AEG Electrolux 68002KF-N User manual

68002KF-N
User Manual
Gebruiksaanwijzing
Ceramic glass
induction hob
Glaskeramische
inductie-kookplaat

2
Dear Customer
Thank you for choosing one of our high-quality products.
With this appliance you will experience the perfect combination of functional
design and cutting edge technology.
Convince yourself that our appliances are engineered to deliver the best per-
formance and control - indeed we are setting the highest standards of excel-
lence.
In addition to this you find environmental and energy saving aspects as an inte-
gral part of our products.
To ensure optimal and regular performance of your appliance please read this
instruction manual carefully. It will enable you to navigate all processes perfect-
ly and most efficiently.
To refer to this manual any time you need to, we recommend you to keep it in a
safe place. And please pass it to any future owner of the appliance.
We wish you much joy with your new appliance.
Th
e
f
o
ll
ow
i
ng sym
b
o
l
s are use
d
i
n t
hi
s user
i
n
f
ormat
i
on:
1
Warning! This must be read! Important advice for the safety of persons and
information on avoiding damage to the appliance
3General information and advice
2Information on environmental protection
zDangerous voltage

3
Contents
Operating Instructions 4
Safety instructions 4
Description of the Appliance 6
Cooking surface layout 6
Control panel layout 6
Touch Control sensor fields 7
Displays 8
Residual heat indicator 8
Operating the appliance 9
Switching the appliance on and off 9
Setting the heat setting 9
Locking/unlocking the control panel 9
Using the child safety device 10
Switching the power function on and off 11
Using the timer 12
Automatic switch off 14
Tips on Cooking and Frying 15
Cookware for induction cooking zones 15
Tips on energy saving 16
Examples of cooking applications 17
Cleaning and Care 18
What to do if … 19
Disposal 20
Installation Instructions 21
Safety instructions 21
Guarantee/Customer Service 23
Service 25
Assembly 54
Rating Plate 57

Operating Instructions4
Operating Instructions
1Safety instructions
Please comply with these instructions. If you do not, any damage resulting is not
covered by the warranty.
Correct use
•This appliance is not intended for use by children or other persons whose
physical, sensory or mental capabilities or lack of experience and knowledge
prevents them from using the appliance safely without supervision or instruc-
tion by a responsible person to ensure that they can use the appliance safely.
•Do not leave the appliance unattended during operation.
•This appliance should be used only for normal domestic cooking and frying of
food.
•The appliance must not be used as a work surface or as a storage surface.
•Additions or modifications to the appliance are not permitted.
•Do not place or store flammable liquids, highly inflammable materials or fusi-
ble objects (e.g. plastic film, plastic, aluminium) on or near the appliance.
Children’s safety
•Small children must be kept away from the appliance.
•Only let bigger children work on the appliance under supervision.
•To avoid small children and pets unintentionally switching the appliance on,
we recommend activation of the child safety device.
General safety
•The appliance may only be installed and connected by trained, registered
service engineers.
•Built-in appliances may only be used after they have built in to suitable built-
in units and work surfaces that meet standards.
•In the event of faults with the appliance or damage to the glass ceramic
(cracks, scratches or splits), the appliance must be switched off and discon-
nected from the electrical supply, to prevent the possibility of an electric
shock.
•Repairs to the appliance must only be carried out by trained registered service
engineers.

5Safety instructions
Safety during use
•Remove stickers and film from the glass ceramic.
•There is the risk of burns from the appliance if used carelessly.
•Cables from electrical appliances must not touch the hot surface of the appli-
ance or hot cookware.
•Overheated fats and oils can ignite very quickly. Warning! Fire hazard!
•Switch the cooking zones off after each use.
•Users with implanted pacemakers should keep their upper body at least 30 cm
from induction cooking zones that are switched on.
•Risk of burns! Do not place objects made of metal, such as knives, forks,
spoons and saucepan lids on the cooking surface, as they can get hot.
Safety when cleaning
•For cleaning, the appliance must be switched off and cooled down.
•For safety reasons, the cleaning of the appliance with steam jet or high-pres-
sure cleaning equipment is not permitted.
How to avoid damage to the appliance
•The glass ceramic can be damaged by objects falling onto it.
•The edge of the glass ceramic can be damaged by being knocked by the cook-
ware.
•Cookware made of cast iron, cast aluminium or with damaged bottoms can
scratch the glass ceramic if pushed across the surface.
•Objects that melt and things that boil over can burn onto the glass ceramic
and should be removed straightaway.
•Do not use the cooking zones with empty cookware or without cookware.
•To avoid damaging cookware and glass ceramics, do not allow saucepans or
frying pans to boil dry.
•The ventilation gap of 5mm between the worktop and front of the unit un-
derneath it must not be covered.

