Advantage Controls GF Manual

1
Manual
Model GF
Digital Glycol
Feeder
Installation
Maintenance
Repair
Manual
Advantage Controls
P.O. Box 1472
Muskogee, OK 74402
Phone: [phone]
Fax: [phone]
www.advantagecontrols.com 6/2016

2
Table of Contents
I. Introduction .................................................................................................2
 II. ModelNumberingandGeneralSpecications............................................3
III. Installation...................................................................................................4
Electrical Wiring ...............................................................................4
Mounting Instructions.......................................................................4
Typical Installation and Measurements ............................................5
Start Up and Test Procedure / Recommendations...........................6
IV. Digital Front Panel Description ...................................................................7
V. Digital System Operation Overview ............................................................8
Description of Set Up Menu Screens...............................................8
Calibration........................................................................................9
Pressure Set ..................................................................................10
Clock Set........................................................................................ 11
System Set.....................................................................................12
Diagnostics.....................................................................................13
Level Set ........................................................................................14
VI. Parts List...................................................................................................15
VII. Digital Controller Wiring ............................................................................18
VIII. Troubleshooting and Maintenance............................................................19
IX. Warranty ...................................................................................................21
Reference Chart % Propylene Glycol.............................................................................22
Reference Chart % Ethylene Glycol...............................................................................22
I. Introduction
The Advantage Controls Glycol Feed Systems are design to regulate pressure in closed loop Hydronic
Heating and Cooling applications.
Advantage Controls micro-processor base controller reads a solid state pressure transducer, displays
system pressure, and uses a 16 character keyboard for the entry of control parameters. The micro-
processor has built in real-time clock and EEPROM back-up for all user settings, in case of power
interruptions. Setting for all functions are made using the keyboard, readings are displayed on a back
lit 16 character alphanumeric display.
Advantage Controls Glycol Feeders are stand alone pre-wired, pre-plumbed systems designed for ease
of installation. Our systems are mounted on a powder coated steel frame with anchor points.
AdvantageControlsModelDesignationallowsforawidevarietyofcongurations,operationandfunction
ofeachGlycolFeedSystemsthisisdependentonyourspecicmodelnumber.Pleasecheckyour
model number against the selection guide for better understanding of your system.
Please read this instruction manual to become familiar with your system.

3
II. ModelNumberingandGeneralSpecications
BUILD A MODEL GF - __ __ __ __ __ __ - __ __
TANK SELECTION
0 = No tank
1 = 55 gallon poly
2 = 100 gallon poly
3 = 30 gallon poly
7 = 150 gallon poly
STAND SELECTION
A = Powder Coated steel stand
B = Powder Coated steel stand w/ mixer bracket
C = Tank top mount (no tank included)
D = Portable stand with built in rollers
PUMP SELECTION
*Dual pump sys. require 2 pump selections (i.e., -11)
0 = No pump
1 = 1.5 gpm at 100 PSI; 1/3 hp
2 = 3.75 gpm at 100 PSI; 1/2 hp
3 = 6.1 gpm at 60 PSI; 1/3 hp
4 = 9.9 gpm at 60 PSI; 1.5 hp
5 = 30 gpd at 100 PSI; solenoid driven
PUMP CONFIGURATION
A = Standardconguration
B = Alternating pumps for single loops
(requires 2 pump selections)
C = Pump plumbed for transfer duty into tank
LOOP SELECTION
*Dual loop sys. require 2 loop selections (i.e., -11)
0 = No loop
1 = Sch 80 PVC loop; 100 PSI max; 100°F max
2 = Copper/brass loop; 100 PSI max; 180°F max
3 = Carbon steel loop; 100 PSI max
CONTROL SELECTION
A = Digital controller w/ 0-100 PSI pressure transducer
for 30 gal & + sizes
D = Pressure transducer, level wand and pump
starter relay for use with separately ordered
MegaTron or XS with 4-20mA input ability
F = Digital controller for dual loops with two sensors
OPTIONS
1 = 240V
2 = 4-20mA output of pressure on digital controller
3 = Solenoid valve for pressure relief on digital units
4 = 30-50 PSI pressure switch for analog units
5 = Position backcheck to use tank for expansion
H = 1/4” PVC pipe instead of pump suction tubing
M = Mixer controls (order mixer separate)
Y = ETL approval (only on units with controller option D)
Most units include poly tank and stand, low
level switch with audible alarm (100db) with
silence switch, dry contact alarm, pressure
relief valve and plumbing assembly with
pressure gauge.
Digital models display the actual loop
pressure and allow for user settable control
points from a pressure sensor rated for 5-100
psi (0.3-6.9 bar). 16 character LCD, backlit
display. EPROM memory.

