Advantech ICR-4434 User manual

LTE Advanced Industrial Router
ICR-4434
USER MANUAL

ICR-4434
c
2022 Advantech Czech s.r.o. No part of this publication may be reproduced or transmitted in any form or
by any means, electronic or mechanical, including photography, recording, or any information storage and retrieval
system without written consent. Information in this manual is subject to change without notice, and does not
represent a commitment on the part of Advantech.
Advantech Czech s.r.o. shall not be liable for incidental or consequential damages resulting from the furnish-
ing, performance, or use of this manual.
All brand names used in this manual are the registered trademarks of their respective owners. The use of
trademarks or other designations in this publication is for reference purposes only and does not constitute an
endorsement by the trademark holder.
i

ICR-4434
Used symbols
Danger – Information regarding user safety or potential damage to the router.
Attention – Problems that can arise in specific situations.
Information, notice – Useful tips or information of special interest.
GPL licence
Source codes under GPL licence are available at https://icr.advantech.cz/source-code
address.
Advantech Czech s.r.o., Sokolska 71, 562 04 Usti nad Orlici, Czech Republic
Document No. MAN-0065-EN, revision from February 4, 2022. Released in the Czech Republic.
ii

ICR-4434
Contents
1 Product Oveview 2
1.1 Product Introduction ................................. 2
1.2 Product Usage Examples .............................. 3
1.3 Hardware Overview ................................. 5
1.4 Order Codes ..................................... 7
1.5 Package Contents .................................. 8
1.6 Product Dimensions ................................. 9
1.7 Mounting Recommendations ............................ 10
1.8 Wall Mounting ..................................... 11
1.9 DIN Rail Mounting .................................. 12
1.10 Product Label ..................................... 13
2 Hardware Functionality 14
2.1 SIM Card Slots .................................... 14
2.2 Antennas Interfaces ................................. 15
2.3 Ethernet Interfaces .................................. 15
2.4 SFP Cage ....................................... 16
2.5 Power Supply ..................................... 17
2.6 I/O Port Interfaces .................................. 19
2.7 Serial Interfaces ................................... 20
2.8 USB Port ....................................... 21
2.9 MicroSD Card Reader ................................ 22
2.10 LED Status Indication ................................ 24
2.11 Reset Functions ................................... 25
3 First Use 27
3.1 Connecting the Router ................................ 27
3.2 Starting up the Router ................................ 27
3.3 Router Configuration ................................. 28
4 Technical Parameters 30
4.1 Basic Parameters ................................... 30
4.2 Standards and Regulations ............................. 31
4.3 Type Tests and Environmental Conditions ..................... 32
4.4 Parameters of Cellular Module ........................... 33
4.5 Parameters of GNSS ................................. 33
4.6 Parameters of WiFi .................................. 34
4.7 Parameters of I/O Ports ............................... 35
4.8 Parameters of PoE .................................. 35
iii

ICR-4434
4.9 System Configuration ................................ 36
Appendix A: Troubleshooting 37
Appendix B: Customer Support 40
Appendix C: Regulatory & Safety Information 41
Appendix D: Related Documents 43
iv

ICR-4434
List of Figures
1 Access to the Internet from LAN .......................... 3
2 Backed up Access to the Internet .......................... 3
3 Using VPN Tunnel .................................. 4
4 Serial Gateway .................................... 4
5 Hardware Overview of the Router .......................... 5
5 Router Dimensions – Front View .......................... 9
6 Router Dimensions – Top View ........................... 9
7 Rotated Wall Mounting Clips ............................. 11
8 Default Position of the DIN Rail Clips ........................ 12
9 Removing Router from the DIN Rail ......................... 12
10 Label Example .................................... 13
5 SIM Cards Insertion ................................. 14
6 Ethernet Connector Pinout of RJ45 Socket .................... 15
7 SFP Module Installation ............................... 16
8 Power Connector Pinout ............................... 17
9 Position of the Grounding Screw .......................... 18
10 I/O Connector Pinout ................................. 19
11 Functional Scheme of the Binary Interface ..................... 19
12 Serial Connector Pinout ............................... 20
13 USB Connector Pinnout ............................... 21
14 MicroSD Card Insertion ............................... 22
15 Resetting the Router ................................. 25
16 Router Connection .................................. 27
17 Router’s Web Interface ................................ 29
v

