AEI VH-9208-SU(S) User manual

VoIP Phone
VH-9208-SU(S) / VH-9108-SU(S)
QIG
V 1.02

1
1 O Ov ve er r v vi ie ew w
This phone is a full-feature telephone that provides voice communication. Read this QIG carefully to learn how to
operate this product and take advantage of its features.
P
Pa ac ck ka ag ge e C Co on nt te en nt ts s
When unpacking the VoIP phone, ensure all the following items are present and undamaged. If anything appears to be
missing or broken, contact your dealer for a replacement.
1. Base Unit
2. Handset
3. AC Adaptor
4. RJ-45 Cable
5. Quick Installation Guide (This document)
2
2 P Pr ro od du uc ct t D De es sc cr ri ip pt ti io on n
This chapter contains important information to help you familiarize yourself with the functions of the VoIP phone.
F
Fr ro on nt t V Vi ie ew w
Name
Description
1
Ring Indicator
A red light indicator means that you have incoming
calls.
2
Dialing Pad
Press the buttons to dial a phone number or enter
alphabetical characters.
3
Speed dial Service
Keys
Press any of the keys to speed dial the preset contact
number.
4
Function keys
Redial
Press to call the last number dialed.
Hold
Press to put an active call on hold.
LINE 1 / LINE 2
There are two LINEs bottom in this IP Phone.
1
2
3
4

3
Name
Description
Volume control keys
Increases or decrease the volume for the currently
active voice receiver for handset. The volume button
also controls the ringer volume when on-hook.
MESSAGE
Press to retrieve voice messages.
SPEAKER
Press to activate the speakerphone for hands free
conversations.
B
Ba ac ck k V Vi ie ew w
NO.
Name
Description
1
LAN port
Connects to HUB, ADSL, or Switch(PSE)
2
DC 5V Power jack
Connects to AC power adapter. (Optional. While base
unit is not powered via a PSE)
3
Handset jack
Connects to handset.
Name
Description
USB Charger port
Connects to mobile equipment charging cable.
3
3 O Op pe er ra at ti io on n
A
An ns sw we er ri in ng g a a C Ca al ll l
An incoming call is indicated by a ringing tone and a flashing indicator at the top of both handset and base units. You
can answer the call by doing one of the followings:
Pick up the handset to answer the call.
M
Ma ak ki in ng g a a C Ca al ll l
Dialing with the Keypad
Enter the telephone number with the alphanumerical keypad.
After entering the number you want to call, press the #key to force dialing or wait for 3 seconds before the number

is dialed automatically.
C
Ca al ll l O Op pt ti io on ns s
While a call is in progress, a number of additional options are available.
U
Us si in ng g t th he e S Sp pe ea ak ke er r P Ph ho on ne e
For hands free operation, you can use the built‐in speaker to talk on the phone. To use the speakerphone, follow the
steps below:
While talking on the phone, press the SPEAKER key on the phone to enable the Speakerphone function.
Press Speaker key again to terminate the call.
P
Pu ut tt ti in ng g a a C Ca al ll l o on n H Ho ol ld d
You may want to put a call on hold temporarily while doing some work or attending to a second incoming or outgoing
call. To put a call on hold, do one of the following:
Press the HOLD key on the phone to put the call on hold.
When you receive a second call, press the next available LINE key to attend to the new call, and the first call will be
put on hold automatically.
4
4 S Su up pp po or rt t
To configure through the web browser, do the following:
Ensure the phone is powered up and connected to a DCHP network.
Press HOLD/MUTE *112*113# (HOLD for 2-Line / MUTE for 1-Line), the IP address is displayed on the LCD
screen.
Open your browser (such as Internet Explorer, Firefox, etc.) and type in the web address of the phone. For
example, if the IP address you obtain in step 4 above is 192.168.1.2, enter the web address: http:// 192.168.1.2:8000.
When the Web login front page is displayed. Enter the user name and the password and click Login.
The administrator’s user name and password are “admin”and “1234”respectively.
For technological support, please email to [email protected].
