Adtech iMASTER - A1 Series User manual

A1-User’s Manual
iMASTER –A1
User’s Manual
Doc. No
ADT-A1-01-E201709(04)

A1-User’s Manual
CONTENTS
1. A1 series VFD ........................................................................................１
1.1Information before Use ....................................................................................................................１
1.1.1 Check of product............................................................................................................................... １
1.1.2 Parts .................................................................................................................................................... １
1.1.3 Preparation of device and Parts for operation ............................................................................... ２
1.1.4 Installation ......................................................................................................................................... ２
1.1.5 Distribution ........................................................................................................................................ ２
1.2Names and Uses of Parts .................................................................................................................２
1.2.1 End product........................................................................................................................................ ２
1.2.2 Remove the front cover .................................................................................................................... ３
2. Specifications.........................................................................................４
2.1Specifications.....................................................................................................................................４
2.1.1 200V class (032A ~ 310A) ............................................................................................................... ４
2.1.2 400V class (016A ~ 217A) ............................................................................................................... ５
2.1.3 400V class (260A ~ 296A) ............................................................................................................... ６
2.1.4 Other commons................................................................................................................................. ７
3. Installation ......................................................................................... １０
3.1Installation .....................................................................................................................................１０
3.1.1 Cautions before installation..........................................................................................................１０
3.1.2 A1 Dimension (IP00) ......................................................................................................................１２
4. Wiring ................................................................................................. ２０
4.1Wiring.............................................................................................................................................. ２０
4.1.1 Installation method of VFD keypad to panel ..............................................................................２０
4.1.2 Wiring precaution ...........................................................................................................................２１
4.1.3 A1Terminal Connection Diagram and Description ....................................................................２５
4.1.4 Terminal wiring diagram (Power terminal block) .......................................................................２７
4.1.5 Control terminal line diagram (Basic I/O terminal block) .........................................................２９
5. Peripheral Devices............................................................................. ３３
5.1Peripheral Devices......................................................................................................................... ３３
5.1.1 Composition of peripheral devices ..............................................................................................３３
5.1.2 Dynamic braking unit (DBU) and Resistors .................................................................................３４
6. Keypad................................................................................................ ３５
6.1Keypad View & Operation ............................................................................................................３５
6.1.1 Keypad View....................................................................................................................................３５
6.1.2 Keypad operation ...........................................................................................................................３８
7. Quick Start Guide .............................................................................. ５０
7.1Frequency Command Source to Up/Down Arrow Keys ........................................................... ５０
7.2Frequency Command Source to Input Analog Voltage/ Current ...........................................５１

A1-User’s Manual
7.3Frequency Command Source to Input Terminal –Multi Speed Frequency ........................... ５２
7.4Frequency Command Source to Input Terminal –Up/Down .................................................. ５３
7.5Frequency Command Source to Modbus RS-485 .................................................................... ５４
7.6Run Command Source to Run / Stop Keys on Keypad ............................................................５５
7.7Run Command Source to Input Terminal .................................................................................. ５５
7.8Run Command Source to Modbus RS-485................................................................................ ５６
8. A1 Parameters ................................................................................... ５７
8.1A1 Parameters Overview .............................................................................................................. ５７
8.1.1 VFD running status ........................................................................................................................５８
8.1.2 Frequency reference indication ....................................................................................................５８
8.1.3 Trip information .............................................................................................................................５８
8.1.4 Time counter...................................................................................................................................６０
8.1.5 VFD firmware Information.............................................................................................................６０
8.1.6 Standard DI, DO (RN0~RN3, AL0-AL1-AL2) ...............................................................................６１
8.1.7 Standard AI (O, OI) .........................................................................................................................６２
8.1.8 Standard AO (FM, AMI)...................................................................................................................６３
8.1.9 Start/stop/direction.......................................................................................................................６４
8.1.10 Start/Stop mode .............................................................................................................................６６
8.1.11 Frequency reference.......................................................................................................................６７
8.1.12 Acceleration/Deceleration.............................................................................................................６９
8.1.13 Speed search...................................................................................................................................６９
8.1.14 Over voltage suppression..............................................................................................................７０
8.1.15 KEB ...................................................................................................................................................７０
8.1.16 DWELL ..............................................................................................................................................７０
8.1.17 Frequency limits .............................................................................................................................７０
8.1.18 Fault functions................................................................................................................................７１
8.1.19 Motor thermal protection..............................................................................................................７２
8.1.20 System Overload/Underload detection........................................................................................７２
8.1.21 PID....................................................................................................................................................７３
8.1.22 DBR Duty Cycle ...............................................................................................................................７５
8.1.23 Monitoring/Scaling.........................................................................................................................７５
8.1.24 Droop...............................................................................................................................................７５
8.1.25 RS-485 (Modbus) ...........................................................................................................................７５
8.1.26 Fieldbus (option) ............................................................................................................................７６
8.1.27 User parameters .............................................................................................................................７７
8.1.28 System .............................................................................................................................................７８
8.1.29 Motor control..................................................................................................................................７９
8.1.30 Motor data.......................................................................................................................................８０
8.2Parameter detail ............................................................................................................................ ８１
8.2.1 VFD running status ........................................................................................................................８１
8.2.2 Frequency reference indication ....................................................................................................８３
8.2.3 Trip information .............................................................................................................................８４
8.2.4 Time counter...................................................................................................................................８６
8.2.5 VFD firmware information.............................................................................................................８８
8.2.6 Standard DI, DO..............................................................................................................................８９
8.2.7 Standard AI (O, OI) .........................................................................................................................９７
8.2.8 Standard AO (FM, AMI)............................................................................................................... １０２

