AECO QMP000040 User manual

Part number: QMP000040 - Model: SMS88-P5 2NC H1 PL
Dimension in mm
TECHNICAL CHARACTERISTICS
Rated operational voltage Ue: 24 Vac/dc
Rated operational current Ie: 0.25A
Max switching load: 6W (resistive load)
Function: 2NC (with magnetic actuator present)
Termal current ITh: 0.25A
Rated insulation voltage Ui: 60Vac / 75Vdc
Rated impulse withstand voltage
Uimp: 1.5KV
Electrical endurance: 1 million of cycles
Assured operating
distance Sao: 5 mm with target AMS88-P5 and 8 mm with target AMS88-P8
Assured release distance Sar: 15 mm with target AMS88-P5 and 20 mm with target AMS88-P8
Repeat accurancy: < 10%
Switching distance: 200Hz
Response time:
SIL level (SIL CL): up to SIL3 according to IEC 62061 e EN 62061
Performance level (PL): up to PL e according to EN ISO 13849-1
Safety category: up to 4 according to EN ISO 13849-1
B10d for each channel: 400.000 cycles (full load: DC12, 24V, 0.25A) e 20.000.000 of cyles ( with AECO safety
Module)
Conformig to the standard: EN 60947-1, IEC 60947-1, EN 60947-5-1, IEC 60947-5-1, EN 60947-5-2, IEC 60947-5-2,
EN 60947-5-3 , IE
Conforms to the directives: 2006/42/EC - Machinery Directive and 2014/30/EU - Electromagnetic Compatibility
Directive
Temperature limits: -25 ÷ +80°C
Protection degree: IP67
Pollution degree: 3
Schock resistance: 30gn -11ms according to IEC 60068-2-27 and EN 60068-2-27
Vibrations resistance: 10gn-(10 ... 150Hz) according to IEC 60068-2-6 and EN 60068-2-6
Housing material: PBT +FV
