advidia A-18 User manual

0
Network Bullet Camera
Quick Start Guide

Network Bullet Camera·Quick Start Guide
1
1
About this Manual
This Manual is applicable to A-18, A-28, A-38 Network Camera.
The Manual includes instructions for using and managing the
product. Pictures, charts, images and all other information
hereinafter are for description and explanation only. The
information contained in the Manual is subject to change, without
notice, due to firmware updates or other reasons. Please find the
latest version in the company website
Please use this user manual under the guidance of professionals.
Legal Disclaimer
REGARDING TO THE PRODUCT WITH INTERNET ACCESS, THE USE OF
PRODUCT SHALL BE WHOLLY AT YOUR OWN RISKS. OUR COMPANY
SHALL NOT TAKE ANY RESPONSIBILITES FOR ABNORMAL OPERATION,
PRIVACY LEAKAGE OR OTHER DAMAGES RESULTING FROM CYBER
ATTACK, HACKER ATTACK, VIRUS INSPECTION, OR OTHER INTERNET
SECURITY RISKS; HOWEVER, OUR COMPANY WILL PROVIDE TIMELY
TECHNICAL SUPPORT IF REQUIRED.
SURVEILLANCE LAWS VARY BY JURISDICTION. PLEASE CHECK ALL
RELEVANT LAWS IN YOUR JURISDICTION BEFORE USING THIS
PRODUCT IN ORDER TO ENSURE THAT YOUR USE CONFORMS THE
APPLICABLE LAW. OUR COMPANY SHALL NOT BE LIABLE IN THE
EVENT THAT THIS PRODUCT IS USED WITH ILLEGITIMATE PURPOSES.
IN THE EVENT OF ANY CONFLICTS BETWEEN THIS MANUAL AND THE
APPLICABLE LAW, THE LATER PREVAILS.
Regulatory Information
FCC Information

Network Bullet Camera·Quick Start Guide
2
2
Please take attention that changes or modification not expressly
approved by the party responsible for compliance could void the
user’s authority to operate the equipment.
FCC compliance: This equipment has been tested and found to
comply with the limits for a Class B digital device, pursuant to part
15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation.
This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference
will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which
can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the
following measures:
—Reorient or relocate the receiving antenna.
—Increase the separation between the equipment and receiver.
—Connect the equipment into an outlet on a circuit different from
that to which the receiver is connected.
—Consult the dealer or an experienced radio/TV technician for help
FCC Conditions
This device complies with part 15 of the FCC Rules. Operation is
subject to the following two conditions:
1. This device may not cause harmful interference.
2. This device must accept any interference received, including
interference that may cause undesired operation.

Network Bullet Camera·Quick Start Guide
3
3
EU Conformity Statement
This product and - if applicable - the supplied
accessories too are marked with "CE" and comply
therefore with the applicable harmonized European
standards listed under the EMC Directive 2014/30/EU, the RoHS
Directive 2011/65/EU
2012/19/EU (WEEE directive): Products marked
with this symbol cannot be disposed of as unsorted
municipal waste in the European Union. For proper
recycling, return this product to your local supplier
upon the purchase of equivalent new equipment, or dispose of it at
designated collection points. For more information see:
www.recyclethis.info
2006/66/EC (battery directive): This product
contains a battery that cannot be disposed of as
unsorted municipal waste in the European Union.
See the product documentation for specific battery
information. The battery is marked with this symbol, which may
include lettering to indicate cadmium (Cd), lead (Pb), or mercury (Hg).
For proper recycling, return the battery to your supplier or to a
designated collection point. For more information see:
www.recyclethis.info
Industry Canada ICES-003 Compliance
This device meets the CAN ICES-3 (B)/NMB-3(B) standards
requirements.

Network Bullet Camera·Quick Start Guide
4
4
Safety Instruction
These instructions are intended to ensure that user can use the
product correctly to avoid danger or property loss.
The precaution measure is divided into “Warnings” and “Cautions”
Warnings: Serious injury or death may occur if any of the warnings
are neglected.
Cautions: Injury or equipment damage may occur if any of the
cautions are neglected.
Warnings
●In the use of the product, you must be in strict compliance with
the electrical safety regulations of the nation and region. Please
refer to technical specifications for detailed information.
●Input voltage should meet both the SELV (Safety Extra Low
Voltage) and the Limited Power Source with 24 VAC or 12 VDC
according to the IEC60950-1 standard. Please refer to technical
specifications for detailed information.
Warnings Follow these
safeguards to prevent
serious injury or death.
Cautions Follow these
precautions to prevent potential
injury or material damage.

