Advantage Controls RT Operating instructions

1
Manual
Series R
Model RT
Combination Metering Pump
Timer Controller
Installation
Maintenance
Repair
Manual
Advantage Controls
P.O. Box 1472
Muskogee, OK 74402
Phone: [phone]
Fax: [phone]
www.advantagecontrols.com
email: [email protected] 12/08

2
Model RT Pump
Instruction & Maintenance Manual
Table of Contents
Contents Page
I. Introduction ................................................................................3
Model Numbering.......................................................................3
II. Unpacking ..................................................................................4
III. Safety Considerations................................................................4
IV. Installation..................................................................................4
A. Mounting ...........................................................................4
B. Electrical ...........................................................................5
C. Chemical Injection Plumbing ............................................5
V. Start-Up......................................................................................8
A. Front Panel Description ....................................................8
B. Run Mode Explanation .....................................................8
C. Set-Up Mode Explanation.................................................8
D. Priming the Pump .............................................................9
E. Stroking Speed or Frequency ...........................................9
F. Stroke Lenghth .................................................................9
G. Calculating Output ............................................................9
VI. Feed Timer Options .................................................................10
VII. Menu Maps .............................................................................. 11
VIII. Maintenance ............................................................................12
A. Diaphragm Replacement ................................................12
B. Suction and Discharge Check Valve Replacement ........12
C. Liquid End Diagram ........................................................13
D. Pump Replacement Parts...............................................14
IX. Trouble Shooting Guide ...........................................................15
X. Warranty and Factory Service Policies ....................................17

3
I. Introduction
This manual covers all facets of operation of the Advantage MicroTron™ pump, including unpacking,
mounting, electrical and plumbing connection, and start-up. Safety, maintenance and repair, warranty, and
factory information is also provided. Please read this manual completely before proceeding. Observe safety
protocols and heed all warnings and precautions.
Model Numbering
MicroTron™ Series R pump model numbers dene the output, pressure and control functions present on a
particular pump. Your pump may be supplied with one or more of the options described in this manual.
To determine what features apply to your pump, check the model number label located on the pump.
Model Number Example R T 30 X 1 – P V C 1 - S
Control Function
T = Dual Biocide Timers,
Dual Percent Timers &
Dual Water Meter Pulse Timers
Output
30 = 30 gallons per day at 110 psi
55 = 55 gallons per day at 75 psi
15 = 15 gallons per day at 150 psi
17 = 17 gallons per day at 250 psi
Stop Function Options
X = Standard
D = Auto Stop
E = Flow Switch Assembly
G = Flow Switch
Voltage
1 = 115 volt with USA plug (standard)
2 = 220 volt no plug
3 = 220 volt with specied plug
L = 115 volt with US plug and no control relay pigtail
Pump Head Material
P = Glass-Filled Polypropylene (standard)
K = Kynar
V = PVC
S = Stainless
Seat Material
V = Viton (standard)
F = Teon
H = Hypalon
Check Ball
C = Ceramic (standard)
D = Ceramic single on discharge
S=Stainless
Tubing Connections
1 = 3/8” PE, models up to 150 psi (standard)
2 = ¼” PE, 250 psi models (standard)
P = ¼” MNPT
V = 3/8” Clear exible suction tubing
Special Options
S = 3-function injection valve
NOTE: This list represents our most popular options. If you have an option not covered, contact the factory
or your dealer for more details.