ICR-4434
List of Tables
1 Hardware Overview of the Router .......................... 6
2 Order Codes Overview ................................ 7
1 Contents of Package ................................. 8
2 Ethernet Connector Pinout Description of RJ45 Socket .............. 15
3 Tested SFP Cages .................................. 16
4 Power connector pinout ............................... 17
5 Connection of I/O Ports ............................... 19
6 Connection of RS232 ................................ 20
7 Connection of CAN Bus ............................... 20
8 Connection of RS485 ................................ 20
9 USB Connector Pinnout ............................... 21
10 Technical Specifications of MicroSD Card ..................... 22
11 LED Status Indication ................................ 24
12 Overview of Router Reboot and Reset ....................... 26
13 Basic Parameters ................................... 30
14 Standards and Regulations ............................. 31
15 Type Tests and Environmental Conditions ..................... 32
16 Technical Parameters of Cellular Module ...................... 33
17 Technical Parameters of GNSS ........................... 33
18 Technical Parameters of WiFi ............................ 34
19 Electrical Characteristics of Binary Inputs ..................... 35
20 PoE PSE Parameters ................................ 35
21 System Configuration ................................ 36
1

ICR-4434
1. Product Oveview
1.1 Product Introduction
The ICR-4434 is LTE Advanced Cat 12 Router & Powerful Edge Computing Gateway
focused on the global market.
Thanks to the ultra high-speed of data transfer, up to 600 Mbps for download and 150
Mbps for upload, is this router an ideal solution for demanding IoT applications such as
industrial routers and gateways, digital signage, industrial computers, and tablets, etc.
Two antennas, the main ANT and the diversity DIV, are intended for the cellular network.
An antenna for GNSS can be connected to the router. The router, assembled in a robust metal
box, is equipped with five 1Gb Ethernet ports, one SFP cage together with interfaces of
RS232,RS485,CAN bus, two binary inputs and two binary outputs. To backup the cellular
connection, the router offers two SIM card readers on the rear side of the router under the
SIM cover. A microSD card can be inserted under this cover as well. The designated router
models can be equipped with a WiFi module with 3x3 MIMO antennas.
Configuration of the router may be done via a password-protected Web interface. Web in-
terface provides detailed statistics about the router’s activities, signal strength, detailed system
log etc. The router supports VPN tunnels using IPSec (), OpenVPN,GRE,L2TP or PPTP to
make sure safe communication. IPv6 Dual Stack,DHCP,NAT,NAT-T,DynDNS,DNS proxy,
VLAN,QoS,NTP,VRRP, control by SMS, port forwarding, primary connection backup and
many other functions are supported.
The router provides diagnostic functions which include automatically monitoring the PPP
connection, automatic restart in case of connection losses, and a hardware watchdog that
monitors the router status.
The user may insert Linux scripts which are started on various actions. It is possible to
create up to four different configurations for the same router. These configurations can be
switched when necessary via Web interface, SMS or binary input status.
The router can automatically upgrade its configuration and firmware from your central
server. WebAccess/DMP and WebAccess/VPN remote device management platforms are
supported as well.
Examples of possible applications
•mobile office
•fleet management
•security system
•telematic
•telemetric
•remote monitoring
•vending and dispatcher machines
2

ICR-4434
1.2 Product Usage Examples
The router is primarily intended for these four basic situations:
I. Access to the Internet from LAN
Figure 1: Access to the Internet from LAN
II. Backed up access to the Internet (from LAN)
Figure 2: Backed up Access to the Internet
3

ICR-4434
III. Secure networks interconnection or using VPN
Figure 3: Using VPN Tunnel
IV. Serial Gateway
Figure 4: Serial Gateway
4

