Advantech SKY-8232D User manual

SKY-8232D ManualV0120220210 Copyright2022 AdvantechCo.Ltd.Allrightsreserved Page I
SKY-8232D
Compact 2U Edge Server based on Dual
3rd Gen Intel® Xeon® Scalable
Processors

SKY-8232D ManualV0220220411 Copyright2022 AdvantechCo.Ltd.Allrightsreserved Page II
Revision History
Date (mm/dd/yyyy)
Revision
Modifications
2022/03/10
V01
First release
2022/04/11
V02
Updated content

SKY-8232DManualV0220220411 Copyright2022 AdvantechCo.Ltd.Allrightsreserved Page III
Copyright and Trademarks
Advantech Co., Ltd. reserves the right to make improvements in the products described
in this manual at any time without notice. No part of this manual may be reproduced,
copied, translated or transmitted in any form or by any means without the prior written
permission of Advantech Co., Ltd. Information provided in this manual is intended to be
accurate and reliable. However, Advantech Co., Ltd. assumes no responsibility for its
use, nor for any infringements of the rights of third parties, which may result from its
use.
About This Manual
Thank you for purchasing and using the Advantech SKY-8232D.
The target audience of this manual includes users, administrators and technicians. This
publication is a useful reference when installing, configuring, operating and managing
the SKY-8232D.
This manual is organized as follows:
◼Section 1:Getting Started helps you with the first steps with the SKY-8232D.
◼Section 2:Product Specification provides a detailed description of the SKY-8232D
and its features.
◼Section 3:Configuration and Service describes how to change the SKY-8232D’
configuration or how to install and service replaceable items.
◼Section 4:Tips, Tricks and Troubleshooting provides best practices and other
information that may be helpful for operation and troubleshooting of the SKY-8232D.
◼Appendices provide supplemental information referenced in the other sections of this
document.
Useful Documents
If you cannot find the information you’re looking for or need more detailed information
on a specific topic, please refer to the list of additional documents and other sources of
information below. Please contact your Advantech representative if you need help on
obtaining these documents or still can’t find what you’re looking for.
- Information on Intel CPUs, Chipsets and NIC silicon can be found at: www.intel.co
- Getting Started Guide for Advantech SKY-8232D QuickStart Linux Image
-SKY-8232D Advanced Platform Management User’s Guide
- ipmitool how-to can be found at: http://linux.die.net/man/1/ipmitool
-An introduction to IPMI can be found at:
http://www.intel.com/content/www/us/en/servers/ipmi/ipmi-home.html

SKY-8232D ManualV0220220411 Copyright2022 AdvantechCo.Ltd.Allrightsreserved Page IV
Technical Support and Assistance
1. Visit the Advantech website at http://support.advantech.com where you can find the
latest information about our products.
2. Contact your distributor, sales representative, or Advantech's customer service
center for technical support if you need additional assistance. Please have the
following information ready before you call:
- Product name and serial number
- A description of your peripheral attachments
- A description of your software (operating system, version, application software,
etc.)
- A complete description of the problem
- The exact wording of any error messages
Product Warranty (2 Years)
Advantech warrants to you, the original purchaser, that each of its products will be free
from defects in materials and workmanship for two years from the date of purchase.
This warranty does not apply to any products which have been repaired or altered by
persons other than repair personnel authorized by Advantech, or which have been
subject to misuse, abuse, accident or improper installation. Advantech assumes no
liability under the terms of this warranty as a consequence of such events.
If an Advantech product is defective, it will be repaired or replaced at no charge during
the warranty period. For out-of-warranty repairs, you will be billed according to the cost
of replacement materials, service time and freight. Please consult your dealer for more
details. Because of Advantech’s high quality-control standards and rigorous testing,
most of our customers never need to use our repair service. But if you think you have
obtained a defective product, please follow these steps:
1. Collect all the information about the problem encountered. (For example, CPU
speed, Advantech products used, other hardware and software used, etc.)
Note!
To make our service more efficient, please make a note of anything abnormal
and list any onscreen messages you get when the problem occurs.
2. Call your dealer and describe the problem. Please have your manual, product, and
any other helpful information readily available.
3. If your product is diagnosed as defective, obtain an RMA (return merchandize
authorization) number from your dealer. This allows us to process your return more
quickly.