A1-User’s Manual
8.2.9 Start/Stop/Direction .................................................................................................................. １０６
8.2.10 Start/Stop mode ......................................................................................................................... １１１
8.2.11 Frequency reference................................................................................................................... １１４
8.2.12 Acceleration/Deceleration......................................................................................................... １２４
8.2.13 Speed Search............................................................................................................................... １２８
8.2.14 Over voltage suppression.......................................................................................................... １２９
8.2.15 KEB ............................................................................................................................................... １３５
8.2.16 DWELL .......................................................................................................................................... １３６
8.2.17 Frequency limits ......................................................................................................................... １３７
8.2.18 Fault functions............................................................................................................................ １３８
8.2.19 Motor thermal protection.......................................................................................................... １４３
8.2.20 System Overload/Underload detection.................................................................................... １４４
8.2.21 PID................................................................................................................................................ １４６
8.2.22 DBR Duty cycle ......................................................................................................................... １５４
8.2.23 Monitoring/Scaling..................................................................................................................... １５５
8.2.24 Droop........................................................................................................................................... １５６
8.2.25 RS-485 (Modbus) ....................................................................................................................... １５９
8.2.26 Fieldbus (option) ........................................................................................................................ １６６
8.2.27 User parameters ......................................................................................................................... １６７
8.2.28 System ......................................................................................................................................... １６８
8.2.29 Motor control.............................................................................................................................. １７０
8.2.30 Motor data................................................................................................................................... １７４
9. Checking and Trouble shooting ...................................................１７７
9.1Error code....................................................................................................................................１７７
9.1.1 Error code list ............................................................................................................................. １７７
9.2Trouble Shooting .......................................................................................................................１７９
9.2.1 Trip monitor display .................................................................................................................. １７９
9.2.2 oC (Over Current) ....................................................................................................................... １８０
9.2.3 SC (Short Circuit) ........................................................................................................................ １８１
9.2.4 ETH (Motor Overload) ................................................................................................................ １８２
9.2.5 IoLt (VFD Overload) .................................................................................................................... １８３
9.2.6 ov (DC link Over Voltage) .......................................................................................................... １８４
9.2.7 Lv (DC link Under Voltage)........................................................................................................ １８５
9.2.8 ot (Over Temperature) ............................................................................................................... １８６
9.2.9 PF (Input Power Loss)................................................................................................................. １８７
9.2.10 FF (Fan Fault)............................................................................................................................... １８８
9.2.11 VFD doesn’t turn on................................................................................................................... １８９
10. Functional Safety ..........................................................................１９０
10.1Functional Safety......................................................................................................................１９０
10.1.1 Safety standard product ............................................................................................................ １９０
10.1.2 Safety function description and wiring diagram .................................................................... １９０

