ADJ ELEMENT Series User manual

ELEMENT HEXIP
ELEMENT HEXIP CHROME
User Instructions

2
©2023 ADJ Products, LLC all rights reserved. Information, specications, diagrams, images, and instructions herein
are subject to change without notice. ADJ Products, LLC logo and identifying product names and numbers herein are
trademarks of ADJ Products, LLC. Copyright protection claimed includes all forms and matters of copyrightable materials
and information now allowed by statutory or judicial law or hereinafter granted. Product names used in this document may
be trademarks or registered trademarks of their respective companies and are hereby acknowledged. All non-ADJ Products,
LLC brands and product names are trademarks or registered trademarks of their respective companies.
ADJ Products, LLC and all afliated companies hereby disclaim any and all liabilities for property, equipment, building, and
electrical damages, injuries to any persons, and direct or indirect economic loss associated with the use or reliance of any
information contained within this document, and/or as a result of the improper, unsafe, insufcient and negligent assembly,
installation, rigging, and operation of this product.
ADJ PRODUCTS LLC World Headquarters
6122 S. Eastern Ave. | Los Angeles, CA 90040 USA
Tel: [phone] | Fax: [phone] | www.adj.com |[email protected]
ADJ Supply Europe B.V.
Junostraat 2 | 6468 EW Kerkrade | Netherlands
Tel: [phone] | Fax: [phone] | www.americandj.eu | [email protected]
RISK GROUP 3 - RISK OF EXPOSURE TO ULTRAVIOLET (UV) RADIATION!
FIXTURE EMITS HIGH INTENSITY WAVEVLENGTH OF ULTRAVIOLET LIGHT.
WEAR PROPER EYE AND SKIN PROTECTION.
DO NOT OPERATE FIXTURE WITH DAMAGED/MISSING EXTERNAL COVER OR
PROTECTIVE LENS.
DO NOT LOOK DIRECTLY INTO THE (UV) LIGHT AND/OR VIEW (UV) LIGHT
DIRECTLY WITH OPTICAL INSTRUMENTS THAT MAY CONCENTRATE THE
LIGHT/RADIATION OUTPUT.
AVOID PROLONGED PERIODS OF EXPOSURE.
AVOID WEARING WHITE COLOR CLOTHING AND/OR USING (UV) PAINTS ON
SKIN.
AVOID DIRECT EYE AND/OR SKIN EXPOSURE AT DISTANCES SHORTER THAN
11 FEET (3.3 METERS).
INDIVIDUALS SUFFERING FROM A RANGE OF EYE CONDITIONS, SUNLIGHT EXPOSURE DISORDERS, OR
INDIVIDUALS USING PHOTOSENSITIVE MEDICATION MAY EXPERIENCE DISCOMFORT IF EXPOSED TO THE
ULTRAVIOLET (UV) LIGHT EMTTED FROM THIS FIXTURE.
Europe Energy Saving Notice
Energy Saving Matters (EuP 2009/125/EC)
Saving electric energy is a key to help protecting the environment. Please turn off all electrical products when they are not in
use. To avoid power consumption in idle mode, disconnect all electrical equipment from power when not in use. Thank you!
DOCUMENT VERSION
Due to additional product features and/or enhancements, an updated version of this
document may be available online.
Please check www.adj.com for the latest revision/update of this manual before
beginning installation and/or programming.
Date Document
Version
Software
Version DMX Channels Notes
09/11/17 1.2 1.01 6/7/8/11/12 ETL Version
11/07/18 1.4 1.06 No Change Display Lock
Remote Functions Updated
12/09/20 1.6 1.08 No Change Changed nomenclature in System Menu
06/12/23 1.8 N/C No Change Update format and remove Airstream