ICR-4434
1.3 Hardware Overview
The router case preview is shown in Figure 5. A short description of hardware parts of the
router is listed in Table 1, including the links to the chapters with a detailed description.
Figure 5: Hardware Overview of the Router
5

ICR-4434
# Item/Caption Type Description
1 LEDs - Status LED indication; see Chapter 2.10.
2 RST - Button to reboot the router or to restore the default
configuration; see Chapter 2.11.
3 PWR 2-pin
terminal
Power supply socket; see Chapter 2.5.
4 ETH2 SFP cage SFP cage socket for modules with speed up to 10 Gbps;
see Chapter 2.4.
5 ETH1 RJ45 1 Gb Ethernet connection for the second LAN; see Chap-
ter 2.3.
6 ETH0 RJ45 1 Gb Ethernet switched connection (with four ports) for the
first LAN; see Chapter 2.3.
7 USB USB-A USB 2.0 host port; see Chapter 2.8.
8 SERIAL & I/O 14-pin
terminal
RS232, RS485, CAN bus, binary input, and binary out-
put interfaces. See Chapter 2.6 for more information and
Chapter 4.7 for I/O parameters.
9 GNSS, DIV,
ANT
SMA Cellular module and GNSS antennas connectors. See
Chapter 2.2 for more information, Chapter 4.4 for cellular
module parameters and Chapter 4.5 for GNSS parame-
ters.
10 WIFI1 R-SMA Three connectors for the WiFi antennas. See Chapter 2.2
for more information and Chapter 4.6 for technical param-
eters.
11 Grounding
screw
M3 Pay attention to proper grounding; see Chapter 2.5.
12 SIM slots
microSD slot
micro-SIM
microSD
Two micro-SIM card slots; see Chapter 2for more infor-
mation and Chapter 4.4 for cellular module parameters.
MicroSD card slot; see Chapter 2.9.
13 Wall clips - Wall mounting clips, included as standard accessories;
see Chapter 1.8.
Table 1: Hardware Overview of the Router
6

ICR-4434
1.4 Order Codes
Order codes overview is shown in the table below.
Order code Configuration
ICR-4434 LTE Advanced Cat 12 cellular module, Gb ETH SWITCH, GNSS, SFP cage,
USB, microSD card slot, RS232, RS485, CAN bus, two binary inputs, two
binary outputs, two SIM readers
ICR-4434SLTE Advanced Cat 12 cellular module, Gb ETH SWITCH, GNSS, SFP cage,
PoE PSE, USB, microSD card slot, RS232, RS485, CAN bus, two binary
inputs, two binary outputs, two SIM readers
ICR-4434WLTE Advanced Cat 12 cellular module, Gb ETH SWITCH, GNSS, SFP cage,
Dual-Band WiFi, USB, microSD card slot, RS232, RS485, CAN bus, two
binary inputs, two binary outputs, two SIM readers
ICR-4434WS LTE Advanced Cat 12 cellular module, Gb ETH SWITCH, GNSS, SFP cage,
PoE PSE,Dual-Band WiFi, USB, microSD card slot, RS232, RS485, CAN
bus, two binary inputs, two binary outputs, two SIM readers
Table 2: Order Codes Overview
7

ICR-4434
1.5 Package Contents
The standard set of router includes items listed in the following table:
Item# Description Figure Q’ty
1Router 1 pcs
2Wing for wall mounting
(screwed on the router) 2 pcs
32-pin terminal block for power supply
(deployed on the router) 1 pcs
4
14-pin terminal block for RS232,
RS485, CAN BUS, and I/O
(deployed on the router)
1 pcs
5Printed Quick Start Guide 1 pcs
Table 1: Contents of Package
8

ICR-4434
1.6 Product Dimensions
For the dimensions of the router see the figures below. Note that all sizes are measured in
millimeters.
Figure 5: Router Dimensions – Front View
Figure 6: Router Dimensions – Top View
9

