ADIRmed ADI997-01-HD Series User manual

Bariatric Padded Blood
ADI997-01-HD-SERIES
USER GUIDE
Drawing Chair

Thank you
for your
purchase.
AdirMed maintains a strong practice
of ongoing development of products
and commercial research.
We recognize that starting and maintaining a medical practice
is expensive. We’ll help make the process cost-eective and
elegant. Additionally, our team of specialists will ensure
everything you need works as eciently as possible, so youcan
eectively treat your clients.

Table of Contents
1Parts List
2Hardware List
3Assembly Instructions
10 Notes
12 Limited Warranty
13 Disclaimer

1
Parts List
A
D
G
J
B
E
H
K L
C
F
I
Leg (x2)
Seat Support
Backrest
Front Flip Armrest (x2)
Center H Support
Backing Rails(x2)
Left Arm Rest
Footrest
Seat Cushion
Adjustment Knob (x4)
Right Arm Rest Seat Support Bar

2
Hardware List
2
Large Screw (x 12)
1
Medium Screw (x4)
3
Small Screw (x 12)

3
Assembly Instructions
Note:
When assembling the chair, do not over-tighten the screws.
Finish the whole assembly and then tighten rmly.
Step 1:
A. Locate both Legs (A) and the Center H Support (B).
A
B
A

4
Step 2:
A. Attach both Legs (A) to the Center H Support (B) using eight
Small Screws (3).
A
B
A
Step 3:
A. Locate the Footrest (C), and place it between both Legs (A),
as pictured.
B. Secure it into place with two Large Screws (2).
B
C
A

5
Step 4:
A. Locate and place the Seat Support (D) between both Legs
(A), as pictured.
B. Secure into place with four Small Screws (3).
B
A
D

6
Step 5:
A. Locate both Backing Rails (E) and the Seat Cushion (F).
B. Attach both Backing Rails (E) to the Seat Cushion (F) with
four Medium Screws (1).
Step 6:
A. Locate and attach the Backrest (G) with four Large Screws
(2), as pictured.
F
E
E
G

7
Step 7:
A. Locate the Seat Support Bar (L), line it up with the holes on
the bottom of the chair.
B. Attached the constructed seat with the Seat Support Bar
(L) to the assembled base,as pictured.
C. Insert 6 Large Screws (2) through the Center H Support (B)
and into the seat.
D. Tighten the screws until secure.
Step 8:
A. Locate the Left Arm Rest (H) and the Right Arm Rest (K),
insert it into the left and right pole.
H
K
L

8
Step 9:
A. Insert two Adjustment Knob’s (I) into the left and right pole,
as pictured.
Step 10:
A. Locate and insert both Front Flip Arm Rest’s (J) into the Left
Arm Rest (H) and Right Arm Rest (K).
B. Insert the two remaining Adjustment Knobs (I), as pictured.
I
J
K
H
I

9
Step 11:
A. Ensure all your screws are tightened and secure.
B. Your Blood Drawing Chair is now ready to be used.

10
Notes

11
Notes

12
Limited Warranty
1. AdirCorp (the company) warrants to the purchaser that the product will be free
from defects in workmanship and materials for a period of two (2) years from
the date of purchase.
2. These warranties are not assignable or transferable to any other person.
3. Any damage to the product as a result of misuse, tampering, abuse, neglect,
accident, improper installation, modification, unauthorized service, destruction,
or the alteration of the serial number, or use violate of the instructions furnished
by the Company will void this warranty.
4. The sole responsibility of the Company shall be limited to the repair or replace-
ment (in its sole discretion) of any component of the product which fails to con-
form to this warranty at no cost to the purchaser for the period of the warranty.
5. Contact the Company directly to obtain service under this warranty. If it
becomes applicable to send a defective product to the Company, a Return Au-
thorization Number must first be obtained from the company. To obtain service
under this warranty, purchaser must provide the Company with the following
items (a) proof of purchase, (b) police or fire department report, (c)
photographs of damaged sad, and (d) written testimonial.
6. Products shipped without prior Return Authorization and Return Authorization
Number may not be accepted, and the Company will not be responsible for
their disposition and/or cost of return to the owner.
7. The Company will not assume any responsibility for any loss or damage
incurred in shipping. All return authorized products should include a copy of the
original invoice in order that this warranty may be Honored.
8. This warranty is not an insurance policy. The Company is not responsible for
any manner of damage to or theft of the Purchaser’s product or it’s contents
9. We recommend that the product being returned is accompanied by the sales
receipt with all relevant information regarding the purchase of the item and is
returned to the Company within ten (10) days of the claim date of purchase to
validate this warranty.
10. Any implied warranties that the purchaser may have are limited to the duration
of the warranties described above. There are no further warranties that extend
or apply beyond the face hereof, and the company expressly disclaims and
excludes any and all warranties of merchantability or fitness for a particular
purpose. Some states do not allow limitations on how long an implied warranty
lasts, so the above limitation may not apply to you.
11. Repair or replacement shall be the sole remedy for the purchaser under this
warranty. The company shall not be liable for any direct, indirect, incidental or
consequential damages, losses or expense arising from the use or misuse of
the product. Some states do not allow the exclusion or limitations of incidental
or consequential damages, so the limitation may not apply to you.
12. This warranty gives you specific legal rights, and you may also have other rights
which vary from state to state.
