NetVanta 1230 Series
Hardware Installation Guide
1700594G1 NetVanta 1234
1700595G1 NetVanta 1234 PoE
1700598G1 NetVanta 1238
1700599G1 NetVanta 1238 PoE
61700594G1-34B
July 2009

Trademarks NetVanta 1230 Series Hardware Installation Guide
2 Copyright © 2009 ADTRAN, Inc. 61700594G1-34B
Trademarks
Any brand names and product names included in this manual are trademarks, registered trademarks, or
trade names of their respective holders.
To the Holder of the Manual
The contents of this manual are current as of the date of publication. ADTRAN reserves the right to change
the contents without prior notice.
In no event will ADTRAN be liable for any special, incidental, or consequential damages or for
commercial losses even if ADTRAN has been advised thereof as a result of issue of this publication.
Software Licensing Agreement
Each ADTRAN product contains a single license for ADTRAN-supplied software. Pursuant to the
Licensing Agreement, you may: (a) use the software on the purchased ADTRAN device only and (b) keep
a copy of the software for backup purposes. This Agreement covers all software installed on the system, as
well as any software available on the ADTRAN website. In addition, certain ADTRAN systems may
contain additional conditions for obtaining software upgrades.
901 Explorer Boulevard
P.O. Box 140000
Huntsville, AL 35814-4000
Phone: [phone]
Copyright © 2009 ADTRAN, Inc.
All Rights Reserved.
Printed in U.S.A.
Changes or modifications to this unit not expressly approved by the party responsible for
compliance could void the user’s authority to operate the equipment.

NetVanta 1230 Series Hardware Installation Guide Conventions
61700594G1-34B Copyright © 2009 ADTRAN, Inc. 3
Conventions
Notes provide additional useful information.
Cautions signify information that could prevent service interruption or damage to the
equipment.
Warnings provide information that could prevent injury or endangerment to human
life.

Safety Instructions NetVanta 1230 Series Hardware Installation Guide
4 Copyright © 2009 ADTRAN, Inc. 61700594G1-34B
Safety Instructions
When using your telephone equipment, please follow these basic safety precautions to reduce the risk of
fire, electrical shock, or personal injury:
1. Do not use this product near water, such as a bathtub, wash bowl, kitchen sink, laundry tub, in a
wet basement, or near a swimming pool.
2. Avoid using a telephone (other than a cordless type) during an electrical storm. There is a remote
risk of shock from lightning.
3. Do not use the telephone to report a gas leak in the vicinity of the leak.
4. Use only the power cord, power supply, and batteries indicated in the manual. Do not dispose of
batteries in a fire. They may explode. Check with local codes for special disposal instructions.
5. The socket-outlet shall be installed near the equipment and shall be easily accessible.
If any of the following conditions occur, unplug the product from the electrical outlet and replace the part
or contact your qualified service personnel:
1. The power cable, extension cable, or plug is damaged.
2. An object has fallen into the product.
3. The product has been exposed to water.
4. The product has been dropped or damaged.
5. The product does not operate correctly when you follow the operating instructions.
Save These Important Safety Instructions
These units contain no user-serviceable parts. They should only be serviced by qualified
service personnel.
Additional safety guidelines, such as Waste Electrical and Electronic Equipment (WEEE)
are given in the NetVanta Safety and Regulatory Information document on the AOS
Documentation CD.

NetVanta 1230 Series Hardware Installation Guide FCC Radio Frequency Interference Statement
61700594G1-34B Copyright © 2009 ADTRAN, Inc. 5
FCC Radio Frequency Interference Statement
This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant
to Part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful
interference when the equipment is operated in a commercial environment. This equipment generates,
uses, and can radiate radio frequency energy and, if not installed and used in accordance with the
instruction manual, may cause harmful interference to radio frequencies. Operation of this equipment in a
residential area is likely to cause harmful interference in which case the user will be required to correct the
interference at his own expense.
Canadian Emissions Requirements
This digital apparatus does not exceed the Class A limits for radio noise emissions from digital apparatus
as set out in the interference-causing equipment standard entitled “Digital Apparatus,” ICES-003 of the
Department of Communications.
Cet appareil numérique respecte les limites de bruits radioelectriques applicables aux appareils numériques
de Class A prescrites dans la norme sur le materiel brouilleur: “Appareils Numériques,” NMB-003 edictee
par le ministre des Communications.
Service and Warranty
For information on the service and warranty of ADTRAN products, visit the ADTRAN website at
http://www.adtran.com/support.

