ADS-tec TT13 User manual

User Manual
Tablet PCs
TT13
Version 2.0
Version 2.0

Tablet PCs TT13
2
© ads-tec GmbH • Heinrich-Hertz-Str. 1 • D-72622 Nürtingen
Product Portfolio
Copyright
ads-tec GmbH
Heinrich-Hertz-Str. 1
D-72622 Nürtingen
Germany

Tablet PCs TT13
3
© ads-tec GmbH • Heinrich-Hertz-Str. 1 • D-72622 Nürtingen
INDEX
About us......................................................................................................................................5
1Remarks.....................................................................................................................6
1.1 Relevant data communication with the device.......................................................................6
1.2 Description of the warning symbols used in this guide........................................................6
1.3 Data, Images, Amendments and Variations............................................................................6
1.4 Trademarks.................................................................................................................................6
1.5 Copyright....................................................................................................................................7
1.6 Certifications / tests ..................................................................................................................8
1.7 Scope of delivery.......................................................................................................................9
2Operating instructions............................................................................................10
2.1 Operating location...................................................................................................................10
2.2 Damages due to Improper Use...............................................................................................10
2.3 Warranty / Repairs...................................................................................................................11
2.4 Handling and proper disposal of lithium batteries...............................................................11
2.5 Safety Instructions ..................................................................................................................11
2.6 External device dimensions ...................................................................................................12
3Commissioning .......................................................................................................13
3.1 Available interfaces.................................................................................................................13
3.2 Readiness for Operation Checks ...........................................................................................14
3.3 Touchscreen.............................................................................................................................14
4Front panel functions..............................................................................................15
4.1 Status indicators......................................................................................................................15
4.2 Front control keys ...................................................................................................................18
5Interfaces.................................................................................................................21
5.1 20V DC power supply..............................................................................................................21
5.2 14.4V DC Battery operating mode..........................................................................................21
5.3 USB connections.....................................................................................................................23
5.4 ODU-Interface (optional) .........................................................................................................25
5.5 Network connection (RJ45) ....................................................................................................27
5.6 MIC in ........................................................................................................................................28
5.7 Line out.....................................................................................................................................29
5.8 ExpressCard slot .....................................................................................................................29

Tablet PCs TT13
4
© ads-tec GmbH • Heinrich-Hertz-Str. 1 • D-72622 Nürtingen
6Software & driver installation.................................................................................30
6.1 Battery information & diagnostics tool................................................................................. 30
6.2 TT13 HDD Protection .............................................................................................................. 33
6.3 TT13 Wireless Konfiguration ................................................................................................. 35
6.4 TT13 Touch Rotation .............................................................................................................. 38
6.5 TT13 Monitoring ...................................................................................................................... 41
6.6 TT13 adsxtern Test ................................................................................................................. 43
6.7 Manual Reinstallation ............................................................................................................. 43
6.8 Installation of the TT13 Software Package.......................................................................... 44
6.9 WLAN........................................................................................................................................ 49
6.10 Bluetooth.................................................................................................................................. 52
6.11 UMTS (optional)....................................................................................................................... 53
6.12 RFID reader (optional) ............................................................................................................ 62
6.13 Camera (optional).................................................................................................................... 65
6.14 Soft keyboard .......................................................................................................................... 68
7Accessories.............................................................................................................72
7.1 DVD drive / external type (optional ....................................................................................... 72
7.2 Laser product safety............................................................................................................... 73
7.3 Transport Case........................................................................................................................ 74
7.4 Battery Charging Station C4/TT13......................................................................................... 75
7.5 Substitution Power Supply .................................................................................................... 79
7.6 Car Power Supply ................................................................................................................... 79
7.7 Substitution-Battery................................................................................................................ 79
7.8 TT13 Mechanical Docking Adapter ....................................................................................... 80
7.9 Table Stand.............................................................................................................................. 81
7.10 Wall Bracket............................................................................................................................. 83
7.11 Substitution Pack of Touch Stylus........................................................................................ 83
7.12 3 Point Cord............................................................................................................................. 83
7.13 Hand Strap............................................................................................................................... 87
7.14 ODU 10pol to RS232 Adaptercable 1m ................................................................................. 89
7.15 Protection Bezel...................................................................................................................... 89
8Certifications...........................................................................................................90
8.1 Certifications / tests................................................................................................................ 90
8.2 Electromagnetic compatibility (EMC) ................................................................................... 91
8.3 FCC Approval .......................................................................................................................... 92
9Technical details.....................................................................................................93
9.1 Display data............................................................................................................................. 93
9.2 Computer data......................................................................................................................... 93
9.3 General data............................................................................................................................. 94
10 Service and Support...............................................................................................95
10.1 ads-tec Support....................................................................................................................... 95
10.2 Company Address .................................................................................................................. 95