SKY-8232D ManualV0220220411 Copyright2022 AdvantechCo.Ltd.Allrightsreserved Page V
4. Carefully pack the defective product, a fully-completed Repair and Replacement
Order Card and a photocopy of the proof of purchase date (such as your sales
receipt) in a shippable container. A product returned without proof of the purchase
date is not eligible for warranty service.
5. Write the RMA number visibly on the outside of the package and ship it prepaid to
your dealer.
Warnings, Cautions and Notes
Warning!
Warnings indicate conditions, which if not observed, can cause
personal injury!
Caution!
Cautions are included to help you avoid damaging hardware or losing
data.
Note!
Notes provide additional information.
We Appreciate Your Input
Please let us know of any aspect of this product, including the manual, which could
use improvement or correction. We appreciate your valuable input in helping make our
products and documentation better.
Please send all such - in writing to: [email protected]

SKY-8232D ManualV0220220411 Copyright2022 AdvantechCo.Ltd.Allrightsreserved Page 6
TABLE OF CONTENTS
Getting Started ...................................................................13
1.1 Safety Instructions ................................................................................................14
1.1.1 Safety Precautions per IEC704-1 ................................................................14
1.1.2 Safety Precautions –Static Electricity.......................................................... 15
1.2 Unpacking............................................................................................................. 16
1.3 Installation and Configuration................................................................................ 17
1.3.1 Chassis Slide Rail Installation...................................................................... 17
1.3.2 Powering On................................................................................................ 19
1.3.3 Connecting to Monitor, Keyboard and Mouse.............................................. 19
1.3.4 Connecting to the Serial Console ................................................................ 19
1.3.5 Installing an OS........................................................................................... 22
1.3.5.1 Pre-Installed reference OS...............................................................22
1.3.5.2 Installing and/or boot an OS from a USB key.................................... 23
1.3.5.3 Installing an OS via network boot .....................................................23
1.3.5.4 Booting an OS via network boot........................................................23
1.4 Getting Help: Technical Support and Assistance ..................................................25
Product Specification .........................................................26
2.1 Overview............................................................................................................... 27
2.2 Product Versions .................................................................................................. 28
2.3 Technical Specifications .......................................................................................29
2.3.1 SKY-8232D System Specification................................................................ 29
2.3.2 System Dimensions..................................................................................... 31
2.4 Detail Description.................................................................................................. 32
2.4.1 Front Elements............................................................................................ 32
2.4.1.1 LEDs Details ....................................................................................33
2.4.1.2 Front Button Details..........................................................................35
2.4.1.3 Fan Module Details ..........................................................................35
2.4.1.4 Storage LED..................................................................................... 36
2.4.2 Rear Panel ..................................................................................................37
2.4.2.1 Disk bay detail.................................................................................. 38
2.4.3 Inside the System........................................................................................39
2.4.4 System Block Diagram ................................................................................40
2.4.5 Processor(s)................................................................................................41
2.4.5.1 Processor Feature Details................................................................41
2.4.6 Memory....................................................................................................... 42
2.4.6.1 Memory Sub-System........................................................................ 42
2.4.6.2 DDR4 DIMM Location and SMBus Mapping..................................... 43
2.4.6.3 Validated Memory Modules.............................................................. 44
2.4.7 Network Interface (On board) ...................................................................... 44
2.4.8 PCIe Expansion........................................................................................... 44
2.4.9 TPM............................................................................................................. 46
2.4.10 Mass Storage............................................................................................46
2.4.11 Internal Storage......................................................................................... 47
2.4.12 BIOS.......................................................................................................... 48
2.4.12.1 Password Protection....................................................................... 48
2.4.12.2 BIOS Defaults................................................................................. 48
2.4.13 Advanced Platform Management............................................................... 49
2.4.13.1 Hardware and Environmental Monitoring........................................49