A1-User’s Manual
１
1. A1 series VFD
1.1 Information before Use
1.1.1 Check of product
Bring the VFD out of the box, check the rating shown on a side of the product body and whether
the VFD type and rated output are exactly what you ordered. Check also whether the product has
been damaged during delivery.
Model: A1-140A (Note1)-2E- 00
A1
140A
2
E
00
name
Max. Applicable Motor Capacity
Input Voltage
Keypad
IP
A1
32A
7.5 [kW]
2: 3Phase
200 ~ 240[V]
E: LED
C: LCD
00: IP00
54: IP54
45A
11 [kW]
64A
15 [kW]
76A
18.5 [kW]
90A
22 [kW]
114A
30 [kW]
140A
37 [kW]
170A
45 [kW]
205A
55 [kW]
261A
75 [kW]
310A
90 [kW]
16A
7.5 [kW]
4: 3Phase
380 ~ 480[V]
23A
11 [kW]
32A
15 [kW]
38A
18.5 [kW]
45A
22 [kW]
58A
30 [kW]
075A
37 [kW]
090A
45 [kW]
110A
55 [kW]
149A
75 [kW]
176A
90 [kW]
217A
110 [kW]
260A
132 [kW]
296A
160 [kW]
eypad
1.1.2 Parts
If you have any doubt about the product or found the product damaged, call our company’s
branch offices (see the back cover of the manual)

A1-User’s Manual
２
1.1.3 Preparation of device and Parts for operation
Preparation for operation might slightly vary. Prepare parts according to the use.
1.1.4 Installation
Make sure you install the product correctly considering the place, direction or surroundings in
order to prevent decrease in the life and performance of the VFD.
1.1.5 Distribution
Connect the power supply, electric motor and operating signals (control signals) to the terminal
block. If you fail to connect them correctly, the VFD and peripheral devices might be damaged.
1.2 Names and Uses of Parts
1.2.1 End product

A1-User’s Manual
３
1.2.2 Remove the front cover
1. Keypad(LED/LCD)
2. Logic BOX
3. Upper plate
4. Power terminal
Release screws and
remove the front cover
1
2
3
4

A1-User’s Manual
４
2. Specifications
2.1 Specifications
2.1.1 200V class (032A ~ 310A)
Model A1-xxxA(Note1)-2
032
045
064
076
090
114
Motor Applied [kW] (Note2)
HD
5.5
7.5
11
15
18.5
22
ND
7.5
11
15
18.5
22
30
Rated
Output
Rated Output(Note3)
Current [A]
HD
24
32
45
64
76
90
ND
32
45
64
76
90
114
Rated
Capacity [kVA]
HD
200V
8
11
16
22
26
31
240V
10
13
19
27
32
37
ND
200V
11
16
22
26
31
39
240V
13
19
27
32
37
47
Output Frequency [Hz]
0~400Hz(Note4)
Output Voltage [V]
3 Phase 200~240V(Note5)
Rated
Input
Available Voltage [V]
3 phase 200~240V (± 10%)
Input Frequency [Hz]
50/ 60Hz (± 5%)
Rated Input Current [A]
HD
23
32
45
64
77
92
ND
31
45
64
77
91
116
Power loss [kW]
HD
0.15
0.21
0.31
0.42
0.52
0.62
ND
0.21
0.31
0.42
0.52
0.62
0.84
EMC Filter
Built-in 61800-3 C3
Model A1-xxxA(Note1)-2
140
170
205
261
310
-
Motor Applied [kW] (Note2)
HD
30
37
45
55
75
-
ND
37
45
55
75
90
-
Rated
Output
Rated Output(Note3)
Current [A]
HD
114
140
170
211
261
-
ND
140
170
205
261
310
-
Rated
Capacity [kVA]
HD
200V
39
48
59
73
90
-
240V
47
58
71
88
108
-
ND
200V
48
59
71
90
107
-
240V
58
71
85
108
129
-
Output Frequency [Hz]
0~400Hz(Note4)
Output Voltage [V]
3 Phase 200~240V(Note5)
Rated
Input
Available Voltage [V]
3 phase 200~240V (± 10%)
Input Frequency [Hz]
50/ 60Hz (± 5%)
Rated Input Current [A]
HD
102.9
126.9
154.4
187.7
257.3
-
ND
126.9
154.4
188.7
257.3
308.8
-
Power loss [kW]
HD
0.60
0.74
0.90
1.10
1.50
-
ND
0.74
0.90
1.10
1.50
1.80
-
EMC Filter
Built-in 61800-3 C3