Network Bullet Camera·Quick Start Guide
5
5
●Do not connect several devices to one power adapter as
adapter overload may cause over-heating or a fire hazard.
●Please make sure that the plug is firmly connected to the power
socket. When the product is mounted on wall or ceiling, the
device shall be firmly fixed.
●If smoke, odor or noise rise from the device, turn off the power
at once and unplug the power cable, and then please contact
the service center.
●Proper configuration of all passwords and other security
settings is the responsibility of the installer and/or end-user.
Cautions
●Make sure the power supply voltage is correct before using the
camera.
●Do not drop the camera or subject it to physical shock.
●Do not touch sensor modules with fingers. If cleaning is
necessary, use clean cloth with a bit of ethanol and wipe it
gently. If the camera will not be used for an extended period,
please replace the lens cap to protect the sensor from dirt.
●Do not aim the camera at the sun or extra bright places.
Blooming or smearing may occur otherwise (which is not a
malfunction), and affect the endurance of sensor at the same
time.
●The sensor may be burned out by a laser beam, so when any
laser equipment is in using, make sure that the surface of
sensor will not be exposed to the laser beam.

Network Bullet Camera·Quick Start Guide
6
6
●Do not place the camera in extremely hot, cold (the operating
temperature shall be-30°C ~+60°C , dusty or damp locations,
and do not expose it to high electromagnetic radiation.
●To avoid heat accumulation, good ventilation is required for
operating environment.
●Keep the camera away from liquid while in use.
●While in delivery, the camera shall be packed in its original
packing, or packing of the same texture.
●Regular part replacement: a few parts (e.g. electrolytic
capacitor) of the equipment shall be replaced regularly
according to their average enduring time. The average time
varies because of differences between operating environment
and using history, so regular checking is recommended for all
the users. Please contact with your dealer for more details.
●Improper use or replacement of the battery may result in
hazard of explosion. Replace with the same or equivalent type
only. Dispose of used batteries according to the instructions
provided by the battery manufacturer.
●If the product does not work properly, please contact your
dealer or the nearest service center. Never attempt to
disassemble the camera yourself. (We shall not assume any
responsibility for problems caused by unauthorized repair or
maintenance.)

Network Bullet Camera·Quick Start Guide
7
7
Table of Contents
1 Appearance Description ................................................................. 8
Overview of Type I Bullet Camera(A-18, A-38) ................ 8
Overview of Type II Bullet Camera(A-28)....................... 10
2 Installation.................................................................................... 12
Installation of Memory Card ......................................... 13
Installation of the Bullet Camera................................... 14
Installation of Network Cable Water-proof Jacket......... 16
3 Setting the Network Camera over the LAN .................................. 19
Wiring ........................................................................... 19
Activating the Camera................................................... 20
Activation via Web Browser................................ 20
Activation via Advidia Camera Finder Utility....... 21
4 Accessing via Web Browser .......................................................... 24

Network Bullet Camera·Quick Start Guide
8
8
1Appearance Description
Overview of Type I Bullet Camera(A-18,
A-38)
1
2
3
4
5
6
9
7
8

Network Bullet Camera·Quick Start Guide
9
9
Type I Bullet Camera
Description
No.
Description
No.
Description
1
Mounting Base
4
Lens
2
Back Case
5
Sun Shield
3
Front Case
6
Power Cable
7
Reset Button
8
GND Screw
9
10/100M Self-adaptive
Ethernet Interface
Type I camera does not support the function of Wi-Fi or SD card.
Press Reset button about 10s when the camera is power on or
rebooting to restore the default settings, including the user name,
password, IP address, port No., etc.

Network Bullet Camera·Quick Start Guide
10
10
Overview of Type II Bullet Camera(A-28)
13
24
5
7
6
8
9
10
Type II Bullet Camera

Network Bullet Camera·Quick Start Guide
11
11
Description
No.
Description
No.
Description
1
Mounting Base
6
Grounding Screw
2
Back Case
7
10/100M Self-adaptive
Ethernet Interface (PoE)
3
Front Case
8
Power Supply (DC 12V)
4
Lens
9
Memory Card Slot
5
Sun Shield
10
Reset Button
This type of bullet camera supports PoE power supply. You can
power the camera by connecting both DC 12V interface and the
Ethernet interface. Or you can connect the Ethernet interface
only.
Press and hold the reset button about 10s when the camera is
powering on or rebooting to restore the default settings, including
the user name, password, IP address, port No., etc.

