ADX FIREPOWER H02 User manual

FIREPOWER H02
RGB GAMING MOUSE
INSTRUCTION MANUAL
AFPH0219

GB Contents
Safety Warnings...................................................................................................5
Unpacking............................................................................................................7
Product Overview................................................................................................8
System Requirements .........................................................................................8
Software Installation...........................................................................................8
User Interface.......................................................................................................9
Prole Setting................................................................................................... 10
DPI Setting ........................................................................................................ 11
Light Setting ..................................................................................................... 12
Macro Setting.................................................................................................... 13
Hints and Tips.................................................................................................... 15
Specications.................................................................................................... 15
NO Innhold
Sikkerhetsadvarsler ............................................................................................5
Pakke opp.......................................................................................................... 16
Produktoversikt................................................................................................ 17
Systemkrav........................................................................................................ 17
Installasjon av programvare............................................................................ 17
Brukergrensesnitt............................................................................................. 18
Prolinnstilling................................................................................................. 19
DPI innstilling ................................................................................................... 20
Lysinnstilling..................................................................................................... 21
Makroinnstilling ............................................................................................... 22
Råd og tips ........................................................................................................ 24
Spesikasjoner ................................................................................................. 24

SE Innehållsförteckning
Säkerhetsföreskrifter..........................................................................................5
Packa upp.......................................................................................................... 25
Produktöversikt................................................................................................ 26
Systemkrav........................................................................................................ 26
Installation av fast programvara..................................................................... 26
Användargränssnitt ......................................................................................... 27
Prolinställning................................................................................................ 28
DPI inställning .................................................................................................. 29
Ljusinställning .................................................................................................. 30
Makroinställning .............................................................................................. 31
Tips och råd....................................................................................................... 33
Specikationer.................................................................................................. 33
FI Sisältö
Turvavaroitukset .................................................................................................6
Pakkauksesta purkaminen .............................................................................. 34
Tuotteen yleiskatsaus ...................................................................................... 35
Järjestelmävaatimukset................................................................................... 35
Ohjelmistoasennus........................................................................................... 35
Käyttöliittymä................................................................................................... 36
Proiliasetus ..................................................................................................... 37
DPI asetus.......................................................................................................... 38
Valoasetus......................................................................................................... 39
Makroasetus ..................................................................................................... 40
Vihjeitä ja vinkkejä........................................................................................... 42
Tekniset tiedot.................................................................................................. 42

DK Indholdsfortegnelse
Sikkerhedsforanstaltninger ...............................................................................6
Udpakning ........................................................................................................ 43
Produktoversigt................................................................................................ 44
Systemkrav........................................................................................................ 44
Soiftwareinstallation........................................................................................ 44
Brugergrænseade........................................................................................... 45
Prolindstilling................................................................................................. 46
DPI indstillinger................................................................................................ 47
Lysindstillinger ................................................................................................. 48
Makro-indstilling.............................................................................................. 49
Gode råd............................................................................................................ 51
Specikationer.................................................................................................. 51
GR Περιεχόμενα
Προειδοποιήσεις ασφαλείας ..............................................................................6
Αφαίρεση συσκευασίας ................................................................................... 52
Επισκόπηση προϊόντος.................................................................................... 53
Απαιτήσεις συστήματος................................................................................... 53
Εγκατάσταση λογισμικού ................................................................................ 53
Περιβάλλον χρήστη.......................................................................................... 54
Ρύθμιση προφίλ................................................................................................ 55
Ρύθμιση DPI ...................................................................................................... 56
Ρύθμιση φωτισμού........................................................................................... 57
Ρύθμιση μακροεντολών................................................................................... 58
Υποδείξεις και Συμβουλές ............................................................................... 60
Προδιαγραφές .................................................................................................. 60