SKY-8232DManualV0220220411 Copyright2022 AdvantechCo.Ltd.Allrightsreserved Page 7
2.4.13.2 Thermal Management ....................................................................50
2.4.14 Power Supplies..........................................................................................51
2.4.14.1 AC PSU..........................................................................................51
2.4.14.2 DC PSU.......................................................................................... 52
2.5 Advanced Platform Features................................................................................. 54
2.5.1 Intrusion Detection.......................................................................................54
2.5.2 Watchdogs .................................................................................................. 54
2.6 Available Accessories and Related Products........................................................ 55
2.6.1 Accessories................................................................................................. 55
2.6.2 Spare Parts ................................................................................................. 55
2.6.3 Related Products......................................................................................... 56
Configuration and Service ..................................................57
3.1 Jumper Settings....................................................................................................58
3.2 BIOS Setup Menu................................................................................................. 58
3.3 Installing Components ..........................................................................................92
3.3.1 Removing the Top Cover.............................................................................92
3.3.2 Reinstalling the Top Cover ..........................................................................93
3.3.3 Middle bar installation ...........................................................................93
3.3.4 PCIe Card Installation.................................................................................. 94
3.3.5Disk Installation............................................................................................96
3.3.5.1 2.5” HDD/SSD Drives ....................................................................... 96
3.3.5.2 M.2 SSD...........................................................................................97
3.3.6 Memory Installation .....................................................................................98
3.3.7 CPU Installation......................................................................................... 100
3.4 Firmware Upgrades ............................................................................................ 101
3.5 Replacing FRUs.................................................................................................. 101
3.5.1 Air Filter..................................................................................................... 101
3.5.2 PSU Modules ............................................................................................ 102
3.5.3 Disk Drives................................................................................................ 103
3.5.3.1 2.5” HDD ........................................................................................ 103
3.5.3.2 M.2 SSD......................................................................................... 103
3.5.4 DIMMs....................................................................................................... 103
Tips, Tricks and Troubleshooting ....................................105
Connector Pinout and LED Information ...........................106
A.1 Console Port....................................................................................................... 107
A.2 USB 3.0/2.0 Type A Connectors......................................................................... 108
A.3 VGA Connector.................................................................................................. 110
A.5 RJ45 10/100/1000BASE-T Ports........................................................................ 111
A.5.1 Connector Pinout ...................................................................................... 111
A.5.2 LED Definition........................................................................................... 111
A.6 RJ45 Management Ports.................................................................................... 112
BIOS POST Code...............................................................113
Power Supply Specification .............................................121
C.1 Redundant 1200W AC PSU............................................................................... 122

SKY-8232DManualV0220220411 Copyright2022 AdvantechCo.Ltd.Allrightsreserved Page 8
C.2 Redundant 800W DC PSU................................................................................. 124
Declaration of Conformity ................................................126
Warranty and RMA ............................................................128
Glossary ............................................................................130