Service and Warranty NetVanta 1230 Series Hardware Installation Guide
6 Copyright © 2009 ADTRAN, Inc. 61700594G1-34B

61700594G1-34B Copyright © 2009 ADTRAN, Inc. 7
Table of Contents
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Physical Descriptions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
NetVanta 1230 Series . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Power over Ethernet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
SFP Module Slots . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Product Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Unit Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Tools Required . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Mounting Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Supplying Power to the Unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Appendix A. Connector Pin Definitions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

Table of Contents NetVanta 1230 Series Hardware Installation Guide
8 Copyright © 2009 ADTRAN, Inc. 61700594G1-34B

61700594G1-34B Copyright © 2009 ADTRAN, Inc. 9
List of Figures
Figure 1. NetVanta 1234 Front Panel Layout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Figure 2. NetVanta 1234 Rear Panel Layout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Figure 3. NetVanta 1234 PoE Front Panel Layout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Figure 4. NetVanta 1234 PoE Rear Panel Layout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Figure 5. NetVanta 1238 Front Panel Layout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Figure 6. NetVanta 1238 Rear Panel Layout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Figure 7. NetVanta 1238 PoE Front Panel Layout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Figure 8. NetVanta 1238 PoE Rear Panel Layout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Figure 9. Wallmount Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

List of Figures NetVanta 1230 Series Hardware Installation Guide
10 Copyright © 2009 ADTRAN, Inc. 61700594G1-34B

61700594G1-34B Copyright © 2009 ADTRAN, Inc. 11
List of Tables
Table 1. Front Panel LED Descriptions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Table A-1. 10/100Base-T Ethernet Port Pinouts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Table A-2. SFP Slot Pinouts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Table A-3. 1000Base-T Gigabit Ethernet Port Pinouts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28

List of Tables NetVanta 1230 Series Hardware Installation Guide
12 Copyright © 2009 ADTRAN, Inc. 61700594G1-34B

61700594G1-34B Copyright © 2009 ADTRAN, Inc. 13
1. INTRODUCTION
The NetVanta 1230 Series includes the NetVanta 1234, NetVanta 1234 Power over Ethernet (PoE),
NetVanta 1238, and NetVanta 1238 PoE.
This hardware installation guide lists the NetVanta 1230 units’ specifications, describes the physical
characteristics of the units, introduces basic functionality, and provides installation instructions.
2. PHYSICAL DESCRIPTIONS
NetVanta 1230 Series
The NetVanta 1230 and NetVanta 1230 PoE Series are managed switches housed in 1U-high rack-mountable
metal enclosures that include a universal AC power supply. The front panels contain 24 (NetVanta 1234 Series)
or 48 (NetVanta 1238 Series) 10/100Base-T Ethernet interfaces and four 10/100/1000Base-T Gigabit Ethernet
interfaces all accessed via standard RJ-45 connectors. Two industry standard small form-factor pluggable (SFP)
slots (supporting industry standard SFP modules) are available for high-speed uplink via fiber. NetVanta 1230
units run the ADTRAN Operating System (AOS), and are managed through an EIA-232 CONSOLE port
(DB-9) located on either the front or rear panel, Telnet session, or Web-based graphical user interface
(GUI). The NetVanta 1230 is RoHS compliant.
Power over Ethernet
The NetVanta 1230 Series PoE switches provide the same basic functionality as the standard product. PoE
provides the ability to detect attached powered devices (PDs), and deliver 48 VDC to the PD via existing CAT 5
cabling. The PoE switches are fully compliant with the IEEE 802.3af PoE standard. By default, the PoE
switches discover and provide power to IEEE-compliant PDs. NetVanta 1230 Series PoE switches support
legacy PoE.
SFP Module Slots
The NetVanta 1230 Series devices support two SFP slots that accept a number of industry standard SFP
modules. The SFP modules provide Gigabit Ethernet fiber connectivity for high-speed uplinks or switch
stacking. The following modules are available for purchase (both of these modules require fiber optic cable with
LC connectors):
• 1200480E1 1000Base-SX Multi-Mode SFP Module
• 1200481E1 1000Base-LX Single-Mode SFP Module
In this document, the term NetVanta 1230 means all of the units collectively. If a statement
only applies to one particular switch, the text refers to that switch individually.

