Operating and Installation Instructions

50
Contents
Safety warnings ................................................................................ 50
Description of the cooker hood .......................................................... 52
Control Panel .................................................................................... 53
Maintenance and cleaning................................................................. 55
Guarantee conditions ........................................................................ 5
Technical specifications .................................................................... 60
Installation ........................................................................................ 60
Safety warnings
This appliance is to be used solely as a household appliance. It has
been manufactured according to the international safety and quality
standards. Note that the safety devices alone are not capable of
eliminating all accident risks.
It is therefore very important to carefully read all the operating
instructions, recommendations and warnings prior to installation and
use of the appliance. Note in particular the text paragraphs with the
danger triangle design, to avoid damages to persons or objects.
Keep this instruction booklet in a safe place: this booklet should
always accompany the appliance at such time as it is sold or given to
other persons for use.
Installation and service
 Any electrical installation of the cooker hood must be carried out by
a qualified electrician and the hood itself must be installed by
someone with experience. Installation made by an unqualified
person can lead to loss of function of the cooker hood and possible
damage to person and and/or property.
 The cooker hood must be at least 50 cm above electric hobs or
electric ranges, or at least 70 cm above gas burners or gas ranges.
 Ensure that the power cable is not damaged during installation.
 The cooker hood is only in stand by mode unless the plug or the
fuse is disconnected.
 The cooker hood cannot be connected to flues of other appliances
that run on energy sources other than electricity. Please, keep to the
provisions of official directives regarding fume discharge.
S Innehållsförteckning ............................................................. 2
N Innholdsfortegnelse ............................................................ 14
FIN Sisällysluettelo .................................................................. 26
DK Indholdsfortegnelse ............................................................ 3
UK Contents ............................................................................ 50

51
Use of cooker hood
 This appliance is for domestic use only in a normal household.
 Never leave any deep-frying, melting fat, paraffin or any other
inflammable liquid unattended on the hob. In the event of fire:
Immediately switch off the cooker hood and the cooker. Note! Cover
the fire. Never use water.
 Never do any flambé cooking underneath the cooker hood. It can
cause a fire. Remember that overheated fat may spontaneously
ignite. Never leave the frying pan unattended.
 It is essential that the grease filter is regularly cleaned to help avoid
fat dripping on to the hot zone and causing a fire. Read the section
on Maintenance and Cleaning in the instruction book.
Disposal
 Prevent accidents when disposing of your cooker hood. Disconnect
the power plug from the wall socket and cut the power cord at the
hood inlet.Contact your local authority for information on where to
dispose the cooker hood.

52
Description of the Appliance
Functions
There are two possible systems:
 Extraction of air to the outside using an optional venting kit and
evacuation duct.
 Recirculation using an optional charcoal filter.
The air outlet must not be connected to chimney flues or combustion
gas ducts. The air outlet must under no circumstances be connected
to ventilation ducts for rooms in which fuel-burning appliances are
installed.
Accessories
The following are included with the cooker hood:
 1 hood canopy complete with controls, lighting and fan motor.
 1 telescopic chimney stack formed by: U-shaped upper section and
U-shaped lower section.
 1 recirculation spigot.
 1 plastic bag containing: 1 wall bracket to fix the hood, rawl plugs,
screws, and documentation.
The following can be ordered from your retailer:
 Charcoal filter, KF20. The charcoal filter is to be used when the hood
is connected to the recirculation mode.
Only for CHDD 8890: The cooker hood is supplied ready for use as
a recirculation hood and may be used for extraction by removing the
charcoal filter which has been fitted inside the cooker hood.
Extractor version
 The air is discharged to the outside through a
pipe, which must be fitted to connection flange
A. Fig. 1.
 In order to obtain the best performance the
hose should have a diameter equal to the outlet
hole.
Filter Version
 The air is filtered through a charcoal filter and
returned to the kitchen.
 You will need an original AEG charcoal filter KF
20 for the filtering function.
 Optionally, the position of the chimney
elements can be changed.
When using the hood in the filter version the
chimney must be fixed at the top, with the air
outlet grill at the side.
Fig. 1
A