Network Bullet Camera·Quick Start Guide
12
12
2Installation
Before you start:
●Make sure the device in the package is in good condition and all
the assembly parts are included.
●The standard power supply is 12V DC, please make sure your
power supply matches with your camera.
●Make sure all the related equipment is power-off during the
installation.
●Check the specification of the products for the installation
environment.
●Make sure that the wall is strong enough to withstand four
times the weight of the camera and the bracket.
For the camera that supports IR, you are required to pay attention to
the following precautions to prevent IR reflection:
●Dust or grease on the dome cover will cause IR reflection.
Please do not remove the dome cover film until the installation
is finished. If there is dust or grease on the dome cover, clean
the dome cover with clean soft cloth and isopropyl alcohol.
●Make sure that there is no reflective surface too close to the
camera lens. The IR light from the camera may reflect back into
the lens causing reflection.
●The foam ring around the lens must be seated flush against the
inner surface of the bubble to isolate the lens from the IR LEDS.
Fasten the dome cover to camera body so that the foam ring
and the dome cover are attached seamlessly.

Network Bullet Camera·Quick Start Guide
13
13
Installation of Memory Card
Type II and Type III camera support memory card function. Follow
the steps to mount and unmount a memory card.
Steps:
1. Unscrew the cover on back case to expose memory card slot.
Cover
Unscrew the Cover
2. Insert the memory card into the memory card slot.
Insert Memory Card

Network Bullet Camera·Quick Start Guide
14
14
3. (Optional)To unmount the memory card, push to get it ejected.
4. Screw the cover back to the camera.
Installation of the Bullet Camera
Both wall mounting and ceiling mounting are suitable for the bullet
camera. Wall mounting will be taken as an example in this section.
You can take steps of wall mounting as a reference if ceiling
mounting is adopted.
Steps:
1. Drill the screw holes in the wall according to the drill template.
Ceiling Mounting
Hole
Hole
Hole
Drill Template
2. Route the corresponding cables.
3. Secure the camera to the wall with the supplied Screws.

Network Bullet Camera·Quick Start Guide
15
15
Secure the Camera to the Ceiling
4. Connect the cables and power on the camera to view live view
image.
5. Adjust the surveillance angle.
Tilt: 0°to 90°
Adjusting Nut
Pan:
0°to 360°
Rotate:
0°to 360°
3-axis Adjustment
1). Loosen the adjusting nut.
2). Adjust the pan direction [0°to 360°].

Network Bullet Camera·Quick Start Guide
16
16
3). Adjust the tilt direction [0°to 90°].
4). Rotate the camera [0°to 360°] to adjust the lens to the
surveillance angle.
5). Tighten the adjusting nut to complete the installation.
Installation of Network Cable Water-proof
Jacket
Purpose:
If the camera is installed outdoor, you can adapt the water-proof
accessory for the network cable after the camera is secured on the
installation surface.
①②③④⑤⑥ ⑦
Figure 2-6 Water-proof Accessory Components
Table 2-1 Components
No.
Components
1
Camera’s Network Interface Socket
2
O-Type Gasket
3
Network Plug

Network Bullet Camera·Quick Start Guide
17
17
No.
Components
4
Waterproof Endcap
5
Waterproof Rubber Gasket
6
Lock Nut
7
Network Cable from Router/Switch
Camera
Switch/Router
Align the snap and notch.
i. Insert ⑤into ④.
ii. Secure ⑥with ④.
Water-proof Accessory Installation
Steps:

Network Bullet Camera·Quick Start Guide
18
18
Feed the plugless network cable ⑦through the lock nut ⑥,
waterproof rubber gasket ⑤(rubber gasket inset ridge must
face waterproof endcap), and the water-proof endcap ④in
order.
Crimp an RJ-45 network plug ③onto the end of the cable,
taking care to insert the twisted pairs of wires in correct order.
Place the O-type gasket ②onto the end of the camera’s
network interface socket ①.
Insert the network plug ③into the camera’s network interface
socket①.
Insert the water-proof rubber gasket ⑤into the waterproof
endcap ④, and secure lock nut ⑥with the water-proof
endcap ④.
Align the snap on the water-proof endcap ④with the notch on
the camera’s network interface socket ①,and then secure the
water-proof endcap ④to the camera’s network interface
socket ①to finish installation.

Network Bullet Camera·Quick Start Guide
19
19
3Setting the Network Camera over the
LAN
Note:
You shall acknowledge that the use of the product with Internet
access might be under network security risks. For avoidance of any
network attacks and information leakage, please strengthen your
own protection.
If the product does not work properly, contact your dealer or the
nearest service center for help.
Wiring
Connect the camera to network according to the following figures.
半球
Network Cable
or
Network Camera
Computer
Connecting Directly
网络交换机
半球
Network Cable
Network Cable
or
or
Network Camera Computer
Connecting via a Switch or a Router