A1-User’s Manual
５
2.1.2 400V class (016A ~ 217A)
Model A1-xxxA(Note1)-4
016
023
032
038
045
058
Motor Applied [kW] (Note2)
HD
5.5
7.5
11
15
18.5
22
ND
7.5
11
15
18.5
22
30
Rated
Output
Rated Output(Note3)
Current [A]
HD
12
16
23
32
38
45
ND
16
23
32
38
45
58
Rated
Capacity [kVA]
HD
380V
8
11
15
21
25
30
480V
10
13
19
27
32
37
ND
380V
11
15
21
25
30
38
480V
13
19
27
32
37
48
Output Frequency [Hz]
0~400Hz(Note4)
Output Voltage [V]
3 Phase 380~480V(Note5)
Rated
Input
Available Voltage [V]
3-phase 380~480V (± 10%)
Input Frequency [Hz]
50/ 60Hz (± 5%)
Rated Input Current [A]
HD
12
16
23
32
38
46
ND
16
23
32
38
45
59
Power loss [kW]
HD
0.15
0.21
0.31
0.42
0.52
0.62
ND
0.21
0.31
0.42
0.52
0.62
0.84
EMC Filter
Built-in 61800-3 C3
Model A1-xxxA(Note1)-4
075
090
110
149
176
217
Motor Applied [kW] (Note2)
HD
30
37
45
55
75
90
ND
37
45
55
75
90
110
Rated
Output
Rated Output(Note3)
Current [A]
HD
58
75
90
110
149
176
ND
75
90
110
149
176
217
Rated
Capacity [kVA]
HD
380V
38
49
59
72
98
116
480V
48
62
75
91
124
146
ND
380V
49
59
72
98
116
143
480V
62
75
91
124
146
180
Output Frequency [Hz]
0~400Hz(Note4)
Output Voltage [V]
3 Phase 380~480V(Note5)
Rated
Input
Available Voltage [V]
3-phase 380~480V (± 10%)
Input Frequency [Hz]
50/ 60Hz (± 5%)
Rated Input Current [A]
HD
59.6
73.5
89.4
109.2
149.0
178.8
ND
73.5
89.4
109.2
149.0
178.8
218.5
Power loss [kW]
HD
0.60
0.74
0.90
1.10
1.50
1.80
ND
0.74
0.90
1.10
1.50
1.80
2.20
EMC Filter
Built-in 61800-3 C3

A1-User’s Manual
６
2.1.3 400V class (260A ~ 296A)
Model A1-xxxA(Note1)-4
260
296
-
-
-
-
Motor Applied [kW] (Note2)
HD
110
132
-
-
-
-
ND
132
160
-
-
-
-
Rated
Output
Rated Output(Note3)
Current [A]
HD
217
260
-
-
-
-
ND
260
296
-
-
-
-
Rated
Capacity [kVA]
HD
380V
143
171
-
-
-
-
480V
180
216
-
-
-
-
ND
380V
171
195
-
-
-
-
480V
216
246
-
-
-
-
Output Frequency [Hz]
0~400Hz(Note4)
Output Voltage [V]
3 Phase 380~480V(Note5)
Rated
Input
Available Voltage [V]
3-phase 380~480V (± 10%)
Input Frequency [Hz]
50/ 60Hz (± 5%)
Rated Input Current [A]
HD
218.5
262.2
-
-
-
-
ND
262.2
317.8
-
-
-
-
Power loss [kW]
HD
2.20
2.64
-
-
-
-
ND
2.64
3.20
-
-
-
-
EMC Filter
Built-in 61800-3 C3
Note 1) The number that has included at model name means rated current of VFD
Note 2) Motor Applied indicates the maximum capacity applied to use of a standard 4 pole standard motor.
Note 3) The output of rated current is limited according to setting of the carrier frequency.
Note 4) In case of Sensorless, you can set the frequency at up to 300Hz by selecting 2
as the '98.01' (Motor control mode)
Note 5) The maximum output voltage does not go up over the supplied power voltage. You can select the
output voltage as you want below the supplied power voltage.