Physical Descriptions NetVanta 1230 Series Hardware Installation Guide
14 Copyright © 2009 ADTRAN, Inc. 61700594G1-34B
This section includes a list of features, a list of shipping contents, and a description of the unit’s front and rear
panel designs. For additional information, refer to the following sections:
•Product Specifications on page 21
•Mounting Options on page 23
•Supplying Power to the Unit on page 25
For information on switch configuration for a specific application, refer to the quick configuration documents
provided on the AOS Documentation CD shipped with your base unit. For details on the command line interface
(CLI), refer to the AOS Command Reference Guide (also included on your CD).
NetVanta 1230 Series Shipping Contents
Each NetVanta 1230 units are shipped in their own cardboard shipping carton. Open each carton carefully, and
avoid deep penetration into the carton with sharp objects.
After unpacking the unit, inspect it for possible shipping damage. If the equipment has been damaged in transit,
immediately file a claim with the carrier and contact ADTRAN Customer Service (refer to the Repair and
Replacement section of the Support page on the ADTRAN website at http://www.adtran.com/support).
Domestic shipments of the NetVanta 1230 Series include the following items:
• NetVanta 1230 Series base unit
• AOS documentation bundle
• Rackmount brackets
• A detachable power cable with a grounded, three-prong plug
International shipments of the NetVanta 1230 Series include the following items:
• NetVanta 1230 Series base unit
• AOS documentation bundle
• Rackmount brackets
• All necessary power cords

NetVanta 1230 Series Hardware Installation Guide Physical Descriptions
61700594G1-34B Copyright © 2009 ADTRAN, Inc. 15
NetVanta 1234 Front Panel Design
The NetVanta 1234 front panel is shown below. Table 1 on page 20 describes all of the LEDs, and Appendix A
on page 27 shows the connector pinouts.
Figure 1. NetVanta 1234 Front Panel Layout
NetVanta 1234 Front Panel Features
Status LED
The STAT LED indicates the unit’s status and is located to the lower left corner of the unit.
CONSOLE Interface
The CONSOLE interface is an EIA-232 serial port (DCE) that provides for local management and
configuration (via a DB-9 female connector).
10/100Base-T Ethernet Interfaces
The NetVanta 1234 front panel contains 24 10/100Base-T Ethernet interfaces (RJ-45). These interfaces
are arranged in stacked pairs, with the numbers 1through 24 screened directly above or below the
corresponding port. Status LEDs numbered 1through 24 are located in the LED bank on the left side
of the unit.
10/100/1000Base-T Gigabit Ethernet Interfaces
The NetVanta 1234 front panel contains four 10/100/1000Base-T Gigabit Ethernet interfaces (RJ-45).
These interfaces are arranged in two stacked pairs, with the numbers G1 through G4 screened directly
above or below the corresponding port. Status LEDs numbered G1 through G4 are located in the LED
bank on the left side of the unit.
SFP Slots
The NetVanta 1234 front panel contains two standard SFP slots for fiber connectivity. These
interfaces, numbered G1 and G2, are associated with the Gigabit Ethernet interfaces numbered G1 and
G2 and share status LEDs. (Use either the RJ-45 connectors or the SFP slots. The fiber slots have
precedence.)
Connection directly to an external modem requires a cross-over cable.
G2
G3
G4
NetVanta 1234
7
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
G1
G2
G3
G4
1 3 5 9 11 13 15
246810 12 14 16
17 19 21 23
18 20 22 24
STAT
G1

Physical Descriptions NetVanta 1230 Series Hardware Installation Guide
16 Copyright © 2009 ADTRAN, Inc. 61700594G1-34B
NetVanta 1234 Rear Panel Design
The NetVanta 1234 rear panel is shown below.
Figure 2. NetVanta 1234 Rear Panel Layout
NetVanta 1234 Rear Panel Interfaces
Power Connection
The rear panel has a power input to the AC universal power supply. Please refer to Supplying Power to
the Unit on page 25 for connection details.
NetVanta 1234 PoE Front Panel Design
The NetVanta 1234 PoE front panel is shown below. Table 1 on page 20 describes all of the LEDs, and
Appendix A on page 27 shows the connector pinouts.
Figure 3. NetVanta 1234 PoE Front Panel Layout
NetVanta 1234 PoE Front Panel Features
Status LED
The STAT LED indicates the unit’s status and the LEDs are located on the lower left corner of the unit.
Mode Selector Button
The mode selector button is used to select the type of activity displayed on the LEDs labeled
1through 24. If LINK/ACT is selected, the LEDs display the link status/activity of the ports. If PoE is
selected, the LEDs display the status of PDs connected to the ports.
CONSOLE Interface
The CONSOLE interface is an EIA-232 serial port (DCE) that provides for local management and
configuration (via a DB-9 female connector).
10/100Base-T Ethernet Interfaces
The NetVanta 1234 PoE front panel contains 24 10/100Base-T Ethernet interfaces (RJ-45). These
interfaces are arranged in stacked pairs, with the numbers 1through 24 screened directly above or
below the corresponding port. Status LEDs numbered 1through 24 are located in the LED bank on the
left side of the unit.
Connection directly to an external modem requires a cross-over cable.
100-240 VAC
50-60 Hz
0.5A MAX
G2
G3
G4
NetVanta 1234
7
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
G1
G2
G3
G4
Power over Ethernet
1 3 5 9 11 13 15
246810 12 14 16
17 19 21 23
18 20 22 24
STAT
G1
LINK/ACT
PoE