Description of the Appliance6
Description of the Appliance
Cooking surface layout
Control panel layout
Induction cooking zone 2200 W
with power function 3100 W
Induction cooking zone 1800 W
Induction cooking zone 1400 W
Control panel Induction cooking zone 1800 W
with power function 2800 W
On/Off
with power indicator
Heat setting selection
Lock
Timer display
Power function
C
oo
ki
ng zone
i
n
di
cators
Timer function
Display
Timer

7Description of the Appliance
Touch Control sensor fields
The appliance is operated using Touch Control sensor fields. Functions are con-
trolled by touching sensor fields and confirmed by displays and acoustic signals.
Touch the sensor fields from above, without covering other sensor fields.
Sensor field Function
On / Off To switch the appliance on and off
Increase settings Increasing heat setting/time
Decrease settings Decreasing heat setting/time
Timer Timer selection
Lock Locking/unlocking the control panel
Power Switching the power function on and
off

Description of the Appliance8
Displays
Residual heat indicator
1Warning! Risk of burns from residual heat. After being switched off, the cook-
ing zones need some time to cool down. Look at the residual heat indicator .
3Residual heat can be used for melting and keeping food warm.
The induction cooking zones create the heat required for cooking directly in
the base of the cookware. The glass ceramic is merely heated by the residual
heat of the cookware.
The cooling fan switches itself on and off depending upon the temperature of
the electronics.
Display Description
Cooking zone is switched off
- Heat settings Heat setting is set
Fault Malfunction has occurred
Pan detection Cookware is unsuitable or too small or
no cookware has been placed on the
cooking zone
Residual heat Cooking zone is still hot
Child safety device Lock/child safety device is engaged
Power Power function is switched on
Automatic switch off Switch off is active.

9Operating the appliance
Operating the appliance
3Use the induction cooking zones with suitable cookware.
Switching the appliance on and off
3After switching on, within approx. 10 seconds a heat setting or a function must
be set, otherwise the appliance automatically switches itself off.
Setting the heat setting
Locking/unlocking the control panel
The control panel, with the exception of the “On/Off” sensor field, can be locked
at any time in order to prevent the settings being changed e.g. by wiping over
the panel with a cloth.
3When you switch the appliance off, the locking function is automatically
switched off.
Control panel Display Pilot light
Switch on Touch for 2 seconds / lights up
Switch off Touch for 1 second / none goes out
Control panel Display
Increase Touch to /
Decrease Touch to
Switch off Touch and at the same time
Control panel Display
Switch on Touch (for 5 seconds)
Switch off Touch previously set heat setting

Operating the appliance10
Using the child safety device
The child safety device prevents unintentional use of the appliance.
Setting the child safety device
Overriding the child safety device
The child safety device can be released in this way for a single cooking session; it
remains activated afterwards.
Releasing the child safety device
Step Control panel Display/Signal
1. Switch on the appliance
(Do not set a heat setting)
2. Touch until the signal sounds Acoustic signal
3. Touch
Appliance switches off. The child safety device is engaged.
Step Control panel Display/Signal
1. Switch on the appliance
2. Touch and at the same time / acoustic signal
Until the appliance is next switched off, it can be used as normal.
Step Control panel Display/Signal
1. Switch on the appliance
2. Touch until the signal sounds Acoustic signal
3. Touch
Appliance switches off. The child safety device is released.