4
III. Installation
Electrical Wiring
The standard digital glycol feeder controller has an internal regulated power supply that will operate in the
range of approximately 100 to 250 VAC on the incoming wiring. Output relay(s) are protected with a
replaceable fuse. Each relay’s output voltage will equal incoming line voltage. The Standard prewired units
are supplied with a 8 foot, 16 AWG, 3 wire grounded, 120 VAC USA power cord for incoming power.
NOTE:Liquidtightttingsandlabeledsignalleadcablesareprovidedforallsignal(lowvoltage)
connections,lowdrumlevelandpressuretransducer.
WARNINGS:
1. Thecontrollershouldbeconnectedtoitsownisolatedcircuitbreaker,andforbest
results, the ground should be a true earth ground, not shared. Wiring must be done
according to all applicable local codes.
2. Power(linevoltage)mustbedisconnectedwhilemakinganyconnections.Ifpoweris
suppliedtotheunit,linevoltagewillbepresentontherelaycards.
3. Lowvoltagesignalwires(transducer,level,alarm,etc.)shouldneverberuninconduit
withhighvoltagewires.
Mounting Instructions
Select a mounting location that provides the operator easy access to the unit and a clear view of the controller.
The location should be convenient to grounded electrical connections and system plumbing connections.
Mount the glycol feeder stand to a level concrete pad using the ½” mounting holes in the base of the stand.
Concrete pad construction and anchoring bolts must comply with local building codes. The required sample
line plumbing should be connected to the return header of the Hydronic system
WARNING:
Avoid locations that expose the controller to direct sunlight, vapors, vibration,
liquid spills or extreme temperatures; less than 0°F (-17.8°C) or greater than 120°F (50°C).
EMI(electromagnetic interference) from radio transmissions and electric motors can also
causedamageorinterferenceandshouldbeavoided.
!
!

5
Typical Installation and Measurements
System
Connection
Circulation Pump
B
A
E
Side View Shown
1/4” bolt hole drilled
3/4” from outside edge
Note: This is for mounting
holes only. Controller will
extend beyond this depth.
GLYCOL STAND FOOT PRINT
C
D
A B C D E
30gal
113.5L
23 ¾”
60.3 cm
51”
129.5 cm
27 ½”
69.8 cm
25 ½”
64.7 cm
30 ½”
77.4 cm
55gal
208.1L
27 ½”
69.8 cm
65”
165.1 cm
27 ½”
69.8 cm
25 ½”
64.7 cm
32”
81.2 cm
100gal
378.5L
31 ¼”
79.3 cm
66”
167.6 cm
37”
93.9 cm
35”
88.9 cm
38”
96.5 cm

6
Start Up and Test Procedure / Recommendations
1. Beforellingtank,besurethatthetankandthelterbowlarefreeofpackingmaterialandor
construction debris.
2. Check plumbing as it may have become loose from vibrations during shipping.
3. Fill Tank
4. Open isolation valve to system.
5. If there are no leaks verify that the pressure gauge agrees with system pressure. This value may
vary do to connection to Hydronic systems placement.
6. Before applying power to the controller, remove fuse from lower relay enclosure. (There will be two
(2) fuses on dual pump system) Reasoning behind this is, factory settings may not agree with your
system and this gives time for you to set your parameters before applying power to the pump or
pumps.
7. Apply power to your system. Plug it in.
8. Once you are familiar with the controller from either reading the instruction manual or trial and error.
Proceed with setting perimeters that are correct for your hydronic system.

