AEG 61100MF-an Operating instructions

61100MF-an
Glass Ceramic Cooking Surface
Operating Instructions
Installations Instructions
All manuals and user guides at all-guides.com
all-guides.com

2
Dear customer,
Please read these operating instructions through carefully.
Above all, please take note of the «Safety» section on the first few pages.
Please keep these operating instructions for later reference. Pass them on
to any subsequent owner of the appliance.
The warning triangle and/or specific words (Warning!, Caution!,
Important!) are used to highlight instructions that are important for your
safety or for the function of the appliance. It is imperative that these in
structions are observed.
1. This symbol guides you step by step when operating the appliance.
2. ...
3. ...
Next to this symbol you receive additional information and practical tips on
using the appliance.
Tips and information about the economical and ecological use of the ma
chine are marked with a cloverleaf.
In the event of a malfunction, these operating instructions contain infor
mation on how to rectify faults yourself, see the «What to do, if...» section.
In the event of technical problems, our local FACTORY CUSTOMER SERVICE
CENTRE is always available to provide assistance (you will find addresses
and telephone numbers in the «Customer Service Centres» section).
Please also take note of the contents of the «Service» section.
Printed on paper manufactured with environmentally sound processes.
He who thinks ecologically acts accordingly ...
All manuals and user guides at all-guides.com

Content
3
CONTENT
OPERATING INSTRUCTIONS 4. . . . . . . . . . . . . . . . . . . . . . . . . . .
Safety 4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Disposal 6. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Appliance Description 7. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Prior to Using for the first Time 7. . . . . . . . . . . . . . . . . . . . . . .
Initial Cleaning 7. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Operation of the cooking surface 8. . . . . . . . . . . . . . . . . . . . . .
Switching On the Triple Ring Cooking Zone 8. . . . . . . . . . . . . . . . . . . . .
Residual Heat Indicator 8. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Usage, Tips 9. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Pans 9. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Tips on Saving Energy 9. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Cleaning and care 10. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Ceramic Glass 10. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
The Hob Frame 11. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
What to do if ... 12. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
INSTALLATION INSTRUCTIONS 35. . . . . . . . . . . . . . . . . . . . . . . . .
Technical Data 13. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Legal stipulations, standards, directives 14. . . . . . . . . . . . . . . . .
Safety Instructions for the Installer 15. . . . . . . . . . . . . . . . . . . .
Installing into a kitchen worksurface 16. . . . . . . . . . . . . . . . . . .
Electrical connection 19. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Combination 19. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
SERVICE 23. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
All manuals and user guides at all-guides.com

4
OPERATING INSTRUCTIONS
Safety
The safety aspects of this appliance comply with the accepted technical
standards and the German Appliance Safety Law. However, we also consider
it our obligation as a manufacturer to make you aware of the following
safety information.
Electrical Safety
The new appliance may only be installed and connected up by quali-
fied personnel, according to the manufacturers instructions and to the
relevant country standards.
Repairs to the appliance should only be carried out by approved service
engineers. Improper repairs can cause injury or significant malfunction. If
your appliance needs repairing, please contact your local AEG Service Force
Centre.
If your appliance malfunctions, or fractures, cracks or splits appear:
- switch off all cooking zones,
- Disconnect the hob from the electricity supply.
Child Safety
The cooking zones will become hot when the hob is in use. Therefore, al
ways keep small children away.
Safety During Use
This appliance is intended for domestic cooking only. It is not designed for
commercial or industrial purposes.
Do not use the hob to heat the room.
Take care when plugging electrical appliances into mains sockets near the
hob. Connecting leads must not come into contact with the hot surface.
Overheated fats and oils catch fire quickly. You should supervise cooking
when preparing foods in fat or oil (e.g. chips).
Switch the cooking zones off after use.
If a hot pan is placed on a cold cooking zone, and the cooking zone is hea
ted by the pan, no indication is given on the residual heat display.
Operating Instructions
All manuals and user guides at all-guides.com

