AECO SMC-12LM NO AGD3 Series User manual

www.aecosensors.com
YSM NNNNNN
SMC-12LM NO AGD3
YSM000017
SMC-12LM NO LC5 AGD3
YSM000018
SMC-12LM NO LC10 AGD3
YSM000019
FM013EX Rev. B
SMC-12LM NO AGD
LC10
3
LC5
ETC000470
SMC-12LM NO AGD3■
mm
mm
V
A
W/VA
Hz
°C
IP
> 6
NO
230
1.5
120
100
-25 ÷ +70
67
2 x 0.50mm² PVC
NO
80
CH17
M12x1
BLUE
BROWN
Sensing distance (Sn)
Hysteresis (’’H’’)
Max switching voltage
Ambient temperature range
IP rating
Housing material
Cable
Output type
Max switching current
Max switching power
Max switching frequency
> 20 with M20 magnet
Nichelled Brass
2mt, 5mt or 10mt
WIRING DIAGRAM
Characteristics
Models
Dimensions ‘’mm’’
4. Electrical and Mechanical Characteristics
( Description )( Code )
3.3 Product series
The magnetic sensors series includes the models
listed below :
SMC-12LM NO AGD3■
Potentially explosive atmosphere
with GAS and/or DUST.
Cable length "2mt".
Cable length "5mt".
Cable length "10mt".
Equipment category "3"
according to 2014/34/EU Directive.
Magnetic Sensor with cylindrical enclosure
"M12x1" and "NORMALLY OPEN" output
3.2 Description diagram
3.1 Code diagram
Magnetic sensor intended for use in the explosive atmospheres
according to 2014/34/EU ATEX Directive .
system.
Progressive number
3. Sensor identification
The series is only identified by the '' ''
and '' ''. The diagrams for the decoding are shown below.
Code
Description
SMC-12LM NO AGD3■
1. Introduction
This manual should be read and understood in all its parts before proceeding
with installation of the sensor.
The Magnetic Sensors series, are intended to be
used in a potentially explosive atmospheres with presence of GAS and/or
DUST. They are designed and produced according to the requirements of the
following standards:
SMC-12LM NO AGD3
■
2. Installation and Startup
The sensor must be installed, connected and activated only by specialized
personnel. Personnel must be familiar with the types of protection anti-ignition,
the production rules and regulations in the potentially explosive area. The user
is solely responsible for the choice and the use of sensor suitable to the final
application. When installing the sensor observe the following requirements:
Check whether the classification of the sensor is suitable for the application
(see‘’ATEX Marking’’ to paragraph 5 and marking on the equipment).
Make sure that the connection cable of the sensor does not have the
endings too tight. Moreover it must not prevent the movement of people
and/or things.
Do not touch uninsulated parts of the connecting cable of the sensor before
having it disconnected from the supply voltage. Do not install the sensor
during a thunderstorm with lightning.
If the cable is subject to movement, do not place the sheath with bending
radius too short; Pay attention to the mounting of the parties subject to
movement and to the fixed ones.
Separate the power cables from the connecting cable of the sensor.
Make sure that the sensor housing is always ground wired.
Operating Instructions
GB
According to:
Annex VII group II, equipment category 3G/3D
Directive 2014/34/EU ( ATEX )
Protect the sensor cable according to EN 60079-14 standard.
The electrical and mechanical characteristics of this series are shown in Table 1:
Tab. 1 - Electrical and Mechanical Characteristics
* EN60079-0:2012 + A11:2013 - Explosive atmospheres-Part 0 : Equipment.
General requirements.
* EN60079-18:2015 - Explosive atmospheres - Part 18: Equipment protection
by encapsulation ‘’m’’.