7
DigitalFrontPanelDrawing
IV. Digital Front Panel Description
READ: 1x16 (1/4”) Alpha Numeric Display.
CONTROL: Relay 1, Relay 2 - HOA switches for control relays.
SETUP/RUNkey - System initializes into RUN mode. Press this switch to toggle the controller
from SET UP mode to RUN mode.
UP/DOWNarrows - Used to change the display from one line to the next. All menus are circular,
so when all items in a menu have been displayed, the display will return to the
originally displayed item.
ENTERkey - Used to access a menu and to log a changed value into the program.
CLEARkey - Used to clear numerical values from items being changed in the SET UP
mode.
DECIMALkey - Used at certain places to change a function or displayed items. For example,
when temperature is being displayed, pressing the DECIMAL key will change
the reading from Fahrenheit to Celsius or visa versa.
NUMERICALkeys - Used to enter new values in the SET UP mode.
ENTER
CLEAR
•
1
SET UP
RUN

8
V. DigitalSystemOperationOverview
MicroTron controllers have two modes of operation, RUN and SET UP. Both the RUN and SET UP menus
are circular. Pressing the DOWN key in either menu will display the next line of information on the display.
After the last item in a menu has been displayed, pressing the DOWN key will return the display to the top
line of that menu.
RUN MODE - This mode is for normal operation. The control relays will only be automatically activated
in this mode. In the RUN mode the display will read system values. If an alarm is present
thedisplayasheswiththealarmstatus.
The RUN menu will display values such as pressure, day, time, date and other values
depending upon the features present on the unit. The unit will automatically return to the
RUN mode if no keys are pressed for three minutes.
SET UP MODE - This mode is used to make adjustments to settings and readings on the controller. To
access the SET UP mode from the RUN screen, press the SETUP/RUN key. Use the up
or down arrow to scroll through the various SET UP menus. When you want to enter a
specicSETUPmenu,presstheENTERkey.OnceyouhaveenteredaSETUPsub
menu you will be able to step through that menu’s options with the down arrow key.
Relays may be forced on while in the SET UP mode. Press the desired relay test key to
forceiton.Pressitasecondtimetoturnito󰀨.OncetheunitreturnstotheRUNmode,
relays will activate automatically.
Description of SET UP Menu Screens
The SET UP menu is the main menu circle of set up sub-menus used to customize your unit to the particular
parameters needed for your installation. Listed on the following pages is a description and menu map of each
SET UP menu.
NOTES:
1. Depending upon your model number, your unit may not use all of the SET UP options listed.
2. AfteryoupressENTERorCLEARtochangeanumericalvalueintheSETUPmenu,usethe
numberkeystodenethenewvalue.PressENTERagaintoenterthenewvalue.
3. When entering new numeric values, all available digits (characters) must be entered.  The
numberofavailabledigitsdependsuponthescaleofoperation.Positionofcursorindicates
number of digits to be entered.
 Forexample,whenenteringaruntimevalueforatimerintheminuteandsecondsscale(10:30
wouldequal10minutesand30seconds).Youwouldneedtokeyinanumberof0030tomake
it0(zero)minutesand30seconds.

9
-- CALIBRATION --
CALIBRATE XXX psi
(DAGF-2 systems have additional options.
Continue cycling down for each system.)
To change pressure reading
To accept value keyed in
using number keys
CAL. FACTOR
(Read only for diagnostics)
Return to CALIBRATION screen
CALIBRATION
This menu is used to change the display system
pressure. After the unit is properly installed and when
power is supplied to the controller, the display will read
PRESSURE XX psi. This will be the system pressure
of the closed loop. A dual system controller will display
P1 XX psi, and P2 XX psi, with P1 representing closed
loop system 1 pressure and P2 representing closed
loop system 2 pressure.
Press the Setup/Run key, and the display will read
CALIBRATION, press CLEAR. The display will read
calibration, followed by the current system pressure.
To change this reading, press ENTER, and key in the
correct psi reading. (note: you must enter three digits,
as in 52 psi would be entered as 052. Press ENTER
to accept the calibrated pressure entry.
CAL. FACTOR - This is a relative number used in
diagnostics.
Normal Cal. Factor on valve is between 900-1500.
Extreme values - above 1500 or below 800.
CLEAR
ENTER
ENTER