GB Safety Warnings
Never point the optical sensor towards the face, particularly
the eyes, to avoid possible injury.
• While the mouse is in use, the optical light is visible to the naked
eye. Avoid looking directly into the emitter hole while the mouse
is active.
• Your product complies with CE rules.
• This product has no serviceable parts. Use of controls or
adjustments of procedures other than the Instruction Manual may
result in danger.
NO Sikkerhetsadvarsler
Sikt aldri den optiske sensoren mot ansiktet , spesielt øynene ,
for å unngå mulig skade.
• Når musen er i bruk, er det optiske lyset synlig for det blotte øye.
Ikke se direkte inn i utstrålingshullet mens musen er i bruk.
• Produktet er i samsvar med CE-reglene.
• Dette produktet har ingen servicedeler. Bruk av kontroller
eller justeringer av andre typer enn de som er oppgitt i
Instruksjonsmanual, kan føre til fare.
SE Säkerhetsföreskrifter
Rikta aldrig den optiska sensorn mot ditt ansikte, särskilt inte
mot ögonen, för att undvika skador.
• När musen används kan man se den optiska strålen med ögat.
Undvik att titta direkt i strålningshålet när musen är aktiv.
• Din produkt uppfyller CE-reglerna.
• Denna produkt har inga servicebara delar. Användning
av kontroller eller justeringar av procedurer andra än de i
Instruktionsbok kan resultera i fara.

FI Turvavaroitukset
Älä koskaan suuntaa optista anturia kohti kasvoja, erityisesti
kohti silmiä. Näin vältät mahdolliset vammat.
• Optinen valo näkyy paljain silmin, kun hiiri on käytössä. Vältä
katsomasta suoraan lähetinreikään hiiren ollessa aktiivinen.
• Tämä tuote on CE-sääntöjen mukainen.
• Tässä tuotteessa ei ole huollettavia osia. Ohjainten käyttö tai
toimenpiteiden säätäminen toisin kuin tässä Käyttöopas voi johtaa
vaaratilanteeseen.
DK Sikkerhedsforanstaltninger
Peg aldrig den optiske sensor mod ansigtet, især øjnene, for at
undgå mulige skader.
• Når musen er i brug, er det optiske lys synligt for øjet. Undgå at
kigge direkte i laserhullet, mens musen er aktiv.
• Produktet overholder CE-reglerne.
• Dette produkt har ingen servicerbare dele. Brug af kontroller
eller justeringer på anden måde end beskrevet i denne
Brugervejledning kan medføre fare.
GR Προειδοποιήσεις ασφαλείας
Μην στρέφετε ποτέ τον οπτικό αισθητήρα προς το πρόσωπο,
ιδιαίτερα τα μάτια, για να αποφύγετε πιθανό τραυματισμό.
• Ενώ το ποντίκι λειτουργεί, το οπτικό φως είναι ορατό με γυμνό μάτι.
Αποφεύγετε να κοιτάτε απευθείας στην οπή του πομπού, ενώ το
ποντίκι είναι ενεργό.
• Το προϊόν σας συμμορφώνεται με τους κανόνες CE.
• Αυτό το προϊόν δεν διαθέτει εξαρτήματα που μπορούν να
επισκευαστούν. Η χρήση χειριστηρίων ή διαδικασιών διαφορετικών
από εκείνες που καθορίζονται στις Οδηγίες χρήσης μπορεί να
προκαλέσουν έκθεση σε κίνδυνο.

GB
7
Unpacking
Remove all items from the packaging. Retain the packaging. If you
dispose of it please do so according to local regulations.
The following items are included:
Thank youfor purchasing your new product.
We recommend that you spend some time reading this
instruction manual in order that you fully understand all
the operational features it oers. You will also nd some
hints and tips to help you resolve any issues.
Read all the safety instructions carefully before use and
keep this instruction manual for future reference.
Gaming Mouse

GB
8
1. Right Button
2. Scroll Wheel
3. Left Button
1
2
3
4. DPI Buttons
Select dierent dpi.
5. Forward/Backward
Buttons
Product Overview
5
4
System Requirements
Operating Systems: Microsoft® Windows® 7 / 8 / 10
Hardware: 1 available USB port
Software Installation
1. Plug the unit into the USB port of your computer.
2. Download the latest gaming software from
https://downloads.adxgaming.com
3. Run the software installer.
4. Follow the installation instruction to complete the installation.
5. Choose ADX Gaming.exe from the desktop to start the
software.
The software is not available for MAC OS.

GB
9
Left Click1
1 3
2
6
7
Wheel Click2
Right Click3
Forward4
Backward5
DPI +6
DPI –7
4
5
Profile 1 Profile 2 Advanced Light Macro
Reset Apply
User Interface
Choose ADX Gaming.exe from the desktop to start the software.
1. Setting options.
2. Minimise the software.
3. Exit the software.
4. Restore to default setting.
5. Save the current setting.
1 2
4 5
3

GB
10
Left Click1
1 3
2
6
7
Wheel Click2
Right Click3
Forward4
Backward5
DPI +6
DPI –7
4
5
Profile 1 Profile 2 Advanced Light Macro
Reset Apply
1
2
Prole Setting
Select Prole from the user interface.
1. Prole
Selecting prole 1-2 will load the desired setting of your
choice.
2. Customising the Buttons
• Change the mouse button into desired functions from the
function list.
• Left click cannot be customised unless another left click is
set.

