AEG Perfekt Pyramid?30 User manual









PerfektPyramid‐30,PerfektPyramid‐36
RangeHoodInstructionManual









Thankyouforthepurchaseofthisproduct.Pleasereadthe
manualcarefullybeforeoperatingtheappliance.


1|Page


Contents

ImportantSafetyInstructions2
Introduction3
Features3
Installation4‐5
HowtoUse6
GroundingInstructions7
SafetyInformation8
TroubleShooting9
ElectricalDiagram10
Specifications11
Cleaning&Maintenance12
InstallationDiagram13
Warranty14








14|Page

Warranty
AEGAppliancesareimportedanddistributedinNorth
AmericabyEuro‐LineAppliancesInc.
Formoreinformationvisitwww.euro‐line‐appliances.com
orcontact:

871CranberryCourt,
Oakville,Ontario.L6L6J7
Canada
Tel905‐829.3980

1‐800‐421‐6332–Euro‐LineAppliancesInc.
1‐800‐ELA‐WEST–Euro‐LineAppliancesWest

marketing@euro‐line‐appliances.com

AllAEGAppliancesarebackedbyacomprehensive2‐year
partandlabourwarranty.Informationonserviceandparts
availablefromEuro‐Partsat1‐800‐678‐8352



13|Page


InstallationDiagram















2|Page

ImportantSafetyInstructions
○Readandsavetheseinstructions
○Warning‐Toreducetheriskoffireorelectricshock,do
notusethisfanwithanysolid‐statespeedcontroldevice.
○CAUTION:Forgeneralventilatinguseonly.Donotuse
toexhausthazardousorexplosivematerialsandvapors.
○Warning‐Toreducetheriskofarangetopgreasefire:
Neverleavesurfaceunitsunattendedathighsettings.
Boiloverscausesmokingandgreasyspilloversthat
mayignite.Heatoilsslowlyonlowormediumsettings.
AlwaysturnhoodONwhencookingathighheator
whenflambéingfood(i.e.CrepesSuzette,Cherries
Jubilee,PeppercornBeefFlambé)
Cleanventilatingfansfrequently.Greaseshouldnotbe
allowedtoaccumulateonfanorfilter.
Useproperpansize.Alwaysusecookwareappropriate
forthesizeofthesurfaceelement.
○Warning‐Toreducetheriskofinjurytopersonsinthe
eventofarangetopgreasefire,observethefollowing:
Smotherflameswithaclose‐fittinglid,bakingsheet,or
metaltray,andthenturnofftheburner.Becarefulto
preventburns.Iftheflamesdonotgooutimmediately,
evacuateandcallthefiredepartment.
Neverpickupaflamingpan‐youmaybeburned.
Donotusewater,includingwetdishclothsortowelsa
violentsteamexplosionmayresult.
UseanextinguisherONLYif:A)Youknowyouhavea
classABCextinguisher,andyoualreadyknowhowto
operateit.B)Thefireissmallandcontainedinthe
areawhereitstarted.C)Thefiredepartmentisbeing
called.D)Youcanfightthefirewithyourbacktoan
exit.


3|Page


Introduction

oThisappliancehasbeenmanufacturedwithmaterials
andprocessesthatrespecttheenvironment.Wehope
thatyouwillcontinuethisimportantconsiderationin
theoperationofthisapplianceandthedisposalofthe
packagingmaterials–thankyou.
oTheinstallationworkmustbeundertakenbya
qualifiedtechnicianexperiencedinrangehood
installation.Pleaseconnectthecorrectpowerrating
(seepage10)
oThemanufacturerdisclaimsallliabilityforanydamage
orinjurycausedasaresultofnotfollowing
instructionsforinstallationcontainedinthefollowing
text
oTheapplianceisnotintendedforusebyyoung
childrenorinfirmpersonswithoutsupervision
oYoungchildrenshouldbesupervisedtoensurethat
theydonotplaywiththeappliance
oThemaximumnumberofburnerscoveredbyarange
hoodshouldnotexceed5
oAnymodificationstotheappliance,electricwireand
plugisdangerousandvoidsthewarranty