11Operating the appliance
Switching the power function on and off
The power function makes additional power available to the front induction
cooking zones, e.g. to bring a large volume of water to the boil.
The power function is activated for 8 minutes for the front left cooking zone
and for 5 minutes for the front right cooking zone. After these times, the induc-
tion cooking zones automatically return to cooking level .
3If the power function has ended, the cooking zones automatically switch back to
the heat setting set previously.
Power Management
The cooking zones of the cooking surface
have a maximum power available to them.
Two cooking zones make up a pair (see fig-
ure).
So that the Power function can always be
carried out, Power Management may re-
duce the power of the other cooking zone
in the pair
Example: heat setting 9 is selected on a
cooking zone. The Power function is
switched on for the cooking zone paired up
with it. The Power function is performed,
but heat setting 9 on one cooking zone and Power function on the other cook-
ing zone of a pair exceeds the maximum output for both. Therefore Power Man-
agement reduces the first cooking zone that was switched on from 9 to 7, for
example, and the display for this cooking zone alternates between 9 and 7 and
then remains on the current maximum of 7. (Whether the display alternates be-
tween 9 and 7 or 9 and 6 or other values, depends on the appliance type and the
size of the cooking zone.)
Control panel Display
Switch on Touch
Switch off Touch
Touch

Operating the appliance12
Using the timer
All cooking zones can each use one of the two timer functions at the same time.
3If a cooking zone is switched off, the timer function set is also switched off.
3If a heat setting is set on this cooking zone in addition to a countdown timer,
the cooking zone is switched off after the time set has elapsed.
Selecting a cooking zone
3The heat setting indicator of the selected cooking zone goes out, as long as the
timer time can be set.
3If the pilot light is flashing more slowly, the heat setting indicator appears again
and the heat setting can be re-set or modified.
3If other timer functions are set, after a few seconds the shortest remaining time
of all the timer functions is displayed and the corresponding pilot light flashes.
Function Condition Outcome after the
time has elapsed
Automatic cut-out a heat setting is set acoustic signal
00 flashes
Cooking zone switches
off
Countdown timer cooking zones not in use acoustic signal
00 flashes
Step Control panel Display
1. Touch once Pilot light of the first cook-
ing zone flashes
2. Touch once Pilot light of the second
cooking zone flashes
3. Touch once Pilot light of the third
cooking zone flashes
4. Touch once Pilot light of the fourth
cooking zone flashes

13Operating the appliance
Setting time
Switching off the Timer function
Changing the time
Step Control panel Grill setting
1. Selecting cooking
zone
Telltale of cooking zone selected flashes
2. Touch or from
the selected cooking
zone
01 to 99 minutes
3. Touch or from
the selected cooking
zone for more than 4
seconds
... 05...10...15... 20 or... 95... 90... 85...
80... (5-minute steps for easy setting)
After a few seconds the power indicator flashes more slowly.
The time is set.
The time counts down.
Step Control panel Display
1. Select a cooking
zone
Pilot light of the selected cooking zone
flashes more quickly.
Remaining time is displayed
2. Touch for the cook-
ing zone selected
The remaining time counts down to 00.
The pilot light goes out.
The Timer function for the selected cooking zone is switched off.
Step Control panel field Display
1. Select cooking
zone
Pilot light of the cooking zone selected
flashes faster
The time remaining is displayed
2. Touch or for the
cooking zone selected
01 to 99 minutes
After a few seconds the pilot light flashes more slowly.
The time is set.
The time counts down.

Operating the appliance14
Displaying the time remaining for a cooking zone
Switching off the acoustic signal
Automatic switch off
Cooking surface
•If after switching on the cooking surface, a heat setting is not set for a cook-
ing zone within approx. 10 seconds, the cooking surface automatically switch-
es itself off.
•If all cooking zones are switched off, the cooking surface automatically
switches itself off after approx. 10 seconds.
Induction cooking zones
•If cookware that is not suitable is used, lights up in the display and after 2
minutes the indicator for the cooking zone switches itself off.
•If one of the cooking zones is not switched off after a certain time, or if the
heat setting is not modified, the relevant cooking zone switches off automati-
cally. is displayed. Before being used again, the cooking zone must be set to
.
Step Control panel field Display
1. Select cooking
zone
Pilot light of the cooking zone selected
flashes faster
The time remaining is displayed
After a few seconds the pilot light flashes more slowly.
Step Control panel field Acoustic signal
1. Touch Acoustic signal to acknowledge.
Acoustic signal stops.
Heat setting Switches off after
1- 26 hours
3- 45 hours
54 hours
6- 91.5 hours