3
General Information 4
IP54 Rated 5
Key Features | Warranty Returns 6
Limited Warranty (USA Only) 7
Safety Guidelines 8
Overview 10
Wireless Setup 11
UC IR Remote | Controls 12
Installation 13
Battery
Handling Guidelines
Battery Status and Recharging
Replacement
17
17
18
19
System Menu 21
Primary-Secondary Setup 27
DMX Setup | DMX Addressing 28
DMX Traits 29
IR Default Values | Editing RGBA IR Button Values 32
Color Macros 33
White Color Temperature Presets 34
Dimmer Curves and Dimmer Modes 35
Cleaning & Maintenance 36
Torque Settings for Screws 37
Specifications 38
CONTENTS

4
GENERAL INFORMATION
INTRODUCTION
Please read and understand the instructions in this manual carefully and thoroughly before attempting
to operate this device. These instructions contain important safety and use information.
This product is intended for use by professionally trained personnel only, and is not suitable for
private use.
UNPACKING
Every device has been thoroughly tested and has been shipped in perfect operating condition. Carefully
check the shipping carton for damage that may have occurred during shipping. If the carton is damaged,
carefully inspect the device for damage, and be sure all accessories necessary to install and operate
the device have arrived intact. In the event damage has been found or parts are missing, please contact
our customer support team for further instructions. Please do not return this device to your dealer
without rst contacting customer support. Please do not discard the shipping carton in the trash. Please
recycle whenever possible.
INCLUDED ITEMS:
• Charging base (x1)
• Power adapter (x1)
• UC-IR24 remote (x1)
CUSTOMER SUPPORT
Contact ADJ Service for any product related service and support needs.
Also visit forums.adj.com with questions, comments or suggestions.
ADJ SERVICE USA - Monday - Friday 8:00am to 4:30pm PST
323-582-2650 | Fax: [phone] | [email protected]
ADJ SERVICE EUROPE - Monday - Friday 08:30 to 17:00 CET
[phone] | Fax: [phone] | [email protected]
REPLACEMENT PARTS please visit parts.adj.com
IMPORTANT NOTICE!
THERE ARE NO USER SERVICEABLE PARTS INSIDE THIS UNIT.
DO NOT ATTEMPT ANY REPAIRS YOURSELF; DOING SO WILL VOID YOUR MANUFACTURER’S
WARRANTY. DAMAGES RESULTING FROM MODIFICATIONS TO THIS FIXTURE AND/OR THE
DISREGARD OF SAFETY INSTRUCTIONS AND GUIDELINES IN THIS MANUAL VOID THE
MANUFACTURER’S WARRANTY AND ARE NOT SUBJECT TO WARRANTY CLAIMS AND/OR REPAIRS.
It is strongly recommended to power the xture down completely when not in use. Doing so will
reduce wear on the xture due to sustained or extended operational periods, thereby maximizing
its operational lifespan.

5
IP54 RATED
IP54 RATED NON-PERMANENT TEMPORARY USE OUTDOOR WET LOCATIONS
An IP54 rated lighting xture is designed with an enclosure that effectively protects ingress
(entry) of external foreign objects and water. The International Protection (IP) rating
system is commonly expressed as “IP” (Ingress Protection) followed by two numbers (i.e.
IP54) where the numbers dene the degree of protection. The rst digit (Foreign Bodies
Protection) indicates the extent of protection against particles entering the xture, and the second digit
(Water Protection) indicates the extent of protection against water entering the xture. An IP54 rated
lighting xture is designed to protect against harmful deposits of dust, (the ingress of dust is NOT totally
prevented, but cannot enter in an amount sufcient to interfere with satisfactory operation of the xture)
(5), and water splashed against the xture from any direction (4), and is intended for temporary (short-
term), non-continuous use locations.
**IP54 RATING NOTICE***
TO MAINTAIN THE IP54 RATING INTEGRITY, THE CONTROL PANEL ACCESS DOOR ON
THE FIXTURE MUST REMAIN COMPLETELY CLOSED AT ALL TIMES TO PREVENT WATER
DAMAGE AND/OR ELECTRICAL SHOCK!
IP54

