Advantech PAX-332 Series User manual

User Manual
PAX-332 Series
32” FHD True-Flat Medical Monitor

PAX-332 User Manual
Copyright
The documentation and the software included with this product are copyrighted 2021
by Advantech Co., Ltd. All rights are reserved. Advantech Co., Ltd. reserves the right
to make improvements in the products described in this manual at any time without
notice. No part of this manual may be reproduced, copied, translated, or transmitted
in any form or by any means without the prior written permission of Advantech Co.,
Ltd. The information provided in this manual is intended to be accurate and reliable.
However, Advantech Co., Ltd. assumes no responsibility for its use, nor for any
infringements of the rights of third parties that may result from its use.
Trademarks
All trademarks and registered trademarks are property of their respective owners.
Disclaimer
Although every attempt has been made to achieve technical accuracy in this manual,
we assume no responsibility for errors that may be found. Our goal is to provide you
with the most accurate and usable documentation possible. To assist us with
improving this manual, we welcome all comments and constructive criticism. Please
send all feedback in writing to suppor[email protected].
Important
Please read this user manual carefully to familiarize yourself with the correct, safe,
and effective usage procedures. Additionally, we recommend that you retain this
manual for future reference.
Importante
Lea detenidamente este manual del usuario para familiarizarse con los procedimien-
tos de uso eficaces y seguros. Conserve este manual para futuras consultas.
重要
ご使用前には必ず取扱説明書をよくお読みになり、正しくお使いください。 この取
扱説明書は大切に保管してください。
Part No.2008033212 Edition 3
Printed in China June 2021

iii PAX-332 User Manual
User Instructions
The document contains text and illustrations that provide a comprehensive overview
of the system. The text provides explanations and clear instructions in an easy-to-fol-
low sequence that instructs the user on the practical use of the product.
Additional Information and Assistance
Contact your distributor, sales representative, or an Advantech customer service cen-
ter for technical support should you require additional assistance. Be sure to have the
following information ready before calling:
Product name and serial number
Description of your peripheral attachments
Description of your software (operating system, version, application software,
etc.)
A comprehensive description of the problem
The exact wording of any error messages
Note: This equipment is a source of electromagnetic waves. Before use, ensure that
no EMI-sensitive devices at risk of malfunctioning are located in the surrounding
area.
Manufacturer
Advantech Co., Ltd.
No.1, Alley 20, Lane 26, Rueiguang Road Neihu District, Taipei,
Taiwan 114, R.O.C.
Tel: [phone]
Visit the Advantech website at www.advantech.com or www.advantech.com.tw for
additional information.

PAX-332 User Manual

v PAX-332 User Manual
Contents
Chapter 1 Introduction..........................................1
1.1 Introduction ............................................................................................... 2
1.2 Features .................................................................................................... 2
1.3 Specifications............................................................................................ 3
1.3.1 Display .......................................................................................... 3
1.3.2 Input/Output Terminals ................................................................. 3
1.3.3 General ......................................................................................... 4
1.3.4 Environmental ............................................................................... 4
1.3.5 AVAS - Advantech Video Archiving Solution (Optional) ............... 5
1.3.6 Input/Output Signal Connectors.................................................... 5
Chapter 2 Installation............................................7
2.1 Unpacking ................................................................................................. 8
2.2 System Controls........................................................................................ 8
Figure 2.1 PAX-332 Monitor Front View ...................................... 8
2.2.1 I/O Ports........................................................................................ 9
2.2.2 Display .......................................................................................... 9
2.2.3 OSD Key Functions ...................................................................... 9
2.2.4 Input/Output Signal Ports............................................................ 10
2.2.5 Interface on AVAS Back Panel ................................................... 11
2.3 Viewing Angle ......................................................................................... 11
2.4 Positioning............................................................................................... 11
2.5 Connecting AC/DC Power....................................................................... 12
2.6 Connecting Video.................................................................................... 12
Chapter 3 OSD Menu ..........................................13
3.1 OSD Menu Controls ................................................................................ 14
3.1.1 Display Mode .............................................................................. 14
3.1.2 Display Function ......................................................................... 15
3.1.3 Select Region.............................................................................. 16
3.1.4 Picture......................................................................................... 17
3.1.5 Analog (Option)........................................................................... 18
3.1.6 Color ........................................................................................... 19
3.1.7 Advance ...................................................................................... 20
3.1.8 Advance ...................................................................................... 21
3.1.9 Input ............................................................................................ 22
3.1.10 Audio (Option)............................................................................. 23
3.1.11 Other........................................................................................... 24
3.1.12 Information .................................................................................. 25
3.1.13 OSD Input Source....................................................................... 25
3.1.14 PIP Table .................................................................................... 25
Chapter 4 Safety Information .............................27
4.1 Symbols .................................................................................................. 28
4.2 FCC Compliance ...............................................28
4.2.1 Class A........................................................................................ 28
4.3 CE Marking ....................................................29
4.4 VCCI (Voluntary Control Council for Interference) ...................29
4.5 Disposal of Waste...............................................29

