ADF Web AXIS HD67555 User manual

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
DeviceNet Master
/
P
ROFIBUS
Slave
Document code: MN67555_ENG Revision 1.00 Page 1 of 20
User Manual
Revision 1.00
English
DeviceNet Master / PROFIBUS Slave -
Converter
(Order Code: HD67555)
for Website information:
www.adfweb.com?Product=HD67555
for Price information:
www.adfweb.com?Price=HD67555
Benefits and Main Features:
Very easy to configure
Low cost
PROFIBUS Baudrate up to 12M
Wide supply input range
Isolation between two buses
Industrial temperature range:
-40°C / 85°C (-40°F / 185°F)
For others Gateways / Bridges:
CANo en to Modbus
See also the following links:
www.adfweb.com?Product=HD67001 (Modbus RTU Master)
www.adfweb.com?Product=HD67502 (Modbus RTU Slave)
www.adfweb.com?Product=HD67504 (Modbus TCP Master)
www.adfweb.com?Product=HD67505 (Modbus TCP Slave)
For others Gateways / Bridges:
For CAN bus 2.0A and/or CAN bus 2.0B to Modbus
See also the following links:
www.adfweb.com?Product=HD67011 (Modbus RTU Slave)
www.adfweb.com?Product=HD67012 (Modbus RTU Master)
www.adfweb.com?Product=HD67514 (Modbus TCP Slave)
www.adfweb.com?Product=HD67515 (Modbus TCP Master)
Do you have an your customer protocol?
See the following links:
www.adfweb.com?Product=HD6700
Do you need to choose a device? do you want help?
Ask it to the following link:
www.adfweb.com?Cmd=helpme
HD67555
Axis Solutions Pvt Ltd is the Authorized Distributor of $')ZHE in India
www.axisindia.in | [email protected]

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
DeviceNet Master
/
P
ROFIBUS
Slave
Document code: MN67555_ENG Revision 1.00 Page 2 of 20
INDEX:
Page
INDEX 2
UPDATED DOCUMENTATION 2
REVISION LIST 2
WARNING 2
TRADEMARKS 2
SECURITY ALERT
EXAMPLE OF CONNECTION 4
CONNECTION SCHEME 5
CHARACTERISTICS 6
CONFIGURATION 6
POWER SUPPLY 7
FUNCTION MODES 8
LEDS 9
PROFIBUS 10
RS2 2 10
DEVICENET 11
USE OF COMPOSITOR SW67555 12
NEW PROJECT / OPEN PROJECT 12
SET COMMUNICATION 1
DEVICENET NETWORK 14
DEFINE BYTE 15
GSD FILE 15
UPDATE DEVICE 16
MECHANICAL DIMENSIONS 18
ORDER CODE 18
ACCESSORIES 18
DISCLAIMER 19
OTHER REGULATIONS AND STANDARDS 19
WARRANTIES AND TECHNICAL SUPPORT 20
RETURN POLICY 20
PRODUCTS AND RELATED DOCUMENTS 20
Pagina 2 di 20
UPDATED DOCUMENTATION:
Dear customer, we thank you for your attention and we remind you that
you need to check that the following document is:
Updated
Related to the product you own
To obtain the most recently updated document, note the “document code”
that appears at the top right-hand corner of each page of this document.
With this “Document Code” go to web page www.adfweb.com/download/
and search for the corresponding code on the page. Click on the proper
“Document Code” and download the updates.
To obtain the updated documentation for the product that you own, note
the “Document Code” (Abbreviated written "Doc. Code" on the label on
the product) and download the updated from our web site
www.adfweb.com/download/
REVISION LIST:
Revision Date Author Cha ter Descri tion
1.000 07/07/2009 Fl All First release version
1.001 0/04/2010 Dp All Revision
1.002 15/07/2010 Ft All Revision
1.00 14/01/201 Nt & Fl All Added new chapters
WARNING:
ADFweb.com reserves the right to change information in this manual
about our product without warning.
ADFweb.com is not responsible for any error this manual may contain.
TRADEMARKS:
All trademarks mentioned in this document belong to their respective
owners.

