ADTRAN 6540 Product manual

installation guide
SHDSL 2-Wire/4-Wire
NTU Product Series
Installation and Maintenance Guide
Document Number: 61230001E1-5E
July 2015

SHDSL 2-Wire/4-Wire NTU Product Series Installation and Maintenance Guide
ii 61230001E1-5E
Front Matter
Trademarks
Any brand names and product names included in this document are trademarks, registered
trademarks, or trade names of their respective holders.
To the Holder of this Document
The contents of this document are current as of the date of publication. ADTRAN®reserves
the right to change the contents without prior notice.
In no event will ADTRAN be liable for any special, incidental, or consequential damages or
for commercial losses even if ADTRAN has been advised thereof as a result of issue of this
documen
About this Document
This document provides instructions for the installation and maintenance of the SHDSL 2-
Wire/4-Wire NTU Product Series. The intended audience for this information is the craft-
person responsible for the installation and maintenance of the equipment. These instructions
assume familiarity with the intended use of the equipment, basic required installation skills,
and knowledge of local and accepted safety practices.
Additionally, this document provides provisioning information specific to the User Interface
of the SHDSL 2-Wire/4-Wire NTU Product Series. The intended audience for this information
is system management personnel responsible for the configuration of the software applica-
tions. User Interface provisioning assumes familiarity with the intended use of the equipment,
concepts peculiar to this product, and a computer operations skill set.
Related information can be obtained by referring to the applicable Component and System
level documentation.
.
901 Explorer Boulevard
P.O. Box 140000
Huntsville, AL 35814-4000
[phone]
©2015 ADTRAN, Inc.
All Rights Reserved.
®

61230001E1-5E iii
Revision History
Conventions
The following typographical conventions are used in this document:
This font indicates a cross-reference link.
This font indicates references to other documentation and is also used for emphasis.
This font is used for strong emphasis.
Thisfont indicates a System Response (on-screen messages and prompts).
Thisfont indicates System Input (text to be typed exactly as shown).
This Font indicates screen menu items, fields and parameters.
THIS FONT indicates keyboard keys (ENTER, ESC, ALT). Keys that are to be pressed simulta-
neously are shown with a plus sign (ALT + X indicates that the ALT key and X key should be
pressed at the same time).
THIS FONT indicates silk-screen labels or other system label items.
Revision Date Description
B May 2006 Initial revision created from 61230001L1-5B to add RoHS
Directive 2002/95/EC compliance
C December 2006 Revise to include TSCAN features
D September 2011 Revise Safety and Regulatory Compliance content
E July 2015 Remove RoHS Directive 2002/95/EC compliance information.

SHDSL 2-Wire/4-Wire NTU Product Series Installation and Maintenance Guide
iv 61230001E1-5E
Hazard Classifications
The following hazard classifications are used in this document:
DANGER
!
DANGER indicates a hazard with a high level of risk which, if not avoided,
will result in death or serious injury.
WARNING
!
WARNING indicates a hazard with a medium level of risk which, if not
avoided, could result in death or serious injury.
CAUTION
!
CAUTION indicates a hazard with a low level of risk which, if not avoided,
could result in minor or moderate injury. CAUTION can also be used to alert
against unsafe practices associated with events that could lead to personal
injury.
NOTICE
Notice call-outs indicate a potentially hazardous situation not related to
personal injury, such as messages related to property damage only.
NOTE
Notes inform the user of additional, but essential, information or features.

61230001E1-5E v
Icons
The following icons are used throughout the ADTRAN document suite:
Training
ADTRAN offers training courses on our products. These courses include overviews on
product features and functions while covering applications of ADTRAN product lines.
ADTRAN provides a variety of training options, including customized training and courses
taught at our facilities or at customer sites.
For inquiries concerning training, contact ADTRAN:
Training Phone: [phone]
Training Fax: [phone]
Training Email: [email protected]
deployment guide
installation guide
jobAid
reference guide
diagnostic guide
safety and regulatory
engineering guide
application guide
release notes
upgrade guide
user guide

SHDSL 2-Wire/4-Wire NTU Product Series Installation and Maintenance Guide
vi 61230001E1-5E

