PCM-3343 Startup Manual 1
Before you begin installing your card, please make sure that
the following items have been shipped:
1 x PCM-3343 SBC
1 x Startup manual
1 x CD-ROM (Manual, Driver, Utility)
1 x Cable 6P-6P-6P PS/2 KB & Mouse 20 cm
(p/n: 1700060202)
1 x PS2 Cable 6P (MINI-DIN)-6P (Wafer 2.0 mm) 6 cm
(p/n: 1703060053)
1 x USB cable 2port 2.0 mm pitch w/ bracket 26 cm
(p/n: 1703100260)
1 x RS232 x2 ports 2.0 mm pitch 22 cm
(p/n: 1701200220)
1 x RS-422/485 W/D-SUB COM 4P 15 cm
(p/n: 1703040157)
1 x VGA cable D-SUB 15P(F)/12P-1.25 mm 15 cm
(p/n: 1700000898)
1 x LAN cable RJ45/2*5P-2.0 15 cm
(p/n: 1700017863)
1 x PC/104 screw and copper post package
(p/n: 9660104000)
Optional Accessories
1 x IDE cable 44P/44P/44P 35 cm (p/n:1701440350)
If any of these items are missing or damaged, please con-
tact your distributor or sales representative immediately.
Note: Acrobat Reader is required to view any PDF file.
Acrobat Reader can be downloaded at: www.adobe.com/
Prodindex/acrobat/readstep.html (Acrobat is a trademark
of Adobe).
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
11.
PCM-3343 DM&P Vortex86DX-1 GHz SOC
PC/104 SBC, LVDS, TTL, dual LAN, CFC and On board
memory
Startup Manual
Standard SBC Functions
Processor: DM&P Vortex86DX SOC 1GHz
– x86 Compatible Processor Core 6 stage pipeline
– Floating point unit support
– Embedded I / D Separated L1 Cache 16K I-Cache, 16K
D-Cache
– DMA Controller
– Package Type 27x27, 581 Ball BGA
System Memory: Supports On board DDR2 333
SDRAM Memory 256MB. Up to 512MB for optional
2nd Cache Memory: 256 KB on the processor
BIOS: Award integrated 16 Mbit ROM in SOC
Watchdog timer: System reset; Software programmable
from 30.5μ sec.to 512 sec. x 2 sets
Expansion Interface: PC/104 (ISA)
Battery: Lithium 3V/210 mAh
Enhanced IDE interface: One channel supports up to
two EIDE devices . Supports UDMA 33 mode
Note! When you use CF socket , IDE connector just can
attach one IDE device.
CFC: Solid State Disk (SSD) supports one 50-pin socket
for CFC type I (type II optional) shared with primary IDE
External SPI on board Flash: Optional onboard 4MByte
SPI Flash Disk(Support by request for boot device or
storage on DOS OS)
Serial ports: Four serial RS-232 ports, one of them can
be configured to RS-422/485 ports by jumper J2
1. CN7 provides two RS-232 serial ports (COM3/4).
2. CN12 provides two RS-232 serial ports (COM1/2).
3. CN6 provides one RS-422/485 serial port adjusted by
J2, and you just can select either COM2 (RS-232) on
CN12 or RS-422/485 on CN6.
Note!
When RS-422/485 on CN6 is enable, COM2(RS-232)
on CN12 will be disable.
When using PWM Brightness control, COM2 will be
configured as PWM function using. You can select
either COM2 or PWM Brightness control function.
•
•
•
•
•
•
•
•
•
•
•
1.
2.
Specications
Packing List
For more information on this and other Advantech
products, please visit our website at:
http://www.advantech.com
http://www.advantech.com/eplatform
For technical support and service, please visit our
support website at:
http://service.advantech.com/support
This manual is for the PCM-3343 series Rev. A1
Part No. 2006334300
Print in China
1st Edition,
March 2010