6
KEY FEATURES
• Battery power
• RGBAW+UV 6-in-1 LEDs
• IP54 rating
• Indoor or outdoor usage
INCLUDED ITEMS:
• Charging base (x1)
• Power adapter (x1)
• UC-IR24 remote (x1)
WARRANTY REGISTRATION
Please fill out the enclosed warranty card to validate your purchase. All returned service items,
whether under warranty or not, must be freight pre-paid and accompanied by a return authorization
(R.A.) number. The R.A. number must be clearly written on the outside of the return package. A brief
description of the problem as well as the R.A. number must also be written down on a piece of paper
included in the shipping carton. If the unit is under warranty, you must provide a copy of your proof of
purchase invoice. You may obtain an R.A. number by contacting our customer support team on our
customer support number. All packages returned to the service department not displaying an R.A.
number on the outside of the package will be returned to the shipper.

7
LIMITED WARRANTY (USA ONLY)
A. ADJ Products, LLC hereby warrants, to the original purchaser, ADJ Products, LLC products to be free of manufacturing
defects in material and workmanship for a prescribed period from the date of purchase (see specic warranty period
on reverse). This warranty shall be valid only if the product is purchased within the United States of America, including
possessions and territories. It is the owner’s responsibility to establish the date and place of purchase by acceptable
evidence, at the time service is sought.
B. For warranty service, you must obtain a Return Authorization number (RA#) before sending back the product-please
contact ADJ Products, LLC Service Department at 800-322-6337. Send the product only to the ADJ Products, LLC
factory. All shipping charges must be pre-paid. If the requested repairs or service (including parts replacement) are
within the terms of this warranty, ADJ Products, LLC will pay return shipping charges only to a designated point within
the United States. If the entire instrument is sent, it must be shipped in its original package. No accessories should be
shipped with the product. If any accessories are shipped with the product, ADJ Products, LLC shall have no liability
whatsoever for loss of or damage to any such accessories, or for the safe return thereof.
C. This warranty is void of the serial number has been altered or removed; if the product is modied in any manner which
ADJ Products, LLC concludes, after inspection, affects the reliability of the product, if the product has been repaired or
service by anyone other than ADJ Products, LLC factory unless prior written authorization was issued to purchaser by
ADJ Products, LLC; if the product is damaged because not properly maintained as set forth in the instruction manual.
D. This is not a service contact, and this warranty does not include maintenance, cleaning or periodic check up. During
the period specied above, ADJ Products, LLC will replace defective parts at its expense with new or refurbished parts,
and will absorb all expenses for warrant service and repair labor by reason of defects in material or workmanship. The
sole responsibility of ADJ Products, LLC under this warranty shall be limited to the repair of the product, or replacement
thereof, including parts, at the sole discretion of ADJ Products, LLC. All products covered by this warranty were
manufactured after August 15, 2012, and bear identifying marks to that effect.
E. ADJ Products, LLC reserves the right to make changes in design and/or improvements upon its products without any
obligation to include these changes in any products theretofore manufactured.
F. No warranty, whether expressed or implied, is given or made with respect to any accessory supplied with products
described above. Except to the extent prohibited by applicable law, all implied warranties made by ADJ Products, LLC
in connection with this product, including warranties of merchantability or tness, are limited in duration to the warranty
period set forth above. And no warranties, whether expressed or implied, including warranties of merchantability or
tness, shall apply to this product after said period has expired. The consumer’s and/or Dealer’s sole remedy shall be
such repair or replacement as is expressly provided above; and under no circumstances shall ADJ Products, LLC be
liable for any loss or damage, direct or consequential, arising out of the use of, or inability to use, this product.
G. This warranty is the only written warranty applicable to ADJ Products, LLC Products and supersedes all prior warranties
and written descriptions of warranty terms and conditions heretofore published.
LIMITED WARRANTY PERIODS
• Non L.E.D. Lighting Products = 1-year (365 days) Limited Warranty (Such as: Special Effect Lighting, Intelligent
Lighting, UV lighting, Strobes, Fog Machines, Bubble Machines, Mirror Balls, Par Cans, Trussing, Lighting Stands etc.
excluding LED and lamps)
• Laser Products = 1 Year (365 Days) Limited Warranty (excludes laser diodes which have 6 month limited warranty)
• L.E.D. Products = 2-year (730 days) Limited Warranty (excluding batteries which have a 180 day limited warranty)
Note: 2 Year Warranty only applies to purchases within the United States.
• StarTec Series = 1 Year Limited Warranty (excluding batteries which have a 180 day limited warranty)
• ADJ DMX Controllers = 2 Year (730 Days) Limited Warranty