61230001E1-5E vii
Contents
Scope of this Guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
In this Guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
SHDSL 2-Wire/4-Wire Mode, Line Rate . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Industry Standards Compliance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Safety and Regulatory Compliance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Avis sur la sécurité et la conformité à la réglementation 7
Konformitätserklärung zur Sicherheit und Einhaltung von Normen 7
Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Shipping Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Front Panel Push Buttons . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Front Panel LEDs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Push Button and LED Indicator Interaction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Rear Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Power Supply . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
AC Powering . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
DC Powering . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Span Powering . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
SHDSL Pinout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
G.703 Pinout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Nx64K Port V.35, ISO 2593, 34-pin Female Pinout . . . . . . . . . . . . . . . . . . . . . . . . . 18
V.36 Pinout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
X.21 Pinout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Optioning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Timeslot Cross-Connect Map . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Timeslot Allocation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Timing Sources . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Menu Tree . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

SHDSL 2-Wire/4-Wire NTU Product Series Installation and Maintenance Guide
viii 61230001E1-5E
Local and Remote Loopbacks for Ports and Services . . . . . . . . . . . . . . . . . . . . . . . 27
Bit Error Rate Tester (BERT) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Searching for Pattern . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
BERT Application . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Bad Splice Detection (TScan) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Managing TScan . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Bad Splice Detection (TSCAN) Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Restart Bad Splice Detector Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
Bad Splice Detection (TSCAN) 24 Hour Counts Screen . . . . . . . . . . . . . . . . . . 36
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
Appendix A
Warranty and Customer Service. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-1
Warranty. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-1
ADTRAN Sales . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-1
ADTRAN Technical Support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-1
ADTRAN Repair/CAPS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-1
Repair and Return Address . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-1

61230001E1-5E ix
Figures
Figure 1. Typical System Application . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Figure 2. Typical Campus Application . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Figure 3. Compliance Labels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Figure 4. Front Panel for 6540 and 6541 Models . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Figure 5. Front Panel for 6542 Model . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Figure 6. Rear Panel for Model 6540, AC Powered . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Figure 7. Rear Panel for Model 6540, DC Powered . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Figure 8. Rear Panel for Model 6541, AC Powered . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Figure 9. Rear Panel for Model 6541, DC Powered . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Figure 10. Rear Panel for Model 6542, Span or DC Powered . . . . . . . . . . . . . . . . . . . . . . 15
Figure 11. Contiguous Time Slot Allocation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Figure 12. Non-Contiguous Time Slot Allocation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Figure 13. Timing Sources . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Figure 14. 6500 Series Menu Tree . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Figure 15. BERT and Remote Loopback . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Figure 16. BERT with Remote BERT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Figure 17. Bad Splice Detection (TSCAN) Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
Figure 18. Restart Bad Splice Detector Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
Figure 19. Bad Splice Detection (TSCAN) 24 Hour Counts Screen . . . . . . . . . . . . . . . . . . 36

SHDSL 2-Wire/4-Wire NTU Product Series Installation and Maintenance Guide
x61230001E1-5E
Tables
Table 1. Topic List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Table 2. SHDSL 2-Wire/4-Wire NTU Modules . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Table 3. 2-Wire/4-Wire Multi-Rate Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Table 4. Product Feature Set Matrix . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Table 5. Front Panel Push Buttons . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Table 6. LED Indicator Functionality . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Table 7. LED Indication - No Port Selected . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Table 8. LED Indication - G.703 Port Services . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Table 9. Rear Panel Connectors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Table 10. SHDSL Port RJ-45 Pinout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Table 11. G.703 Port RJ-45 Pinouts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Table 12. Nx64k Port V.35 34-Pin Pinout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Table 13. V.35 to V.36 Adapter Cable Pinouts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Table 14. X.21 Pinouts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Table 15. Loopback Test Summary . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Table 16. KEY to Symbols used in Table 15. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Table 17. Bad Splice Detection (TSCAN) Menu Options . . . . . . . . . . . . . . . . . . . . . . . . . 34
Table 18. Restart Bad Splice Detector Screen Options . . . . . . . . . . . . . . . . . . . . . . . . . . 35
Table 19. SHDSL 2-Wire/4-Wire NTU Product Series Specifications . . . . . . . . . . . . . . . . 37

61230001E1-5E 1
NTU Product Series
SHDSL 2-Wire/4-Wire NTU
Scope of this Guide
This guide provides instructions for the installation and maintenance of the SHDSL 2-Wire/4-
Wire NTU Product Series, including connections, optioning, and troubleshooting.
In this Guide
This guide contains the topics listed in Table 1.
Table 1. Topic List
Topic See Page
Introduction 2
Safety and Regulatory Compliance
Avis sur la sécurité et la conformité à la réglementation
Konformitätserklärung zur Sicherheit und Einhaltung von Normen
7
Installation 9
Connections 14
Optioning 22
Troubleshooting 27
Specifications 37

