Advantech MIC-3666 User manual

User Manual
MIC-3666
Dual 10 Gigabit Ethernet XMC

MIC-3666 User Manual ii
Copyright
The documentation and the software included with this product are copyrighted 2010
by Advantech Co., Ltd. All rights are reserved. Advantech Co., Ltd. reserves the right
to make improvements in the products described in this manual at any time without
notice. No part of this manual may be reproduced, copied, translated or transmitted
in any form or by any means without the prior written permission of Advantech Co.,
Ltd. Information provided in this manual is intended to be accurate and reliable. How-
ever, Advantech Co., Ltd. assumes no responsibility for its use, nor for any infringe-
ments of the rights of third parties, which may result from its use.
Acknowledgements
Intel®and Pentium®are trademarks of Intel®Corporation.
Microsoft®Windows®and MS-DOS are registered trademarks of Microsoft®Corp.
All other product names or trademarks are properties of their respective owners.
Product Warranty (2 years)
Advantech warrants to you, the original purchaser, that each of its products will be
free from defects in materials and workmanship for two years from the date of pur-
chase.
This warranty does not apply to any products which have been repaired or altered by
persons other than repair personnel authorized by Advantech, or which have been
subject to misuse, abuse, accident or improper installation. Advantech assumes no
liability under the terms of this warranty as a consequence of such events.
Because of Advantech’s high quality-control standards and rigorous testing, most of
our customers never need to use our repair service. If an Advantech product is defec-
tive, it will be repaired or replaced at no charge during the warranty period. For out-
of-warranty repairs, you will be billed according to the cost of replacement materials,
service time and freight. Please consult your dealer for more details.
If you think you have a defective product, follow these steps:
1. Collect all the information about the problem encountered. (For example, CPU
speed, Advantech products used, other hardware and software used, etc.) Note
anything abnormal and list any onscreen messages you get when the problem
occurs.
2. Call your dealer and describe the problem. Please have your manual, product,
and any helpful information readily available.
3. If your product is diagnosed as defective, obtain an RMA (return merchandise
authorization) number from your dealer. This allows us to process your return
more quickly.
4. Carefully pack the defective product, a fully-completed Repair and Replacement
Order Card and a photocopy proof of purchase date (such as your sales receipt)
in a shippable container. A product returned without proof of the purchase date
is not eligible for warranty service.
5. Write the RMA number visibly on the outside of the package and ship it prepaid
to your dealer.
Part No. 20023666001 Edition 2
Printed in Taiwan October 2017

iii MIC-3666 User Manual
Declaration of Conformity
CE
This product has passed the CE test for environmental specifications when shielded
cables are used for external wiring. We recommend the use of shielded cables. This
kind of cable is available from Advantech. Please contact your local supplier for
ordering information.
FCC Class A
Note: This equipment has been tested and found to comply with the limits for a Class
A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference when the equipment is
operated in a commercial environment. This equipment generates, uses, and can
radiate radio frequency energy and, if not installed and used in accordance with the
instruction manual, may cause harmful interference to radio communications. Opera-
tion of this equipment in a residential area is likely to cause harmful interference in
which case the user will be required to correct the interference at his own expense.
FM
This equipment has passed the FM certification. According to the National Fire Pro-
tection Association, work sites are classified into different classes, divisions and
groups, based on hazard considerations. This equipment is compliant with the speci-
fications of Class I, Division 2, Groups A, B, C and D indoor hazards.
Technical Support and Assistance
1. Visit the Advantech web site at http://support.advantech.com where you can find
the latest information about the product.
2. Contact your distributor, sales representative, or Advantech's customer service
center for technical support if you need additional assistance. Please have the
following information ready before you call:
–Product name and serial number
–Description of your peripheral attachments
–Description of your software (operating system, version, application software,
etc.)
–A complete description of the problem
–The exact wording of any error messages

MIC-3666 User Manual iv
Warnings, Cautions and Notes
Document Feedback
To assist us in making improvements to this manual, we would welcome comments
and constructive criticism. Please send all such - in writing to: support@advan-
tech.com.
Warning! Warnings indicate conditions, which if disregarded, can cause personal
injury!
Caution! Cautions are included to help you avoid damaging hardware or losing
data. e.g.:
There is a danger of a new battery exploding if it is incorrectly installed.
Do not attempt to recharge, force open, or heat the battery. Replace the
battery only with the same or equivalent type recommended by the man-
ufacturer. Discard used batteries according to the manufacturer's
instructions.
Note! Notes provide optional additional information.

