Advanced Illumination MicroBrite Series User manual

1
• Provides stable, diffuse, and even light source
• Used to evenly illuminate a variety of surfaces for color or
defect detection
• Available in four sizes: 50mm, 115mm, 180mm, and
280mm
0 - 60°C
Up to 2 meters (80”) long - 105°C rated PVC jacket, foil shield with drain.
L70 = 50,000 hours
Normal Operating Temperature
Weight (Kg)
Standard Cable Information
Photobiological Risk Factor
IEC 62471
Compliance
IP Rating
Lumen Maintenance
Electrical Specifications
Unavailable
IP40
Group 1 (Low-Risk) Applicable Wavelengths: 455, 530, 625, WHI
Color 24v Current (A)
All Other Controls (A Max)
Part Number
625 n/a 0.13
WHI n/a 0.22
455 n/a 0.22
530 n/a 0.22
625 0.7 0.32
WHI 0.7 0.54
455 0.7 0.54
530 0.7 0.54
625 1.4 0.64
WHI 1.4 1.08
455 1.4 1.08
530 1.4 1.08
625 1.6 0.74
WHI 1.6 1.24
455 1.6 1.24
530 1.6 1.24
DF198-050
DF198-115
DF198-180
DF198-280
For RGB draw, please see DCS-100E manual for power requirements.
1
1
Product Highlights
General Specifi cations
DF198
MicroBriteTM Series Ring Lights
Released 7/15/2015
Updated 5/2/2016

2
DF198
Released 7/15/2015
Updated 5/2/2016
DF198-050
DF198-115
DF198-180
DF198-280
(A)
Outer
Diameter
(B)
Inner
Diameter
50.0 (1.97)
(C)
Housing
Thickness
18.3 (0.72) 16.6 (0.66)
113.3 (4.46) 74.9 (2.95) 19.3 (0.76)
179.9 (7.09) 141.9 (5.59) 18.2 (0.72)
280.0 (11.02) 241.4 (9.50) 18.2 (0.72)
Part
Number
Model Size
in mm
Spectral
Wavelength
Connector/
Control
Alternative
Connector
DF198 XXX XXXXX XXX
DF198 050
115
180
280
455 (blue)
530 (green)
625 (red)
WHI (white)
RGB
C1
C5
IC
I3
I3S
24
M12
DF198-100WHII3
DF198-180625C1
Ex: Available with IC, I3, I3S and 24v options only
The 24v version will have a lower output intensity by ~10-15%
and operate at a temp ~10-15% higher than other options
Available with C1 option only
Not available with 24v option
1
1
2
2
3
3
4
4
Mechanical Specifi cations
Part Number Key
C1 Connector
For use with:
DCS Series
Controllers
C5 Connector
For use with:
Pulsar 320 Strobe
Controller.
IC
Continous in-line
controller
Powered with:
24V power supply
I3
Combination
strobe/continous
in-line controller
Powered with:
24V power supply
Build to Order: shipped in two weeks
DF198-100WHII3
Stock Product: shipped next day
Connector | Control Options
I3S
Default-OFF
strobe/continous
in-line controller
Powered with:
24V power supply
24
Flying/tinned leads
Powered with:
24V power supply

3
DF198
Released 7/15/2015
Updated 5/2/2016
Optical measurement taken using DF198-180WHII3 @ 100mm
Intensity Distribution
80-100%
60-80%
40-60%
20-40%
10-20%
0-10%
Working Area (FWHM)
@ Working Distance Light Output
@64 (mm)
@100 (mm)
@300 (mm)
188 (mm)
198 (mm)
371 (mm) Irradiance (W/M²): Min 17.2; Typ 20.3
Illuminance (kLux): Min 5.9; Typ 7.0
Irradiance (W/M²): Min 87.8; Typ 103.3
Illuminance (kLux): Min 30.6; Typ 36.1
Irradiance (W/M²): Min 110.5; Typ 130.0
Illuminance (kLux): Min 39.9 ; Typ 47.0
Optical Performance
Working Distance (mm) Irradiance (klux) Illuminance (W/m2) Part Number
12.7 703 223
300 4.2 1.5
50 94.2 32.7
100 42.6 14.6
300 5.9 2.1
64 130 47
100 103.3 36.1
300 20.3 7
100 62.5 22.7
200 41.4 14.5
300 23.8 8.2
DF198-180
DF198-280
DF198-115
DF198-050
FWHM Diameter (mm)
33.0
100 37.2 12.3 83.8
114.3
114.3
142.2
317.5
188.0
198.1
370.8
315.0
340.4
403.9
Area of Illuminance & Intensity for All DF198-WHI
Area of Illuminance & Intensity for DF198-180WHI
=25mm

4
DF198
Released 7/15/2015
Updated 5/2/2016
This product was tested and complies with the regulatory requirements and limits for electromagnetic compatibility
(EMC) as stated in the product specications. These requirements and limits are designed to provide reasonable
protection against harmful interference only when the product is operated in its intended industrial electromagnetic
environment. To minimize the potential for electromagnetic interference or unacceptable performance degradation,
install and use this product in strict accordance with the instructions in the product documentation.
Every Advanced illumination, Inc. (Ai) product is thoroughly inspected and tested before leaving the factory.
Products are warranted to be free of defects in workmanship and materials for a period of two years from the
original date of purchase. Should a defect develop during this period, please contact Ai Customer Service or your
Ai distributor for a Return Merchandise Authorization (RMA), and return the complete product, freight prepaid, to
Ai. If a defect is found, Ai will - at our discretion - repair or replace the product without charge. Ai claims no liability
for any implied warranties, including “merchantability” and “tness for a specic purpose.”
Warranty Information
Electromagnetic Compatibility
Operation and Wiring
Optional M12 Pinout
2
4
1
5
3
male
5-position
Pin
(M12)
Function Wire
Color
1 +24 VDC Brown
2 N/A White
3 GND Blue
4 N/A Black
24 Volt
PNP/Active High
Trigger
Pin
(M12)
Function Wire
Color
1 +24 VDC Brown
2 Reserved White
3 GND Blue
4Black
0-10 VDC Analog
Control
5Gray
ICS 3 (I3 and I3S)
Pin
(M12)
Function Wire
Color
1 +24 VDC Brown
2 GHI White
3 GND Blue
4 GLO Black
ICS 2 (IC)
5 N/A BlackN/A

5
DF198
Released 7/15/2015
Updated 5/2/2016
For information on existing orders, or to make an order adjustment, contact us Monday through Friday 8:00 am to
5:00 pm, ET or send an email to [email protected].
Customer Service
Company Information
Advanced Illumination
Email: [email protected]
Web: advancedillumination.com
© 2015 Advanced Illumination Inc. All rights reserved
440 State Garage Road, Rochester VT. 05767
Phone: [phone]
Fax: [phone]