Features

oThisapplianceismanufacturedfromtopquality
materials,andofferssuperbstreamlinedeffects
oWithhighsuctionpowerandlownoise,itisdesigned
toremovecookingfumesfromyourkitchenquietly
andeffectively
12|Page


Cleaning&Maintenance

1. Cleanthesurfaceofthehoodeveryweekwithmild
soapordetergent.Avoidsolvents,acid,alkali,scouring
padsorpowderthatcouldirreparablydamagethe
stainlesssteelsurface
2. Thegreasefiltersmaybewashedusingmildsoap,
detergentordegreasingagents
3. Thecharcoalfilterscannotbecleanedandbustbe
generallyreplacedafter6monthsofuse



















11|Page


Specifications


PerfektPyramid‐30
PowerSupply110‐120V,60Hz
RatedInputPower97W
LightingPower1x2W
MotorPower95W
Airflow500CFM
OutletDiameter150mm
HardwireorPlugPlug


PerfektPyramid‐36
PowerSupply110‐120V,60Hz
RatedInputPower99W
LightingPower2x2W
MotorPower95W
Airflow500CFM
OutletDiameter150mm
HardwireorPlugPlug








4|Page


Installation(ductisnotsupplied)
1. Therangehoodshouldbemountedatadistanceof
24”(600mm)fromanelectricorinductioncooktop,
and30”(762mm)aboveagascooktopforsafetyand
optimumperformance.Iftheinstructionsfor
installationofthegascooktopspecifyagreater
distance,thishastobetakenintoaccount.(seepic1,in
nextpage)Theexhaustairmustnotbedischarged
intoafluewhichisusedforexhaustingfumesfrom
otherappliancesburninggasorotherfuels
2. Toinstallontothewall,mountingbracketshouldbe
positionedonwall13.75”(350mm)abovethebottom
oftherangehood.(seepic1andpic2innextpage)
3. Insertexpandingscrewsintotheholes.(seepic2in
nextpage)
4. Drill2holesinwall2.75”(70mm)oneithersideof
centrepointofrangehood.Drill2additionalholesfor
mountingbracket2.36”(60mm)fromexistingholes.
5. Addtheboot(alternativepart)totheonewayvalve,
andconnectittothekitchenoutletvent.(seepic3in
nextpage)
6. Inserttheouterchimney,theouterchimneyshouldbe
fixedonthemainbodybyscrews.Thenmountthe
bracketandinserttheinnerchimneyandscrewitto
tighten.(seepic4innextpage)
7. Ensurethatthewallthehoodistobeinstalledonis
sufficientlysturdytocarrytheweightofthehood.It
shouldbemountedlevelforbestperformance
8. Donotconnecttoacommonventwithanyother
appliancessuchasagasheater,waterheater,
washer/dryer,etc.


5|Page

9. Theductshouldnotbebentmorethanspace120°
fromtheonewayvalveoutletinthekitchenvent
10. Checktomakesurethattheelectricalcordisnotin
contactwithsharpedgesoftheappliance
11. Besurethattheplugisaccessibleafterinstallation
12.Ductlessinstallations(orRecirculatingInstruction)for
ductlessinstallations,Removelabelonundersideofhood
indicatinginstallationofcharcoalfilter.Attachcharcoal
filter,partCF‐B,byplacinginopeninganddippinginplace.


600 762mm (24"~30")
-
950-1112mm (38"~44")



Pic1
Pic
5
Pic
4
Pic2
Pic3
10|Page


ElectricalDiagrams


PerfektPyramid‐30






PerfektPyramid‐36








9|Page


TroubleShooting

Ifanyproblemoccurs,pleasedetachtheplugfromthe
socketandcontactEuro‐Partsorasimilarlyqualified
personinordertoavoidahazard.