v MIC-3666 User Manual
Safety Instructions
1. Read these safety instructions carefully.
2. Keep this User Manual for later reference.
3. Disconnect this equipment from any AC outlet before cleaning. Use a damp
cloth. Do not use liquid or spray detergents for cleaning.
4. For plug-in equipment, the power outlet socket must be located near the equip-
ment and must be easily accessible.
5. Keep this equipment away from humidity.
6. Put this equipment on a reliable surface during installation. Dropping it or letting
it fall may cause damage.
7. The openings on the enclosure are for air convection. Protect the equipment
from overheating. DO NOT COVER THE OPENINGS.
8. Make sure the voltage of the power source is correct before connecting the
equipment to the power outlet.
9. Position the power cord so that people cannot step on it. Do not place anything
over the power cord.
10. All cautions and warnings on the equipment should be noted.
11. If the equipment is not used for a long time, disconnect it from the power source
to avoid damage by transient overvoltage.
12. Never pour any liquid into an opening. This may cause fire or electrical shock.
13. Never open the equipment. For safety reasons, the equipment should be
opened only by qualified service personnel.
14. If one of the following situations arises, get the equipment checked by service
personnel:
The power cord or plug is damaged.
Liquid has penetrated into the equipment.
The equipment has been exposed to moisture.
The equipment does not work well, or you cannot get it to work according to
the user's manual.
The equipment has been dropped and damaged.
The equipment has obvious signs of breakage.
15. DO NOT LEAVE THIS EQUIPMENT IN AN ENVIRONMENT WHERE THE
STORAGE TEMPERATURE MAY GO BELOW -20° C (-4° F) OR ABOVE 60° C
(140° F). THIS COULD DAMAGE THE EQUIPMENT. THE EQUIPMENT
SHOULD BE IN A CONTROLLED ENVIRONMENT.
16. CAUTION: DANGER OF EXPLOSION IF BATTERY IS INCORRECTLY
REPLACED. REPLACE ONLY WITH THE SAME OR EQUIVALENT TYPE
RECOMMENDED BY THE MANUFACTURER, DISCARD USED BATTERIES
ACCORDING TO THE MANUFACTURER'S INSTRUCTIONS.
The sound pressure level at the operator's position according to IEC 704-1:1982 is
no more than 70 dB (A).
DISCLAIMER: This set of instructions is given according to IEC 704-1. Advantech
disclaims all responsibility for the accuracy of any statements contained herein.

MIC-3666 User Manual vi
Safety Precaution - Static Electricity
Follow these simple precautions to protect yourself from harm and the products from
damage.
To avoid electrical shock, always disconnect the power from your PC chassis
before you work on it. Don't touch any components on the CPU card or other
cards while the PC is on.
Disconnect power before making any configuration changes. The sudden rush
of power (electrostatic discharge) as you connect a jumper or install a card may
damage sensitive electronic components.
We Appreciate Your Input
Please let us know of any aspect of this product, including the manual, which could
use improvement or correction. We appreciate your valuable input in helping make
our products better.

vii MIC-3666 User Manual
Contents
Chapter 1 General Information ............................1
1.1 Introduction ............................................................................................... 2
1.2 Specifications ............................................................................................ 3
1.2.1 Ethernet ........................................................................................ 3
1.2.2 PCI Express .................................................................................. 3
1.2.3 Power Consumption...................................................................... 3
1.2.4 Mechanical and Environmental Specifications.............................. 3
1.2.5 Software Support .......................................................................... 3
1.2.6 Compliance ................................................................................... 3
1.3 Safety Precautions .................................................................................... 4
Chapter 2 Hardware and Driver Installation .......5
2.1 Initial Inspection ........................................................................................ 6
2.2 Connector Locations ................................................................................. 6
2.3 Card Installation ........................................................................................ 7
2.4 Front Panel LED Indicators ....................................................................... 7
Figure 2.1 MIC-3666 front panel LEDs ........................................ 7
2.5 Driver/Utility Installation............................................................................. 7
Appendix A Pin Assignments .................................9
A.1 P15 Connector ........................................................................................ 10
Table A.1: MIC-3666 XMC Connector P15 Pin Assignments .... 10