8
SAFETY GUIDELINES
For Your Own Personal Safety, Please Read and Understand This Manual Completely Before
You Attempt To Install Or Operate This Unit!
This xture is a sophisticated piece of electronic equipment. To guarantee smooth operation, it is
important to follow all instructions and guidelines in this manual. ADJ Products, LLC is not responsible
for injury and/or damages resulting from the misuse of this xture due to the disregard of the information
printed in this manual. Only qualied and/or certied personnel should perform installation of this
xture, and only the original rigging parts included with this xture should be used for installation. Any
modications to the xture and/or the included mounting hardware will void the original manufacturer’s
warranty and increase the risk of damage and/or personal injury.
PROTECTION CLASS 1 - FIXTURE MUST BE PROPERLY GROUNDED
THERE ARE NO USER SERVICEABLE PARTS INSIDE THIS UNIT.
DO NOT ATTEMPT ANY REPAIRS YOURSELF; DOING SO WILL VOID
YOUR MANUFACTURER’S WARRANTY. DAMAGES RESULTING
FROM MODIFICATIONS TO THIS FIXTURE AND/OR THE DISREGARD
OF SAFETY INSTRUCTIONS AND GUIDELINES IN THIS MANUAL
VOID THE MANUFACTURER’S WARRANTY AND ARE NOT SUBJECT
TO ANY WARRANTY CLAIMS AND/OR REPAIRS.
DO NOT PLUG FIXTURE INTO A DIMMER PACK!
NEVER OPEN THIS FIXTURE WHILE IN USE!
UNPLUG POWER BEFORE SERVICING FIXTURE!
MAXIMUM AMBIENT OPERATING TMEPERATURE IS 104°F (40°C)!
NEVER TOUCH FIXTURE WITH BARE HANDS DURING OPERATION, AS SURFACE
TEMPERATURE DURING OPERATION MAY REACH 167°F (75°C)!
KEEP FLAMMABLE MATERIALS AWAY FROM FIXTURE!
NEVER LOOK DIRECTLY INTO THE LIGHT SOURCE!
RETINA INJURY RISK - MAY INDUCE BLINDNESS!
SENSITIVE PERSONS MAY SUFFER AN EPILEPTIC SHOCK!
APPLIES TO LIGHTING FIXTURE ONLY! CHARGING COMPONENTS ARE NOT IP
RATED AT ALL!
INGRESS OF DUST INTO FIXTURE IS NOT ENTIRELY PREVENTED, BUT WILL NOT
ENTER IN SUFFICIENT QUANTITY TO INTERFERE WITH OPERATION OF DEVICE.
FIXTURE PROTECTED AGAINST WATER SPLASHES FROM ANY DIRECTION.
IP54