10
-- PRESSURE SET (1 & 2) --
CUT-INXXX psi
(DAGF-2 systems have two separate
PRESSURE SET menus.)
To change cut-in pressure
To accept value keyed in
using number keys
CUT-OUT XXX psi
To change cut-out pressure
To accept value keyed in
using number keys
RELIEF TRIP (Set to “0” to disable)
To change high alarm setting
To accept value keyed in
using number keys
RELIEF DIFF XXX psi
Tochangereliefdi󰀨pressure
To accept value keyed in
using number keys
LIMIT TIME H:MM (Set to “0” to disable)
To change limit time
To accept value keyed in
using number keys
RELAYDELAY :SS (Set to “0” to disable)
To change relay delay
To accept value keyed in
using number keys
Return to PRESSURE SET screen
CLEAR
ENTER
PRESSURESET(1&2)
This menu is used to used to set the on and o󰀨
pressures for the pump (or pumps in the case of a
dual system). From the Run mode, press the Setup/
Run key. Press the down arrow until the display reads
PRESSURE SET (or P1 set for a dual controller).
Press ENTER. The display will read CUT-IN XX psi.
Press CLEAR, and use the numerical keypad to key in
the psi value at which you want the pump to activate
(note: you must enter 3 digits as above).
Press ENTER to accept the new value.
Use the down arrow to scroll to CUT-OUT XX psi.
Press ENTER. Press CLEAR, and key in the psi value
atwhichyouwantthepumptoshuto󰀨.PressENTER
to accept the new value.
Note: Cut-out pressure must be at least 5 PSI greater
than Cut-in pressure.
Press the down arrow, the display will read RELIEF
TRIP XX psi. If this is set to something other than
000, the unit will activate a second relay within the
controller when the relief trip point is exceeded (over
pressure). To set, press CLEAR, then use the number
keys to key in the desired trip point value.
Press ENTER to accept the new value.
RELIEF TRIPS: 55 psi for High Pressure
30 psi for Low Pressure
Press the down arrow, the display will read LIMIT
TIME X:XX. If this is set at anything other than 0:00,
the pump will only be allowed to run for the amount
of time set. This is to prevent possible damage to
the pump in the event of malfunction. To change the
limit time, press CLEAR, then use the number keys
to key in the desired limit time value. Press ENTER
to accept the new value. Press the down arrow, the
display will read RELAY DELAY XX. This function is
for slowing the response of system pressure reading,
delaying the relay action where your system pressure
is somewhat erratic.
ENTER
CLEAR
ENTER
DUALPUMPOPERATIONFORONEPLUMBINGLOOP(OPTIONB)
MicroTron digital glycol feeders with option B include a redundant glycol feed pump. By default,
pump #1 will be the active pump. To select pump #2 as the active pump, perform the following steps:
1. Using the front panel keypad, press the HOA
key labeled RELAY #1 or the HOA key labeled
RELAY #3. The display will read OUTPUT:
PUMP 1 (or OUTPUT: PUMP 2 if pump #2
had been previously selected).
2. Press the ENTER key to toggle the
activation mode between pump #1 and
pump #2.
3. Press the SETUP RUN key to accept the
pump selection and return to the normal
operating mode.
CLEAR
ENTER
CLEAR
ENTER
CLEAR
ENTER
CLEAR
ENTER

11
-- CLOCK SET --
SET TIME XX.XX (HH.MM)
To change time
To accept value keyed in
using number keys
SET DATE XX.XX.XXXX (MM.DD.YYYY)
To change date
To accept value keyed in
using number keys
SETDAY (Sunday-Saturday)
To change day
To cycle through day options
To set day
Return to CLOCK SET screen
CLOCK SET
This menu is for adjusting the time, date and day of
the week.
After entering a new value, hit the ENTER key to
accept the value and advance.
The clock time is based on a 24 hour clock. So, a time
of 1:00 pm would be shown as 13.00.
NOTES:
 Ifunitdoesn’thaveabiocidetimer,there 
 willnotbeaSETDAYselection.
ENTER
CLEAR
ENTER
CLEAR
ENTER
ENTER
ENTER