MIC-3666 User Manual viii

Chapter 1
1General Information

MIC-3666 User Manual 2
1.1 Introduction
The MIC-3666 is a low power, dual-port 10 GbE XMC, with SFP+ pluggable modules
for multi-mode and single-mode fiber media and is based on the Intel® 82599ES 10
Gigabit Ethernet controller. The XMC provides a high performance PCIe x8 interface
at 5 Gb/s per lane at an outstanding low power dissipation of less than 10 W. Support
for Intel’s offloading and platform enhancement features yields maximum network
throughput while preserving valuable CPU cycles for application processing.
The MIC-3666 features an Intel® 82599 which provides Intel® Virtualization Technol-
ogy for Connectivity (VT-c) including Virtual Machine Device Queues (VMDq) and
PCI SIG compliant Single Root I/O Virtualization (SR-IOV), helping to reduce I/O bot-
tlenecks, boost throughput, and reduce latency. Where virtualization is required,
VMDqs improve performance by offloading the data-sorting burden from the virtual
machine manager (VMM) to the network controller. The MIC-3666’s specialized fea-
tures include Layer 2 & 3 security with IPSec & LinkSec; Intel® I/OAT Acceleration
Technology v3.0; VLAN tagging, stripping and packet filtering; and TCP, iSCSI, and
Fiber Channel over Ethernet (FCoE) offload.

3 MIC-3666 User Manual
Chapter 1 General Information
1.2 Specifications
1.2.1 Ethernet
Two 10 Gigabit Ethernet channels on the front panel
SFP+ connectors on the front panel - compatible with Finisar FTLX8571D3BCL
SFP+ transceiver module.
One Intel® 82599ES Ethernet controller
Supports PCI Express 2.0 (5 GT/s)
Supports Intel® Virtualization Technology for Connectivity (VT-c) including Vir-
tual Machine Device Queues2(VMDq) and Virtual Machine Direct Connect
(VMDc), which is based on the PCI SIG compliant Single Root I/O Virtualization
(SR-IOV)
Integrated IPSec & LinkSec security engines
Implements TCP segmentation offload (TSO), Receive Side Coalescing (RSC),
iSCSI and Fiber Channel over Ethernet (FCoE) offload
Two LEDs per channel signal both LAN link and activity status
1.2.2 PCI Express
PCIe x8 interface at 5 Gb/s per lane
Both lanes on XMC Connector P15
1.2.3 Power Consumption
+3.3 V, 0.25 A max.
VPWR (+5 V), 1.5 A max.
1.2.4 Mechanical and Environmental Specifications
Operating temperature: 0 ~ 55° C (32 ~ 131° F)
Storage Temperature: -40 ~ 80° C (-40 ~ 176° F)
Humidity (operating): 95% @ 40° C (non-condensing)
Humidity (non-operating): 95% @ 60° C (non-condensing)
Board size: 74 x 149 mm (2.9” x 5.78”)
Weight: 0.104 kg (0.23 lb)
1.2.5 Software Support
Drivers from Intel®for Windows®and Linux
1.2.6 Compliance
IEEE Std 1386.1-2001 PMC specification
VITA 42.0-2005, 42.3-2006 XMC specifications

MIC-3666 User Manual 4
1.3 Safety Precautions
Follow these simple precautions to protect yourself from harm and the products from
damage.
To avoid electric shock, always disconnect the power from your system chassis
before you work on it. Don’t touch any components on the board or other boards
while the system is powered.
Disconnect power before making any configuration changes. The sudden rush
of power as you connect a jumper or install a board may damage sensitive elec-
tronic components.
Always ground yourself to remove any static charge before you touch your CPU
board. Be particularly careful not to touch the chip connectors.
Modern integrated electronic devices, especially CPUs and memory chips, are
extremely sensitive to electrostatic discharge and electrical fields. Keep the
board in its antistatic packaging when it is not installed in the chassis, and place
it on a static dissipative mat when you are working with it. Wear a grounding
wrist strap for continuous protection.