A1-User’s Manual
７
2.1.4 Other commons
1) Control & Operation
Features
Performance Specification
Control Method(Note1)
V/F control, Sensorless Vector
Output Frequency Range(Note2)
0.5 ∼400Hz (Sensorless Vector Control: 0.5 ∼300Hz)
Frequency Accuracy
Digital command ± 0.01% of Max Frequency /
Analog Frequency ± 0.1% (25± 10℃)
Frequency Resolution
Digital Setting : 0.01Hz (below 100Hz), 0.1Hz (above 100Hz)
Analog setting: 0.06Hz (DC 0∼10V, 4∼20mA)
Voltage/ frequency
Characteristic
Constant torque, Variable torque
Carrier Frequency
1~10kHz (default: ND 2kHz, HD 3kHz)
Overload Current Rate
Heavy Duty(150%, 1min), Normal Duty(120%, 1min)
Acceleration/Deceleration
0.1∼3000 sec (Linear, S curve, U curve), 2ND Acceleration and Deceleration
DC Injection Braking
Separately configurable start and stop up to 10 sec,
100 % motor rated current
Input Signal
Frequency
Set by Keypad (LED, LCD)
Input voltage: DC 0∼10V (Input impedance 10KΩ)
Input current: DC 4∼20mA (Input impedance 200Ω)
Run/Stop
Run / Stop key
Input Terminal: Forward Run/Reverse Run
Input Terminal: Start, Stop, FW/RV Selection
Intelligent Input
Terminal
Run selection 1~2, Run source 1~3
Frequency selection 1~2
Multi-speed Inputs 1~3
Jogging 1~2
External trip 1~5
UP/DOWN
PID Integral Reset, PID Disable
2nd Acceleration / Deceleration
Emergency Stop
Reset
Parameter lock

A1-User’s Manual
８
Features
Performance Specification
Output Signal
Intelligent Output
Terminal
(RN0-RN1,RN2-RN3,
AL0-AL1-AL2)
Run (VFD Running Status Signal)
FA1 (Frequency Arrival Signal 1)
FA2 (Frequency Arrival Signal 2)
OL (Overload Alarm)
OD (PID Error Deviation Signal)
AL (Fault Signal)
FM Output
Analog Output Meter (DC 0~10V full scale. Max ∙ 1mA)
Output Frequency, Output Current, Output Voltage, Output Power and
Output Torque
AMI Output
Analog Output Meter (4~20mA full scale. Max ∙ 250Ω)
Output Frequency, Output Current, Output Voltage, Output Power and
Output Torque
2) Application & Protection Functions
Features
Performance Specification
Application
Specification Functions
Curved Acceleration / Deceleration Profile,
Upper and Lower Limiters,
8-stage Speed Profile,
Carrier Frequency Change (1 to 10Khz),
Frequency Skip
Process Jogging,
Electronic Thermal Level Adjustment,
Retry Function,
Trip History Monitor,
Auto Tuning,
V/f Characteristic Selection,
Speed Search
Automatic Torque Boost,
Frequency Conversion Display,
Protection Functions
Over Current / Short Circuit
DC link Over Voltage /DC link Under Voltage,
Motor Overload,
VFD Overload
EEPROM Error,
Communication Error,
IGBT Over Temperature,
Input Phase loss,
Ground Fault,
External Event
Fan Fault
OVS Control Fail
Safety

A1-User’s Manual
９
3) Use Environment & Option
Feature
Performance Specification
Environment specification
Ambient Temperature
CT (Heavy Duty) load: - 10 ~ 50℃
VT (Normal Duty) load: - 10~ 40℃
(It is recommended that you use less than 80% load when you use VT load at 50℃.
And if ambient temperature is above 40℃, Carrier frequency should be lower than
default value.)
Storage temperature
-20~60℃
Ambient humidity
Below 90% RH (Installed with no dew condensation)
Vibration
5.9m/s2(0.6G). 10~55Hz
Shock
10 Hz to 20Hz, 9.8m/s² Max, 20Hz to 55Hz, 5.9m/s² Max
Location
Under 1000m above sea level, indoors
(Installed away from corrosive gasses dust)
Standard Compliant
UL 508C, IEC 61800-3
Protective Design
IP00 open-chassis, NEMA Type 1 enclosure.
Option
Fieldbus, Ext I/O, Encoder, Remote operator, Bracket, AC reactor,
Noise filter, Braking resistor, Dynamic braking unit
(EMC filter and DC reactor are Built in.)
Note 1) '98.01'(Motor control mode) to 2 (sensorless vector control) Selected, refer to below
Set a value more than 2kHz at '98.03'(PWM carrier frequency)
Sensorless vector performance will be reduced when using a motor less than
half of the rated capacity of the VFD.
Multiple motors cannot be driven by sensorless vector control.
Note 2) To operate the motor over rated frequency, consult the motor manufacturer about
the maximum allowable rotation speed.