12
-- SYSTEM SET --
PASSWORD XXXX
To change password
To accept value keyed in
using number keys
PROPORTIONAL OUT
STRAIGHT OUT
ZERO IN XXX psi
(Read only for diagnostics.
DAGF-2 systems have additional options.
Continue cycling down for each system.)
UNITS: PSI
UNITS: BAR
Return to SYSTEM SET screen
SYSTEMSET
Thismenuisusedtocongurethecontrollertospecic
operational needs. All of the items in this menu may
not apply depending on the controller model but will
always be present.
NOTE:Donotusethismenutomakecalibration
adjustments. Use the Calibration screen. Some
features disabled and does not apply on this
model.
PASSWORD - If a value of 0000 is entered, a password
is not required. If a password is entered, it must be
usedtooperatethecontroller.Iftherstdigitiszero,
relays may be activated without a password.
ZERO IN - CAUTION! This this function is used
only when there is zero or no pressure at the sensor
(Pressure Transducer). If ENTER BUTTON is pushed
when there is pressure at the sensor the accuracy
of the controller will be greatly e󰀨ected.  Refer to
troubleshooting section at end of manual.
ENTER
CLEAR
ENTER
ENTER
ENTER

13
-- DIAGNOSTICS --
MODEL # DAGF
FIRMWAREV.(n)
TESTDISPLAY
Displaywillash(allspacesshould
light)pressENTERagaintonish
test
TESTKEYPAD
Key on keypad pressed,
corresponding number appears
on display, ENTER to quit
RESET CALIBRATE
If pressed resets calibrations to factory
default
MAX PSI: XXX
Press CLEAR to change
pressure scale
Use numerical keys and then
press ENTER to accept
OUTPUT Pump 1
(Only on DAGF-1 systems.)
T oggles between pumps
Return to DIAGNOSTICS screen
ENTER
DIAGNOSTICS
This menu is used to select, enter and test the following
items.
MODEL NUMBER - Read only screen.
FIRMWARE VERSION NUMBER - Read only screen.
Have both available for service
TEST DISPLAY - Press ENTER and all pixels will
ash.Makeavisualchecktoseethatallpixelsarelit.
TEST KEYPAD - Press ENTER, then press each
individual key to test its function. NOTE: Pressing the
SET UP/RUN key returns display to the main menu.
Pressing ENTER again returns to TEST KEYPAD.
RESET CALIBRATE - CAUTION! Pressing ENTER
Button here will reset calibration data to factory
defaults. You will need to reset or verify all setting
after doing this.
MAX PSI: XXX - This allows you to set the maximum
psi. The max setting should correspond to the max
pressure rating of the transducer. On the standard
model, this is 100 psi. This setting allows the controller
to be used with pressure transducers with “other”
output ranges. Press CLEAR to change the pressure
scale. Use numerical keys and then press ENTER to
accept.
OUTPUT Pump 1 (DAGF-1 models only)
This is used in conjunction with feeders with Option
B, dual pump system. This allows the operator to
switch from pump one to pump two when option E is
specied.
ENTER
ENTER
ENTER
CLEAR
ENTER

14
-- LEVEL SET --
LEVEL ONE ENABLED
LEVEL ONE DISABLED
LEVEL ONE: NO PUM P
LEVEL ONE: PUMP OK
LEVEL TWO ENABLED
LEVEL TWO DISABLED
LEVEL TWO: NO PUMP
LEVEL TWO: PUMP OK
LEVEL THREE ENABLED
LEVEL THREE DISABLED
LEVEL THREE: NO PUMP
LEVEL THREE: PUMP OK
LEVEL FOUR ENABLED
LEVEL FOUR DISABLED
LEVEL FOUR: NO PUMP
LEVEL FOUR: PUMP OK
Return to LEVEL SET screen
LEVEL SET
LEVELENABLE-Enable and Disable options allow
for the activation or deactivation of the control logic
that governs the input of the level wand(s). Up to four
level wands can be used simultaneously.
LEVEL: PUMP - Each level wand, in the Enabled
state, can be used to control the high voltage relay
output(s) of the controller.
When the “No Pump” option is selected, by pressing
ENTER on the keypad, the high voltage relay output(s)
will deactivate upon the level wand being triggered.
When the “Pump OK” option is selected, by pressing
ENTER on the keypad, the high voltage relay output(s)
will not deactivate upon the level wand being triggered
but an alarm message will appear on the display of the
controller that reads: Possible Dry Pump.
Note: Levels 2, 3 and 4 are a built in function of the
MicroTron control platform. Not used on glycol feeder
models.
ENTER
ENTER
ENTER
ENTER
ENTER
ENTER
ENTER
ENTER