PAX-332 User Manual
4.6 Safety and Maintenance ......................................................................... 30
4.6.1 Radio Frequency ........................................................................ 31
4.6.2 Keep Away From Windows......................................................... 31
4.6.3 Storage Temperature.................................................................. 31
4.6.4 Image Persistence ...................................................................... 31
4.6.5 Placement and Adjustment of the Monitor.................................. 32
Appendix A Cleaning............................................. 33
A.1 Cleaning the LCD Panel ......................................................................... 34
A.2 Cleaning the Cabinet .............................................................................. 34
Appendix B Troubleshooting................................ 35
B.1 Non-Responsive Power Button............................................................... 36
B.2 No Picture ............................................................................................... 36
B.3 No Video ................................................................................................. 36
B.4 Image Persistence .................................................................................. 36
B.5 Unstable, Unfocused, or Swimming Image............................................. 36
B.6 Incorrect Display Image Size .................................................................. 36

Chapter 1
1Introduction

PAX-332 User Manual 2
1.1 Introduction
Advantech’s PAX-332 is a 32-inch TFT LCD monitor designed to serve as a medical
imaging display. With DICOM GSDF calibration and 14-bit gamma correction for
white balance, PAX-332 is optimized for displaying high-quality medical images and
videos.
1.2 Features
True flat design with AR filter (optional)
High brightness and high contrast ratio
Integral LED backlight system
Wide viewing angle
32-inch widescreen with full HD resolution
Wide input connectivity for maximum flexibility
HDMI 2.0 supports up to 1920 x 1080@60 Hz
DisplayPort 1.2 supports up to 1920 x 1080@60 Hz
SDI supports up to 1920 x 1080@60 Hz (optional)
DVI supports up to 1920 x 1080@60 Hz (optional)
Multi-standard video system supported: NTSC, PAL, SECAM (optional)
Multi-standard RGB (PC) monitor supports up to 1920 x 1080@60 Hz (optional)
Compatible with standard VESA mode and supports user-defined mode
Dual modality connectivity
Automatically detect input source to change signal
Video enhancement features
14 bit look-up table (LUT) processing
DICOM GSDF (part 14) compliant
DICOM Clear, Blue mode supported
Variable Gamma and DICOM (color temp) mode
Variable picture control
Variable image size
Variable multi-image display mode
Built-in Advantech AVAS module (optional)
Built-in Touch Screen (optional)

3 PAX-332 User Manual
Chapter 1 Introduction
1.3 Specifications
1.3.1 Display
1.3.2 Input/Output Terminals
Note! The specifications are subject to change without notice.
Model Name
PAX-332-C2A-NAS PAX-332-C2B-NAS
PAX-332-C2B-NAR PAX-332-C2F-NAS
Screen Size (Active Area) 31.55" (698.4(H) x 392.9(V) [mm])
Aspect Ratio 16:9
Number of Pixels 1920 (H) x 1080 (V)
Pixel Pitch (H x V) 0.36375(H) x 0.36375(V) [mm]
Display Colors 16.7 million (8 bit)
Brightness (Typical) 450 cd/m2
Contrast Ratio (Typical) 1,300:1
Display Mode AH-IPS
Response Time (Typical) 25 ms (Gray to Gray)
Viewing Angle (H/V) 178/178
Touchscreen (Optional) Projected capacitive
Item
Specifications
PAX-332-C2A-NAS PAX-332-C2B-NAS
PAX-332-C2B-NAR PAX-332-C2F-NAS
DC Power Input DC Jack x 1 DC24V, 10.41A or 9.58A or 8.35A (MAX)
DC Power Output DC Jack x 1 -DC5V or DC12V
RS-232C Mini DIN Jack x
1 (8 pin) - Service port
SDI Input BNC Jack x 1 -
Serial input common mode: 2.2V[p-
p](75Ω)
MAX: 1920 x 1080@60 Hz
SDI Output BNC Jack x 1 -
Serial input common mode: 2.2V[p-
p](75Ω)
MAX: 1920 x 1080@60 Hz
S-Video Input Mini DIN Jack x
1 (4 pin) -
Y: 1V[p-p] (75 Ω), C: 0.286V[p-p] (75 Ω)
[NTSC]
Y: 1V[p-p] (75 Ω), C: 0.300V[p-p] (75 Ω)
[PAL/ SECAM]
S-Video Output Mini DIN Jack x
1 (4 pin) -
Y: 1V[p-p] (75 Ω), C: 0.286V[p-p] (75 Ω)
[NTSC]
Y: 1V[p-p] (75 Ω), C: 0.300V[p-p] (75 Ω)
[PAL/ SECAM]
Video Input BNC Jack x 1 - 1V[p-p] (75 Ω) [NTSC/PAL/SECAM]
Video Output BNC Jack x 1 - 1V[p-p] (75 Ω) [NTSC/PAL/SECAM]
DVI 1 Input DVI Jack x 1
(Type D)
Digital RGB: TMDS
MAX: 1920 x 1080@60 Hz