GB
11
800
3DPI1 Repeat (2-127)
100Firing Interval
times
ms
Fire Setting DPI Setting
Pointer Speed
Double-cick
Scroll Wheel
1600DPI2
2400DPI3
3200DPI4
4800DPI5
7200DPI6
1234567891011
1234567891011
1234567891011
Enhance pointer precision
Scroll one screen at a time
Profile 1
Profile 2 Advanced Light Macro
Reset Apply
1
23
4
5
6
78
DPI Setting
Select Setting from the user interface.
1. Fire Setting
• Fire can be repeated a specied number of times
• Repeat re in a interval
2. Pointer Speed
Adjust the speed of your mouse pointer.
3. Pointer Acceleration
Acceleration increases the cursor’s movement speed
depending on how quickly the mouse is moved.
4. Double-click
Adjust the double click response time.
5. Scroll Wheel
Adjust the scrolling speed.
6. Scroll for One Page
Scroll per vision page.
7. DPI Setting
Sensitivity (DPI) pertains to how much eort is needed to
move the mouse pointer in any direction. The higher the DPI,
the faster the mouse movement.
8. Colour
Select desired LED colour.

GB
12
On Off
LED
High Low
LED Brightness
DPI Multicolour
Waltz
Slow Fast
4 Seasons Disable
Rainbow Floe Light
LED Effect
Breathing
21 345678
Profile 1
Profile 2 Advanced Light Macro
Restore Default Apply
1
2
3
4
Light Setting
Select Light from the user interface.
1. LED
Turn LED on or o
2. Brightness
Select brightness level.
3. LED eect option
Select desired light eect.
4. Breathing Sequence
Select breathing sequence level.

GB
13
Macro List Keypress Sequence
New Macro
Record
Record Delay
Delay ms
No Delay
Fire mode
One-time mode
50
Attack
Skill 1
Skill 2
Leftkey
88 ms
Leftkey
88ms
Profile 1
Profile 2 Advanced Light Macro
Restore Default Apply
1 3
5
6
7
New Macro
Rename
Delete Macro
Import One
Import All
Export One
Export All
Edit
Delete
Insert
2 4
Macro Setting
Select Macro from the user interface.
1. Macro List
A list of macro prole.
2. New Marco
Rename
Delete Macro
Import One
Import All
Export One
Export All
3. Keypress recorded
4. Edit: edit selected
command.
Delete: Remove selected
command.
Insert: Insert time delay,
keyboard, mouse or scroll
command
5. Create New Macro
Create new macro prole.
6. Start/Stop record
Record keyboard and
mouse commands.
7. Record Delays: Insert
time delay between each
command while recording
macro.
Delays: Delay (1sec =
1000ms)
No Delay: Disable with
time delay
Fire mode: macro will
repeat as long as the button
is clicked.
One-time mode: macro
will run once.

GB
14
Assigning Macro
By assigning a macro to a mouse button, you can execute complex
combinations with ease.
1. Choose New Macro to create new macro prole.
2. Press RECORD to start macro by pressing keyboard keys.
3. Press STOP when nishing macro, and press APPLY to save.
4. Choose a desired mouse button to apply MACRO from the
function list.
5. Press the chosen mouse button to playback macro.

GB
15
Hints and Tips
• Make sure the USB plug is fully plugged into a USB port and
the computer is on or try to use a dierent USB port.
• If the mouse is moving erratically, change the working surface
which the mouse is operating on.
• If the software is not working properly, uninstall it and then
reboot the computer. Re-install the software.
• If the unit is not working properly, re-insert the USB plug into
the USB port.
Specications
Model AFPH0219
Resolution 500 – 7200 dpi
Dimensions (L x W x H) 131.4 x 72.3 x 42.1 mm
Net Weight 140g
Features and specications are subject to change without prior
notice.
The symbol on the product or its packaging indicates that this
product must not be disposed of with your other household
waste. Instead, it is your responsibility to dispose of your waste
equipment by handing it over to a designated collection point for
the recycling of waste electrical and electronic equipment. The
separate collection and recycling of your waste equipment at the
time of disposal will help conserve natural resources and ensure that it is
recycled in a manner that protects human health and the environment.
For more information about where you can drop o your waste for recycling,
please contact your local authority, or where you purchased your product.
Windows is a registered trademark of Microsoft Corporation in the United
States and other countries.
All trademarks are the property of their respective owners and all rights are
acknowledged.