15Tips on Cooking and Frying
Tips on Cooking and Frying
3Information on acrylamides
According to the latest scientific knowledge, intensive browning of food, espe-
cially in products containing starch, can constitute a health risk due to acryla-
mides. Therefore we recommend cooking at the lowest possible temperatures
and not browning foods too much.
Cookware for induction cooking zones
Cookware material
3Cookware for induction cooking zones is labelled as suitable by the manufactur-
er.
Suitability test
Cookware is suitable for induction cooking, if …
•... a little water on an induction cooking zone set to heat setting 9 is heated
within a short time.
•... a magnet sticks to the bottom of the cookware.
3Certain cookware can make noises when being used on induction cooking zones.
These noises are not a fault in the appliance and do not affect operation in any
way.
Cookware material Suitable
Steel, enamelled steel yes
Cast iron yes
Stainless steel if appropriately labelled by the manufacturer
Aluminium, copper, brass ---
Glass, ceramic, porcelain ---

Tips on Cooking and Frying16
Bottom of the cookware
The bottom of the cookware should be as thick and flat as possible.
Pan size
Induction cooking zones adapt automatically to the size of the bottom of the
cookware up to a certain point. However the magnetic part of the bottom of the
cookware must have a minimum diameter depending on the size of the cooking
zone.
3The cookware must be placed centrally on the cooking zone.
Tips on energy saving
2Place cookware on the cooking zone before it is switched on.
2If possible, always place a lid on the cookware.
Diameter of cooking zone
[mm]
Minimum diameter of dish base
[mm]
210 180
180 145
145 120

17Tips on Cooking and Frying
Examples of cooking applications
The information given in the following table is for guidance only.
The power function is suitable for heating large quantities of liquid.
Heat
setting
Cooking-
process suitable for Cooking time Tips/Hints
0Off position
1Keeping
food warm Keeping cooked foods warm as required Cover
1-2 Melting
Hollandaise sauce,
melting butter, chocolate,
gelatine
5-25 mins. Stir occasionally
Solidifying Fluffy omelettes, baked eggs 10-40 mins. Cook with lid on
2-3
Simmer-
ing on low
heat
Simmering rice and milk-
based dishes
Heating up ready-cooked
meals
25-50 mins.
Add at least twice as
much liquid as rice, stir
milk dishes part way
through cooking
3-4 Steaming
Braising
Steaming vegetables, fish
braising meat 20-45 mins.
With vegetables add only
a little liquid (a few table-
spoons)
4-5 Boiling
Steaming potatoes 20-60 mins.
Use only a little liquid, e.
g.: max. ¼l water for
750 g potatoes
Cooking larger quantities of
food, stews and soups 60-150 mins. Up to 3 l liquid plus in- gredients
6-7 Gentle
Frying
Frying escalopes, veal cor-
don bleu, cutlets, rissoles,
sausages, liver, roux, eggs,
pancakes, doughnuts
Steady frying Turn halfway through
cooking
7-8 Heavy
Frying
Hash browns, loin steaks,
steaks, Flädle (pancakes for
garnishing soup)
5-15 mins.
per pan
Turn halfway through
cooking
9
Boiling
Searing
Deep
frying
Boiling large quantities of water, cooking pasta, searing meat (goulash,
pot roast), deep frying chips