9
SAFETY GUIDELINES
• RISK GROUP 3 - RISK OF EXPOSURE TO ULTRAVIOLET (UV)
RADIATION!
• FIXTURE EMITS HIGH INTENSITY WAVELENGTH OF
ULTRAVIOLET LIGHT.
• WEAR PROPER EYE AND SKIN PROTECTION.
• DO NOT OPERATE FIXTURE WITH DAMAGED/MISSING
EXTERNAL COVER OR PROTECTIVE LENS.
• DO NOT LOOK DIRECTLY INTO THE (UV) LIGHT AND/OR VIEW
(UV) LIGHT DIRECTLY WITH OPTICAL INSTRUMENTS THAT
MAY CONCENTRATE THE LIGHT/RADIATION OUTPUT.
• AVOID PROLONGED PERIODS OF EXPOSURE.
• AVOID WEARING WHITE COLOR CLOTHING AND/OR USING
(UV) PAINTS ON SKIN.
• AVOID DIRECT EYE AND/OR SKIN EXPOSURE AT DISTANCES SHORTER THAN 11 FEET (3.3 METERS).
• INDIVIDUALS SUFFERING FROMARANGE OF EYE CONDITIONS, SUNLIGHT EXPOSURE DISORDERS,
OR INDIVIDUALS USING PHOTOSENSITIVE MEDICATION MAY EXPERIENCE DISCOMFORT IF
EXPOSED TO THE ULTRAVIOLET (UV) LIGHT EMITTED FROM THIS FIXTURE.
• Be sure to save the packing carton in the unlikely event the device has to be returned for service.
• Do not spill water or other liquids into or on to the xture, charging system, or IR remote.
• Be sure that the voltage of the power source matches the required voltage for the device.
• Do not open up the device for any reason. There are no user serviceable parts inside.
• Disconnect the device’s main power when left unused for long periods of time.
• Never connect this device to a dimmer pack.
• Do not attempt to operate this device if it has been damaged in any way.
• Never operate this device with the cover removed.
• To reduce the risk of electrical shock or re, do not expose the charging system, IR remote, or xture to rain
or moisture.
• Do not attempt to operate this device if the power cord has been frayed or broken.
• Do not attempt to remove or break off the ground prong from the electrical cord. This prong is used to reduce
the risk of electrical shock and re in the event of an internal short.
• Disconnect from main power before making any type of connection.
• Never block the ventilation holes. Always be sure to mount this device in an area that will allow proper
ventilation. Allow about 6” (15cm) between this device and a wall.
• The charging system and xture are intended for indoor use only. Use of these devices outdoors voids all
warranties.
• Always mount this unit in a safe and stable matter.
• Please route your power cord out of the way of foot trafc. Power cords should be routed so they are not
likely to be walked on, or pinched by items placed upon or against them.
Maximum operating temperature for this xture is 113 degrees F (45 degrees C). Do not operate this
device when ambient temperature exceeds this value!
Keep ammable materials away from this xture!
CHARGING DEVICES AND FIXTURE ARE DESIGNED FOR INDOOR USE ONLY! DO NOT EXPOSE TO
RAIN OR MOISTURE!
The device should be serviced by qualified service personnel when:
A. The power-supply cord or the plug has been damaged.
B. Objects have fallen on, or liquid has been spilled into, the device.
C. The charging devices or fixture have been exposed to rain or water.
D. The appliance does not appear to operate normally or exhibits a marked change in performance.

10
MODE SETUP UP DOWN
POWER IN-AC 100-240V, 50/60Hz
Fuse: T2A 250V
ON
I
O
OFF
Battery On/Off Switch
Mode, Setup, Up,
& Down Buttons
Display Screen
Kickstand
OVERVIEW
Battery On/Off Switch: This switch is used to turn ON battery power and also turn ON the PCB output.
See page 22 “Load Setting” to activate.
Kickstand: This kickstand is used to angle the unit to various degrees. There are 3 different degree
levels. Note: Be very cautious at the degree in which you angle the unit at, due to the fact that it could
fall over.
Power Input & Fuse Holder: This input is used to connect the included I.E.C. power cord. After
connecting the power cord, plug the other end into a matching power source. Located inside the power
socket is the fuse housing. See page 35 for fuse replacement.
Mode Button: This button lets you scroll through the system menu. Setup Button: This button lets you
access the submenus.
Up & Down Button: These button’s are used to scroll through submenus and make adjustments in the
submenu’s.
Digital Display: This will display the various menus, submenus, and adjustments.
Control Panel Access Door: Lifting this door will allow you to access the controls and functions.
Power Input &
Fuse Holder
Control Panel
Access Door