NetVanta 1230 Series Hardware Installation Guide Physical Descriptions
61700594G1-34B Copyright © 2009 ADTRAN, Inc. 17
10/100/1000Base-T Gigabit Ethernet Interfaces
The NetVanta 1234 PoE front panel contains four 10/100/1000Base-T Gigabit Ethernet interfaces
(RJ-45). These interfaces are arranged in two stacked pairs, with the numbers G1 through G4 screened
directly above or below the corresponding port. Status LEDs numbered G1 through G4 are located in
the LED bank on the left side of the unit.
SFP Slots
The NetVanta 1234 PoE front panel contains two standard SFP slots for fiber connectivity. These
interfaces, numbered G1 and G2, are associated with the Gigabit Ethernet interfaces numbered G1 and
G2 and share status LEDs. (Use either the RJ-45 connectors or the SFP slots. The fiber slots have
precedence.)
NetVanta 1234 PoE Rear Panel Design
The NetVanta 1234 rear panel is shown below.
Figure 4. NetVanta 1234 PoE Rear Panel Layout
NetVanta 1234 PoE Rear Panel Interfaces
Power Connection
The rear panel has a power input to the AC universal power supply. Please refer to Supplying Power to
the Unit on page 25 for connection details.
NetVanta 1238 Front Panel Design
The NetVanta 1238 front panel is shown below. Table 1 on page 20 describes all of the LEDs, and Appendix A
on page 27 shows the connector pinouts.
Figure 5. NetVanta 1238 Front Panel Layout
NetVanta 1238 Front Panel Features
Status LED
The STAT LED, which indicates the unit’s status, is located to the lower left of the front panel adjacent
to RJ-45 port 2.
10/100Base-T Ethernet Interfaces
The NetVanta 1238 front panel contains 48 10/100Base-T Ethernet interfaces (RJ-45). These interfaces
are arranged in stacked pairs, with the numbers 1through 48 screened directly above or below the
corresponding port. Status LEDs for each stacked pair are located directly over the interfaces.
100-240 VAC
50-60 Hz
2.9A MAX
G2
G3
G4
NetVanta 1238
7
12 34 56 78 910 1112 13141516 1718 1920 2122 232425262728 2930 3132 3334 353637383940 41424344 45464748
1 3 5 9 11 13 15
246810 12 14 16
17 19 21 23 25 27 29 31
18 20 22 24 26 28 30 32
33 35 37 39 41 43 45 47
34 36 38 40 42 44 46 48
STAT
G1
G1 G2 G3 G4