Tablet PCs TT13
5
© ads-tec GmbH • Heinrich-Hertz-Str. 1 • D-72622 Nürtingen
ABOUT US
ads-tec GmbH
Heinrich-Hertz-Str. 1
D-72622 Nürtingen
Germany
Phone: [phone]
Fax: [phone]
E-Mail: [e-mail]
Home: www.ads-tec.com
ads-tec GmbH provides large enterprises and globally active corporations with cutting edge
technology, up-to-date know-how and comprehensive services in the area of automation
technology, data processing technology and systems engineering.
ads-tec GmbH implements full automation solutions from planning to commissioning and is
specialized in handling and material handling technologies.
The data systems division develops and produces PC based solutions and offers a broad
range of industrial PCs, thin clients and embedded systems.
ads-tec is specialized in modifying and optimizing embedded operating systems and
develops software tools to complement its hardware platforms.

Tablet PCs TT13
6
© ads-tec GmbH • Heinrich-Hertz-Str. 1 • D-72622 Nürtingen
1REMARKS
1.1 RELEVANT DATA COMMUNICATION WITH THE DEVICE
The following documents are essential for setting up and operating this device:
USER MANUAL:
Contains information for installation, commissioning and operating the device along with
technical data of the device hardware.
a
1.2 DESCRIPTION OF THE WARNING SYMBOLS USED IN THIS GUIDE
Warning:
The “Warning” symbol precedes warnings on uses or operations that might either
lead to personal injury and/or hazards, or to any hardware and software damages.
Note:
This Symbol indicates special notes, terms and/or conditions that strictly need to be
observed to ensure optimised and/or zero-defect operations. It also precedes tips
and suggestions for efficient unit implementation and software optimisation.
1.3 DATA,IMAGES,AMENDMENTS AND VARIATIONS
The texts, data and images herein are not binding. The right to any subsequent
amendment and/or variation due to any technical and engineering progresses in the art
whatsoever is hereby reserved.
1.4 TRADEMARKS
It is hereby notified that any software and/or hardware trademarks further to any company
brand names as mentioned in this User’s Guide are all strictly subject to the various
trademark, brand name and patent protection rights.
Windows®, Windows®CE are registered trademarks of Microsoft Corp.
Intel®, Pentium®, Atom™ , Core™2 are registered trademarks of Intel Corp.
IBM®, PS/2®and VGA®are registered trademarks of IBM Corp.
CompactFlash™ and CF™ are registered trademarks of SanDisk Corp.
RITTAL®is a registered trademark of the Rittal Werk Rudolf Loh GmbH & Co. KG.
Any further additional trademarks and/or brand names herein, be they domestic or
international, are hereby duly acknowledged.

Tablet PCs TT13
7
© ads-tec GmbH • Heinrich-Hertz-Str. 1 • D-72622 Nürtingen
1.5 COPYRIGHT
This User’s Guide inclusive of all the images it contains is entirely proprietary and subject
to copyright. Any irregular use of this Guide by third parties infringing copyright terms is
thus strictly forbidden. Reproduction, translation, as well as electronic and photographic
image storage and/or amendment processes, are subject to prior written authorisation
directly by M/s. ads-tec GmbH.
Any violation and infringement thereto will be held liable for compensation of all damages.

Tablet PCs TT13
8
© ads-tec GmbH • Heinrich-Hertz-Str. 1 • D-72622 Nürtingen
1.6 CERTIFICATIONS /TESTS
The TT13 system has the following certifications:
CE compatibility
EN 61000-6-3:2007 Electromagnetive Emission,
Klasse B
EN 55022:2006 Electromagnetive Emission
EN 61000-6-2:2005 Electromagnetive Emission
EN55024:1998+A1:2001+A2:2003
Electromagnetive Emission
UL/cUL201
USL/CNL E217133
GOST-R certificate
Device complies with standard
WLAN certificates for 802.11 a/b/g
for the
EU countries (ETSI)
2,400 MHz –2,483.5 MHz
5,150 MHz –5,350 MHz
5,470 MHz –5,725 MHz
USA / Canada (FCC)
2,400 MHz - 2,483.5 MHz
5,150 MHz - 5,350 MHz
5.725 MHz –5.850 MHz
Japan
2,400 MHz –2,483.5 MHz
5,150 MHz –5,350 MHz
5,470 MHz –5,725 MHz
Australia
2,400 MHz –2,483.5 MHz
5,150 MHz –5,350 MHz
5,470 MHz –5,725 MHz
Russia
2,400 MHz –2,483.5 MHz