11
WIRELESS SETUP
This device does not feature physical DMX connector ports. Therefore, in order to utilize DMX
control, the user must rst setup the device to run wireless DMX control. Follow the directions
below to congure wireless DMX control:
1. First, select the DMX Channel Mode that you would like the device to operate in. Press MODE until
the the “DMX Settings” menu is displayed on the screen. Use the UP or DOWN buttons to scroll to
“DMX Channel Mode,” then press the SETUP button.
2. Use UP or DOWN to scroll through the DMX Channel Mode options, then press SETUP to con-rm
your selection.
3. Next, enable the device’s Wireless capability. Press MODE until the “Personality” menu is displayed
on the screen, then use UP or DOWN to scroll to “Wireless Settings” and press SETUP.
4. Use UP or DOWN to scroll to “Enable Wireless,” then press SETUP to select this option.
5. Use UP or DOWN once again to toggle this setting to “Yes,” then conrm by pressing SETUP.
6. Next, select the Wireless channel. Press MODE until the “Personality” menu is displayed on the
screen again, then use UP or DOWN to scroll to “Wireless Settings” and press SETUP.
7. Use UP or DOWN to scroll to “Set Wireless Channel,” then press SETUP again.
8. Now use UP or DOWN to scroll to your desired Wireless channel. Selectable values range from 00
to 14.
9. Finally, set the DMX address. Press the MODE button until the “DMX Settings” menu is displayed
on the screen, then use UP or DOWN to scroll to “DMX Address,” then press SETUP.
10. Use the UP or DOWN buttons to scroll to your desired DMX address, then press SETUP to conrm
your selection. Available values range from 001 to 512. Refer to the DMX Addressing section of this
manual for detailed guidance. Repeat these steps for each individual unit that you wish to use.
There are many factors that can affect and/or interrupt a wireless signal, including walls, glass, metal,
objects, and people. Therefore, the following guidelines are recommended in order to maximize the
chances of having a clear path for the wireless signal to reach the device:
• Install the device a minimum of 9.8 ft (3m) above audiences and/or ground level.
• Arrange the wireless antenna in an upright, vertical position.
• Position devices in direct line of sight of the transmitting controller.
Careful planning and testing of the selected installation location is critical to ensure optimum and
reliable wireless operation.
9.8 ft (3m)
Above Ground

12
UC IR REMOTE CONTROL
The UC IR (sold separately) infrared remote gives you control of various functions (See below). To
control the xture you must aim the remote at the front of the xture and be no more than 30 feet away.
To use the ADJ UC IR you must rst activate the xtures infrared sensor, to activate the sensor please
see the instructions on page #.
CONTROLS
STAND BY - Pressing this button will blackout the xture. Press the button again to return to the initial
state.
FULL ON - Press this button to fully light up the unit.
FADE/GOBO - This button can activate color change mode, color fade mode, or combination color
change and fade mode. Each press of the button will switch through the 3 different modes. Use the
numeral buttons 1-9 to select the program number within your desired mode. Use the dimmer buttons
to adjust the output intensity. Note: Running speed is not adjustable using the IR control functions.
Example: In color change mode (AJXX), press the numeral buttons “1+3”
to run color change program “13”. In color fade mode (AFXX), press the
numeral button “7” to run color fade program “7”. Note: Color change and
fade combination mode has only one program.
“DIMMER +” and “DIMMER -” - Use these buttons to adjust the output
intensity in operating mode.
STROBE - Press this button to activate strobing. Use buttons 1-4 to adjust
the strobe speed. “1” being the slowest, “4” being the fastest.
COLOR - Press this button to activate color macro mode. Use the numeral
buttons 1-9 to select your desired color. Use the dimmer buttons to adjust
the output intensity.
Numeral Buttons 1-9 - Use buttons 1-9 to select your desired color in static
color mode, or your desired program in color fade mode and color change
mode. In static color mode, color fade mode, or color change mode, press
the corresponding numeral buttons to select your desired color or program.
SOUND ON & OFF - Use the buttons to activate and deactivate sound active mode.
SHOW 0 - Press this button along with any single numeral button to access a static color, or program
within color change mode and color fade mode.