SKY-8232D ManualV0220220411 Copyright2022 AdvantechCo.Ltd.Allrightsreserved Page 9
LIST OF FIGURES
Figure 1-1: PuTTY Session Configuration...................................................................20
Figure 1-2: PuTTY Serial Configuration......................................................................20
Figure 1-3: PuTTY Keyboard Settings ........................................................................ 21
Figure 1-4: PuTTY Colour Settings............................................................................. 21
Figure 1-5: BIOS POST Screen..................................................................................22
Figure 2-1: Carrier Grade Server SKY-8232D............................................................. 27
Figure 2-2: System Dimensions..................................................................................31
Figure 2-3: Front Panel...............................................................................................32
Figure 2-4: Status LEDs (Front Panel)........................................................................ 33
Figure 2-5: Front Buttons............................................................................................ 35
Figure 2-6: Fan Module............................................................................................... 36
Figure 2-7: Internal storage LED................................................................................. 36
Figure 2-8: System Rear View....................................................................................37
Figure 2-9: Disk Bays ................................................................................................. 38
Figure 2-10: Disk Tray................................................................................................38
Figure 2-11: System Top View (Cover Removed).......................................................39
Figure 2-12: Block Diagram ........................................................................................ 40
Figure 2-13: DIMM and CPU Location........................................................................ 44
Figure 2-14: PCIe Cages (Top View)..........................................................................45
Figure 2-15: Location of mSATA Sockets ...................................................................46
Figure 2-15: Location of internal storages................................................................... 47
Figure 2-16: System Airflow and Fans........................................................................ 50
Figure 2-17: AC PSU Details ......................................................................................51
Figure 2-18: DC PSU Details...................................................................................... 52
Figure 3-1: BIOS POST Screen..................................................................................58
Figure 3-2: BIOS Setup Screen Organization .............................................................59
Figure 3-3: BIOS Setup Main Screen.......................................................................... 59
Figure 3-4: Platform Setup: Main Screen....................................................................61
Figure 3-5: Platform Setup: Serial Console Menu....................................................... 61
Figure 3-6: Platform Setup: USB Configuration Menu................................................. 63
Figure 3-7: Platform Setup: Trusted Computing (TPM1.2).......................................... 64
Figure 3-8: Platform Setup: Trusted Computing (TPM2.0).......................................... 65
Figure 3-9: Platform Setup: Virtualization.................................................................... 67
Figure 3-10: Platform Setup: Platform Management................................................... 68
Figure 3-11: Platform Setup: Imanager Healther Guard.............................................. 69
Figure 3-12: Hardware Setup......................................................................................70
Figure 3-13 Hardware Setup: CPU Configuration .......................................................71
Figure 3-14: Hardware Setup: North bridge ................................................................ 72
Figure 3-15: Hardware Setup: DIMM Information........................................................73
Figure 3-16: Hardware Setup: PCI Express Ports Configuration................................. 74
Figure 3-17: Hardware Setup: UPI Configuration........................................................80

SKY-8232DManualV0220220411 Copyright2022 AdvantechCo.Ltd.Allrightsreserved Page 10
Figure 3-18: Hardware Setup: Southbridge................................................................. 81
Figure 3-19: Hardware Setup: SATA Configuration.....................................................82
Figure 3-20: Hardware Setup: ACPI Settings.............................................................. 83
Figure 3-21: Hardware Setup: Runtime Error Logging ................................................84
Figure 3-22: Hardware Setup: NVMe Configuration....................................................85
Figure 3-23: Hardware Setup: Intel VROC..................................................................85
Figure 3-24: Sever Management Setup...................................................................... 86
Figure 3-25: Security Menu.........................................................................................87
Figure 3-26: Post and Boot Menu............................................................................... 88
Figure 3-27: Post and Boot Menu: CSM Configuration ...............................................89
Figure 3-28: Save & Exit Menu................................................................................... 90
Figure 3-29: Slide Top Cover Back............................................................................. 92
Figure 3-30: Middle bar installation............................................................................. 93
Figure 3-31 PCIe Card Cage Assembly: Thumb screw location.................................. 94
Figure 3-32 PCIe Card Cage Assembly: PCIe cage latch........................................... 94
Figure 3-33: PCIe Card Cage Assembly: PCIe slot latch ............................................95
Figure 3-34: PCIe Card Cage Assembly: Connect power cable..................................95
Figure 3-35: PCIe Card Cage Assembly: PCIe cage guide pins.................................. 95
Figure 3-36: PCIe Card Cage Assembly: External power adapter............................... 96
Figure 3-37: Opening the Disk Tray............................................................................ 96
Figure 3-38: Removing the Disk Tray.......................................................................... 97
Figure 3-39: Mounting the Drive in the Disk Tray........................................................ 97
Figure 3-40: M.2 SSD Installation............................................................................... 98
Figure 3-41: Opening DIMM Latches..........................................................................98
Figure 3-42: DIMM Key Alignment..............................................................................98
Figure 3-43: DIMM Insertion into Slide Rails...............................................................99
Figure 3-44: Seating the DIMM in the Socket.............................................................. 99
Figure 3-46: Air Filter Assembly................................................................................ 102
Figure 3-47: Unlocking and Removing a DIMM......................................................... 104
Figure A-1: RJ45 Console Connector ....................................................................... 107
Figure A-2: USB Type A Connector.......................................................................... 108
Figure A-3: DisplayPort Connector ........................................................................... 110
Figure A-5: RJ45 10/100/1000Base-T Connector ..................................................... 111
Figure A-6: RJ45 management port Connector......................................................... 112