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
DeviceNet Master
/
P
ROFIBUS
Slave
Document code: MN67555_ENG Revision 1.00 Page of 20
SECURITY ALERT:
G ENERAL I NFORMATION
To ensure safe operation, the device must be operated according to the instructions in the manual. When using the device are required for
each individual application, legal and safety regulation. The same applies also when using accessories.
I NTENDED U SE
Machines and systems must be designed so the faulty conditions do not lead to a dangerous situation for the operator (i.e. independent limit
switches, mechanical interlocks, etc.).
Q UALIFIED P ERSONNEL
The device can be used only by qualified personnel, strictly in accordance with the specifications.
Qualified personnel are persons who are familiar with the installation, assembly, commissioning and operation of this equipment and who
have appropriate qualifications for their job.
R ESIDUAL R ISKS
The device is state of the art and is safe. The instrument can represent a potential hazard if they are inappropriately installed and operated
by personnel untrained. These instructions refer to residual risks with the following symbol:
This symbol indicates that non-observance of the safety instructions is danger for people to serious injury or death and / or the
possibility of damage.
CE CONFORMITY
The declaration is made by us. You can send an email to [e-mail] or give us a call if you need it.

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
DeviceNet Master
/
P
ROFIBUS
Slave
Document code: MN67555_ENG Revision 1.00 Page 4 of 20
EXAMPLE OF CONNECTION:

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
DeviceNet Master
/
P
ROFIBUS
Slave
Document code: MN67555_ENG Revision 1.00 Page 5 of 20
CONNECTION SCHEME:
Figure 1: Connection scheme for HD67555

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
DeviceNet Master
/
P
ROFIBUS
Slave
Document code: MN67555_ENG Revision 1.00 Page 6 of 20
CHARACTERISTICS:
The Configurable DeviceNet Master / PROFIBUS Slave - Converter allows the following characteristics:
Two-directional information between network DeviceNet and PROFIBUS;
Eletrical isolation between two buses;
Up to 244 bytes in reading and 244 bytes in writing on PROFIBUS;
Power Supply 8…19V AC or 12… 5V DC;
Mountable on 5mm Rail DIN;
Temperature range -40°C to 85°C.
CONFIGURATION:
You need Compositor SW67574 software on your PC in order to perform the following:
Define the parameter of the DeviceNet;
Define the parameter of the PROFIBUS;
Define DeviceNet network;
Determinate which DeviceNet byte transfer in PROFIBUS and vice versa;
Create a GSD File;
Update the device.

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
DeviceNet Master
/
P
ROFIBUS
Slave
Document code: MN67555_ENG Revision 1.00 Page 7 of 20
POWER SUPPLY:
The devices can be powered at 8…19V AC and 8… 5V DC. The consumption depends to the code of the device. For more details see the two
tables below.
VAC
VDC
Vmin Vmax Vmin Vmax
8V 19V 8V 35V
Consumption at 24V DC:
Device Consum tion [W/VA]
HD67555 .5
HD67555
Caution: Not reverse the olarity ower

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
DeviceNet Master
/
P
ROFIBUS
Slave
Document code: MN67555_ENG Revision 1.00 Page 8 of 20
FUNCTION MODES:
The device has got two functions mode depending of the position of the ‘Dip2 of Dip-Switch A’:
The first, with ‘Dip2 of Dip-Switch A’ at “OFF” position, is used for the normal working of the device.
The second, with ‘Dip2 of Dip-Switch A’ at “ON” position, is used for upload the Project and/or Firmware.
For the operations to follow for the updating, see ‘UPDATE DEVICE’ section.
According to the functioning mode, the LEDs will have specifics functions, see ‘LEDS’ section.