PAX-332 User Manual 4
* The specifications are subject to change without notice.
1.3.3 General
1.3.4 Environmental
DVI 1 Output DVI Jack x 1
(Type D)
Digital RGB: TMDS
MAX: 1920 x 1080@60 Hz
DVI 2 Input DVI Jack x 1
(Type D) -Digital RGB: TMDS MAX: 1920 x 1080@60Hz
DVI 2 Output DVI Jack x 1
(Type D) -Digital RGB: TMDS MAX: 1920 x 1080@60Hz
HDMI 2.0 Input HDMI Jack x 1
(Type A)
Digital RGB: TMDS
MAX: 1920 x 1080@60 Hz
HDMI 1.4 Input
(For Ndcoder)
HDMI Jack x 1
(Type A)
(Internal
Connection)
-Digital RGB: TMDS
MAX: 1920 x1080@60Hz
DP 1.2 Input DP Jack x 1 DisplayPort 1.2
MAX: 1920 x 1080@60 Hz
USB Up USB-B Jack x 1 USB 2.0 (for touchscreen)
RGB Input D-Sub Jack x 1 -
Analog RGB:
0.7V[p-p](75Ω), H/
CS/V: TTL (2.2 kΩ),
SOG: 1V[p-p](75Ω)
MAX: 1920 x
1080@60 Hz
-
Audio Input Ear Jack x 1 -
Audio: 0.5V [rms]
(normal), 2 channel
(L+R)
-
Audio Output Ear Jack x 1 -
Audio: 0.5V[rms]
(normal), 2 channel
(L+R)
-
DVI Output
(For Display)
DVI Jack x 1
(Type D)
(Internal
Connection)
- -
Digital RGB: TMDS
MAX: 1920 x
1080@60Hz
LAN RJ45 Jack x 1 - - 1GbE
SFP+ Module - - SFP+ 10 Gbps
Model Name
PAX-332-C2A-NAS PAX-332-C2B-NAS
PAX-332-C2B-NAR PAX-332-C2F-NAS
Power Supply DC24V, 10.41A or 9.58A or 8.35A (MAX)
Power Consumption (Typical) 54.2W 54.3W 78.3W
Dimensions (Without Stand)
[W mm x H mm x D mm] 768.99 x 484.03 x 79.55 [mm]
Weight (Without stand) 11.94 kg 12.04 kg 12.42 kg
Temperature Operating 0 ~ 40 °C
Storage -20 ~ 60 °C
Humidity Operating Ta = 40 °C, 90% RH (non-condensing)
Storage 5 ~ 90%
Pressure Operating 500 hPa to 1013 hPa
Storage 500 hPa to 1013 hPa

5 PAX-332 User Manual
Chapter 1 Introduction
1.3.5 AVAS - Advantech Video Archiving Solution (Optional)
Built-in LEDs indicate the AVAS status, as explained below.
1. Blinking green: operating as normal
2. Blinking orange: warning notification
3. Continuous orange: FPGA is starting up
4. Blinking red: error notification
5. Off: no power supplied to the AVAS
1.3.6 Input/Output Signal Connectors
PAX-332-C2F-NAS (AVAS optional)
PAX-332-C2B-NAS, PAX-332-C2B-NAR (RGB optional)
PAX-332-C2A-NAS
LAN 1 x RJ45 jack 1 x GbE
SFP+ Module SFP+ 10 Gbps
Note! The plug of the power supply cord is the AVAS disconnecting device.
The equipment should be installed near an outlet socket that is easily
accessible.