4
II. Unpacking
The MicroTron™ Model RT has been shipped as a complete package, ready for installation.
If the shipping carton shows any signs of damage, notify the shipping company immediately
upon receipt. Advantage Controls cannot be held responsible for damage from shipping.
Unpack the carton and insure the following items are present:
1. Model RT pump/controller 4. Injection tting
2. Suction, discharge and bleed tubing 5. Instruction manual
3. Foot valve and weight 6. A two wire cable
III. Safety Considerations
NOTE: All MicroTron™ pumps are primed with water before leaving the factory. If the
solution to be pumped is not compatible with water, disassemble the pump uid end before
use. After disassembly, thoroughly dry the pump head, valves, and seals before pump is
reassembled and used.
A. Chemical Compatibility
MicroTron™ metering pumps are designed to work with most liquid chemicals depending upon
your pump’s liquid end materials of construction. A chemical resistance chart is available for
determining specic compatibility with a wide variety of chemicals. If you have further
compatibility questions, contact Advantage Controls service department at 1-800-743-7431.
B. Safety and Preparation
Always wear the proper protective clothing and gear when working around chemicals and
chemical metering pumps. Safety glasses, gloves, and aprons are critical in preventing accidental
exposure to dangerous chemicals. Liquids under pressure can present a special hazard when
a line or seal is punctured resulting in the spraying of chemical many yards away. If a chemical
spillage occurs, consult the Material Safety Data Sheet (MSDS) for specic instructions regarding
the chemical being used.
IV. Installation
A. Mounting
The standard Model RT is prewired for easy installation. Select a secure mounting
location convenient to electrical and plumbing connections that is accessible by the
operator. Do not install the pump in a location where the ambient temperature
exceeds 120°F (50°C). The pump is suitable for most outdoor installations, shielding from
direct exposure to the elements is recommended. The properties of solutions to be
metered should also be considered concerning temperature changes and effects to poly tubing.
Accessory item R00225 (plastic mounting bracket) is recommend for a secure installation.

5
B. Electrical
1. The Standard MicroTron™ pump has a voltage regulated internal power supply capable
of operating in the range of approximately 95 to 135 VAC. Use a supply voltage of 100 to
120 VAC for best results. The 3-wire grounded plug must be used in a 3-wire wall plug.
2. With a 240 volt option, the MicroTron™ pump has a voltage regulated internal power
supply capable of operating in the range of approximately 195 to 260 VAC. Use a
supply voltage of 210 to 250 VAC for best results. Pump is supplied without a country
specic plug unless otherwise specied.
CAUTION: Never remove ground wire from plug!
3. Control relay output voltage is equal to incoming line voltage with a 5 amp fuse.
Notes: 1. An isolated circuit breaker with a true earth ground is highly
recommended to insure uninterrupeted operation.
2. Low voltage signal wire (water meter signal or probe wire) should
never be run in conduit with high voltage wire above 30 VAC.
C. Chemical Injection Plumbing
1. Piping Connections
The MicroTron™ pump uses carefully matched components to achieve a predictable
metering output. This predictability can only be maintained if all tting sizes remain
unaltered. Do not attempt to reduce tubing size. All tubing connections should be
double checked to insure against leakage. If hazardous chemicals are being pumped, use
shielding around discharge tubing.
NOTE: When cutting lengths of tubing for your installation, ensure a clean, square
cut. Use short lengths of tubing and as few connections as possible.
2. Tubing Nuts
Do not overtighten the tubing connectors. Tighten the ttings no more than 1/4 turn
after the tting contacts the seal. Hand tighten only. Do not use a wrench or pliers
as they may damage the ttings. Do not use Teon tape except on NPT ttings. Be
sure to observe applicable local plumbing codes.
WARNING: Clear exible tubing is not intended for pressurized use.

6
3. Tubing Connections
3/8"
1/4"
TUBING MUST SLIP OVER NIPPLE
1/4" TUBING
ADAPTER
IMPORTANT THE END OF THE TUBING
MUST EXTEND 1/4" BEYOND ADAPTOR
4. Suction Lift vs Flooded Suction Applications
Suction Lift Installation
Mount the MicroTron™ pump around the top of the solution tank, not to exceed 5 feet
from pump to bottom of tank.
Flooded Suction
This installation is recommended for very low outputs, solutions that gasify and/or high
viscosity solutions. Priming is easier and loss of prime is reduced. Failure of the pump
diaphragm or rupture of the solution tubing can cause loss of solution in the tank.
Suction lift Flooded Suction Not recommended