SKY-8232D ManualV0220220411 Copyright2022 AdvantechCo.Ltd.Allrightsreserved Page 11
LIST OF TABLES
Table 1-1: Packaging List ...........................................................................................16
Table 1-2: PXE BIOS Options.....................................................................................24
Table 2-1: Available Product Versions........................................................................ 28
Table 2-2: Front Elements ..........................................................................................32
Table 2-3: Status LEDs...............................................................................................33
Table 2-4: Front Buttons............................................................................................. 35
Table 2-5: Fan Module................................................................................................36
Table 2-6: Internal storage LED.................................................................................. 36
Table 2-7: Rear Panel List..........................................................................................37
Table 2-8: Disk ...........................................................................................................38
Table 2-9: Disk Tray ...................................................................................................38
Table 2-10: Internal system components list...............................................................39
Table 2-11: 3rd Gen Intel® Xeon® Scalable Processors supported list ...................... 41
Table 2-12: Third Gen Intel® Xeon® Scalable processors DDR4 DIMM SMBus Address
List..............................................................................................................................43
Table 2-13: Validated DIMMs .....................................................................................44
Table 2-14: AC PSU Details .......................................................................................51
Table 2-15: DC PSU Details.......................................................................................52
Table 2-16: Accessories .............................................................................................55
Table 2-17: Spare Parts..............................................................................................55
Table 2-18: Related Products .....................................................................................56
Table 3-1: Main Menu................................................................................................. 60
Table 3-2: Serial Console Menu.................................................................................. 62
Table 3-3: USB Configuration Menu ...........................................................................63
Table 3-4: Trusted Computing Menu (TPM1.2)...........................................................64
Table 3-5: Trusted Computing Menu (TPM2.0)...........................................................66
Table 3-6: Virtualization..............................................................................................67
Table 3-7: Platform Management................................................................................ 68
Table 3-8: Southbridge ...............................................................................................70
Table 3-9: CPU Configuration.....................................................................................71
Table 3-10: Northbridge..............................................................................................73
Table 3-11: PCI Express Ports Configuration..............................................................74
Table 3-12: UPI Configuration.....................................................................................80
Table 3-13: Southbridge .............................................................................................81
Table 3-14: SATA Configuration.................................................................................82
Table 3-15: ACPI Setting............................................................................................ 84
Table 3-16: Runtime Error Logging.............................................................................84
Table 3-17: Server Management Setup......................................................................86
Table 3-18: Post & Boot Menu....................................................................................88
Table 3-19: CSM Configuration................................................................................... 89
Table 3-20: Save & Exit Menu Options....................................................................... 90

SKY-8232DManualV0220220411 Copyright2022 AdvantechCo.Ltd.Allrightsreserved Page 12
Table A-1: Console Connector Pin Assignment........................................................ 107
Table A-2: USB 3.0 Type A Connector Pin Assignment or Pin Assignment .............. 108
Table A-3: USB 2.0 Type A Connector Pin Assignment or Pin Assignment .............. 109
Table A-4: DisplayPort Connector Pin Assignment................................................... 110
Table A-5: RJ45 10/100/1000Base-T Connector Pin Assignment............................. 111
Table A-6: RJ45 Connector LED Indication............................................................... 111
Table A-7: RJ45 Management port Connector Pin Assignment ................................ 112
Table B-1: BOIS POST Codes.................................................................................. 114
Table C-1: 1200W AC Power Supply Specification................................................... 122
Table C-2: 800W DC Power Supply Specification..................................................... 124

SKY-8232D ManualV0220220411 Copyright2022 AdvantechCo.Ltd.Allrightsreserved Page 13
Chapter 1
Getting Started