Tablet PCs TT13
9
© ads-tec GmbH • Heinrich-Hertz-Str. 1 • D-72622 Nürtingen
Note:
A respective conformity declaration for the authority in charge is available at the
manufacturer and may be viewed on request.
All connected components, as well as cable connections must also meet these
requirements for compliance with the EMC legislation. For this reason, screened
bus and LAN cables including screened connectors must be used and installed
according to the instructions in this user manual.
1.7 SCOPE OF DELIVERY
The following components are included in the scope of delivery:
1 x device
1 x 20V DC power supply unit
2 x batteries
AS AN OPTION:
1 x DVD drive, external
1 x transport case

Tablet PCs TT13
10
© ads-tec GmbH • Heinrich-Hertz-Str. 1 • D-72622 Nürtingen
2OPERATING INSTRUCTIONS
This device contains electrical voltages and extremely sensitive components. The
manufacturer, or a service partner authorised by the manufacturer, should be consulted if
you plan to make any modifications. For this type of work, the device must be switched off
at the mains and the power lead must be disconnected. Suitable measures for avoiding
electrostatic discharge towards parts of the components when touching the equipment
must be taken. If the device is opened by an unauthorised person, hazards for the user
might arise and any warranty claim will cease.
General instructions:
All users must read this manual and have access to it at all times.
Installation, commissioning and operation may only be carried out by trained and
qualified staff.
The security instructions and the manual itself must be observed by all persons
who work with this device.
At the location of use the valid guidelines and regulations for accident prevention
must be observed.
The manual contains the most important instructions on how to use this device in a
safe way.
Appropriate storage, proper transport, installation and commissioning, as well as
careful operation are prerequisites for ensuring safe and proper operation of the
device.
Warning:
Any leads (e.g. power leads, interface cables) may only be connected if the device
is switched off in order to avoid damaging the device.
2.1 OPERATING LOCATION
This device is designed for professional and portable use indoors and outdoors. You have
to take care that the environmental conditions specified in the technical data specification
are met.
Warning:
The device may only be switched on after acclimatising to the ambient temperature in
order to avoid condensate accumulation. The same applies if the device has previously
been exposed to extreme temperature variations.
To avoid overheating in operation: The device must not be exposed to direct
radiation by sunlight or any other light or heat source.
2.2 DAMAGES DUE TO IMPROPER USE
Should the service system have evident signs of damages incurred e.g. due to wrong
operation or storage conditions or due to improper unit use, the unit must be
decommissioned or scrapped. Ensure that it is safe from accidental re-implementation.

Tablet PCs TT13
11
© ads-tec GmbH • Heinrich-Hertz-Str. 1 • D-72622 Nürtingen
2.3 WARRANTY /REPAIRS
During the unit warranty period, any repairs thereto must strictly be conducted solely by the
manufacturer or by service personnel that has been duly authorised by the manufacturer.
2.4 HANDLING AND PROPER DISPOSAL OF LITHIUM BATTERIES
This device contains a lithium battery to supply the systemclock until there is no power
supply connected. Depending on exposure, the battery has a lifetime of 3-5 years.
Note:
High thermal exposure will age the battery faster.
Warning:
By using the wrong types of batteries, there is acute danger of explosion.
Warning:
Lithium batteries should not be exposed to fire, soldered, recharged, opened, short-
circuited, reversed or heated above 100 °C and they should be disposed of properly
as well as protected against sunlight, moisture and condensation.
The lithium battery can only be replaced by the same type or a type recommended by the
manufacturer.
The used lithium battery should be disposed of in accordance with local legal regulations.
2.5 SAFETY INSTRUCTIONS
Warning:
All unit assembly operations must be strictly conducted only under safe, secure and
zero-potential conditions.
Special Note:
When handling parts and components susceptible to electrical discharge, please
accurately observe all the relevant safety provisions.
(DIN EN 61340-5-1 / DIN EN 61340-5-2 refers)

Tablet PCs TT13
12
© ads-tec GmbH • Heinrich-Hertz-Str. 1 • D-72622 Nürtingen
2.6 EXTERNAL DEVICE DIMENSIONS

Tablet PCs TT13
13
© ads-tec GmbH • Heinrich-Hertz-Str. 1 • D-72622 Nürtingen
3COMMISSIONING
The power supply connection and interfaces of this device are installed at the side of case.
All supply leads and all required data leads have to be connected before starting
commissioning.
Warning:
The device must be switched off before connecting or disconnecting any cables in
order to prevent damage to the electronics!
The device may only be switched on after acclimatising to the ambient temperature
in order to avoid condensate accumulation. Make sure to meet the permissible
voltage requirements for this device.
After switching off and before switching on you must wait for at least 10 seconds.
Note:
The screen of a data cable must always be connected with the connector housing
(EMC).
Under the embedded operating system, interfaces must explicitly be enabled and
required drivers must be installed in order to be able to use them.
3.1 AVAILABLE INTERFACES