5
Safety When Cleaning
For safety reasons do not clean the appliance with a steam jet or high pres
sure cleaner.
Clean the hob in accordance with the maintenance and cleaning instruc
tions in this manual.
How to Avoid Damage to Your Appliance
Do not use the hob as a work surface or for storage.
Do not use the cooking zones with empty pans, or without pans.
Ceramic glass is insensitive to temperature shock and very robust, however
it is not unbreakable. Hard and sharp objects, in particular, can damage the
cooking surface if they fall on it.
Do not use cast iron pans or pans with damaged bases that are rough or
burred. Scratching may occur when the pans are slid.
Do not place any pans on the hob frame. Scratching may occur or the paint
damaged.
Ensure that liquids containing acids, e.g. vinegar, lemon or scale remover do
not come into contact with the hob frame, otherwise matt spots will ap
pear.
If sugar or a dish containing sugar comes into contact with a hot cooking
zone and then melts, remove the soiling immediately whilst still hot using a
scraper. If it cools, damage to the surface may occur on removal.
Keep all items and materials that can melt away from the ceramic glass
surface, e.g. plastics, aluminium foil, or oven foils. If something of this na
ture should melt onto the ceramic glass surface, it must also be removed
immediately using the scraper.
If you wish to use special types of pan (e.g. a pressure cooker, simmering
pan, wok, etc.), please observe the manufacturer's instructions.
Avoid boiling pans dry. The bases could be irreparably damaged in the pro
cess and the glass ceramic cooking surface also damaged.
Operating Instructions
All manuals and user guides at all-guides.com

6
Disposal
Disposing of the packaging material
•All packaging can be recycled, sheet and hard foam parts are appropriately
marked. Please dispose of packaging material and any old appliance with
due regard to safety and the environment.
Information on disposal
•The appliance must not be disposed of in the household rubbish.
•You can obtain information about collection dates or public tips from your
local refuse department or council.
Warning! Before disposing of old appliances make them inoperable. Cut off
the mains cable.
Operating Instructions
All manuals and user guides at all-guides.com
all-guides.com

7
Appliance Description
Features of the hob
Prior to Using for the first Time
Initial Cleaning
Wipe the ceramic glass cooking surface with a damp cloth to remove any
traces left from manufacturing.
Important: Do not use any caustic or abrasive cleaners! The surface could
be damaged.
Operating Instructions
Single Ring
Cooking Zone
Outlet for Steam
from the oven
Residual Heat
Indicators
Triple Ring
Cooking zone
Residual Heat
Indicators
Casserole Zone
Single Ring
Cooking Zone
Touch Switch for
Switching On Triple Ring
All manuals and user guides at all-guides.com

8
Operation of the cooking surface
When the cooking zones are switched on, they may hum briefly. This is a
characteristic of all ceramic glass cooking zones and does not impair either
the function or the life of the appliance.
The zones are operated using the knobs on the cooker or with using
the knobs on the panel, operation is described in the respective in
struction manuals.
Switching On the Triple Ring Cooking Zone
Depending on the size of the pan, on the triple ring zone the two larger
rings can be switched on, in addition to the smallest cooking zone, using
the appropriate touch switch on the glass ceramic cooking surface.
1. Switch on cooking zone in the normal way using the ring switch.
- The smallest ring on the cooking zone is switched on.
2. Tap the corresponding touch switch on the cooking surface once .
- The larger ring is also switched on.
3. To switch on the largest ring, tap the touch switch again .
4. To switch off the larger ring, tap the touch switch again.
If the triple ring cooking zone is switched off completely using the ring
switch, the larger rings must be switched on again the next time the ring is
switched on, if required.
Residual Heat Indicator
An indicator is assigned to each cooking zone. This illuminates as soon as
the corresponding cooking zone becomes hot and warns against inadver
tent touching.
Important! As long as the residual heat indicator is illuminated, there is a
risk of burns.
Even after the cooking zone is switched off, the corresponding residual
heat indicator will remain on until the cooking zone is cold.
You can use the residual heat for melting and keeping food warm.
Operating Instructions
All manuals and user guides at all-guides.com

9
Usage, Tips
Pans
The better the pan, the better the results.
•You can recognise good pans by their bases. The base should be thick and
as flat as possible.
•Pans with aluminium or copper bases can leave metal discoloration on the
glass ceramic surface that is very difficult or impossible to remove.
•Do not use cast iron pans or pans with damaged bases that are rough or
burred. Permanent scratching may occur when the pans are slid.
•When cold, pan bases are normally bowed slightly in
wards (concave). They should under no circumstances
be bowed outwards (convex).
Tips on Saving Energy
You will save valuable energy if you observe the following tips:
•Always place pans on the cooking zone before
switching on.
•Soiled cooking zones and pan bases increase
the electricity consumption.
•If possible, always fit pans with a lid.
•Switch off the cooking zones before the end of
cooking to make use of the residual heat, e.g. to
keep food warm or for melting.
•The pan base and cooking zone should be the
same size. When purchasing pans, pay attention
to the diameter of the base. Manufacturers of
ten state the diameter of the top of the pan.
•Cooking times are reduced by up to 50% when
a pressure cooker is used.
Operating Instructions
All manuals and user guides at all-guides.com