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
DeviceNet Master
/
P
ROFIBUS
Slave
Document code: MN67555_ENG Revision 1.00 Page 9 of 20
LEDS:
The device has got three LEDs that are used to give information of the functioning status.
The various meanings of the LEDs are described in the table below.
LED Normal Mode Boot Mode
1: DeviceNet State
(yellow)
ON: At least one DeviceNet Slave
device defined in the Compositor
isn’t answering to the Master
OFF: All DeviceNet Slave devices
are in communication
Not used
2: Not used (green) Not used Not used
: Device State (green) Blinks slowly (~1Hz) Blinks quickly: Boot state
Blinks very slowly (~0.5Hz): update in progress

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
DeviceNet Master
/
P
ROFIBUS
Slave
Document code: MN67555_ENG Revision 1.00 Page 10 of 20
PROFIBUS:
The PROFIBUS uses a 9-pin D-SUB connector. The pin assignment is defined like in the right
figure.
Here some codes of cables:
Belden: p/n 18 079A - Continuous Armor DataBus® ISA/SP-50 PROFIBUS Cable;
RS232:
The connection from RS2 2 socket to a serial port (example one from a personal computer), must be made with a Null
Modem cable (a serial cable where the pins 2 and are crossed). It is recommended that the RS2 2C Cable not exceed
15 meters.
The serial port is used for programming the device.

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
DeviceNet Master
/
P
ROFIBUS
Slave
Document code: MN67555_ENG Revision 1.00 Page 11 of 20
DEVICENET:
For terminate the DeviceNet line with a 120Ω resistor it is necessary that the Dip1 of ‘Dip-Switch B’ is at ON position.
Cable characteristics:
DC arameter: Impedance 70 Ohm/m
AC arameters: Impedance 120 Ohm/m
Delay 5 ns/m
Length Baud Rate [b s] Length MAX [m]
125 K 500
250 K 250
500 K 100

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
DeviceNet Master
/
P
ROFIBUS
Slave
Document code: MN67555_ENG Revision 1.00 Page 12 of 20
USE OF COMPOSITOR SW67555:
To configure the Converter, use the available software that runs with
Windows, called SW67555. It is downloadable on the site
www.adfweb.com and its operation is described in this document.
(This manual is referenced to the last version of the software present
on our web site). The software works with MSWindows (MS 2000, XP,
Vista, Seven, 8; 2/64bit).
When launching the SW67555 the right window appears (Fig. 2).
NEW PROJECT / OPEN PROJECT:
The “New Project” button creates the folder which contains the entire device configuration.
A device configuration can also be imported or exported:
To clone the configurations of a programmable “DeviceNet Master / PROFIBUS Slave –
Converter” in order to configure another device in the same manner, it is necessary to
maintain the folder and all its contents;
To clone a project in order to obtain a different version of the project, it is sufficient to
duplicate the project folder with another name and open the new folder with the button
“O en Project”.
Figure 2: Main window for SW67555

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
DeviceNet Master
/
P
ROFIBUS
Slave
Document code: MN67555_ENG Revision 1.00 Page 1 of 20
SET COMMUNICATION:
This section defines the fundamental communication parameter of two buses, DeviceNet bus and
PROFIBUS.
By Pressing the “Set Communication” button from the main window for SW67555 (Fig. 2) the window
"Set Communication" appears (Fig. ).
The window is divided in two sections, one for the PROFIBUS and the other for the DeviceNet.
The means of the fields for “PROFIBUS” are:
In the field “ID Dev.” the address for the PROFIBUS side is defined;
In the field "N Byte IN" the number of byte from the slave PROFIBUS to the converter is defined (at
maximum it is possible to use 244 byte);
In the field "N Byte OUT" the number of byte from the converter to the slave PROFIBUS is defined
(at maximum it is possible to use 244 byte).
The means of the fields for “DeviceNet Master” are:
In the field “ID Dev.” the address for the DeviceNet Master is defined;
In the field “Baud Rate” the velocity of the DeviceNet bus is defined.
Figure 3: “Set Communication”
window