SKY-8232D ManualV0220220411 Copyright2022 AdvantechCo.Ltd.Allrightsreserved Page 14
1.1 Safety Instructions
Warning!
This section provides warnings that precede potentially dangerous procedures
throughout this manual. Instructions contained in the warnings must be
followed during all phases of operation , service, and repair of this equipment.
You should also employ all other safety precautions necessary for the
operation of the equipment in your operating environment.
Caution!
If you are not sure about the precautions applicable to your operating
environment, please contact your company’s safety administrator. For basic
information you may also refer to the safety precautions per IEC704-1 listed
below although Advantech disclaims all responsibility for the accuracy of any
statements contained therein and its applicability for your specific
environment.
Failure to comply with these precautions or with specific warnings elsewhere in this
manual could result in personal injury or damage to the equipment.
Advantech intends to provide all necessary information to install and handle the
SKY-8232D in this manual. Because of the complexity of this product and its various
uses, we do not guarantee that the given information is complete. If you need additional
information, contact your Advantech representative.
The product has been designed to meet the standard industrial safety requirements. It
must not be used except in its specific area as specified in Section 2.3.
Only personnel trained by Advantech or persons qualified in electronics or electrical
engineering is authorized to install service or maintain the product. The information
given in this manual is meant to complete the knowledge of a specialist and must not be
used as replacement for qualified personnel. Operating personnel must not remove
equipment covers. Only factory authorized service personnel or other qualified service
personnel may remove equipment covers for internal subassembly or component
replacement or any internal adjustment.
Do not install substitute parts or perform any unauthorized modification of the
equipment or the warranty may be voided. Contact your local Advantech
representative for service and repair to make sure that all safety features are
maintained.
1.1.1 Safety Precautions per IEC704-1
1. Read these safety instructions carefully.
2. Keep this User Manual for later reference.
3. Keep this equipment away from humidity.
4. Put this equipment on a reliable surface during installation. Dropping it or letting
it fall may cause damage.
5. Make sure the voltage of the power source is correct before connecting the
equipment to the power outlet.

SKY-8232D ManualV0220220411 Copyright2022 AdvantechCo.Ltd.Allrightsreserved Page 15
6. Position the power cord so that people cannot step on it. Do not place anything
over the power cord.
7. All cautions and warnings on the equipment should be noted.
8. If the equipment is not used for a long time, disconnect it from the power source to
avoid damage by transient over-voltage.
9. Never pour any liquid into an opening. This may cause fire or electrical shock.
10. For safety reasons, the equipment should be opened only by qualified service
personnel.
11. If one of the following situations arises, get the equipment checked by service
personnel:
12. The power cord or plug is damaged.
13. Liquid has penetrated into the equipment.
14. The equipment has been exposed to moisture.
15. The equipment does not work well, or you cannot get it to work according
-The equipment has been dropped and damaged.
-The equipment has obvious signs of breakage.
Note!
Do not leave this equipment in an environment where the storage temperature
may go beyond the range specified in Technical Specifications. This could
damage the equipment. The equipment should be in a controlled environment.
Caution!
Danger of explosion if battery is incorrectly replaced. Replace only with the
same or equivalent type recommended by the manufacturer, discard used
batteries according to the manufacturer’s instructions.
16. The sound pressure level at the operator’s position according to IEC 704-1:1982
is no more than 70 dB (A).
DISCLAIMER: The set of instructions is given according to IEC704-1. Advantech
disclaims all responsibility for the accuracy of any statements contained herein.
1.1.2 Safety Precautions –Static Electricity
Follow instructions below to protect yourself from harm and the products from damage:
1. Don’t touch any components inside the system while the system is on.
2. Disconnect power before making any configuration changes. The sudden rush of
power as you connect a jumper or install a card may damage sensitive electronic
components.
3. When unpacking a static-sensitive component from its shipping carton, do not
remove the component's antistatic packing material until you are ready to install
the component in the unit.
4. When transporting any electrical component, first place it in an antistatic
container or packaging.

