IDEO TABLE FRAME
ASSEMBLY INSTRUCTIONS – OAK LEGS
1.00 2.00
4.00
3.00
5.00 6.00
01 - Insert two legs in the upper frame pins.
01 - Insert the other two legs into the frame pins, and at the same time
insert the lower frame inside the legs holes
01 - Insert lower frame into the legs holes
.
01 - Fix the screws VTCB630 to block the legs to the upper frame.
01 - Fix the plane to the upper frame with screws VTBEI635N, pay
attention to put something under the plane to avoid scratch .
INSERTION THE FIRST TWO LEGS INSERTION OF THE REINFORCEMENT CROSS
INSERTIONOF THE LAST TWO LEGS WITH REINFORCEMENT CROSS
ASSEMBLY OF THE LEGS WITH UPPER FRAME ASSEMBLY OF THE TABLE TOP
ASSEMBLY OF THE REINFORCEMENT CROSS
01 - Screw by hand the 4 knobs and block the legs

www.advanta.com.au
1800 800 980
[e-mail] Seating Australia Since 1984
IDEO ROUND TABLE FRAME
ASSEMBLY INSTRUCTIONS – STEEL LEGS
1.00
3.00
2.00
INSERTION OF THE LEGS ON THE LOWER CROSSPIECE
01 - Insert legs in the bottom cross frame, pay attention to align the holes.
FIXING THE STRUCTURE FIXING OF THE TABLE TOP
INSERTION OF THE LEGS ON THE UPPER FRAME
01 - Insertion of the legs on the upper frame.
01 - Fix the cross frame to the legs with screws VTSPEI512Z,
fix legs to the upper frame with screws VTSPEI612N.
4.00
01 - Fix the plane to the upper frame with screws, pay attention to put
something under the plane to avoid scratches.
Table top Screw VTCB630
30 mm
10 mm
Table top Screw VTBEI635N
35 mm
30 mm
!