15
VI. Parts List
Parts List
1. Level wand for 30 gl = ALL-S30; 55 gl = ALL-S42
2. Tank lid for 30 gl = LID-30-C1D; 55 gl = LID-55-C1D
3. Tank for 30gl = AGF-APCT-30; for 55 gl = AGF-APCT-55
4. Pressure relief valve = AGF-PRV
5. Controller (for selection A) = DALL-GF-V
6. Isolation valve = BV-3/4 for PVC; GV-3/4 for copper
7. Back check = CKV-3/4PP for PVC; CKV-3/4B for copper
8. Pressure gauge = AGF-PG
9. Pressure transducer = AGF-PTD
10. Suction shut-off and strainer assembly = AGF-SUCTION
11. Pump = 991F41 (for selection 1); 992MJ07 (for selection 2)
1
2
3
4
5
6
7
8
11
10
6
9
Note: This list covers most of our popular models.
For models not covered, consult factory.

16
17
Note: Dual Digital Glycol Feeders utilize one controller monitoring two separate pressures sensors. The
menu will have additional selections for each function. Both pressure readings will be displayed in the Run
screen: "P1: 060 P2045 psi".
DualDigitalGlycolFeeder(WCD-370302)
No. 530
Calibrated Pressure Relief Valve
Features
A calibrated adjustment feature for setting the valve to the relief pressure required.
All Bronze construction
All stainless steel springs
Specifications
Sizes ½” and ¾” (15 and 20 MM)
Inlet (bottom) is male threaded, NPT
Outlet (side) is female threaded, NPT.
Design
Wats No. 530 is spring operated bronze relief valve designed to be used
as protection against excessive pressure of water, oil or air.
This device is designed for emergency safety relief and shall not be used
as an operation control.
Buna-N disc on machined body seat.
Application
Ideally suited as a by-pass thermal expansion relief valve.
There are a wide variety of applications where the valve is used as a
protective device. One such application would be on various pipelines.

17
19
Parts List

18
VII. Digital Controller Wiring
RED
BLK
B W
R COM
B N.O.
N.C.
R W W
G B
W
G B
R W W
G B
W
G
B
B W
R COM
B N.O.
N.C.
R W W
G B
W
G
B
B W
R COM
B N.O.
N.C.
(Pump #1)
(Pump #2)
(Controller)
(Controller)
Pressure Sensor Dual Loop or Single Loop
with 2 pumps - Fuse Box
Single Loop - Fuse Box
Conduit Layout for LCD Display
2 1
10
9
Low Level
Wand
Pressure
Sensor
Relay
Ribbon
Cable
Power
Screen
Contrast
Low Level
Wand 2
(dual unit model)
Pressure
Sensor 2
(dual unit model)
Red
Black
Red
Black
Black
Red
Black
Red
Pump 1
POWER SUPPLY
Relay / Power Card (REV D)
Green (-12)
White (+5)
Red (+12)
Black (Gnd)
FUSE
FUSE
FUSE
FUSE
FUSE
1
24
N.O N.C NET GRD
N.O N.C NET GRD
N.O N.C NET GRD N.O N.C NET GRD
N.O N.C NET GRD
H N G
POWER INPUT
Ribbon Cable
1
2
9
10
Solenoid
(on single
pump)
Pump 2
(on dual pump )
Solenoid #1
on dual
pump
Solenoid #2
on dual
pump
Dry Contact
54321
Logic Board Relay / Power Board