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
DeviceNet Master
/
P
ROFIBUS
Slave
Document code: MN67555_ENG Revision 1.00 Page 14 of 20
DEVICENET NETWORK:
By pressing the “DeviceNet Network” button from the main
window for SW67555 (Fig. 2) the window “DeviceNet Network”
appears (Fig. 4).
The data of the columns have the following meanings:
In the field “ID” the ID of a slave DeviceNet device is
defined;
In the field “N BYTE IN” the number of input byte of the
slave DeviceNet is defined;
In the field “N BYTE OUT” the number of output byte of
the slave DeviceNet is defined;
In the field “Mnemonic” is possible to insert a description. It isn’t necessary compiling this field, is only a label.
Figure 4: “DeviceNet Network” window

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
DeviceNet Master
/
P
ROFIBUS
Slave
Document code: MN67555_ENG Revision 1.00 Page 15 of 20
DEFINE BYTE:
By pressing the “Define Byte” button from the main window for SW67555
(Fig. 2) the window “FDefByte” appears (Fig. 5).
In the field “Select a Slave” it is possible to select the slave to configure
between those defined in the “DeviceNet Network” step.
The data of the column have the following meanings:
Byte IN side:
In the column “Select” it is possible to check or uncheck the desired
byte of DeviceNet wich will be updated by the PROFIBUS;
In the column “Mnemonic” is possible to insert a description. It isn’t
necessary compiling this field, is only a label.
Byte OUT side:
In the column “Select” it is possible to check or uncheck the desired
byte of DeviceNet wich will be copied in the PROFIBUS;
In the column “Mnemonic” is possible to insert a description. It isn’t
necessary compiling this field, is only a label.
GSD FILE:
By pressing the “GSD File” button it is possible to save the GSD file for the PROFIBUS side.
With this feature you can save the configuration of the gateway of the PROFIBUS side.
Note:
When you import the .gsd file on your Master PROFIBUS you have to add all the modules that are present inside it.
Figure 5: “Define Byte” window

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
DeviceNet Master
/
P
ROFIBUS
Slave
Document code: MN67555_ENG Revision 1.00 Page 16 of 20
UPDATE DEVICE:
By pressing the “U date Device” button it is possible to load the created Configuration into the device; and also the Firmware, if is
necessary.
In order to load the parameters or update the firmware in the Converter, follow these
instructions:
Turn off the Device;
Connect the Null Modem Cable form your PC to the Gateway;
Put Dip2 of Dip-Switch A at “ON” position (see “FUNCTION MODES” section);
Select the “COM ort” and press the “Connect” button;
Turn on the device;
Check the BOOT Led. It must blink quickly (see “LEDS” section);
Press the “Next” button;
Select which operations you want to do.
Press the “Execute update firmware” button to start the upload;
When all the operations are “OK” turn off the device;
Put Dip2 of Dip-Switch A at “OFF” position;
Disconnect the RS2 2 Cable;
Turn on the device.
At this point the configuration/firmware on the device is correctly update.
Figure
6
:
“
Update Device
” windows

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
DeviceNet Master
/
P
ROFIBUS
Slave
Document code: MN67555_ENG Revision 1.00 Page 17 of 20
Note:
When you install a new version of the software it is better if the first time you do the update of the Firmware in the HD67555 device.
Note:
When you receive the device, for the first time, you have to update also the Firmware in the HD67555 device.
Warning:
If the Fig. 7 appears when you try to do the Update before require assistance try these points:
Check if the serial COM port selected is the correct one;
Check if the serial is connected between the PC and the device;
Try to repeat the operations for the updating;
If you are using a dongle try with a native COM port or change the dongle;
Try with another PC;
Try to restart the PC;
If you are using the program inside a Virtual Machine, try to use in the main
Operating System;
If you are using Windows Seven or Vista or 8, make sure that you have the
administrator privileges;
Take attention at Firewall lock.
Figure 7: “ rotection” window