SHDSL 2-Wire/4-Wire NTU Product Series Installation and Maintenance Guide
261230001E1-5E
Introduction
This guide provides procedures for the following SHDSL 2-Wire/4-Wire NTU modules in the
series.
Note: The 6540 and 6541 model sets are separate AC or DC powered versions of the same base product (for example,
P/Ns 1230001 and 1230002; 1230007 and 1230008).
Table 2. SHDSL 2-Wire/4-Wire NTU Modules
Part Number Product Name
1230001E1 6540 SHDSL 2-Wire/4-Wire NTU, AC Powered
1230002E1 6540 SHDSL 2-Wire/4-Wire NTU, DC Powered
1230007E1 6541 SHDSL 2-Wire/4-Wire NTU, AC Powered
1230008E1 6541 SHDSL 2-Wire/4-Wire NTU, DC Powered
1230009E1 6542 SHDSL 2-Wire/4-Wire NTU, Span or DC Powered

Introduction
61230001E1-5E 3
Description
The SHDSL 2-Wire/4-Wire NTU provides an interface between the SHDSL network and the
user Data Terminal Equipment (DTE). It supports applications such as LAN-to-LAN bridging,
Frame Relay circuit, and PABX termination. The SHDSL 2-Wire/4-Wire NTU can be used as
either of the following:
• remote unit to the ADTRAN Total Access®3000 multiservice platform (see Figure 1), or
• pair of units in a point-to-point limited distance campus configuration (see Figure 2), with
one SHDSL 2-Wire/4-Wire NTU configured to “LT” mode.
Figure 1. Typical System Application
Figure 2. Typical Campus Application
SHDSL
REG
2 -4-Wire Twisted Pair(s)
REG Applicable Only for 4-Wire
Management
System
VT100 VT100
Network
SHDSL
2W/4W
NTU
Total Access 3000
or BAU Customer E1
Equipment
(e.g., PABX)
Customer Nx64k
Equipment
(e.g., Router)
SHDSL
LTU
2 -4-Wire
Twisted Pair
VT100 VT100
SHDSL 2W/4W
NTU
SHDSL 2W/4W
NTU
(Configured as an “LT”)
Customer E1
Equipment
(e.g., PABX)
Customer Nx64K
Equipment
(e.g., Router)
Customer E1
Equipment
(e.g., PABX)
Customer Nx64K
Equipment
(e.g., Router)

SHDSL 2-Wire/4-Wire NTU Product Series Installation and Maintenance Guide
461230001E1-5E
SHDSL 2-Wire/4-Wire Mode, Line Rate
The SHDSL 2-Wire/4-Wire NTU supports multi-rate line operation (refer to Table 3).
Table 3. 2-Wire/4-Wire Multi-Rate Operation
Data Rate Type 2-Wire Mode 4-Wire Mode
SHDSL Line Aggregate Data
Rate
200 kbps to 2.312 Mbps (N 64
kbps + 8 kbps, where N = 3 to 36)
In 2-wire mode, 8 kbps of band-
width is required for overhead
framing
400 kbps to 4.624 Mbps (N 64
kbps + 16 kbps, where 2 x N = 3
to 36)
In 4-wire mode, 16 kbps is
required for overhead framing.
Payload Data Rate 192 kbps to 2.304 Mbps (N 64
kbps, where N = 3 to 36)
384 kbps to 4.608 Mbps in 4-wire
mode (2 x N 64 kbps, where N
= 3 to 36)
Service Data Rate 64 kbps to 2.304 Mbps (N 64
kbps, where N = 1 to 36)
64 kbps to 4.608 Mbps (N 64
kbps, where N = 1 to 72)
This is the actual user data rate
delivered to either the G.703 or
Nx64 kbps ports.