7
5. Foot valve installation
A weight is provided to hold the tubing and foot valve in a vertical position at the
bottom of the tank. Do not allow the foot valve to lay horizontally in the chemical
container. This defeats the action of the valve and causes the pump to lose prime.
Keep suction tubing reasonably short and avoid high spots or bends.
6. Injection valve installation
The injection valve is designed to prevent a back ow and to inject chemical into the
line. To work properly, this valve must be mounted within 45 degrees of vertical (see
drawing). One end of the injection valve is 1/2” MNPT. Install this end into the piping
system. Use Teon tape on this tting only. Connect the pump’s discharge tubing to
the opposite end of the injector. Do not use Teon tape or joint compound on this
tting. Connect tubing between this tting and the pump discharge tting at the pump
head.
80
Variation
Acceptable
Flow
DO NOT
Use Teflon Tape
On Machine Threads
USE
Teflon Tape On
These Threads Only
Injection
Check Valve
Pipe Cross
Section
NOTE: When installation is made into a line with zero pressure or when pumping into an
open vessel, use our three-function valve to prevent syphoning.
7. Optional Three Function Valve.
Anti-siphon feature allows metering of liquids “down hill” or into the suction side of
a circulating pump. It provides protection against an accidental application of suction
pressure at the uid injection point. Its Teon coated diaphragm provides a positive
anti-siphon action.
Back pressure function permits metering into atmospheric discharge (open container)
without overpumping.
Line check permits removal of discharge tubing without release of system uid.
8. Priming/bleed valve connection
Connect the clear poly tubing to the outlet of the bleed or priming valve. Position the
free end of this tube in the chemical container. Standard head congurations include a
priming valve built into the head. Clear poly tubing should be connected to the outlet of
this valve, the other end of the tube should be placed in the chemical container above
the uid level.

8
V. Start-Up
A. Front Panel Description
80
20
30
40 50 60
70
90
100
POWER PULSE
Press ENTER to test
Press MENU to access settings
MENU
ENTER
All Model R pumps come with the following standard panel
features:
• 1x16-backlit LCD display
• On/Off power indicator light
• Pulse or Stroke indicator light
• Up and Down arrow keys for setting
adjustments
• MENU key to enter and exit pump set-up
• ENTER key to save desired adjustments
B. Run Mode Explanation
The readout will display one of two modes, Run mode and Set-up mode. Run mode is
displayed only while the pump is in normal operation. The display will show the pump speed
setting.
Manual activation of the relay output and pump stroking can be activated by pressing the
ENTER key while the pump is in the run mode. This will manually activate both functions of
the unit for 3 minutes. After three minutes the unit goes back to automatic.
If the ENTER key is pressed during the 3 minute test, it will revert to automatic.
C. Set Up Mode Explanation
To enter Set-up mode, press MENU. Notice that a cursor appears on the screen signifying that
an adjustment can be made. To change the gure above the cursor press the UP or DOWN
keys until the desired setting appears, then press ENTER to advance. Continue pressing
ENTER to toggle past the other displays. When all settings are made, press MENU to return
to run mode, and save settings.
See Menu Map on Page 11.

9
D. Priming the Pump
1. Settings
Plug in pump, set stroke knob to 100%.
2. Priming/Bleed valve
If uid begins moving up suction line while pump is operating, no further
priming is required. If uid is not moving, open bleed valve approximately one
turn until uid begins to move. When suction line lls, close bleed valve. Do not
over tighten bleed valve. Damage may occur.
3. To prime the Advantage R pump simply press the ENTER key while the pump
is in Run mode. This allows the pump to stroke at the maximum STROKES/MIN
setting.
E. Stroking Speed or Frequency
The R pump allows for an exact number of strokes to be set and read on the front panel
LCD meter. It is adjustable from 0 to 125 strokes per minute (0 to 160 for 55 GPD).
In addition, for applications requiring very low outputs the speed can be set in strokes per
hour from 1 to 125.
F. Stroke Length
The stroke length can be adjusted on all MicroTron™ pumps. This adjustment is a
mechanical adjustment made using the large knob on the control panel. To avoid damage to
the pump, this adjustment should only be made while the pump is running at a high stroking
rate.
Always start adjusting your pump’s output down by reducing the pump’s stroking speed or
frequency. By leaving the stroke length as long as possible you decrease any chance of
loosing prime.
G. Calculating Output
A pump’s output per minute can be determined by dividing the maximum rated gallons per
day by 1440 (minutes per day). For example, a 30 gallons per day (gpd) pump at a maximum
stroke length and speed setting of 125 strokes per minute (spm) will pump 0.000167 gallons
per stroke (gps).
30 ÷ 1440 = 0.0208 gpm ÷ 125 spm = 0.000167
With this value and the pump’s speed setting (strokes per minute) you can calculate your
pump’s output at it’s rated pressure. A 30 gpd pump set at 50 strokes per minute:
50spm x .000167gps x 1440 (minutes per day) = 12.02 gallons per day
Reducing the stroke length will reduce the pump’s output again. If the example pump above
had it’s stroke length reduced to 50% the 12.02 gallons per day output is reduced to 6.01.
(example: 12.02 gpd x 0.50 = 6.01 gpd)
A higher product viscosity will reduce the output. Pressures lower than the pump’s rating can
increase the output.

