AEG Touch II 65320 K-MN Reference manual

Service-Bulletin
TSE-N
05.00
H2 Nr. 03/00
599 50 76-37
Cooking appliances EN
Self-sufficient Cooktops Touch II recess Touch II with pot recognition
Concerning following appliances:
Model PNC
65320 K-MN 949 485 523
65320 K-MN 949 485 634 (240V, GB)
With regard to the aforementioned self-sufficient cooktop recesses with pot recognition electronics, it is
possible that the connecting cable between the Touch II electronics and the pot recognition electronics melts
or the insulation becomes soft, the unisolated wire then lying on the tin bottom. This leads to a short circuit
which results in the pot recognition not working. No subsequent damage occurs as this is only powered by a
11 V signal line !
Remedial measures: When carrying out repairs on the aforementioned recess, the connecting cable is to
be replaced up to SNC 010... ! The spare part number 300 408 900/3. The new
cable is temperature resistant.
Caution: After repair, the pot recognition must be re-calibrated.
Enclosures

Informationsheet Publ-No. 599 507 502
Please Note Please Note
Testing procedure for TOUCH II
1) Calibration of the cooking field
a) Connect to power supply
b) Press front left and front right buttons at the same time and release immediately.
c) The calibration can be commenced after ”u” is displayed on all 4 hotplates
d) Right hotplate
Start by placing the customer’s cooking pot front right (145) and
then place the customer’s cooking plate back right (170 x 265),
Remove the cooking pots when both of the ”u” displays are extinguished.
e) Left hotplate
Start by placing the customer’s cooking pot back left (145) and
then place the customer’s cooking plate back left (210),
Remove the cooking pots when both of the ”u” displays are extinguished.
Observe display
It is imperative that the following be observed after calibration
Disconnect the cooktop from the mains for a period of 1 minute! (Disconnect fuse)
Then reconnect the cooktop to the power supply!
Important information
With regard to the customer’s cooking pots referred to under 1d and 1e, the ports are to be used which the
customer uses.
It is important that the pot is either of the same size or larger than the heating terminal.