Introduction
61230001E1-5E 5
Features
Table 4 is a matrix of product features for the five versions of the SHDSL 2-Wire/4-Wire NTU.
Table 4. Product Feature Set Matrix
Model Number
1230001E1 1230002E1 1230007E1 1230008E1 1230009E1
Physical Description
Net Housing: 5.3 cm (2.1 in.) H x 23.6 cm (9.3 in.) W x 16.8 cm (6.6 in.) D • • • • •
Front Panel Recessed Pushbuttons (4 total)
PORTSELECT •••••
LOCAL LOOP/ERR INJ • • • • •
REMOTE LOOP • • • • •
BERT •••••
Front Panel Tri-Color LED Indicators (Always Eight Total)
Left to Right
Order
Label Function
LED 1 SHDSL SHDSL Port Status, Test Select, Alarms • • • •
LED 2 G.703 G.703 Port Status, Test Select, Alarms • • • •
LED 3 Nx64k Nx64k Port Status, Test Select, Alarms • • • •
SPN PWR Span Power Status •
LED 4 RTS/C Nx64k Port RTS/C Status • • • •
DC PWR Local DC Power Status •
LED 5 RLSD/I Nx64k Port RLSD/I Status • • • •
PRGM Firmware Programming Status •
LED 6 LLOOP Local loopback test status for selected port • • • • •
LED 7 RLOOP Remote loopback test status for selected
port
•••••
LED8 BERT BERTforselectedport/service •••••
Rear Panel
SHDSL Port (RJ-45 135 ohms, TNV-3 rated) • • • • •
G.703 E1 Port (RJ-45 120 ohms, SELV rated) • • •
Optional G.703 E1 Port (RJ-45 to BNC 75 ohms through external adapter,
ADTRAN P/N 1225002L1)
•• •
G.703 E1 Port (BNC, 75 ohms, SELV rated) • • • • •
Nx64k Port X.21 (DB-15 female / ISO 4903, SELV; V.11 electrical) • • • •
Nx64k Port V.35 (M34 Winchester 34-pin female / ISO 2593. SELV rated; V.35,
V.28 electrical
••••
Nx64k Port V.36 using the V.35 (34-pin male) to V.36 (ISO 4902 37-pin female) 12
inch adapter cable, ADTRAN P/N 1225004L1; V.11, V.10 electrical
••••
Local Management Port (DB-9 female, SELV; V.28 electrical) • • • •
AC Power (IEC-320 power receptacle) • • • • •

SHDSL 2-Wire/4-Wire NTU Product Series Installation and Maintenance Guide
661230001E1-5E
Industry Standards Compliance
The SHDSL 2-Wire/4-Wire NTU interfaces adhere to these industry standards, either partially
or in full:
• SHDSL: ITU-T G.991.2 (12/03 and 2003 amendments) and G.994.1 (05/03)
• G.703: ITU-T G.703 (10/98), G.704 (10/98), G.706 (4/91), G.732 (11/88), G.775 (10/98),
G.784 (1/94), G.797 (3/96), G.821 (8/96), G.823 (03/93), and G.826 (2/99)
• Nx64K: ITU-T X.21 (09/92), V.35 (10/84), and V.36 (11/88); and ISO 2593 (1984), 4903
(1991), and 4902 (1980)
DC Power (5.08 mm (0.2 inc.) 4-pin terminal block shrouded male (MOLEX/
BEAU 861904 or equivalent)
•••
Power
100-240 VAC, 50/60Hz, 100 mA • • •
35-80 VDC, 250 mA •
120 VDC Span Powered, 150 mA
120 VDC Span Powered, 150 mA; 35-80 VDC, 250 mA Auto-Switched Local
Powered
•
Table 4. Product Feature Set Matrix (Continued)
Model Number
1230001E1 1230002E1 1230007E1 1230008E1 1230009E1

Safety and Regulatory Compliance
61230001E1-5E 7
Safety and Regulatory Compliance
Avis sur la sécurité et la conformité à la réglementation
Konformitätserklärung zur Sicherheit und Einhaltung von Normen
WARNING •AVERTISSEMENT •WARNUNG
!
• Read all warnings and cautions before installing or servicing this
equipment. Refer to the Safety and Regulatory Compliance Notice for this
product (P/N 61230001E1-17, 61230002E1-17, 61230007E1-17, 61230001E8-
17, or 61230009E1-17) for detailed safety and regulatory information.
• Lisez tous les avertissements et mises en garde avant l’installation de cet
équipement ou la réalisation de toute opération de maintenance. Consultez
l'avis sur la sécurité et la conformité à la réglementation pour ce produit
(P/N 61230001E1-17, 61230002E1-17, 61230007E1-17, 61230001E8-17, ou
61230009E1-17) pour obtenir des renseignements détaillés sur la sécurité et
la réglementation.
• Lesen Sie sich alle Warn- und Sicherheitshinweise durch, bevor Sie dieses
Gerät installieren oder warten. Ausführliche Sicherheits- und
regulatorische Informationen sind in der Konformitätserklärung zur
Sicherheit und Einhaltung von Normen zu diesem Produkt (P/N
61230001E1-17, 61230002E1-17, 61230007E1-17, 61230001E8-17, oder
61230009E1-17) aufgeführt.
The SHDSL 2-Wire/4-Wire NTU complies with the following international standards:
• EN 300 386-2
• IEC 60950/EN 60950/AS NZS60950
•S016
• S043.2
• ITU K.21 Enhanced
• Telstra 1555
Figure 3 shows the compliance code labels for the SHDSL 2-Wire/4-Wire NTU Product Series.