10
VI. Feed Timer Options
Model RT pumps have the following selectable feed timer options.
A. Dual Biocide Timer
Model RT units have two 28-day event timers. Program 1 timer activates the pump to feed.
Program 2 timer activates the relay output.
See Menu Map on Page 11
B. Dual Percent Timer
Model RT units have two percent timers settable for 1-100% of a 5-30 minute repeating cycle.
Timer one controls the pump feed and timer two controls the relay output. These timers are
sequential in operation. Timer one will complete its cycle, then timer two follows.
See Menu Map on Page 11
C. Dual Water Meter Pulse Timer
Model RT units have two timers that can accept pulse from a single contacting head water
meter. Each timer can accumulate 1-100 contacts to activate the feed timer. Each timer can
be set from 0 seconds to 30 minutes and 59 seconds.
Timer one controls the pump feed and timer two controls the relay output.
NOTE: Model RT units come with a two wire cable connected to the pump for
connecting to a contacting head water meter in the make-up water line.
See Menu Map on Page 11

11
VII. RT Menu Map
Model RT
MENU MAP
Use the ARROW keys to change
options and the ENTER key to
continue to next menu item.
125 Strokes/Min
Timer Control? N
Timer Control? Y
New Pass: 0000
Software version 12.3
Pump: No Timer
Pulse1 Acc: 010
Plse1 Tmr = 00:30
Pump: Pulse
%1 = 010% of 30 M
Pump: % Timer
Biocide1 Day: All
Biocide1 Wk = All
Bio1 Start 12:30p
Bio1 Length 0:30
Pump: 28-Day
Timers Run: IND Timers Run: 1->2 Timers Run: 2->1
Clock Set? N Clock Set? Y
Monday, Week 1
January 1, 2007
Time 12:00:00pm
Relay: No Timer
Pulse2 Acc: 010
Plse2 Tmr = 00:30
Relay: Pulse
%2 = 010% of 30 M
Relay: % Timer
Biocide2 Day: All
Biocide2 Wk = All
Bio2 Start 12:30p
Bio2 Length 0:30
Relay: 28-Day
Grayed out menu
items are available
only when timers are
set independent
(Timers Run: IND).

12
VIII. Maintenance
The Advantage MicroTron™ pump is designed for long service life with minimum maintenance.
If for any reason, maintenance is necessary or desireable, the MicroTron™ pump is easily
maintained.
Before any maintenance or service is performed, observe the following precautions:
1. Disconnect the MicroTron™ pump from power source.
2. Drain chemical from discharge tubing.
3. Disconnect discharge tubing from pump.
4. If the MicroTron™ pump is used in a ooded suction application, remove foot valve
from chemical container.
5. Observe relevant safety protocols when handling parts which have been in contact with
hazardous chemicals.
A. Diaphragm Replacement
1. Remove uid end cover by lightly prying it loose from the uid end.
2. Remove the four screws attaching the uid end to pump body.
3. Remove the uid end from the pump body.
4. Unscrew the diaphragm from the pump shaft in a counter-clockwise direction.
Be careful that diaphragm support ring does not fall out.
5. Do not allow sharp or abrasive objects to come in contact with pump parts.
6. Inspect end of shaft to assure that threads are in good condition. Replace shaft bellows if
necessary. No further disassembly is recommended.
7. Screw new diaphragm onto pump shaft until it bottoms out on shoulder of shaft.
It is not necessary to tighten further.
8. Replace uid end. Make sure that screws are evenly tightened.
9. Reconnect plumbing and power. Prime the pump.
B. Suction and Discharge Check Valve Replacement
1. Disconnect suction tubing from pump.
2. Unscrew tting from pump head.
3. Remove check valve from suction tting and replace.
4. Remove O-ring from cavity in uid end.
5. Remove check valve from suction side pump and replace.
6 Install new O-ring in cavity of uid end.
7. Replace valve tting with check valve in uid end.
8. Replace uid end. Make sure that screws are evenly tightened.
9. Reconnect plumbing and power. Prime the pump.
NOTES: 1. Tighten pump head screws after pump’s initial week of operation.
2. When installing check valves, remember that the seats are always installed
at the bottom.