A1-User’s Manual
１０
3. Installation
3.1 Installation
3.1.1 Cautions before installation
!CAUTION
Failure to following recommendation may result in VFD damage, Personal Injury, or Fire.
Be sure to install the unit on flame resistant material such as metal.
Be sure not to place anything flammable such as corrosive gas, explosive gas,
inflammable gas, grinding fluid mist, salt in the vicinity
Do not carry the unit by the top cover, but always by supporting the base of the unit
Be sure not to let foreign matter enter such as cut wire refuse, spatter from welding, iron
refuse, wire, dust, etc.
Be sure to install the VFD in a place which can support the weight according to the
specification in the manual.
Be sure to install the unit on a perpendicular wall which is not subject to vibration.
Be sure not to install and operate a damaged VFD or one with the missed parts
Be sure to install the unit in an area which is not exposed to direct sunlight and well
ventilated. Avoid an environment which tends to be high in temperature, high in humidity
or to have condensation.
Air Flow
Note1)
Note1)
Note2) Note2)
VFD
It is critical to mount the VFD to the proper surface in order to prevent any possible risk of
fire. The temperature of the VFD heatsink can rise very high. The surface must be made of a
non-flammable material (i.e. steel). Attention should also be made to the air gap surrounding
the VFD. Especially, when there is a heat source such as a braking resistor or reactor.
Note1)
10cm or more for 5.5kW to 55kW VFD
30cm or more for 75kW to 132kW VFD
50cm or more for 160kW to 375kW VFD
Note2)
More than 5cm for all capacity VFD

A1-User’s Manual
１１
!CAUTION
Avoid direct ray of light or a warm and humid place.
Install the VFD in a place free from dust, corrosive gas, explosive gas, combustible gas,
mist of coolant and sea damage.
Allowable Temperature range (14 to 122°F, -10 to 50℃).
Allowable humidity range (Below 90% RH).
Mount the VFD in a vertical position using screws or bolts. The mounting surface should also be
free from vibration and can easily hold the weight of the VFD.
Unacceptable (X)Acceptable (O) Acceptable (O) Unacceptable (X)

A1-User’s Manual
１２
3.1.2 A1 Dimension (IP00)
Summarized that is the dimension of A1 models
Respective drawing and sizes are specified in 1) ~ 4)
Model
Frame
W
[mm]
W1
[mm]
H
[mm]
H1
[mm]
D
[mm]
Weight
[KG]
A1-032A-2
F1
180
130
400
390
235
8.00
A1-045A-2
F1
180
130
400
390
235
8.00
A1-064A-2
F1
180
130
400
390
235
8.00
A1-076A-2
F2
220
170
455
445
235
11.00
A1-090A-2
F2
220
170
455
445
235
11.00
A1-114A-2
F3
270
200
550
532
265
18.30
A1-140A-2
F3
270
200
550
532
265
24.04
A1-170A-2
F4
295
200
660
642
265
34.26
A1-205A-2
F4
295
200
660
642
265
34.26
A1-261A-2
F5
345
230
760
735
275
45.08
A1-310A-2
F5
345
230
760
735
275
46.04
A1-016A-4
F1
180
130
400
390
235
8.00
A1-023A-4
F1
180
130
400
390
235
8.00
A1-032A-4
F1
180
130
400
390
235
8.00
A1-038A-4
F2
220
170
455
445
235
11.00
A1-045A-4
F2
220
170
455
445
235
11.00
A1-058A-4
F2
220
170
455
445
235
11.00
A1-075A-4
F3
270
200
550
532
265
23.30
A1-090A-4
F3
270
200
550
532
265
23.50
A1-110A-4
F4
295
200
660
642
265
30.74
A1-149A-4
F4
295
200
660
642
265
30.94
A1-176A-4
F5
345
230
760
735
275
44.40
A1-217A-4
F5
345
230
760
735
275
44.92
A1-260A-4
F6
385
280
800
775
275
55.48
A1-296A-4
F6
385
280
800
775
275
56.24