19
VIII. Troubleshooting&Maintenance
The Advantage Glycol Feeder is designed for many years of trouble free operation. Should a problem occur,
refer to the following chart to help identify the problem. If replacement is required, follow the procedures
listed in the Warranty and Factory Service portion of this manual.
NO POWER TO UNIT, POWER PRESENT AT RECEPTACLE
This happens if the power cord is tripped over or gets caught and pulled by accident.
1. First disconnect plug from live receptacle.
2. Next you will need Phillips #2 driver to remove face plate
 3. Faceplatesaresnugttinganditmayrequireasmallstandarddriverintheslotatthesideofthepaneltoget
it moving.
4. Once the panel is free, let it hang down out of view of the enclosure opening.
5. Locate the connector inside of the enclosure for power this is a GREEN three (3) terminal with screw downs.
6. Reconnect to RELAY / POWER BOARD (Drawing on page 20)
7. Before replacing the panel, do a quick visual of all connections and wiring to ensure no other damage has
occurred.
8. Replace panel and secure.
9. Plug in power cord and proceed with Start-up.
10. Your power issue was not corrected.
Record Model /Serial Numbers and Call Customer Service 1 [phone].
PUMP WILL NOT RUN. BLOWS FUSE WHEN ENERGIZED
This usually is cause by having some debris in the gears of the pump.
1. Before removing the pump head loosen the six head screw a half turn.
2. Replace blown fuse and energize pump.
3. If this corrects issue, de-energize pump, tighten six screw, proceed with Star-Up.
4. If this doesn’t solve issue the pump head should be removed and inspected for particles.
Because of tolerance in the gears it doesn’t take a big particle to freeze the motor.
5. Before removing the head be sure to close the suction line valve.
6. It is not necessary to remove tubing.
7. Remove the six (6) head screws.
8. Be aware of the seal ring as you remove the head.
 9. Withyourngersturnthegearstoinsurethatthemotorisnotseized.
10. If the gears turn freely you may power the pump for a short period to prove rotation.
11. If the gears do not turn freely, but they do turn, try powering the pump for short period.
12. If there is rotation. Replace the Pump Head, being careful to align gasket.
13. If the pump motor is frozen, it is best to replace the entire pump.
PUMP DOES NOT RUN WHEN INDICATOR IS ILLUMINATED
1. Check fuse and that the fuse holder cap is secure
2. Check pump wiring.
 3. Checklevelofuid/depthoflevelwand.
 4. Doespowerdownandupxissue?
• If Yes, there is a limit time set in the PRESSURE SET Menu.
• If No, the most likely cause is a loose wire inside of control enclosure. (See NO POWER TO UNIT, POWER
PRESENT AT RECEPTACLE 1 thru 10 above)
PUMP DOES NOT SHUT OFF WHEN TANK IS EMPTY
1. First verify that in LEVEL SET Menu that level one(1) is active.
2. Level is not Active, press enter to change to active. This should end issue.
3. Level is Active. Disconnect level wand connection. Alarm should sound and pump stop.

20
  •IfYes,inspectendoflevelwandfordebrisordamage,replaceifneeded.(Theoatatbottomofthewand
should have free movement, up and down.
• If No, inspect wire for damage. If no damage visible inspect internal wiring. (See NO POWER TO UNIT,
POWER PRESENT AT RECEPTACLE 1 thru 10 above)
4. If no resolution is found, record Serial / Model numbers and call customer service
LOW LEVEL ALARM STAYS ON
1. Disconnect level wand connection and short across connectors with screw driver. (this is low voltage and not
dangerous)
 2. Thisturnso󰀨thealarm.Thereisaproblemwiththewanditself.
 3. Inspecttheoatendofthelevelwand.
 4. Iftheoatisfreemovingreplacewand.
 5. Shortingtheconnecterdoesnotturno󰀨alarm.Inspectinternalwiring.(SeeNO POWER TO UNIT, POWER
PRESENT AT RECEPTACLE 1 thru 10 above)
6. Still no resolution record Model / Serial numbers and call customer service.
READING ZERO WILL NOT CALIBRATE
1. Isolate glycol feeder from system pressure by closing isolation valve.
2. Release pressure at the sensor by either valve or loosening union.
3. With pressure at zero press ENTER.
4. Controller will than display CALIBRATE.
5. Open Isolation Valve to reestablish pressure to Sensor.
6. Press enter and key in correct pressure.
7. Press enter key and the correct value should display after brief moment.
Maintenance
Maintenance and care will depend upon the usage and environment in which the system is subjected to.
The following is the suggested regular maintenance required to keep the glycol feed system operating
properly:
TANK AND PLUMBING
Periodically check the piping and tubing to insure proper discharge of the glycol solution. The strainer
should be periodically checked for clogging and wear. The level wand should be removed and cleaned to
prevent clogging.
GEAR PUMP
Check for proper operation. If any pump/motor noises, leaks or changes in operation are detected, the
pumpshouldberemovedandexaminedbyacertiedtechnician.Gearpumprepairscanbedi󰀩cultand
shouldonlybeattemptedbyqualiedpersonnel.Improperrepairsorassemblycanresultinpumpfailure
andnullicationofthewarranty.Nolubricationisrequired.
PRESSURE RELIEF VALVE
Periodic checking and replacement of the adjustment seal is the only maintenance required.