13
INSTALLATION
IP RATING
The Element HEXIP is IP54 rated. Ingress of dust is not entirely prevented, but it will not enter in sufcient
quantity to interfere with satisfactory operation of the device. The Element HEXIP is also protected
against splashing water from any direction. WHILE SOME DEGREE OF WATER RESISTANCE IS
PRESENT, THE ELEMENT HEXIP FIXTURE IS NOT INTENDED FOR OUTDOOR USE. Please note
that the charging components are not IP-rated at all, and are intended for use in dry, indoor
conditions only.
FLAMMABLE MATERIAL WARNING!
Keep device a minimum of 5.0 feet (1.5m) away from ammable material and/or pyrotechnics.
ELECTRICAL CONNECTIONS
A qualied electrician should be used for all electrical connections and/or installations.
DO NOT INSTALL THE DEVICE IF YOU ARE NOT QUALIFIED TO DO SO!
The unit MUST be installed following all local, national, and country commercial electrical and
construction codes and regulations.
Before installing or mounting any device, a professional equipment installer MUST be consulted to
determine whether the mounting structure or surface is properly certied to safely support the combined
weight of the xture, clamps, cables, and accessories.
Maximum operating temperature 113 degrees F (45 degrees C). Do not operate the device if ambient
temperatures exceeds this value.
This xture should be installed away from walking paths, seating areas, and areas where unauthorized
personnel might be able to reach the device by hand.
NEVER stand directly below the xture when rigging, removing, or servicing.
Allow approximately 15 minutes for the xture to cool down before servicing.

14
INSTALLATION
CLAMP INSTALLATION
The Element HEXIP features a mounting clamp attachment point on the side of the device, as well
as an eyelet for safety cable at the bottom of one foot (see the illustration below). When mounting
the fixture to a truss or any other suspended or overhead installation, be sure to secure appropriately
rated clamps (not included) to the clamp attachment point, as well as an appropriately rated safety
clamp.
MOUNTING CLAMP
ATTACHMENT
SAFETY CABLE
EYELET
RIGGING
Overhead rigging requires extensive experience, including but not limited to: calculating working load
limits, understanding the installation material being used, and periodic safety inspection of all installa-
tion material and the fixture itself. If you lack these qualifications, do not attempt to perform the instal-
lation yourself. Improper installation can result in bodily injury.
SAFETY CABLE:
ALWAYS ATTACH A SAFETY CABLE WHENEVER INSTALLING THIS FIX-
TURE IN A SUSPENDED ENVIRONMENT TO ENSURE THAT THE FIXTURE
WILL NOT FALL IF THE CLAMP FAILS.