ICR-4434
1.7 Mounting Recommendations
The router can be placed:
•on a flat surface,
•on a wall using the wall mounting clip (see Chapter 1.8),
•on a DIN rail EN 60715 with the metal DIN rail clip (see Chapter 1.9)
For most applications with a built-in router within a switchboard, it is possible to recognize
two kinds of environments:
•A non-public, industry environment of low voltage with high interference,
•a public environment of low voltage and without high interference.
For both of these environments, it is possible to mount the router to a switchboard, af-
ter which there is no need to have examination immunity or issues in connection with EMC
according to EN 61439-1:2011.
In compliance with the EN 61439-1:2011 specification, it is necessary to observe the
following assembly instructions for a router attached to a switchboard:
•For whip antennas it is recommended to observe a minimum distance of 6 cm from ca-
bles and metal surfaces on every side in order to avoid interference. When using an
external antenna separate from the switchboard it is necessary to fit a lightning conduc-
tor.
•When mounting a router on sheet-steel we recommend using a cable antenna.
•For all cables, we recommend to bind the bunch, and for this we recommend:
–The length of the bunch (the combination of power supply and data cables) should
be a maximum 1.5 m. If the length of data cables exceeds 1.5 m or if the cable is
leading towards the switchboard, we recommend installing surge protectors.
–Data cables must not have a reticular tension of ∼230 V/50 Hz or ∼120 V/60 Hz.
•Sufficient space must be left between each connector for the handling of cables,
•To ensure the correct functioning of the router we recommend the use of an earth-
bonding distribution frame for the grounding of the grounding screew, see Chapter 2.5.
10

ICR-4434
1.8 Wall Mounting
The wall mounting clip is supplied with the router as standard accessories.
The router can be screwed to a wall (or another surface) using the wall mounting clips. Two
wall mounting clips are assembled to the router during the production and need to be roteted
as shown of Figure 7.
There are two wholes on the clip with a diameter of 5 millimeters. For detailed information
about the mounting dimensions see Figure 6in Chapter 1.6.
When mounting the wall mounting clip, tighten the screws with max. torque of 0.4 Nm.
Figure 7: Rotated Wall Mounting Clips
11

ICR-4434
1.9 DIN Rail Mounting
The DIN rail clips are not supplied with the router as standard accessories, but they can be
ordered by the order code BB-DIN-ICR32 (two pieces for one router).
Two DIN rail clips can be assembled to the router and used to mount it to the DIN rail which
meets the 60715 standards. The default position of the clips is shown in Figure 8. If needed,
the clips can be rotated vertically as well.
When mounting the clips, tighten the screws with max. torque of 0.4 Nm.
Figure 8: Default Position of the DIN Rail Clips
To remove the router from the DIN rail, it is necessary to lightly push down the router so
that the bottom part of the DIN rail clip hitched to the DIN rail get out of this rail and then fold
out the bottom part of the router away from the DIN rail as shown in Figure 9.
Figure 9: Removing Router from the DIN Rail
12

ICR-4434
1.10 Product Label
An example of the product label, with all the information printed on it, is in the figure below.
Figure 10: Label Example
13

ICR-4434
2. Hardware Functionality
See Chapter 1.3 for the product hardware overwiew. Table 1lists a short description of the
hardware, including the links to the chapters with a detailed description.
2.1 SIM Card Slots
Slots for two SIM cards are located on the rear panel of the router under a metal cover. It
is necessary to insert an activated SIM card, to work properly. If the PIN is required for the
SIM, enter it in the router’s web interface. The SIM cards may have different APNs (Access
Point Names) adjusted. The SIM card changing procedure is described below.
Type of SIM cards: mini-SIM (2FF) 25.0 x 15.0 x 0.76 mm.
Inserting the SIM card:
•Always disconnect the router from the power supply before handling the SIM card.
•Unscrew the SIM card cover screw on the back panel and remove the cover.
•To remove an inserted SIM card, use the flat end of a spudger, or your fingernail,
press the SIM card slightly into its slot until you hear a click. After hearing this click,
release the card, and it will pop out of its slot.
•To insert a SIM card push card into the slot until it clicks into place.
•Place back the cover and fix it by the screw.
Figure 5: SIM Cards Insertion
14