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
DeviceNet Master
/
P
ROFIBUS
Slave
Document code: MN67555_ENG Revision 1.00 Page 18 of 20
MECHANICAL DIMENSIONS:
ORDER CODE:
Order Code: HD67555 - DeviceNet Master / PROFIBUS Slave - Converter
ACCESSORIES:
Order Code: AC34107 - Null Modem Cable Fem/Fem DSub 9 Pin 1,5 m
Order Code: AC34114 - Null Modem Cable Fem/Fem DSub 9 Pin 5 m
Order Code: AC34001 - Rail DIN - Power Supply 220/240V AC 50/60Hz – 12 V AC
Order Code: AC34002 - Rail DIN - Power Supply 110V AC 50/60Hz – 12 V AC
Figure
8
: Mechanical dimensions scheme

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
DeviceNet Master
/
P
ROFIBUS
Slave
Document code: MN67555_ENG Revision 1.00 Page 19 of 20
DISCLAIMER
All technical content within this document can be modified without notice. The content of the document content is a recurring audit.
For losses due to fire, earthquake, third party access or other accidents, or intentional or accidental abuse, misuse, or use under abnormal
conditions repairs are charged to the user. ADFweb.com S.r.l. will not be liable for accidental loss of use or inability to use this product, such
as loss of business income. ADFweb.com S.r.l. shall not be liable for consequences of improper use.
OTHER REGULATIONS AND STANDARDS
WEEE INFORMATION
Disposal of old electrical and electronic equipment (as in the European Union and other European countries with separate
collection systems).
This symbol on the product or on its packaging indicates that this product may not be treated as household rubbish. Instead, it
should be taken to an applicable collection point for the recycling of electrical and electronic equipment. If the product is disposed
correctly, you will help prevent potential negative environmental factors and human health, which could otherwise be caused by
inappropriate disposal. The recycling of materials will help to conserve natural resources. For more information about recycling this
product, please contact your local city office, your household waste disposal service or the shop where you purchased the product.
R ESTRICTION OF H AZARDOUS S UBSTANCES DIRECTIVE
The device respects the 2002/95/EC Directive on the restriction of the use of certain hazardous substances in electrical
and electronic equipment (commonly referred to as Restriction of Hazardous Substances Directive or RoHS).
CE MARKING
The product conforms with the essential requirements of the applicable EC directives.

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
DeviceNet Master
/
P
ROFIBUS
Slave
Document code: MN67555_ENG Revision 1.00 Page 20 of 20
WARRANTIES AND TECHNICAL SUPPORT:
For fast and easy technical support for your ADFweb.com SRL products, consult our internet support at www.adfweb.com.
Otherwise contact us at the address [e-mail]
RETURN POLICY:
If while using your product you have any problem and you wish to exchange or repair it, please do the following:
1) Obtain a Product Return Number (PRN) from our internet support at www.adfweb.com. Together with the request, you need to
provide detailed information about the problem.
2) Send the product to the address provided with the PRN, having prepaid the shipping costs (shipment costs billed to us will not be
accepted).
If the product is within the warranty of twelve months, it will be repaired or exchanged and returned within three weeks. If the product is no
longer under warranty, you will receive a repair estimate.
PRODUCTS AND RELATED DOCUMENTS:
Part Descri tion URL
HD67121 Gateway CANopen / Canopen www.adfweb.com?product=HD67121
HD67502 Gateway CANopen / Modbus - RTU www.adfweb.com?product=HD67502
HD67505 Gateway CANopen / Modbus – Ethernet TCP www.adfweb.com?product=HD67505
HD671 4 Gateway CANopen / DeviceNet www.adfweb.com?product=HD671 4
HD67117 CAN bus Repeater www.adfweb.com?product=HD67117
HD67216 CAN bus Analyzer www.adfweb.com?product=HD67216
Axis Solutions Pvt Ltd is the Authorized Distributor of $')ZHE in India
www.axisindia.in | [email protected]