Chapter 2
2Hardware and Driver
Installation

MIC-3666 User Manual 6
2.1 Initial Inspection
We carefully inspected the MIC-3666 mechanically and electronically before we
shipped it. It should be free of marks and scratches and in perfect working order on
receipt. As you unpack the MIC-3666, check it for signs of shipping damage (dam-
aged box, scratches, dents, etc.). If it is damaged or fails to meet specifications,
notify our service department or your local sales representative immediately. Also
notify the carrier that was used to ship the product to your location from our factory or
distributor. Retain the shipping carton and packing material for inspection by the car-
rier. We will make arrangements to repair or replace the unit after an inspection.
When you handle the MIC-3666, remove it from its protective packaging by grasping
the front metal panel. Keep the anti-vibration packing. Whenever you remove the
card from the PC, store it in this package for protection.
2.2 Connector Locations
Warning! Discharge your body’s static electric charge by touching the back of the
grounded chassis of the system unit (metal) before handling the board.
You should avoid contact with materials that hold a static charge such
as plastic, vinyl and styrofoam. Handle the board only by its edges to
avoid static damage to its integrated circuits. Avoid touching the
exposed circuit connectors.

7 MIC-3666 User Manual
Chapter 2 Hardware and Driver Installation
2.3 Card Installation
The MIC-3666 is a PCI Express bus master XMC module. It can be installed only in a
CompactPCITM board which supports XMC interface. Improper installation of a card
can easily damage the backplane of the chassis. The MIC-3666 install guide helps
you to install the MIC-3666 into an XMC carrier:
To install a card:
1. Shut off the system power.
2. Connect the MIC-3666 to the CompactPCITM CPU board’s PCI Express mezza-
nine connector and attach it with four screws.
3. Connect the SFP+ cable to the connector on the front panel.
4. Power on the system.
5. Configure your system using the network driver appropriate to your operating
system.
2.4 Front Panel LED Indicators
There are two diagnostic LEDs on the front panel. These LEDs show the operating
status of the MIC-3666.
ACT: When the LED is green (blinking), it indicates active data transfer.
LINK: When the LED is yellow (steady), it indicates the link between the hub/
switch and the adapter is established.
Figure 2.1 MIC-3666 front panel LEDs
2.5 Driver/Utility Installation
The MIC-3666 supports PCI Express plug and play. BIOS automatically detects the
MIC-3666 while booting, and assigns an IRQ level and I/O address. No jumper or
switch is required for user configuration. The MIC-3666 uses one Intel®82599ES 10
Gigabit Ethernet controller chip. Thus it is software-compatible with Intel’s®PROSet
utility.
The latest drivers can be found on Intel’s®website:
http://developer.intel.com/design/network/drivers/

MIC-3666 User Manual 8

Appendix A
APin Assignments

MIC-3666 User Manual 10
A.1 P15 Connector
Table A.1: MIC-3666 XMC Connector P15 Pin Assignments
P15 F E D C B A
1 VPWR PCIE_TXN1 PCIE_TXP1 VCC3 PCIE_TXN0 PCIE_TXP0
2 PCIE_RST# GND GND - GND GND
3 VPWR PCIE_TXN3 PCIE_TXNP3 VCC3 PCIE_TXN2 PCIE_TXNP2
4 - GND GND - GND GND
5 VPWR PCIE_TXN5 PCIE_TXP5 VCC3 PCIE_TXN4 PCIE_TXP4
6 - GND GND - GND GND
7 VPWR PCIE_TXN7 PCIE_TXP7 VCC3 PCIE_TXN6 PCIE_TXP6
8 - GND GND - GND GND
9 VPWR - - - - -
10 - GND GND - GND GND
11 VPWR PCIE_RXN1 PCIE_RXP1 - PCIE_RXN0 PCIE_RXP0
12 - GND GND - GND GND
13 VPWR PCIE_RXN3 PCIE_RXP3 - PCIE_RXN2 PCIE_RXP2
14 PCIE_SMBDAT GND GND - GND GND
15 VPWR PCIE_RXN5 PCIE_RXP5 - PCIE_RXN4 PCIE_RXP4
16 PCIE_SMBCLK GND GND - GND GND
17 - PCIE_RXN7 PCIE_RXP7 - PCIE_RXN6 PCIE_RXP6
18 - GND GND - GND GND
19 - - PCIE_WAKE# - CLK_PCIE_N CLK_PCIE_P

11 MIC-3666 User Manual
Appendix A Pin Assignments

www.advantech.com
Please verify specifications before quoting. This guide is intended for reference
purposes only.
All product specifications are subject to change without notice.
No part of this publication may be reproduced in any form or by any means,
electronic, photocopying, recording or otherwise, without prior written permis-
sion of the publisher.
All brand and product names are trademarks or registered trademarks of their
respective companies.
© Advantech Co., Ltd. 2010