NO
16
Pakke opp
Fjern alle gjenstander fra emballasjen. Ta vare på emballasjen. Ta
hensyn til lokale forskrifter om avfallshåndtering hvis du må kaste
emballasjen.
Følgende elementer er vedlagt:
Takk for at du kjøpte ny produktet.
Vi anbefaler at du tar deg tid til å lese gjennom
hele bruksanvisningen så du blir fortrolig med alle
funksjonene. Veiledningen gir deg også mange tips og råd
for å løse eventuelle problemer.
Les alle sikkerhetsanvisningene nøye før bruk og behold
bruksanvisningen for framtidig referanse.
Spillmus

NO
17
1. Høyre knapp
2. Rullehjul
3. Venstre knapp
1
2
3
4. DPI knapp
Velg en annen dpi
5. Forover-/Bakover-
knapper
Produktoversikt
5
4
Systemkrav
Operativsystemer: Microsoft® Windows® 7 / 8 / 10
Maskinvare: 1 tilgjengelig USB-port
Installasjon av programvare
1. Koble enheten til en USB-port på datamaskinen.
2. Last ned den nyeste spillprogramvaren fra
https://downloads.adxgaming.com/NO
3. Kjør installasjonsprogrammet for programvaren.
4. Følg instruksjonene for å fullføre installasjonen.
5. Velg ADX Gaming.exe fra skrivebordet for å starte
programvaren.
Programvaren er ikke tilgjengelig for Mac OS.

NO
18
Left Click1
1 3
2
6
7
Wheel Click2
Right Click3
Forward4
Backward5
DPI +6
DPI –7
4
5
Profile 1 Profile 2 Advanced Light Macro
Reset Apply
Brukergrensesnitt
Velg ADX Gaming.exe fra skrivebordet for å starte programvaren.
1. Innstillingsvalg.
2. Minimer programmet.
3. Avslutt programmet.
4. Gjenopprett til
standardinnstilling.
5. Lagre gjeldende
innstilling.
1 2
4 5
3

NO
19
Left Click1
1 3
2
6
7
Wheel Click2
Right Click3
Forward4
Backward5
DPI +6
DPI –7
4
5
Profile 1 Profile 2 Advanced Light Macro
Reset Apply
1
2
Prolinnstilling
Velg Prole fra brukergrensesnittet.
1. Prol
Velg prol 1–2 for å laste ønsket innstilling.
2. Tilpasse knappene
• Du kan endre museknappen til ønskede funksjoner fra
funksjonslisten.
• Venstreklikk kan ikke tilpasses med mindre et annen
venstreklikk blir stilt inn.

NO
20
800
3DPI1 Repeat (2-127)
100Firing Interval
times
ms
Fire Setting DPI Setting
Pointer Speed
Double-cick
Scroll Wheel
1600DPI2
2400DPI3
3200DPI4
4800DPI5
7200DPI6
1234567891011
1234567891011
1234567891011
Enhance pointer precision
Scroll one screen at a time
Profile 1
Profile 2 Advanced Light Macro
Reset Apply
1
23
4
5
6
78
DPI innstilling
Velg Setting fra brukergrensesnittet.
1. Ildinnstilling
• Ild kan gjentas et spesisert antall ganger
• Gjenta ild i intervall
2. Pekerhastighet
Justere hastigheten på musepekeren.
3. Pekerakselerasjon
Akselerasjon øker markørens bevegelseshastighet avhengig av
hvor raskt musen beveges.
4. Dobbeltklikk
Juster responstid for dobbeltklikk.
5. Rullehjul
Juster rullehastigheten.
6. Rull en side
Rull per synsside
7. DPI-innstilling
Følsomheten (DPI) stiller inn hvor langt musepekeren må
yttes i alle retninger. Jo høyere DPI er, desto raskere beveger
musepekeren seg.
8. Farge
Velg ønsket LED-farge.