PAX-332 User Manual 6
Note: The specifications of Advantech products are subject to change without notice.
1. Type of protection against electric shock: Class l equipment
2. Degree of protection against electric shock: Not classified - no applied parts
3. Classification according to the degree of protection against water ingress: IPX0,
ordinary equipment
4. This equipment is not suitable for use in the presence of flammable anesthetics
or oxygen.
5. Mode of operation: continuous operation
Symbol Signal Connector Specifications
RS-232C RS-232C 1 x Mini DIN jack
(8 pin) Service port
USB Up USB up 1 x USB-B jack Touch control (optional)
Video Video input 2 x BNC jack 1V[p-p] (75 Ω) [NTSC/PAL/
SECAM]
Video output
S-Video
S-video input
2 x Mini DIN jack
(4 pin)
Y: 1V [p-p] (75 Ω), C: 0.286V
[p-p] (75 Ω) [NTSC]
Y: 1V [p-p] (75 Ω), C: 0.300V
[p-p] (75 Ω) [PAL/SECAM]
S-video output
SDI
SDI input
2 x BNC jack
Serial input common mode:
2.2V [p-p] (75 Ω)
1920 x 1080 @ 60 Hz
SDI output
DVI 1 ~ 2
DVI input
2 x DVI jack (Type D) Digital RGB: TMDS
1920 x 1080 @ 60 Hz
DVI output
HDMI
HDMI 1.4 input (for AVAS) 1 x HDMI jack (Type A)
(internal connection)
Digital RGB: TMDS
1920 x 1080 @ 60 Hz
HDMI 2.0 input 1 x HDMI jack (Type A) Digital RGB: TMDS
1920 x 1080 @ 60 Hz
DP DP 1.2 input 1 x DP jack DisplayPort 1.2
1920 x 1080 @ 60 Hz
RGB RGB input 1 x D-Sub jack
Analog RGB: 0.7V [p-p] (75Ω)
H/CS/V: TTL (2.2 kΩ)
SOG: 1V[p-p] (75Ω)
1920 x 1080@60 Hz
Audio Audio input 1 x Ear jack 0.5V[rms](normal)
2 channel (L+R)
Audio Audio output 1 x Ear jack 0.5V[rms](normal)
2 channel (L+R)
Caution! Do not touch the signal inputs, signal outputs, or other connectors while
touching a patient.
External equipment intended for connecting to the signal input, signal
output, or other connectors must comply with the relevant IEC standard
(e.g., IEC 60950 for IT equipment and IEC 60601-1 for medical electrical
equipment). In addition, all such combination systems must comply with
the IEC 60601-1 and IEC 60601-1-1 standard specifications.
If in doubt, contact a qualified technician or your local representative.

Chapter 2
2Installation

PAX-332 User Manual 8
2.1 Unpacking
Before unpacking the LCD monitor, prepare a suitable, level, and clean workspace
near a power outlet. The LCD monitor should be installed in a location with sufficient
airflow and away from direct sunlight. After unpacking the LCD monitor, check to
ensure that the following items have been included in the shipment:
1 x PAX-332 LCD monitor
1 x PAX-332 user manual
If any of the above items are missing or damaged, contact your dealer or sales repre-
sentative immediately. Retain the shipping carton and packing material for storing or
transporting the monitor in the future.
2.2 System Controls
The LCD monitor is designed to provide easy and convenient access to all the control
keys and peripheral ports. Before installation, take the time to familiarize yourself with
the system controls and I/O ports.
Figure 2.1 PAX-332 Monitor Front View

9 PAX-332 User Manual
Chapter 2 Installation
2.2.1 I/O Ports
PAX-332-C2F-NAS (AVAS optional)
(1) (2) (3) (4) (5) (6) (7) (8) (9) (10) (11) (12) (13) (14)
PAX-332-C2B-NAS, PAX-332-C2B-NAR (RGB optional)
(1) (2) (3) (4) (5) (6) (7) (8) (9) (10) (11) (12) (13)
PAX-332-C2A-NAS
2.2.2 Display
PAX-332 features a 32-inch TFT LCD. The screen supports a maximum resolution of
1920 x 1080 @ 60 Hz.
2.2.3 OSD Key Functions
Key Name Function
Power Key
Power On/Off
Menu/Enter Key Select main OSD menu.
Select sub menu.
Apply adjustments (save).
Wake up in DPMS mode.
Exit/Input Key Exit/return to previous menu in main OSD menu.
Used to activate Input hot menu when main OSD menu is not dis-
played.
Used to lock/unlock settings for key activation by holding the key
for longer than 30 sec. when main OSD menu is not displayed.
Left Key Move and adjust values in main OSD menu.
Used to activate “Backup Source MSG On/Off" hot menu by hold-
ing the key for longer than 3 sec. when main OSD menu is not dis-
played.
Wake up in DPMS mode.

