ADX FIREPOWER MK06 User manual

FIREPOWER
MK06
RGB GAMING MOUSE
INSTRUCTION MANUAL
ADXM0620

Contents
Safety Warnings................................................................................. 3
Unpacking.......................................................................................... 4
Product Overview.............................................................................. 5
System Requirements ....................................................................... 5
Software Installation......................................................................... 5
User Interface..................................................................................... 6
DPI Setting ......................................................................................... 7
Lighting Eect.................................................................................... 8
Performance....................................................................................... 9
Polling Rate...................................................................................... 10
Macro Editor..................................................................................... 11
Hints and Tips................................................................................... 12
Specications................................................................................... 12

Safety Warnings
Never point the optical sensor towards the face, particularly
the eyes, to avoid possible injury.
• While the mouse is functioning, the optical light is visible to the
naked eye. Avoid looking directly into the emitter hole while the
mouse is active.
• Your product complies with CE rules.
• This product has no serviceable parts. Use of controls or
adjustments of procedures other than the Instruction Manual may
result in danger.

4
Unpacking
Remove all items from the packaging. Retain the packaging. If you
dispose of it please do so according to local regulations.
The following items are included:
Thank you for purchasing your new product.
We recommend that you spend some time reading this
instruction manual in order that you fully understand all
the operational features it oers. You will also nd some
hints and tips to help you resolve any issues.
Read all the safety instructions carefully before use and
keep this instruction manual for future reference.
Gaming Mouse

5
1. Right Button
2. Scroll Wheel
3. Left Button
1
2
3
4. DPI Button
Select dierent dpi.
5. Forward/Backward
Buttons
Product Overview
4
5
System Requirements
Operating Systems: Microsoft® Windows® 8 / 10
Hardware: 1 available USB port
Software Installation
1. Plug the unit into the USB port of your computer.
2. Download the latest gaming software from
https://downloads.adxgaming.com
3. Run the software installer.
4. Follow the installation instruction to complete the installation.
5. Choose ADX ADXM0620.exe from the desktop to start the
software.
The software is not available for MAC OS.

6
Left Click
1
1
4
5
2
Right Click
2
Wheel Click
3
Forward
4
Backward
Profile
Profile
Macro Editor
5
Restore Apply
3
DPI Setting
Performance
Polling Rate
Lighting Eect
ON
XY Independent X
Current DP: 1600
DPI Colour
400
1
400
800
2
800
1600
3
1600
3200
4
3200
64000
5
64000
12000
6
12000
Y
User Interface
Choose ADX ADXM0620.exe from the desktop to start the
software.
1. Customising the Buttons
• Change the mouse button
into desired functions
from the function list.
• At least 1 mouse button
must remain as the
primary button (left click).
2. Minimise the software
3. Exit the software
4. Macro Editor
Click to enter MACRO
EDITOR section for editing.
5. Select prole
6. Setting Options
7. Restore to default setting
8. Save the current setting
2 31
87
5
4
6

7
Left Click
1
1
4
5
2
Right Click
2
Wheel Click
3
Forward
4
Backward
Profile
Profile
Macro Editor
5
Restore Apply
3
DPI Setting
Performance
Polling Rate
Lighting Eect
ON
XY Independent X
Current DP: 1600
DPI Colour
400
1
400
800
2
800
1600
3
1600
3200
4
3200
64000
5
64000
12000
6
12000
Y
DPI Setting
Select PDI Setting from the user interface.
1. DPI Setting
Sensitivity (DPI) pertains to how much eort is needed to
move the mouse pointer in any direction. The higher the DPI,
the faster the mouse movement.
2. X-Y Independent
• The X-axis (horizontal) and Y-axis (vertical) use the same
sensitivity values.
• You may set dierent sensitivity values to each of the axis by
selecting X-Y Independent.
1
2