SHDSL 2-Wire/4-Wire NTU Product Series Installation and Maintenance Guide
861230001E1-5E
Figure 3. Compliance Labels
This device complies with Part 15 of the FCC rules. Operation is subject to the following two
conditions:
1. This device may not cause harmful interference.
2. This device must accept any interference received, including interference that may cause
undesired operation.
Changes or modifications not expressly approved by ADTRAN could void the user’s
authority to operate this equipment.
SERIAL NO.
100-240VAC 50/60Hz 100mA
Tested To Com p l y
With FCC Standards
FOR HOME OR OFFICE USE
This Class B digital apparatus meets all requirements of the
Canadian Interference-Causing Equipment Regulations.
Cet appareil numérique de la class B respecte les exigences
du Règlement sur le Matériel Brouilleur du Canada.
P/N:1230001E1
EXPRESS 6540
Tested To Comply
With FCC Standards
FOR HOME OR OFFICE USE
This Class B digital apparatus meets all requirements of the
Canadian Interference-Causing Equipment Regulations.
Cet appareil numérique de la class B respecte les exigences
du Règlement sur le Matériel Brouilleur du Canada.
SERIAL NO.
P/N:1230002E1
EXPRESS 6540
SERIAL NO.
100-240VAC 50/60Hz 100mA
Tested To Comply
With FCC Standards
FOR HOME OR OFFICE USE
This Class B digital apparatus meets all requirements of the
Canadian Interference-Causing Equipment Regulations.
Cet appareil numérique de la class B respecte les exigences
du Règlement sur le Matériel Brouilleur du Canada.
P/N:1230007E1
EXPRESS 6541
Tested To Comply
With FCC Standards
FOR HOME OR OFFICE USE
This Class B digital apparatus meets all requirements of the
Canadian Interference-Causing Equipment Regulations.
Cet appareil numérique de la class B respecte les exigences
du Règlement sur le Matériel Brouilleur du Canada.
SERIAL NO.
P/N:1230008E1
EXPRESS 6541
Tested To Comply
With FCC Standards
FOR HOME OR OFFICE USE
This Class B digital apparatus meets all requirements of the
Canadian Interference-Causing Equipment Regulations.
Cet appareil numérique de la class B respecte les exigences
du Règlement sur le Matériel Brouilleur du Canada.
SERIAL NO.
P/N:1230009E1
EXPRESS 6542

Installation
61230001E1-5E 9
Installation
After unpacking any SHDSL 2-Wire/4-Wire NTU, inspect it for damage. If damage has
occurred, file a claim with the carrier, then contact ADTRAN Customer Service. Refer to
Appendix A, “Warranty and Customer Service” for further information. If possible, keep the
original shipping container for returning the unit for repair or for verification of shipping
damage.
Shipping Contents
The contents include the following items:
• SHDSL 2-Wire/4-Wire NTU
• Mating quick-connect terminal screw block (DC models only)
• SHDSL 2-Wire/4-Wire NTU Job Aid (product specific)
CAUTION!
SUBJECT TO ELECTROSTATIC DAMAGE
OR DECREASE IN RELIABILITY
HANDLING PRECAUTIONS REQUIRED

SHDSL 2-Wire/4-Wire NTU Product Series Installation and Maintenance Guide
10 61230001E1-5E
Front Panel Push Buttons
There are four push buttons on the SHDSL 2-Wire/4-Wire NTU front panel (refer to Table 5).
The push buttons are recessed to avoid accidental actuation and can be disabled, either
individually or as a group, using the management interface.
Table 5. Front Panel Push Buttons
Push Button Description
PORT SELECT Press the PORT SELECT button to select the active port. Selection choices
cycle through the following order: No Port, Nx64k, G.703, SHDSL.
LOCAL LOOP /
ERR INJ
If a port is selected, and a Bit Error Rate Test (BERT) is not in progress, press
the LOCAL LOOP/ERR INJ button to initiate or terminate a local loop on the
selected port. If a BERT is in progress, press the button to inject a single bit
error.
REMOTE LOOP If the SHDSL port is selected, press the REMOTE LOOP button to either place
or remove a remote loop on the port by sending a EOC request message to the
LTU (or NTU in campus mode). If the Nx64K port or G.703 port (with only
one service defined) is selected, press this button to place or remove a remote
loop on the selected port's single data service by sending respective inband
loop up or loop down patterns to the far end (in the associated data service
timeslots).
BERT If a port is selected and there are no local loops, press the BERT button to start
or stop a BERT on the selected port.