Tablet PCs TT13
14
© ads-tec GmbH • Heinrich-Hertz-Str. 1 • D-72622 Nürtingen
3.2 READINESS FOR OPERATION CHECKS
Accurately check the unit for any hidden damages possibly incurred during improper
transport and/or handling or wrong operation site and/or storage conditions (e.g. smoke
emissions or formation by the unit, etc.). If any damages are found, the unit must be
decommissioned or scrapped. Ensure that it is safe from accidental re-implementation.
3.3 TOUCHSCREEN
The control system is equipped with an analogue, resistive touchscreen. The driver
software required for its use is already integrated in the respective operating system.
TOUCH STYLUS
Note:
This device is equipped with a supplied touch stylus for comfortably operating the
touchscreen. This stylus should be used for all works on the device in order to
avoid damage to the display.

Tablet PCs TT13
15
© ads-tec GmbH • Heinrich-Hertz-Str. 1 • D-72622 Nürtingen
4FRONT PANEL FUNCTIONS
4.1 STATUS INDICATORS
This device is equipped with different status LEDs in the front. These LEDs indicate current
events, like the system activity state, the current accumulator charge status and WLAN
activities.

Tablet PCs TT13
16
© ads-tec GmbH • Heinrich-Hertz-Str. 1 • D-72622 Nürtingen
SYSTEM LED INDICATORS
DISPLAY
BEHAVIOUR
DESCRIPTION
-
The device is not connected to any
power supply (power
adapter/accumulator)
Static
The device is connected to a power
supply (power adapter/accumulator)
and switched on
Flashes
The device is in suspend mode (this
mode can be set up using the
operating system, re-activation via
power button)
Static
Device is accessing the HDD
POWER LED INDICATORS
-
Device is not connected to any power
supply
Static
Device is supplied by the charged
accumulator
Static
Device is supplied from an external
power supply
Flashes
Internal accumulators of the device are
charged (device must be connected to
a power supply (power adapter)
Static
Device works with the accumulators'
residual capacity

Tablet PCs TT13
17
© ads-tec GmbH • Heinrich-Hertz-Str. 1 • D-72622 Nürtingen
WLAN LED INDICATORS
Static
Device is not connected with a WLAN
network
Static
Device is connected with a WLAN
network
Flashes
Device is connected with a WLAN
network and has data traffic
BLUETOOTH
LED INDICATORS
Static
Bluetooth module is disabled.
Static
Bluetooth module is enabled.
Flashes
Device is connected with a Bluetooth
subscriber and has data traffic

Tablet PCs TT13
18
© ads-tec GmbH • Heinrich-Hertz-Str. 1 • D-72622 Nürtingen
4.2 FRONT CONTROL KEYS
The keys on the front panel are occupied with the following functions by a specific driver in
the soft keyboard:

Tablet PCs TT13
19
© ads-tec GmbH • Heinrich-Hertz-Str. 1 • D-72622 Nürtingen
SYMBOL:
FUNCTION:
ON / OFF pushbutton for the device (approx. 0,5 seconds delayed)
Shift key (SHIFT) for activating the second keyboard level. This key
must be pressed simultaneously with the desired function key
Level 1:
Change task (Alt+ESC) in Windows
Level 2:
Increase the system volume
Level 1:
Switch from Potrait view to Landscape view
Level 2:
Decrease the system volume
Level 1:
Right mouse-key function
Level 2:
Increase display brightness
Level 1:
Activate and deactivate the soft keyboard for letter/character input
using the touchscreen.
Level 2:
Decrease display brightness
Warning:
The front control keys should not be operated with a touch stylus but with the
fingers, only.

Tablet PCs TT13
20
© ads-tec GmbH • Heinrich-Hertz-Str. 1 • D-72622 Nürtingen
Note:
All function keys in the front panel, except for the ON / OFF pushbutton and the Fn
button, have 2 function levels each. The primary function is activated by simply
pushing the respective key. The second function level (small symbol to the top
right) can be activated each time by pushing the Fn key first, and then additionally
pushing the desired function key. It is essential to keep the Fn key always pushed
in order to activate the second function level.
Note:
If the software keyboard is not installed, only the functions for display settings and
volume control are active. The controller display will not be output on the display, in
this case. Above described functions are pre-set ex works.