8
Left Click
1
1
4
5
2
Right Click
2
Wheel Click
3
Forward
4
Backward
Profile
Profile
Macro Editor
5
Restore Apply
3
DPI Setting
Performance
Polling Rate
Lighting Eect
Eect
Colour - double click to pick a colour
Speed
Direction
2
Spectrum Cycling
Lighting Eect
Select Lighting Eect from the user interface.
1. Lighting eect option
2. Customise the colour
Select desired LED colour.
3. Breathing Sequence
Select breathing sequence level.
4. LED owing direction
1
2
3
4

9
Left Click
1
1
4
5
2
Right Click
2
Wheel Click
3
Forward
4
Backward
Profile
Profile
Macro Editor
5
Restore Apply
3
DPI Setting
Performance
Polling Rate
Lighting Eect
Pointer Speed
10
Pointer Acceleration
Scrolling Wheel
3
Scroll for One Page
Double-click
Slow Fast
Performance
Select Performance from the user interface.
1. Pointer Speed
Adjust the speed of your mouse pointer.
2. Scroll Wheel
Adjust the scrolling speed.
3. Double-click
Adjust the double click response time.
1
2
3

10
Left Click
1
1
4
5
2
Right Click
2
Wheel Click
3
Forward
4
Backward
Profile
Profile
Macro Editor
5
Restore Apply
3
DPI Setting
Performance
Polling Rate
Lighting Eect
Polling Rate
500 Hz
Polling Rate
Select Polling Rate from the user interface.
1. Polling Rate
The higher the polling rate, the more often the computer
receives information about the status of your mouse, thus
increasing the mouse pointer’s reaction time.
You can select among 125Hz (8ms), 500Hz (2ms) and 1000Hz
(1ms).
1

11
MACRO
New macro Delete
KEY SEQUENCE
Modify Delete
Start record
Insert option
Record delay
Fire mode
Loop mode
Specied cycle times
1 – 255
Macro Editor
By assigning a macro to a mouse button, you can execute complex
combinations with ease.
Select MACRO EDITOR from
the user interface.
1. Macro List
A list of macro prole.
2. Keypress recorded
3. Create New Macro
Create new macro prole.
4. Delete Current Item
Delete selected macro or
command.
5. Modify
Edit the selected keypress
or delay.
6. Delete
Delete selected keypress
or delay.
7. Start/Stop record
8. Record Delays
Insert time delay between each
command while recording
macro.
* Delay (1sec = 1000ms)
9. Macro Type
Choose a macro type.
Firekey mode: macro will
repeat as long as the button is
clicked.
Loop mode: click once to start
looping the macro, click again
to stop.
Number of loops
10. Insert option
12
7
8
9
10
3 54 6

12
Hints and Tips
• Make sure the USB plug is fully plugged into a USB port and
the computer is on or try to use a dierent USB port.
• If the mouse is moving erratically, change the working surface
which the mouse is operating on.
• If the software is not working properly, uninstall it and then
reboot the computer. Re-install the software.
• If the unit is not working properly, re-insert the USB plug into
the USB port.
Specications
Model ADXM0620
Resolution 400 – 12000 dpi
Dimension (L x W x H) 128.7 x 67.3 x 38.4 mm
Net Weight 102 g
Features and specications are subject to change without prior
notice.
The symbol on the product or its packaging indicates that this
product must not be disposed of with your other household
waste. Instead, it is your responsibility to dispose of your waste
equipment by handing it over to a designated collection point for
the recycling of waste electrical and electronic equipment. The
separate collection and recycling of your waste equipment at the
time of disposal will help conserve natural resources and ensure that it is
recycled in a manner that protects human health and the environment.
For more information about where you can drop o your waste for recycling,
please contact your local authority, or where you purchased your product.
Windows is a registered trademark of Microsoft Corporation in the United
States and other countries.
All trademarks are the property of their respective owners and all rights are
acknowledged.

IB-ADXM0620-201202V2
DSG Retail Ltd. (co. no. 504877)
1 Portal Way, London, W3 6RS, UK