13
C. Liquid End Diagram
OR
2
OR
OR
5
14
8
9
10
4
3
OR
15
13
12
6
11
1
7
Item Description
1 Complete Head Kit
2 Injection Valve
3 Foot Valve
4 Suction Valve
5 Discharge Valve
6 Bleed Valve Assembly
7 Pump Head
8 Pump Diaphragm
9 Support Ring
10 Shaft Seal
11 Head Bolts
12 Priming Tube
13 Suction Tubing
14 Discharge Tubing
15 Weight
Complete Head Kit
includes items:
4,5,6,7,8, and 11

14
D. Replacement Parts
Getting the right materials of construction for your spare parts is easy. Using positions 7-10
of the pump model number, example: RT 30X1-PFCV.Find the assembly needed and add
the codes of your pump’s liquid end after the standard prex part number for the assembly.
Note: For standard pumps using the short model number (example: RT130) use the following liquid
end codes.
a. 110 psi models use -PVC1.
b. 250 psi models use -PVC2.
Part Assemblies
Item Description Part Number
1....................... Complete Head Assembly 110 psi....................................... CKR-1- __ __ __ __
......................... Complete Head Assembly 150 & 250 psi ............................... CKR-2- __ __ __ __
2....................... Injection Valve Assembly .............................................................. INJ- __ __ __ __
Optional ....... 3-Function Injection Valve............................................................ 3FV- __ __ __ __
3....................... Foot Valve Assembly .................................................................. FTV- __ __ __ __
4....................... Suction Valve Assembly.............................................................. SUC- __ __ __ __
5....................... Discharge Valve Assembly............................................................DIS- __ __ __ __
6....................... Priming Valve Assembly ...............................................................PRI- __ __ __ __
Body Seat Ball Connection
P- Glass-lled Poly V- Viton C- Ceramic 1- 3/8” Tube
K- Kynar F- Teon D- Single 2- 1/4” Tube
V- PVC H- Hypalon S- Stainless 3- 3/8” Tube
K- 3/8” Tube
P- 1/4” Pipe
U- 3/8” UV
V- 3/8” Clear Suction
Single Parts
7................. Pump Head 110 psi................................................................. R00026 - __
................... Pump Head 150 & 250 psi ...................................................... R00039 - __
8................. Diaphragm 110 psi .................................................................. R00007
................... Diaphragm 150 & 250 psi........................................................ R00006
9................. Support Ring 110 psi............................................................... R00069
................... Support Ring 150 & 250 psi .................................................... R00068
10............... Shaft Seal................................................................................ R00050
11...............Head Bolts............................................................................... R00045
12............... Priming Tubing ....................................................................... R00255
13............... Suction Tubing 3/8” Clear ....................................................... R00255
................... Suction Tubing 3/8” PE ........................................................... R00122
................... Suction Tubing 1/4” PE .......................................................... R00097
14............... Discharge Tubing 3/8” PE ....................................................... R00122
................... Discharge Tubing 1/4” PE ....................................................... R00267
15............... Weight, Suction Tubing ........................................................... R00139