Physical Descriptions NetVanta 1230 Series Hardware Installation Guide
18 Copyright © 2009 ADTRAN, Inc. 61700594G1-34B
10/100/1000Base-T Gigabit Ethernet Interfaces
The NetVanta 1238 front panel contains four Gigabit Ethernet interfaces (RJ-45). These interfaces are
labeled G1 through G4 and their status LEDs are located directly over the interfaces.
SFP Slots
The NetVanta 1238 front panel contains two standard SFP slots for fiber connectivity. These
interfaces, numbered G1 and G2, are associated with the Gigabit Ethernet interfaces numbered G1 and
G2 and share status LEDs. (Use either the RJ-45 connectors or the SFP slots. The fiber slots have
precedence.)
NetVanta 1238 Rear Panel Design
The NetVanta 1238 rear panel is shown below. Refer to Appendix A on page 27 for pinouts.
Figure 6. NetVanta 1238 Rear Panel Layout
NetVanta 1238 Rear Panel Interfaces
Power Connection
The rear panel has a power input to the AC universal power supply. Please refer to Supplying Power to
the Unit on page 25 for connection details.
CONSOLE Interface
The CONSOLE interface is an EIA-232 serial port (DCE) that provides local management and
configuration (via a DB-9 female connector).
NetVanta 1238 PoE Front Panel Design
The NetVanta 1238 PoE front panel is shown below. Table 1 on page 20 describes all of the LEDs, and
Appendix A on page 27 shows the connector pinouts.
Figure 7. NetVanta 1238 PoE Front Panel Layout
NetVanta 1238 PoE Front Panel Features
Status LED
The STAT LED, which indicates the unit’s status, is located to the lower left of the front panel adjacent
to RJ-45 port 2.
Connection directly to an external modem requires a cross-over cable.
100-240 VAC
50-60 Hz
0.5A MAX
G2
G3
G4
NetVanta 1238
7
1 2 3 4 5 6 7 8 9 10 1112 1314 15 16 1718 1920 2122 23 24 25 26 2728 2930 3132 33 34 35 36 3738 39 40 4142 4344 4546 4748
1 3 5 9 11 13 15
246810 12 14 16
17 19 21 23 25 27 29 31
18 20 22 24 26 28 30 32
33 35 37 39 41 43 45 47
34 36 38 40 42 44 46 48
STAT
G1
G1 G2 G3 G4
LINK/ACT
PoE
Power over Ethernet

NetVanta 1230 Series Hardware Installation Guide Physical Descriptions
61700594G1-34B Copyright © 2009 ADTRAN, Inc. 19
Mode Selector Button
The mode selector button is used to select the type of activity displayed on the LEDs labeled
1through 48. If LINK/ACT is selected, the LEDs display the link status/activity of the ports. If PoE is
selected, the LEDs display the status of PDs connected to the ports.
10/100Base-T Ethernet Interfaces
The NetVanta 1238 PoE front panel contains 48 10/100Base-T Ethernet interfaces (RJ-45). These
interfaces are arranged in stacked pairs, with the numbers 1through 48 screened directly above or
below the corresponding port. Status LEDs for each stacked pair are located directly over the
interfaces.
10/100/1000Base-T Gigabit Ethernet Interfaces
The NetVanta 1238 PoE front panel contains four Gigabit Ethernet interfaces (RJ-45). These interfaces
are labeled G1 through G4 and their status LEDs are located directly over the interfaces.
SFP Slots
The NetVanta 1238 PoE front panel contains two standard SFP slots for fiber connectivity. These
interfaces, numbered G1 and G2, are associated with the Gigabit Ethernet interfaces numbered G1 and
G2 and share status LEDs. (Use either the RJ-45 connectors or the SFP slots. The fiber slots have
precedence.)
NetVanta 1238 PoE Rear Panel Design
The NetVanta 1238 PoE rear panel is shown below. Refer to Appendix A on page 27 for pinouts.
Figure 8. NetVanta 1238 PoE Rear Panel Layout
NetVanta 1238 PoE Rear Panel Interfaces
Power Connection
The rear panel has a power input to the AC universal power supply. Please refer to Supplying Power to
the Unit on page 25 for connection details.
CONSOLE Interface
The CONSOLE interface is an EIA-232 serial port (DCE) that provides local management and
configuration (via a DB-9 female connector).
Connection directly to an external modem requires a cross-over cable.
100-240 VAC
50-60 Hz
5A MAX

Physical Descriptions NetVanta 1230 Series Hardware Installation Guide
20 Copyright © 2009 ADTRAN, Inc. 61700594G1-34B
Table 1. Front Panel LED Descriptions
LED Color Indication
STAT Off Power is off.
Green (flashing) Power up is in progress.
Green (solid) Power is on, power up is complete.
LINK/ACT Green (solid) Link status/activity mode selected.
PoE Green (solid) PoE mode selected.
Port LED in
Link/Activity Mode
(1- 24 NetVanta 1234)
(1- 48 NetVanta 1238)
Off The port is not connected.
Green (solid) The link is up.
Amber (flashing) The link is up and activity (transmit or receive) has occurred
on the port.
Port LED in
Link/Activity Mode
(G1 - G4)
Off The port is not connected.
Green (solid) The link is up.
Amber (flashing) The link is up and activity (transmit or receive) has occurred
on the port.
Port LED in PoE Mode
(1- 24 NetVanta 1234
PoE)
(1- 48 NetVanta 1238
PoE)
Off Powered device is not connected.
Green (solid) Powered device is connected.
Green (flashing) The port has detected a PoE fault.
Ports G1 through G4 are always in LINK/ACT mode.