15
INSTALLATION
KICKSTAND FOR FLOOR PLACEMENT
The Element HEXIP can also be placed on the floor to provide an uplighting display, and features a
retractable kickstand that allows the device to be angled in the direction of the desired display.
To deploy the kickstand, simply toggle the switch on the underside of the device, near the power
charging port (1). The kickstand can then be deployed from the underside (2) at various notched
increments, allowing a maximum angle of 65-90 degrees from the vertical axis (3).
angle range
65°--90°
1 2
3
Angle Range:
65 deg to 90 deg

16
INSTALLATION
KENSINGTON KEY SLOT
The device features a slot for a Kensington-type security device that can be used to prevent theft.
The key slot is located near the bottom of one of the device’s feet, as shown in the illustration below.
Be sure to attach the security device to a sturdy, fixed anchor point.
KENSINGTON
KEY SLOT

17
BATTERY: HANDLING GUIDELINES
Avoid short-circuiting the battery. A short circuit can generate high current, causing the battery to
overheat. This can lead to leakage of electrolyte gel, emission of harmful fumes, or even explosion.
Treat your battery carefully to prevent such issues.
Handle the battery gently to prevent mechanical shock. Actions such as dropping, hitting, or
bending can result in failure or a significantly reduced lifespan of the battery.
Never attempt to disassemble the batteries. This can cause an internal short circuit, which might
result in fire, explosion, or release of harmful fumes. If the electrolyte gel contacts skin or eyes,
immediately rinse the area with fresh water and seek medical attention.
Keep the battery away from heat or fire. Never try to burn or dispose of batteries in fire as this
could lead to an explosion.
Avoid exposing the battery to water or other liquids. Submerging or soaking batteries in any type
of liquid, such as water, seawater, or beverages, is not advised.
For battery replacement, please contact customer support. They are equipped to safely handle
and replace the battery.
Do not use a battery if it shows signs of damage. This can occur during shipping or due to rough
handling. Signs of damage include deformations, unusual odors, or leakage of electrolyte gel. If such
issues are observed, do not use the battery, and keep it away from fire.
Store the battery properly. It should be kept at room temperature and maintained at a charge of at
least 50%. For extended storage, charge the battery every six months to ensure it does not fall below
the 30% charge mark, prolonging its lifespan.
Batteries are chemical devices, and their performance will degrade over time. This is true
even if they are stored without being used. To maximize the life expectancy of your battery, ensure
it is charged properly and kept at the appropriate temperature. If the battery is unable to maintain a
charge for extended periods of time, it may be time to replace it.
Dispose of the battery in accordance with local regulations. Improper disposal can be harmful to
the environment.
In summary, treating your battery with care, keeping it properly charged, and replacing it when
necessary, can help ensure the safety and longevity of your device.

18
BATTERY: BATTERY STATUS AND RECHARGING
Your device comes with a feature that helps you monitor the battery’s condition. To check the life of
the battery, plug in the fixture and press the ‘MODE’ button. Continue pressing until you see a display
that looks like “bXXX.” Here, ‘XXX’ represents the remaining battery life. If you see “b---” instead, it
means your device is currently running on AC power.
Remember, it is not good for the battery to let it completely run out of power. This can shorten its
overall lifespan. You’ll get a heads-up when the battery is running low: if it goes below 30%, the
battery percentage on the display will start flashing. When the battery power drops to 15%, your
device will automatically shut off to save the remaining power. Also, if you’re running on battery power
and there’s no activity for 20 seconds, the display will shift back to showing the battery life.
When it’s time to recharge the battery, you’ll need to plug the provided I.E.C. cord into the matching
I.E.C. input on the side of the device. The other end of the cord goes into a suitable power supply.
Keep the power off while charging; it should take about 4 hours to fully charge the battery. Once it
reaches 100%, the display will stop flashing.
Keep in mind, if you unplug the device from charging and switch to battery power, there might be a
small drop in charge. This is normal.
For a faster recharge, you can adjust the settings of the device. Simply switch the ‘Load Setting’ to
‘Off’, and make sure the battery is turned ‘On’. This way, more power is directed to recharging the
battery.

19
BATTERY: REPLACEMENT
Open front cover.
Locate and remove the 2x
Philips-head screws that
secure battery pack holder.

20
BATTERY: REPLACEMENT
Detach the connector and remove
the battery pack. Replace the
battery pack with new one, and
reattach the connector.
Secure the battery pack cover
with 2x Philips-head screws.