A1-User’s Manual
１３
Model
Frame
W
[inch]
W1
[inch]
H
[inch]
H1
[inch]
D
[inch]
Weight
[Ibs]
A1-032A-2
F1
7.08
5.11
15.74
15.35
9.25
17.63
A1-045A-2
F1
7.08
5.11
15.74
15.35
9.25
17.63
A1-064A-2
F1
7.08
5.11
15.74
15.35
9.25
17.63
A1-076A-2
F2
8.66
6.69
17.91
17.51
9.25
24.25
A1-090A-2
F2
8.66
6.69
17.91
17.51
9.25
24.25
A1-114A-2
F3
10.63
7.87
21.65
20.94
10.43
18.3
A1-140A-2
F3
10.63
7.87
21.65
20.94
10.43
53.00
A1-170A-2
F4
11.61
7.87
25.98
25.28
10.43
75.53
A1-205A-2
F4
11.61
7.87
25.98
25.28
10.43
75.53
A1-261A-2
F5
13.58
9.06
29.92
28.94
10.83
99.38
A1-310A-2
F5
13.58
9.06
29.92
28.94
10.83
101.50
A1-016A-4
F1
7.08
5.11
15.74
15.35
9.25
17.63
A1-023A-4
F1
7.08
5.11
15.74
15.35
9.25
17.63
A1-032A-4
F1
7.08
5.11
15.74
15.35
9.25
17.63
A1-038A-4
F2
8.66
6.69
17.91
17.51
9.25
24.25
A1-045A-4
F2
8.66
6.69
17.91
17.51
9.25
24.25
A1-058A-4
F2
8.66
6.69
17.91
17.51
9.25
24.25
A1-075A-4
F3
10.63
7.87
21.65
20.94
10.43
51.37
A1-090A-4
F3
10.63
7.87
21.65
20.94
10.43
51.81
A1-110A-4
F4
11.61
7.87
25.98
25.28
10.43
67.77
A1-149A-4
F4
11.61
7.87
25.98
25.28
10.43
68.21
A1-176A-4
F5
13.58
9.06
29.92
28.94
10.83
97.89
A1-217A-4
F5
13.58
9.06
29.92
28.94
10.83
99.03
A1-260A-4
F6
15.16
11.02
31.49
30.51
10.83
122.31
A1-296A-4
F6
15.16
11.02
31.49
30.51
10.83
123.99

A1-User’s Manual
１４
1) F1 (A1-032A-2, A1-045A-2, A1-064A-2 / A1-016A-4, A1-023A-4, A1-032A-4)
180 (7.09") [W]
130 (5.12") [W1] 220 (8.66")
235 (9.25") [D]
15 (0.59")
2-Ø 5 (0.2")
2-5 (0.2")
130 (5.51")
5(0.2") 5(0.2")
390(15.35")[H1]
400(15.75")[H]

A1-User’s Manual
１５
2) F2 (A1-076A-2, A1-090A-2/ A1-038A-4, A1-045A-4, A1-058A-4)
220 (8.66") [W]
170 (6.69") [W1]
5(0.2") 5(0.2")
445(17.52")[H1]
455(17.91")[H]
2-Ø 5 (0.2")
220 (8.66")
235 (9.25") [D]
15 (0.59")
2-5 (0.2")
170 (7.09")

A1-User’s Manual
１６
3) F3 (A1-114A-2, A1-140A-2/ A1-075A-4, A1-090A-4)
270 (10.63") [W]
200 (7.87") [W1]
2-Φ9 (0.35")
250 (9.84")
[D]
15 (0.59")
10 (0.39")8 (0.31")
550 (21.65") [H]
200 (7.87") [W1]
2-9 (0.35")
532 (20.95") [H1]
