8
The screen indicators are as follows :
Y1. 2 . . . . 5 . 6
C1
01
F+
Indicators Description
System status
indicates the device in the system. The other
numbers indicate the devices online in the
conference.
A dash over the number indicates that the
listening of this device is validated.
Radio Channel (Chan. setting)
Indicates the radio channel.
Product identifier (Role setting)
Indicates the device number in the conference or
“system listener”.
Volume settings
Indicates the volume level, with 9 levels.
Battery indicator
Provides information on the battery level, with 5
levels:
•Full capacity.
•75% capacity.
•Less than 50% capacity, reload is
recommended.
•Less than 25% capacity, reload is required.
•Minimum capacity, the device cannot work.
Keypad Locked / Unlocked
Except the On/Off function
Indicates whether you are using an enhanced
filter (F+) or a regular one (F)

A
RF37 User Guide
Ref. 07-10-V3-psn p 9
Setting a Conference
To set a conference, you have to perform the following operations :
1. Assign a number to each device that will take part in the
conference.
2. Define the radio channel used for the communication.
3. Enable the devices to enter the communication.
All the parameters, including the volume settings, are stored and remain the
same if the device is switched off or the battery removed.
Assigning a Number to a Device
To set a communication, you must first identify all the devices that will take
part in the conference and assign a number to each of them.
There may be between 2 to 6 devices in a conference, with numbers 01 to
06.
Each device has a unique number that identifies it. One device must be set
with number 01.
NOTE
Avoid assigning the same identifier to several devices as this will prevent the
communication from being set.
Procedure
1. From the main screen, press for two seconds to access the
Role setting menu.
2. In Role setting, select the identifier number using +or -.

A
RF37 User Guide
Ref. 07-10-V3-psn p 10
3. Press OK to validate your choice.
4. Press to select another menu or OK to exit the Device
setting menu.
Changing the intensity of the noise filter
Depending on the noise level in the place where the products will be used,
you can choose an enhanced filter (F+) or a regular one (F).
Procedure
1. From the main screen, press for 2 seconds to access the
Device setting menu
2. Press again to access the Filter setting menu.
3. In the Filter setting menu, change the filter's intensity using
+or -.
4. Press OK to validate your choice
5. Press to select another menu or OK to exit the Device
setting menu.
Moving to a substitution channel
To communicate, the devices must be tuned into the same radio channel
which is assigned to a specific frequency. When delivered, all the devices are
already tuned on channel C1 and must be used on this channel. If, ina
specific area, you have some troubles due to jamming devices which are
working on the same frequency, you can use one of the 3 substitution
channels C2, C3 or C4.

A
RF37 User Guide
Ref. 07-10-V3-psn p 11
Procedure
1. From the main screen, press for 2 seconds to access the
Device setting menu.
2. Press twice to access the Chan. setting menu.
3. In the Chan. setting menu, select the channel using +or -.
4. Press OK to validate your choice.
5. Press to select another menu or OK to exit the Device
setting menu.
NOTE
When you stop using them, devices have to be moved back to radio channel
C1
Enabling Devices to Enter a Conference
To enable communication, devices must memorize an encryption key
provided by device 01. This operation is necessary in the following
conditions:
yTo enable all the devices to enter a conference.
yTo add a device to a conference already set.
IMPORTANT
The devices cannot communicate if this procedure, also known as the
encryption procedure, is not performed.

A
RF37 User Guide
Ref. 07-10-V3-psn p 12
Procedure
Make sure that the following requirements are met before starting the
procedure :
yAll the devices must use the same channel.
yOnly one device has the identifier 01.
Operations
on device 01
5. When the encryption
procedure has been validated on
all other devices, press OK to
end the procedure.
Operations
on the other devices
4. When a device has received
the encryption key from
device 01, it indicates encryption
**DONE**. Press OK to
validate.
1. On all the devices, press for 2 seconds to access the Device
setting menu.
2. On all the devices, press 3 times to access the encryption.
3. On all the devices, press OK to proceed
NOTE
On device 01 : To leave without saving. Press .
On the other devices : To leave without saving if the device does not
return **DONE**, press or.

A
RF37 User Guide
Ref. 07-10-V3-psn p 13
Using the Devices
Using the Listener Mode
You can use a device as a listener only. In the listener mode, the device can
only receive and hear other devices in the conference. It does not enable you
to speak.
IMPORTANT
The listener can only work if you have proceeded to the encryption.
The listener only works if at least 2 devices (01 or 04 and another) are in the
conference.
Procedure
1. Press for 2 seconds to access the Role setting screen.
2. Press +until the role proposed is “system listener.”
3. Press OK to proceed.
NOTE
To exit the Listener Mode, when you are in the Role setting menu, you first
must press –for 2 seconds 2 times sequentially
Validating or Unvalidating Other Devices Listening
For any devices (listener and other devices), you can select which devices of
the system you want to listen to. This is indicated by a small dash over the
number of the device in the main screen.
By default, the listening is validated on every device.

A
RF37 User Guide
Ref. 07-10-V3-psn p 14
Procedure
1. Press for 2 seconds to access the Role setting screen.
2. Press +until the role proposed is “system listener”.
3. Press +for 2 seconds to access the listener selection screen.
4. Press OK to enter.
5. Press +or -to select the device.
6. Press OK to update.
7. When the modifications are finished, press to exit.
Setting the Volume
To set the volume, proceed as follows :
1. Make sure you are on the main screen. Press the +or -key for 2
seconds.
2. You can hear a beep in the earflap.
3. To modify the volume level, press +or -.You can use 9 levels. A
double beep in the earflap indicates the maximum or minimum
level.
4. Press OK to validate.
Locking or Unlocking the Keypad
When you have finished configuring the device, it is recommended that the
keypad be locked.

A
RF37 User Guide
Ref. 07-10-V3-psn p 15
Procedure
1. In the main screen, press OK for 2 seconds until appears
on the screen. The keypad buttons are no longer available for use
except the On/Off button.
2. To unlock the keypad press OK for 2 seconds until the
disappears.
NOTE
The keypad is automatically locked when you switch on the device.
Reloading the Battery
You can reload the batteries before they are unloaded.
The batteries are reloaded in 3 to 4 hours.
Their autonomy is 8 to 16 hours.
CAUTION
When stored unused, the batteries keep discharging due to a small current
consumption in OFF mode. Remove the battery from the device when you
stop using it and check the battery level before re-using once again the
product.

A
RF37 User Guide
Ref. 07-10-V3-psn p 16
Troubleshooting
Frequent problems are outlined below to help you solve them.
I cannot communicate with other devices.
yCheck that all the devices have the same radio channel.
yCheck that one device is identified with number 01 or number 04.
The device cannot enter the conference.
yMake sure all the devices have been encrypted to enter the
conference - especially if you have added a device after having
started the conference.
yAvoid assigning the same number to several devices.
The device does not start.
Check that the battery is correctly inserted.
There are communication disturbances.
Another conference system may be in use close to yours. Change the radio
channel to avoid disturbances.
Make sure there is no contact between the antenna and the wire of the
headset.
I hear crackling noises.
The microphone of one of the other devices is probably damaged. Replace
it.
I can hear myself, there is an echo.
Check there is at least 10 m between the devices’ micros.
The buttons are not working properly.
yEnsure that your finger is pressing the sign on the button.
yAvoid pressing more than one button simultaneously with your
finger or hand.