10
Cleaning and care
Ceramic Glass
Important: Cleaners must not come into contact with the ceramic glass
when hot! All cleaners must be removed with plenty of clean water after
cleaning as they may have a caustic effect when the rings are next heated!
Do not use any aggressive cleaners, such as e.g. grill or oven sprays, coarse
scouring cleaners or pan cleaners that cause scratches.
Clean the ceramic glass surface after each use when it is hand warm or
cold. This means you will avoid soiling becoming burnt on.
Remove scale and water marks, fat spots and metallic shimmering discolo
ration with a commercially available ceramic glass or stainless steel cleaner,
e.g. with "Stahl-Fix or Vitroclen.
Light Soilage
1. Wipe the ceramic glass surface with a damp cloth and a little washing up
liquid.
2. Then rub dry with a clean cloth. No residues of cleaner must be left on the
surface.
3. Once a week, thoroughly clean the entire ceramic glass surface with a com
mercially available ceramic glass cleaner such as Vitroclen.
4. Then wipe the ceramic glass surface with plenty of clean water and rub dry
with a clean fluff-free cloth.
Stubborn Soilage
1. To remove food that has boiled over or
burnt on spots, use a glass scraper.
2. Place the glass scraper at an angle to the
glass ceramic surface.
3. Remove soiling by sliding the scraper.
You can obtain glass scrapers and ceramic
glass cleaners from your specialist retailers.
Operating Instructions
All manuals and user guides at all-guides.com

11
Burnt on Soilage
1. Remove burnt on sugar, melted plastic, aluminium foil or other melted ma
terials immediately, while the hob is still hot, using a glass scraper.
Important: When using the glass scraper
on the hot cooking zone, there is a risk of
burns!
2. Clean the cooking surface as normal once it is
cold.
If the cooking zone has cooled down already
prior to the soilage being removed, warm it up
again for cleaning.
Scratches or dark marks on the ceramic glass
surface, which have been caused by a pan
base with sharp edges, cannot be removed.
However, they do not impair the function of
the cooking surface.
The Hob Frame
Important! Do not put vinegar, lemons or scale removers on the hob frame,
otherwise mat spots will appear.
1. Wipe the frame with a damp cloth and a little washing up liquid.
2. Soften dried dirt with a wet cloth. Then wipe off and rub dry.
Operating Instructions
All manuals and user guides at all-guides.com
all-guides.com

12
What to do if ...
... the cooking zones do not work?
Check whether
- the corresponding cooking zone is switched on.
- the switch is set to the correct heat setting.
- in the case of multi-ring cooking zones: the required heating circuit is
switched on.
- the mains fuse (fuse box) has blown.
If this information does not provide you with the necessary assistance,
please seek specialist advice.
Warning: Repairs to the appliance may only be carried out by approved
service engineers. Improper repairs can cause injury or serious malfunction.
If your appliance needs repairing, please contact your local AEG Service
Force Centre.
Operating Instructions
All manuals and user guides at all-guides.com

13
INSTALLATION INSTRUCTIONS
Important! This appliance must be installed by qualified personnel, accor
ding to the manufacturer's instructions and to the relevant country stan
dards.
Technical Data
Appliance Dimensions
Width 605 mm
Depth 535 mm
Height 45 mm
Cut-Out Dimensions
Width 560 mm
Depth 490 mm
Corner radius R3
Power Consumption
Triple ring cooking zone front left 800/1600/2300 W
Single ring cooking zone rear left 1200 W
Casserole zone rear right 1800 W
Single ring cooking zone front right 1200 W
Heater Element Voltage 230 V ~ 50 Hz
Total load 6.5 kW
Installation Instructions
Prod-nr: 941 054 479
Serie
6.50 kW 230 V ~ 50 Hz
Typ 218.1ZCWBNANHNA
AEG
61100MF-an
SC
0000
All manuals and user guides at all-guides.com