53
Control Panel
 Best results are obtained by using a low speed for normal conditions
and a high speed when odours are more concentrated.
Turn the hood on a few minutes before you start cooking, you will
then get an under pressure in the kitchen. The hood should be left on
after cooking for about 15 minutes or until all the odours have
disappeared. The control switches are located on the units front
panel.
1- Main switch, hood ON/OFF.
Depress for less than 1½ [seconds] the cooker hood goes to
Stand by position (point b is on).
Depress for more than 1½ [seconds] the cooker hood turns off,
ALL the controls (except light push-button) are disabled (display is
off completely).
Depress again for more than 1½ [seconds] to reposition the
cooker hood in Stand by position.
2- Light ON/OFF
3- Display
4- Start and choice of motor speed 1-2-3-1-2.........
5- Intensive speed on/off. The Intensive speed runs for 5 minutes:
If the hood is on when the Intensive speed is activated, the hood
revert to previous speed after 5 minutes.
If the hood is off when the Intensive speed is activated, the hood
will automaticly be turned off after 5 minutes.
To interrupt the Intensive speed, press button 1 or 4.
The letter P appears on the display and the remaining time (the
point a is flashing), upon termination the system emits an audio
sound signal.
6- Self-Timer: times all the speed levels (the point b is flashing),
and then the cooker hood switches off:
The self-timer is sub-divided as follows: 1st speed level 20 minutes
2nd speed level 15 minutes
3rd speed level 10 minutes
The display reveals the remaining operation time, upon termination
the system emits an audio sound signal. Depressing the push-
button again exits the function.
Should the hood or the controls fail to operate: disconnect the power
supply for at least 5 seconds, then turn the hood back on again. Wait
for about 15 seconds prior to checking that the cooker hood is
operating correctly.
123 456
ab
Fig. 2

54
Control device for grease and charcoal filters
This hood is fitted with a device that signals when it is necessary to
clean the grease filter or the charcoal filter (in the case of recirculation
version with charcoal filter).
On delivery, the hood is not supplied with an charcoal filter, so the
saturation indicator will be disabled.
If the hood is to be used with a charcoal filter, the saturation
indicator light must be enabled as follows:
Press buttons 4 and 5 simultaneously and hold them for 3 seconds.
At first only the grease filter LED F will light up, but when the charcoal
filter LED C lights up the saturation indicator will be enabled.
To disable it: Press buttons 4 and 5 again simultaneously and hold
them for 3 seconds, until the charcoal filter LED C goes out.
Grease filter LED F)
LED F will start to flash when it is time to clean the grease filter.
Cleaning will be necessary after 40 working hours. Always comply
with the maintenance instructions for the grease filter.
Charcoal filter LED C)
The charcoal filter LED C will start to flash when the charcoal filter
needs to be replaced.
This operation is necessary after approximately 160 working hours.
Resetting the saturation indicator
After cleaning or replacing the filters, press button 1 for 3 seconds until
the grease filter LED F or the charcoal filter LED C stops flashing.
Warning! The resetting of the saturation indicator MUST be done in
stand-by, never disconnect the hood from the mains.

55
Maintenance and care
Disconnect the cooker hood from the power supply prior to cleaning
the appliance, either by removing the plug from the mains or
removing the fuse.
Clean the filter regularly. The grease deposits in the filter and
discharge tube are fire hazards where a hotplate (or another heat
source) is left on by error.
Cleaning the hood
Clean the outside of the hood using a damp cloth and a mild detergent.
Never use corrosive, abrasive or flammable cleaning products.
Cleaning the grease filters
Clean the filter every month or every other
month according to how much the hood is
used.
The cleaner the filters, the more grease they
collect. To remove the filters, Fig. 3:
 First of all, push the stop on the metal
grease filter back, and then extract the filter
by pulling downward.
The filter is made of aluminium wires on which the
grease collects. Clean the filter in hot water using a
detergent, or in a dishwasher. Let the filter dry before
putting it back. Note that a dishwasher may discolour
the filter.discolouration of the filter can occur, this does not have any
impact on its performance.
 Clean the inner housing using a hot detergent solution only (never
use caustic detergents, abrasive powders or brushes).
Fig. 3