PAX-332 User Manual 10
2.2.4 Input/Output Signal Ports
PAX-332-C2F-NAS (AVAS optional)
1. DC switch
2. DC power input: +24V power connector
3. DC power output: +5V/+12V power connector
4. RS-232C
5. SDI 1 input/output
6. S-Video input/output
7. Video input/output
8. DVI 2 input/output
9. DVI 1 input/output
10. DP/HDMI input
11. USB up
12. SFP+ optional
13. Status optional
14. LAN optional
PAX-332-C2B-NAS, PAX-332-C2B-NAR (RGB optional)
1. DC switch
2. DC power input: +24V power connector
3. DC power output: +5V/+12V power connector
4. RS-232C
5. SDI 1 input/output
6. S-Video input/output
7. Video input/output
8. DVI 2 input/output
9. DVI 1 input/output
10. DP/HDMI input
11. USB up
12. RGB input
13. Audio input/output
Right Key Move and adjust values in main OSD menu.
Used to activate Display Mode hot menu by holding the key for
longer than 3 sec. when main OSD menu is not displayed.
Wake up in DPMS mode.
Port A Key PIP Main input selection function.
Only available when using the PIP function.
Used to change directly to the backup source input specified in A.
Used to display the selectable OSD menu for backup source input
A by holding the key for more than 5 sec.
Is not available when using the PIP function.
Port B Key PIP Sub input selection function.
Only available when using the PIP function.
Used to change directly to the backup source input specified in B.
Used to display the selectable OSD menu for backup source input
B by holding the key for more than 5 sec.
Is not available when using the PIP function.

11 PAX-332 User Manual
Chapter 2 Installation
PAX-332-C2A-NAS
1. DC switch
2. DC power input: +24V power connector
3. DVI 1 input/output
4. DP/HDMI input
5. USB up
2.2.5 Interface on AVAS Back Panel
2.3 Viewing Angle
The PAX-332 LCD monitor can be vertically adjusted to the preferred viewing angle
for maximum comfort.
2.4 Positioning
Before setting up your workstation, prepare a suitable installation space. This should
be a stable, flat, dust-free surface with good surrounding ventilation. Position the
monitor screen away from direct sunlight. The glare caused by reflected sunlight may
render the screen difficult to read.
Name Function
SFP+ SFP+ port for SFP+ modules only
Status LED
Status LED, will indicate the AVAS operational status:
a. Blinking green: operating as normal
b. Blinking orange: warning notification
c. Continuous orange: FPGA is starting up
d. Blinking red: error notification
e. Off: no power supplied to the AVAS
1GbE 1GbE (RJ45) has no function yet
Note! If the power supply cord is unplugged from the power outlet, AVAS will
be disconnected. The power outlet socket should be located near the
equipment and easily accessible.
Caution! Do not force the monitor past its maximum extension in any direction as
this may damage the monitor and the monitor stand.
Caution! When positioning the equipment, ensure that the main ports and
sockets are easily accessible.
Do not place the monitor close to a heat source.
Do not place the monitor in direct sunlight or near a window.
Exposure to direct sunlight or moisture can damage the monitor.

PAX-332 User Manual 12
2.5 Connecting AC/DC Power
Plug the female end of the AC/DC power adapter into the DC power connector.
Plug the female end of the power cord into the AC power connector on the
adapter.
Plug the male end of the power cord into a power outlet socket.
The power cable plug may differ according to the standards of each country.
2.6 Connecting Video
Before connecting the monitor to a PC or other device, ensure all equipment is
powered off.
Connect one end of an HDMI 2.0 cable to the monitor’s HDMI port and the other
end to the HDMI port of the PC or other device. A DP 1.2 cable can be con-
nected to the monitor’s DP port and to the DP port of the PC or other device if
equipped with a DP input port.
Ensure that the cable is securely connected to both the monitor and the PC/
other device. Tighten the connector screws to ensure a secure connection.
The signal input source can be selected via the OSD menu. Refer to Section
3.1.9 for further details.
PAX-332-C2F-NAS (AVAS optional)
PAX-332-C2B-NAS, PAX-332-C2B-NAR (RGB optional)
PAX-332-C2A-NAS

Chapter 3
3OSD Menu

PAX-332 User Manual 14
3.1 OSD Menu Controls
This chapter refers to the On Screen Display (OSD) controls. Using the OSD controls
the user can adjust contrast, brightness, display clarity, color temperature and etc.
Please read this chapter carefully to get the most out of this monitor.
3.1.1 Display Mode
Menu Description Default Remarks
Display Mode Used to select one of the various display
modes. 1P