SKY-8232D ManualV0220220411 Copyright2022 AdvantechCo.Ltd.Allrightsreserved Page 16
1.2 Unpacking
Please check the delivery for completeness as you open the carton carefully. If any of
the items listed in Table 1-1 is missing or damaged, please contact your Advantech
representative.
The SKY-8232D is packaged inside a single carton, collectively referred to as the “box”
in the remainder of this document.
When opening the box, you will find the SKY-8232D embedded in protective foam and
the accessory box embedded to the foam. Remove the accessory box first and then
pull out the unit including the protective foam using both hands. Now, remove the foam
and the plastic sleeve on the unit.
After unpacking the unit, please check for any visible damage of the unit and contact
your Advantech representative in case of any issue.
Table 1-1: Packaging List
Item
Qty.
Description
Server
SKY-8232D
1
Compact 2U High Performance Server
based on Dual 3rd Gen Intel® Xeon®
Scalable Processors
Key lock
1
Key lock (2pcs) for front bezel
HDD Screw
Set
1
Screws (16pcs) for 2.5”drive mounting
M.2 Screw
1
Screws (2 pcs) for M.2.
Heatsink
1
CPU Heatsink (2pcs). ** Will be
assembled in the system if the order
includes CPU.
Slide Rail
(optional)
1
20-inch server slide. (A separate package)
Power cord
1
Power cord *2
Bezel
1
Front bezel *1

SKY-8232D ManualV0220220411 Copyright2022 AdvantechCo.Ltd.Allrightsreserved Page 17
1.3 Installation and Configuration
The SKY-8232D comes as a pre-configured system with CPUs, memory and
peripherals installed in the unit. In the rare case that you procured a barebone system
or need to install components in the SKY-8232D for any other reason, please refer to
Section 3.3.
1.3.1 Chassis Slide Rail Installation
To install the chassis slide rail on the SKY-8232D chassis, please follow below instruction.

SKY-8232DManualV0220220411 Copyright2022 AdvantechCo.Ltd.Allrightsreserved Page 18
Caution!
DO NOT add any weight upon the system when chassis slide rail is installed.

SKY-8232DManualV0220220411 Copyright2022 AdvantechCo.Ltd.Allrightsreserved Page 19
1.3.2 Powering On
Caution!
Before connecting the SKY-8232D to the power outlet, please make sure that
the power rating of the outlet and the SKY-8232D’s PSU match. Please also
make sure that the primary circuit and all power distribution in not overloaded.
Inrush current and steady state power specifications for the SKY-8232D can be
found at the type label on the bottom of the unit.
Connect the power cords to the PSU modules first and then to the power outlets.
The unit will automatically power on after power is supplied. The green LED on the front
panel should be lit as the unit is under power.
Please refer to Section 2.4 for the location of front and rear panel elements.
1.3.3 Connecting to Monitor, Keyboard and Mouse
The SKY-8232D supports two VGA Ports and four USB ports for connection of a
monitor, keyboard and mouse. Please refer to Section 2.4 for information on the
location of the related connectors.
1.3.4 Connecting to the Serial Console
The SKY-8232D supports the operation via a serial terminal connection by default for
scenarios where a directly attached monitor, keyboard and mouse are not available or
not desirable. In this configuration, BIOS output as well as OS output are provided via
a serial terminal connection.
The remainder of this section describes how to configure PuTTY on a Windows plat-
form for connection with the SKY-8232D serial console as a reference. Other
terminal programs may be used in a similar way as well.
Open up PuTTY and begin the configuration as shown below. Please use the
actual COM port’s number on the client machine instead of “COM1”.
1. Specify “COM1”under serial line and “115200”for speed, no parity, no flow
control.
2. Check Serial for connection type.
3. Check “VT100+”for keypad in the keyboard submenu.
4. Check “Colour”or “Both” for “Indicate bolded text”in the colours submenu.
5. Click the “Open” button and a PuTTY terminal screen will appear.

SKY-8232DManualV0220220411 Copyright2022 AdvantechCo.Ltd.Allrightsreserved Page 20
Figure 1-1: PuTTY Session Configuration
Figure 1-2: PuTTY Serial Configuration