56
d
i
h
g
g
g
g
Charcoal filter
 The charcoal filter should only be used if you want to use the hood
in the recirculation function.
 To do this you will need an original AEG charcoal filter (available
from your local Service Force Centre).
Cleaning/replacing the carbon filter
Unlike other carbon filters, the LONGLIFE carbon filter can be
cleaned and reactivated. At normal use the filter should be cleaned
every second month (when using the hood 2,5 hours per day, in
avarage). The best way to clean the filter is in the dishwasher. Use
normal detergent and choose the highest temperature (65º C).
Wash the filter separately so that no food parts gets stuck on the
filter and later causes bad odours. To reactivate the carbon, the
filter should be dried in an oven for 10 minutes with a temperature
of maximum 100º C.
After approximately three years of use, the carbon filter should be
replaced with a new, as the odour reduction capacity will be
reduced.
Fitting
Remove the frame i which supports the filter h by turning 90° the
two knobs g.
Insert the charcoal filter inside the frame and put all parts back in
their place. Fig. 4.
To remove proceed in the reverse order.
 Always specify the hood model code number and serial number
when ordering replacement filters. This information is shown on the
registration plate located on the inside of the unit.
 The charcoal filter can be ordered from your local AEG Service
Force Centre.
Fig. 4

57
Warning
 Failure to observe the instructions on cleaning the unit and
changing the filters will cause a fire hazard. You are therefore
strongly recommended to follow these instructions.
 The manufacturer declines all responsibility for any damage to the
motor or any fire damage linked to inappropriate maintenance or
failure to observe the above safety recommendations.
Changing the light bulb
 Disconnect the cooker hood from the main supply.
 Remove the lamp cover, use a screw driver as a lever. Fig. 5.
 Replace the old bulb with a new one of the same type.
 Refit the lamp cover.
 If the light does not come on, make sure the bulb has been inserted
correctly before contacting your local Service Force Centre.
Fig. 5

5
Guarantee Conditions
Standard guarantee conditions
We, Electrolux, undertake that if within 12 months of the date of the
purchase this Electrolux appliance or any part thereof is proved to be
defective by reason only of faulty workmanship or materials, we will, at
our option repair or replace the same FREE OF CHARGE for labour,
materials or carriage on condition that:
The appliance has been correctly installed and used only on the
electricity supply stated on the rating plate.
The appliance has been used for normal domestic purposes only, and
in accordance with the manufacturers instructions.
The appliance has not been serviced, maintained, repaired, taken apart
or tampered with by any person not authorised by us.
All service work under this guarantee must be undertaken by an
Electrolux Service Force Centre. Any appliance or defective part
replaced shall become the Companys property.
This guarantee is in addition to your statutory and other legal rights.
Home visits are made between 8.30am and 5.30pm Monday to Friday.
Visits may be available outside these hours in which case a premium
will be charged.
Exclusions
This guarantee does not cover:
Damage or calls resulting from transportation, improper use or neglect,
the replacement of any light bulbs or removable parts of glass or
plastic.
Costs incurred for calls to put right an appliance which is improperly
installed or calls to appliances outside the European Community (EC)
or European Free Trade Area.
Appliances found to be in use within a commercial environment, plus
those which are subject to rental
agreements.
Products of Electrolux manufacture which are not marketed by
Electrolux.

59
Special accessories*
Charcoal filter KF20 E-Nr. 942 120 600
European Guarantee
If you should move to another country within Europe then your
guarantee moves with you to your new home subject to the following
qualifications:
The guarantee starts from the date you first purchased your product.
The guarantee is for the same period and to the same extent for labour
and parts as exists in the new country of use for this brand or range of
products.
This guarantee relates to you and cannot be transferred to another user.
Your new home is within the European Community (EC) or European
Free Trade Area.
The product is installed and used in accordance with our instructions
and is only used domestically, i.e. a normal household.
The product is installed taking into account regulations in your new
country.
Before you move please contact your nearest Customer Care centre,
listed below, to give them details of your new home. They will then
ensure that the local Service Organisation is aware of your move and
able to look after you and your appliances.
France Senlis [phone]
Germany Nürnberg [phone]
Italy Pordenone [phone]
Sweden Stockholm [phone]
UK Slough [phone]