14
Legal stipulations, standards, directives
This appliance meets the following standards:
•EN 60 335-1 and EN 60 335-2-6
in respect of the safety of electrical appliances for household use and
similar purposes and
•DIN 44546 / 44547 / 44548
in respect of properties of electrical cookers for the household.
•EN 55014-2 / VDE 0875 Teil 14-2
•EN 55014 / VDE 0875 Teil 14/12.93
•EN 61000-3-2 / VDE 0838 Teil 2
•EN 61000-3-3 / VDE 0838 Teil 3
in respect of basic electromagnetic compatibility (EMC) requirements.
This appliance complies with the following EC directives:
•73/23/EWG dated 19.02.1973 (Low Voltage Directive)
•89/336/EWG dated 03.05.1989 (EMC Directive including Directive
Change 92/31/EWG).
Installation Instructions
All manuals and user guides at all-guides.com

15
Safety Instructions for the Installer
•A device must be included in the electrical installation that makes it possi
ble to isolate the appliance from the mains supply with a minimum contact
separation of 3 mm.
Suitable isolation devices are e.g. cut-outs, fuses (remove screw type fuses
from the holder), earth leakage trips and circuit breakers.
•In respect of fire protection, this appliance corresponds to type Y (IEC
335-2-6). Only this type of appliance may be installed with a high cupbo
ard or wall on one side.
•It is not permitted to fit drawers below the cooking surface.
•Protection against electric shock must be provided by the installation.
•The kitchen unit in which the appliance is fitted must satisfy the require
ments of DIN 68930 in respect of stability.
•Built-in ovens and cooking surfaces are fitted with special connector sy
stems. They may only be combined with appliances with a matching system.
•All cut surfaces are to be sealed with a suitable sealant for protection
against moisture.
•On tiled work surfaces, the joints in the area where the hob sits on the sur
face must be completely filled with grout.
•On natural, artificial stone, or ceramic tops, the snap action springs must be
bonded in place.
•Ensure that the seal is correctly seated in the frame and that it is seated
against the work surface without leaving any gaps. Additional silicon sea
lant must not be applied, this will make removal more difficult in the event
of the need for service.
Installation Instructions
All manuals and user guides at all-guides.com

16
Installing into a kitchen worksurface
Make a note of the serial number on the appliance rating plate prior to
installation. This number will be required in the case of requests for service
and is no longer accessible after installation, as it is on the original rating
plate on the underside of the appliance.
Installation Instructions
optimal 300 mm
maximal 100°C
minimal 50 mm
All manuals and user guides at all-guides.com
all-guides.com

17
Variant 1; with spring clips
Installation Instructions
600
267 223
267
223
= 310 =
= 310 =
605
535
R2
R3
227,5
214,5
45
min. 30
7
Frame
Glass ceramic plate
Worktop
Screws
Catch spring
All manuals and user guides at all-guides.com

18
Variant 2; with spring clamps
Fitting the steam outlet
Installation Instructions
45
min. 30 7
Frame
Glass ceramic plate
Wokrktop
Screws
Catch spring
All manuals and user guides at all-guides.com

19
Electrical connection
Prior to connecting the appliance to the mains, it is to be checked whether
the voltage given on the rating plate, that is the nominal voltage for the
appliance, matches the local mains voltage and the nominal voltage of the
combination appliance. The rating plate is on the bottom trim panel on the
glass ceramic cooking surface.
The mains connection to the built-in oven is to include a device that ena
bles the appliance to be isolated with a contact separation of at least 3 mm
on all poles, e.g. a circuit breaker, earth leakage trip or fuse.
The cable loom with the 12-pole compact connector is to be joined to the
mating connector from the built-in oven.
Please ensure that the connector engages correctly.
After connecting the electrical supply, all cooking zones should be briefly
switched on one after the other at their maximum power, in order to test
whether they are operational.
Combination
The cooking surface can be combined with the following appliances:
Built-in oven: AEG type 53 . . .
AEG type 80 . . .
Low level built-in oven: AEG type 53 . . .
The cooking surface is not permitted to be combined with:
Built-in switch box: AEG type 57 . . .
Installation Instructions
All manuals and user guides at all-guides.com

20
All manuals and user guides at all-guides.com