ProblemCauseSolution
Lighton,but
motordoesnot
work
Theoutletvalveis
blocked
Detachflueandduct
thenturnonthehood
tocheckifthevalves
open
Thecapacitorhas
failed
Callfortechnical
service
Thecontrolswitch
hasbroken
Callfortechnical
service
Lightdoesnot
work,motor
doesnotwork
Nopowersupply
Pluganotherappliance
intothesocketto
confirmthereispower
supply
FusehasblownOpenuptheplugand
replacehe13Afuse
Vibration
Thepropelleris
damagedor
unbalanced
Callfortechnical
service
Thehoodisnot
installedcorrectly
Reviewtheinstallation
instructionsandcheck
theinstallationagain
forloosescrews,
bracketsor
connections
Insufficient
suctioneffect
Thedistance
betweenthehood
andcooktopistoo
great
Checkthatthe
distanceisbetween
600mmand762mm
Thefiltersare
saturated
Cleanthefiltersfrom
greaseresidueand
replaceaftercleaning
6|Page


HowtoUse

3speedadjustment(seepic6)

oPushthe1button,andthemotorwillrunatthelowest
speed
oPushthe2button,andthemotorwillrunatmedium
speed
oPushthe3button,andthemotorwillrunatthe
highestspeed
oPushtheLightbutton,andthelightinglampswill
illuminate.Pushitagainandthelightswillturnoff
oOnanyspeed,Push“T”buttononceandthedelay
timerwillstartworking.Themotorwillbeturnedoff
automaticllyafter5minutes
oPush“T”buttontwice,themotorwillturnoff
immediately.









Pic
6


7|Page


GroundingInstructions

oThisappliancemustbegrounded.Intheeventofan
electricalshortcircuit,groundingreducestheriskof
electricshockbyprovidinganescapewireforthe
electriccurrent.Thisapplianceisequippedwithacord
havingagroundingwirewithagroundingplug.The
plugmustbepluggedintoanoutletthatisproperly
installedandgrounded.
oWarning‐Impropergroundingcanresultinariskof
electricshock.
oConsultaqualifiedelectricianifthegrounding
instructionsarenotcompletelyunderstood,orifdoubt
existsastowhethertheapplianceisproperly
grounded.
oDonotuseanextensioncord.Ifthepowersupplycord
istooshort,havingaqualifiedelectricianinstallan
outletneartheappliance.

WARNING:TOREDUCETHERISKOFFIRE,USEONLYMETAL
DUCTWORKandDUCTCONNECTIONDEVICEFORTHE
APPLIANCEWITHLOGOcETLusORETLusFORTHEAPPLIANCE
WITHLOGOcETL,THEDUCTWORKandDUCTCONNECTION
DEVICEMAYBENON‐METALLICANDSUITABLEMETARIALS.






8|Page


SafetyInformation

oTheremustbepermanentandadequateventilationofthe
roomwhenoperatingtherangehoodwithappliances
burninggasorotherfuels
oDonotcheckthestatusofthefilterswhentherangehood
isoperating–waitatleast30minutesafterswitchingoff
toavoidscalding
oDonottouchtheLEDlightwithin30minutesafter
applianceuse
oAvoidoperatingagascooktopwhenthereisnopanonthe
stove.Itisafirehazardandmaycausedamagetothe
hoodfilters
oDisconnecttheelectricalplugpriortoanymaintenance
oThisapplianceisnotintendedforusebyyoungchildren
unlesstheyhavebeenadequatelysupervisedbya
reasonablepersontoensurethattheycanusethe
appliancesafely
oTherangehoodisforhomeuseonlyandisnotsuitablefor
outdoor,barbeque,andothercommercialapplications
oTherangehoodanditsfiltershouldbecleanedregularly
forbestperformance
oBeforecleaning,pleaseconfirmthatthepowerisswitched
off
oBuildingregulationsconcerningthedischargeofexhaust
airhavetobefulfilled
oDon’tcookwithanopenflameundertherangehood
oForanytechnicalissuesensurethatasuitablyqualified
personhandlesanyrepairsorinspections