60
Technical Specifications
Modell DD 8890 CHDD 8820
CHDD 8890
Dimensions - extractor version (in cm):
Height 70-113 6 ,5-113,4
Width 9, 119,
Depth 50 46
Dimensions - filter version (in cm):
Height 7 -122 77,2 - 123
Width 9, 119,
Depth 50 46
Lighting: 2 x 20W 4 x 20 W
Grease filter: 3 4
Electrical connection: 220 - 240 V 240 V
Maximum absorbed power: 215 W 275 W
Installation
Unpacking
Check that the cooker hood is not damaged. Transportation damages
should immediately be reported to the transport company. Damages,
faults and missing parts should immediately be reported to the retailer.
Dispose carefully of the packaging material so that it is out of the way
of small children.
Position
The cooker hood should be mounted freely hanging on the wall. The
cooker hood must be at least 50 cm above electric hobs or electric
ranges, or at least 70 cm above gas burners or gas ranges.
The cooker hood cannot be connected to flues of other
appliances that run on energy sources other than electricity.
Please, keep to the provisions of official directives regarding fume
discharge.
Electrical connection
The hood has a power cable with earth connection and the rated voltage
is 220-240V.

61
Wall unit mounting - Fig. 6
First decide which functioning version is
better for you.
If you decide to use the hood in exhausting
version we suggest to position the upper
section of the chimney so that the oulet
slots are not visible once installation has
ended, on the contrary if is decided to use
the hood in recycling version BE SURE that
the side with slots is up (see also A-B-C
sequence on on Fig. 6).
Wall unit mounting - Fig. 7
 Mark the wall with a centre line, this will aid mounting procedure (1),
position the template so that the mid line printed on the template
matches with the centre line previously drawn, the lower side of the
template corresponds to the lower side of the hood once mounted
(2).
 Drill two holes Ø mm and fix the support bracket with two wall
plugs and screws (3). Hang the hood (4) and adjust its position (5-
6).
 From the inside of the hood sign two points for definitive fixing (7).
 Remove the hood (8) and drill two holes Ø mm (9), fit two wall
plugs (10).
 Drill two holes Ø mm on the upper side close to the ceilling, fit two
wall plugs (11) (In case the hood is to be used in filter version,
mount the deflector F on the chimney support with four screws
2,9x6,5 (Two screws for model CHDD 20)) and fix the chimney
support with two screws (12).
 Hang the hood again (13) and fix it definitively with two screws (14).
 Fit an exhausting pipe (15) to connect the outlet hole A of the hood
to the outside (Extractor hood) or to the deflector F (Filter version).
 Make electrical connection (16).
 Fix the chimney first up (17a) to the chimney support (17b), then
slide the lower section of the chimney down into the proper housing
on top of the hood (18).
Only for model CHDD 8820: Fix the lower section to the hood with
two screws 3 x 9 mm (19).
A
B
180°
C - OK!
Fig. 6

62
Fig. 7
17b
17b
4-13
4-13
1
2
3
11
11
12
15
17a
17a
65
16
B
G
H
8
8
18
F
9
10
14
7
9
10
14
7
5
6
F
G
19
19
CHDD 8820

63

AEG Hausgeräte GmbH
Postfach 1036
D-90327 Nür berg
http://www.aeg.hausgeraete.de
http://www.aeg.co.uk
© Copyright by AEG LI148A Ed. 06/03
From the Electrolux Group. The world´s No.1 choice.
The Electrolux Group is the world´s largest producer of powered appliances for kitchen,
cleaning and outdoor use. More than 55 million Electrolux Group products (such as refrigerators,
cookers, washing machines,vacuum cleaners, chain saws and lawn mowers are sold each
year to a value of approx. USD 14 billion in more than 150 countries around the world.