2 PCM-3343 Startup Manual
Keyboard/mouse connector: Supports one standard
PC/AT keyboard and a PS/2 mouse
USB: Four USB 2.0 ports compliant universal serial bus
ports
GPIO: 16 bit general purpose Input/Output
I2C: Compliant w/t V2.1, Some master code (general call,
START and CBUS) not support
VGA/TTL Interface
Controller: SMI SM712 2D graphic Chip
VRAM: 4 MB internal memory
Graphic Engine:
– 62.5MHz single clock/cycle engine (EM+)
– 86MHz single clock/cycle engine (EM4+)
– Designed to accelerate DirectDraw
Output Interfaces:
– VGA: Supports up to 1024 x 768 @85Hz
– LVDS: Supports up to 1024 x 768 @ 24-bit LVDS LCD
Panel
– TTL: Supports up to 1024 x 768 @ 24-bit TTL LCD
Panel
– Dual Display: CRT + LVDS and CRT+TTL, support
extended mode and clone Mode
Note! TTL and LVDS interface are not recommended to use
together at the same time.
Ethernet Interface
Supports Dual 10/100 Mbps Ethernet networking
– LAN1 Controller: Integrated Vortex86DX SOC 10/100
Mbps Ethernet
– LAN2 Controller: Realtek RTL 8100CL 10/100 Mbps
Ethernet
OS support
This board supports Win XP, Window WP Embedded, Win
CE , Linux.
Supports Embedded Software API: Watchdog, GPIO,
Brightness control, I2C,and backlight on/off.
Supports Embedded Software Utility: BIOS flash, eSOS,
Embedded Security ID, and Flash Lock.
Software Ordering Information:
2070009536: CE 6.0 Pro PCM-3343 V1.3 ENG
2070009528: XPE WES2009 Vortex86DX V4.0 ENG
2070009529: XPE WES2009 Vortex86DX V4.0 MUI24”
205E343000: SUSI 3.0 SW API for PCM-3343 Window
XP/XPE
For further information about OS support in your PCM-
3343, visit the following . Advantech web resource: www.
advantech.com or please contact your technical support
center.
•
•
•
•
•
•
•
•
•
Mechanical and Environmental
Dimensions: 96 x 90 mm (3.8” x 3.5”) Mechanical Draw-
ing (dxf file) is available
Power Supply Type: AT
Power Requirement: +5 V ± 5%, +12 V ± 5% (Optional),
(5 V only,12 V optional for PC104 add on card and LCD
inverter)
Power Consumption: (Vortex86DX 1GHz, 512MB DDRII
667)
– Power on Load: +5 V@ 1.05 A, +12 V@ 0.01A
– Max load: +5 V@ 1.04 A, +12 V@ 0.01A
– Idle mode: +5 V@ 0.83 A, +12 V@ 0.01A
Power Consumption Conditions:
– Test software: Passmark Burnin Test Pro6.0
– Power on - Boot: Measure the maximum current value of
between system power on and boot-up to O.S.
– Max. load: Measure the maximum current value which
system under maximum load on running Passmark
Burnin Test (CPU: Top speed, RAM &Graphic: Full
loading)
– Idle mode: Measure the current value when system in
DOS mode and without running any program
Operating temperature: 0 ~ 60° C (32 ~ 140° F) (opera-
tion humidity: 40° C @ 85% RH Non-Condensing)
Weight: 0.097 kg (0.214lb) (reference weight of total
package)
•
•
•
•
•
•
•
Specications Specications

PCM-3343 Startup Manual 3
LVDS Panel Power Select (J1)
Setting Function
1-2 3.3 V (default)
2-3 5 V
COM2 RS232/RS422/RS485 Select (J2)
Setting Function
1-2
RS-232 (Default)
3-4 RS-485
5-6
RS-422
The CD disc contains a driver installer program that will
guide you through the installation of various device drivers
needed to take full advantage of your CPU card.
The computer is provided with a battery-powered Real-time
Clock circuit. There is a danger of explosion if the battery is
incorrectly replaced. Replace only with same or equivalent
type recommended by the manufacturer. Discard used bat-
teries according to manufacturer’s instructions.
The device complies with the requirements in Part 15 of
the FCC rules. Operation is subject to the following two
conditions:
This device may not cause harmful interference;
This device must accept any interference received,
including interference that may cause undesired opera-
tion.
1.
2.
The board has a number of connectors and jumpers
that help to configure the system to suit your application
requirements. The tables below list the functions of each
connectors and jumpers.
Label Function
J1 LVDS Panel Power Select
J2 COM2 RS-232/RS422/RS485 Select
CN1
SPI Connecter
CN2 LVDS Panel Connecter
CN3 LCD Panel Connecter
CN4 PS2 Keyboard/Mouse Connecter
CN5
Power In Connecter
CN6 RS422/RS485 Connecter
CN7
COM3/4 Connecter
CN8
PC104 Connecter
CN9 GPIO Connecter
CN10 IDE Connecter
CN11 LAN2 Connecter
CN12 COM1/2 Connecter
CN13 USB1/2 Connector
CN14
Inverter Connector
CN15 System Reset Connector
CN16 -12 V / -5 V Power In Connector
CN17 JTAG Connector
CN18 PWR / HDD LED Connector
CN19 LAN1 LED Connecter
CN20 I2C Connecter
CN21 LAN2 LED Connecter
CN22 VGA Connector
CN23 CF Socket
CN24 LAN1 Connector
CN25 USB3/4 Connecter
Software Installation
Caution
Safety Information
Jumpers and Connectors
Jumpers and Connectors

4 PCM-3343 Startup Manual
PCM-3343 Location Connectors & Jumpers (Component Side)
PCM-3343 Location Connectors & Jumpers (Solder Side)
Locating Connectors and Jumpers

PCM-3343 Startup Manual 5
PCM-3343 Mechanical Drawing (Component Side)
PCM-3343 Mechanical Drawing (Solder Side)
Mechanical Drawings