BROWN
BLUE
SMC-12LM NO AGD3■
V= 230V I= 1.5A P= 120W/VA
Tamb: -25 ÷ +70°C
II 3G Ex mc IIC T6 Gc
II 3D Ex mc IIIC T85°C Dc
AECO Inzago-MI-Italy
Fig. 1
2016 12345
IP67
SMC-12LM NO AGD3■( LC5 LC10■= o )
9. EU Declaration of Conformity
7. Maintenance
The sensor has no serviceable components and can not be changed and / or
repaired. In case of failure, please contact customer service.AECO srl
If necessary, you can ask for a copy of the following documents :AECO srl
You can also download the same documents from web site
( ).
AECO
www.aecosensors.com
Production batch
ATEXmarking
Ambient temperature range
‘’Model’’ description
Electrical parameters
Wiring diagram
8. Labelling
On every sensor of the '' '' is applied
as shown in Fig. 1 :
SMC-12LM NO AGD3■series a label
Temperature class for GAS
Indicates the maximum surface temperature that can reach the sensor
at the maximum ambient temperature according to EN 60079-0.
T6 Maximum surface temperature : 85 °C
Maximum Surface Temperature for DUST
Indicates the maximum surface temperature that can reach the sensor
at the maximum ambient temperature according to EN60079-0.
T85 Maximum surface temperature : 85 ° C
Equipment Protection Level (EPL) for GAS
Indicates the level of protection of the equipment according to
EN 60079-18.
Gc Equipment with protection level ' 'mc
Equipment Protection Level (EPL) for DUST
Indicates the level of protection of the equipment according to
EN 60079-18.
Dc Equipment with protection level ' 'mc
6. Conditions of use in potentially explosive area.
During the use of the sensor in potentially explosive atmosphere observing
the following instructions is important for safety :
The maximum permissible ambient temperature is Ta = +70 °C
To protect the sensor from damage due to shock and vibration
5. ATEX marking
ZONE 2 (Atmosphere with GAS)
ZONE 22 ( DUST)Atmosphere with
for use in
For all models '' '' refere to the ATEX marking below
indicated :
SMC-12LM NO AGD3■
The meaning of the symbols that make the marking is as follows:
Specific mark. Protection against explosion
II
Equipment group.
Category group.
3Equipment designed for use in places where
(ZONE 2 or ZONE 22).
an explosive atmosphere
is present rarely or for short periods
Equipment suitable for use in all other places other than mines and
their surface installations.
GAtmosphere due to the presence of , and .gases vapors mists
DAtmosphere due to the presence of dust
Ex Equipment designed for use in potentially explosive atmospheres
Type of explosive atmosphere.
mc
Type of protection
Encapsulation protection level according to .EN 60079-18''mc''
Explosion group GAS
Specifies the explosion group which the type of GAS belongs to,
according to .EN 60079-20
IIC An typical GAS of this group is the hydrogen
Explosion group DUST
IIIC Conductive dust
Specifies the explosion group which the type of DUST belongs to,
according to EN 60079-0.
II 3D Ex mc IIIC T85°C Dc
II 3G Ex mc IIC T6 Gc
Sensor data sheet
EU Declaration of Conformity
IP protection grade
Manufacture year
declare under our sole responsibility that the products:
EU Declaration of Conformity
Product’s name: Magnetic Sensors
Models: SMC-12LM NO AGD3
ATEX Marking:
II 3G Ex mc IIC T6 Gc
II 3D Ex IIIC T85°C Dcmc
Inzago: 2016.09.01 Maurizio Scaramuzza
We AECO s.r.l.
Via G. Leopardi 5, 20065 Inzago (MI), Italy
2014/34/EU - ATEX Directive
2014/35/EU - Low voltage Directive
Legal representative
CUE053EX REV. A
-25°C Ta +70°C< <
EN60079-0:2012 + A11:2013
EN60079-18:2015
EN 60947-1 : 2007
EN 60947-5-1 : 2004
and are comply with the following armonized standards
to which this declaration relates, meet the requirements of the european directives
SMC-12LM NO AGD3■( LC5 LC10■= or )