Cleaning and Care18
Cleaning and Care
1Take care! Risk of burns from residual heat.
1Warning! Sharp objects and abrasive cleaning materials will damage the appli-
ance. Clean with water and washing up liquid.
1Warning! Residues from cleaning agents will damage the appliance. Remove
residues with water and washing up liquid.
Cleaning the appliance after each use
1. Wipe the appliance with a damp cloth and a little washing up liquid.
2. Rub the appliance dry using a clean cloth.
Removing deposits
1. Place a scraper on the glass ceramic surface at an angle.
2. Remove residues by sliding the blade over the surface.
3. Wipe the appliance with a damp cloth and a little washing up liquid.
4. Rub the appliance dry using a clean cloth.
*Scrapers and cleaners for glass ceramic and stainless steel can be purchased in specialized shops
3Remove stubborn residues with a cleaner for glass ceramic or stainless steel.
3Scratches or dark stains on the glass ceramic that cannot be removed do not
however affect the functioning of the appliance.
Remove
Type of dirt immedi-
ately
when the appliance has
cooled down using
sugar, food containing sugar yes --- a scraper*
plastics, tin foil yes ---
limescale and water rings --- yes
cleaner for glass ceram-
ic or stainless steel*
fat splashes --- yes
shiny metallic discolouration --- yes

19What to do if …
What to do if …
Problem Possible cause Remedy
The appliance cannot be
switched on or is not operat-
ing
More than 10 seconds have
passed since the appliance was
switched on
Switch the appliance on again.
The lock is switched on Switch off the lock (See the
section “Locking/unlocking the
control panel”)
The child safety device is
switched on
Deactivate child safety device
(See the section “Child safety
device”)
Several sensor fields were
touched at the same time
Only touch one sensor field
Automatic switch off has been
triggered
Remove any objects (pan,
cloths, etc.) that are lying on
the control panel. Switch the
appliance on again
The cooking zones automati-
cally reduce the cooking level
to
The sensor fields are partly
covered by a damp cloth or
with liquid
Remove the cloth or the liquid.
Reset the cooking level re-
quired.
The residual heat indicator is
not displaying anything
The cooking zone was only on
for a short time and is there-
fore not hot
If the cooking zone is sup-
posed to be hot, call the Cus-
tomer Service Department.
acoustic signal sounds, appli-
ance switches off
One or more sensor fields have
been covered for longer than
10 seconds
Uncover sensor field
Acoustic signal sounds and
appliance switches itself on
and after 10 seconds off again
The On/Off sensor field has
been covered up, e.g. by a
cloth
Do not place any objects on
the control panel
Display is switching between
two heat settings
Power management is reduc-
ing the power of this cooking
zone
See the section “Switching the
power function on and off”
lights up Unsuitable cookware Use suitable cookware
No cookware on the cooking
zone
Place cookware on the cooking
zone
The diameter of the bottom of
the cookware is too small for
the cooking zone
Move onto a smaller cooking
zone
Use suitable cookware

Disposal20
If you are unable to remedy the problem by following the above sugges-
tions, please contact your dealer or the Customer Care Department.
1Warning! Repairs to the appliance are only to be carried out by qualified service
engineers. Considerable danger to the user may result from improper repairs.
3If the appliance has been wrongly operated, the visit from the customer service
technician or dealer may not take place free of charge, even during the warranty
period.
Disposal
2Packaging material
The packaging materials are environmentally friendly and can be recycled. The
plastic components are identified by markings, e.g. >PE<, >PS<, etc. Please dis-
pose of the packaging materials in the appropriate container at the community
waste disposal facilities.
2Old appliance
The symbol Won the product or on its packaging indicates that this product
may not be treated as household waste. Instead it shall be handed over to the
applicable collection point for the recycling of electrical and electronic equip-
ment. By ensuring this product is disposed of correctly, you will help prevent po-
tential negative consequences for the environment and human health, which
could otherwise be caused by inappropriate waste handling of this product. For
more detailed information about recycling of this product, please contact your
local city office, your household waste disposal service or the shop where you
purchased the product.
is lit Overheating protection for the
cooking zone has been trig-
gered
Switch off the cooking zone.
Switch the cooking zone on
again
Automatic switch off has been
triggered
Switch off the cooking zone.
Switch the cooking zone on
again
and number are displayed Electronics fault Disconnect the appliance from
the electrical supply for a few
minutes (Take the fuse out of
the house’s wiring system)
If after switching on again,
is displayed again, call the cus-
tomer service department
Problem Possible cause Remedy