15
IX. Trouble Shooting
PROBLEM CAUSE REMEDY
Pump does not achieve
or maintain prime
Air trapped in suction line
Foot valve contaminated or improperly
installed
Excessive lift
Suction ttings not properly tightened
Worn or contaminated check valves
Split or pinch in suction tube
Low chemical level
Straighten suction line so as to eliminate
high spots.
Inspect foot valve screen and assure that
foot valve is in a vertical position below
uid level.
Maximum suction lift is 5 feet with water or
uids of similar specic gravity; less with
heavier liquids such as acids. Mount pump
in a lower position relative to the chemical
container.
Check ttings. Overtightening may cause
restriction. Conversely, if any leakage occurs,
pump will suck air and fail to prime.
Inspect check valves in uid end for cleanliness.
Clean or replace as necessary.
Inspect suction tube through its full length
to assure that there are no splits at the
connections or other restrictions. Move
any objects or equipment which impinges
upon suction tube or reroute as required to
assure a smooth transition from foot valve
to pump.
Check uid level in chemical supply tank.
Insufcient uid Stroke adjustment set too low
Worn or contaminated check valves
Obstruction in suction line
Clogged foot valve screen
Output (system) pressure too high
Diaphragm worn or torn
Electronic failure
Check operation of stroke limiter knob.
If pump delivers too low adjustable rate,
check settings. Readjust as required.
Inspect, clean or replace as necessary.
Check suction line for obstructions, clogging,
kinks or pinch points.
Clean or replace foot valve screen.
Relocate the injector to a lower pressure part
of the the system.
Replace diaphragm, making sure that it is
screwed on fully to shoulder of shaft.
Consult dealer or factory.

16
Excessive uid Failure or lack of antisiphon valve
Excessive stroke rate
Improper stroke length
Inspect or add anti-siphon valve. This is
caused when system is in a vacuum condition
or valve in delivery applications with ooded
suction which feeds systems at very low
pressures.
Lower the stroke rate if adjustable on your
pump.
Reduce stroke length.
Pump will not pump System pressure too high
Diaphragm improperly installed
Check valves worn or clogged
Check system pressure to assure that it
is within system rated paramaters of the
pressure.
Make sure that diaphragm is screwed fully
unto shaft.
Clean or replace as required.
Pump will not run not
plugged in
Pump not turned on or not plugged in
Electronic failure
Check outlet with meter to assure that correct
or voltage is present and that power supply
cord is in good condition and plugged in.
Consult dealer or factory.
Excessive noise Pump not primed
No output pressure
Prime pump.
Add an anti-siphon valve to provide 25 PSI
restriction on pump discharge.

17
X. Manufacturer’s Product Warranty
Advantage Controls warrants units of its manufacture to be free of defects in material or
workmanship. Liability under this policy extends for 24 months from date of installation. Liability is limited to
repair or replacement of any failed equipment or part proven defective in material or workmanship upon
manufacturer’s examination. Removal and installation costs are not included under this warranty.
Manufacturer’s liability shall never exceed the selling price of equipment or part in question.
Advantage disclaims all liability for damage caused by its products by improper installation,
maintenance, use or attempts to operate products beyond their intended functionality, intentionally or
otherwise, or any unauthorized repair. Advantage is not responsible for damages, injuries or expense
incurred through the use of its products.
The above warranty is in lieu of other warranties, either expressed or implied. No agent of ours is
authorized to provide any warranty other than the above.
30 Day Billing Memo Policy
Advantage Controls maintains a unique factory exchange program to ensure uninterrupted service
with minimum downtime. If your unit malfunctions, call 1-800-743-7431, and provide our technician with
Model and Serial Number information. If we are unable to diagnose and solve your problem over the phone,
a fully warranted replacement unit will be shipped, usually within 48 hours, on a 30 Day Billing Memo.
This service requires a purchase order and the replacement unit is billed to your regular account for
payment.
The replacement unit will be billed at current list price for that model less any applicable resale
discount. Upon return of your old unit, credit will be issued to your account if the unit is in warranty. If the unit
is out of warranty or the damage not covered, a partial credit will be applied based upon a prorated
replacement price schedule dependent on the age of the unit. Any exchange covers only the controller
or pump. Electrodes, liquid end components and other external accessories are not included.

18
Application Notes:

19
Application Notes:

20
Get the Advantage in Water Treatment Equipment
Advantage Controls can give you the Advantage in products, knowledge
and support on all of your water treatment equipment needs.
 Cooling Tower Controllers
 Boiler Blow Down Controllers
 Blow Down Valve Packages
 Solenoid Valves
 Water Meters
 Chemical Metering Pumps
 Corrosion Coupon Racks
 Chemical Solution Tanks
 Solid Feed Systems
 Feed Timers
 Filter Equipment
 Glycol Feed Systems
 Pre Fabricated Systems
Get the Advantage
11,500
CONDUCTIVITY
uS/cm
