aeolus KaniStar Warmology WMS-1501 User manual

Distributor Contacts
UC-1801
KO2-10FKO2-2F
WMS-1501
KaniStar Warmology
WMS-1501
Professional Vet Equipments Supplier
User Manual

01
Introduction
CONTENTS
Introduc�on .…………………………………………………........................
Quick start guide .…………………………………………………................
Wms-1501-st warmology bodysuit ……………….....................
Wms-1501-mt warmology mat ………………………………..........
Safety warning …………………………………...............……..................
Specifica�ons ...........................................................................
Electrical parameters …………………………………….......................
Trouble shoo�ng ……………………………………………………..............
Packing list ………………………………………………………......................
Warranty ……………………………………………………….........................
01
02
03
04
04
05
05
06
06
06
KaniStar Warmology model number: WMS-1501 was developed for veterinary use only.
Listening to the advices and suggestions from our veterinary clients, KaniStar developed the
WMS-1501 with features far superior to other products in the market. Combined with KaniStar
accessories, this unit is much more affordable and a higher valued product to the veterinary industry.
KANISTAR Warmology model number: WMS-1501 will provide a consistent sterilized warm
atmosphere, surrounding the patient, reducing the chance of Hypothermia (resulting from the anaes-
thetics during surgeries).
Precision LCD Display
Ambient Temperature
Fault Alarm
Over Heat Alarm
Working Temperature Indicator Light
Negative Ion Generator
Sterilization
Swiveling Easy-to-fit Outlet Port
Adjustable Wind Speed (two stages)
Four Pre-set Temperature Setting
The main heating unit offers a multitude of beneficial functions and features.
1. The operating noise level is very low. (53dB).
2. Three tiered sterilization system, 254nm ultra violet light, high concentration negative ion and 0.2μ
m HEPA filtering.
3. Dual detecting temperature control with 1.5 Celsius degree minus tolerance ensured. Two sensors
are located at the outlet from the heat unit also at the end of the hose, detecting and compensating for
heat loss from the hose.
4. Adjustable wind speed (two stages) with stable temperature control.
5. Easy to handle and maintain, smart trouble shooting system installed.
6. Accurate LCD display, real time temperature of blanket monitoring.
7. The unit can be freestanding or easily attached to our specialized stand.
8. Compact and light weighted, using little space, easy to transport.
9. Five pre-set temperatures, Ambient, 93F°(34C°), 98F°(37C°), 104F° (40C°), 109 F° (43C°).
10. Swivelling easy to fit outlet port, makes attaching the hose effortless.

Quick Start Guide
WMS-1501-ST
WARMOLOGY BODYSUIT（Optional Accessory）
02 03
The day the unit is delivered, an inspection of the outer packing should be made first for any damage
to the packing box.
Then the unit should be unpacked carefully, all components and the machine should be inspected for
any damage.
If any damage is evident, the carrier or dealer should be notified immediately.
The manufacturer is not liable for any damage caused by a third party "transport or delivery company".
The unit should be placed in a well ventilated position and all inlets and outlets should be unobstructed.
There should be a 10cm or 4-inch clearance on all sides.
Connect the air flow hose to the air outlet.
Connect the power cable to a suitable power outlet, the unit is now in standby mode.
Press and hold the sterilization button on the control panel for 3 seconds. The unit will begin
sterilizing process for approximately 5
minutes, countdown will be displayed on the
LCD screen. Sterilizing can be cancelled by
pressing the same button. No other function
on the unit will operate during this process.
When sterilizing has concluded, the unit is
ready to be used.
You can now attach the desired attachment
to the hose.
The fan speed default is set at “high”. Fan
speed can be changed at this time.
Then select the operating temperature by
choosing one of the 5 pre-set temperature
buttons on the control panel to start the
machine.
The LCD screen will display: current
temperature (in large font), selected
temperature and elapse time (in small font).
Precision
LCD Display
Ambient
Temperature
Fault Alarm
Over Heat Alarm
Working
Temperature
Indicator Light
Negative Ion
Generator
Sterilization
Adjustable
Wind Speed
(two stages)
Four Pre-set
Temperature
Setting
Temperature Settings
Standby Button
If a different temperature is selected during
use, the elapse time will be reset automatical-
ly to zero.
By holding the same temperature selecting
button, the accumulative time will be
displayed.
The green light will illuminate when the
working temperature is reached.
The negative ion generator can be selected at
any stage of operating from the control panel.
This will provide a sterilized air flow to the
blanket.
The fan speed can be adjusted at any time.
Note: The unit will not operate correctly if the holes are not facing in the correct direction. This could
result in overheating or malfunction.
Only KaniStar accessories should be used with the WMS-1501.
The unit should not be used with accessories or parts other than the manufacturer’s parts or accesso-
ries.
Any other supplies’ parts that are used in the unit will be used at the risk of the operator.
All warranty will be void and no responsibility will be taken by KaniStar if any of the instructions are not
strictly followed.
Only operated under the guidance of qualified licensed veterinarian.
1. The body suit fully envelops the torso and limbs. (The limb wrap is our exclusive patented system).
2. Disposable nonwoven material, very cost effective.
3. Evenly distributes heat through 3D outlets system on wrapping “suit”.
4. The best choice for anaesthesia temperature management.
5. Different sizes available for small, medium and large animals.
6. Can be used with WMS-1501-MT mat to form a complete warming system.
7. Non-inflatable paw guards against thermal injury to the heat-sensitive paws and lower legs.
8. Durable and flexible materials that provide the ability to warm patients in various positions.
9. Disposable blankets are designed for single use only to create a sterilized environment and avoid
cross contamination.
SML

04 05
Specifications
Electrical Parameters
Safety Warning
WMS-1501-MT
WARMOLOGY MAT（Optional Accessory）
1. The best solution available for Convalescent Animal Normothermia maintenance.
2. The fabric will remain dry and warm for extended periods of treatment during ventilation and fluid
transfusion.
Allowing the patients to avoid the pain and discomfort of eczema, bedsores (pressure ulcers), Reliev-
ing possible irritation to the patient’s skin which could cause skin problems, especially when patient’s
activities have been restricted in a cage where the mat or floor is wet for a longer than normal period.
This mat is an ideal choice to help create a 24/7 dry and warm environment for animals. This
significantly helps the healing process.
3. Made from patent pending fabric with cubic honeycomb structure, provides 3D support to the
patient’s body (40 points per square centimetre), filtering dirt in dense fibres.
1. Flexible, easily moulded to suit different sized animals.
2. The sterilized warm air will provide much better ventilation. Also significantly lower the risk of
infection.
3. Definitely a very good choice for young animal incubation.
4. Machine washable, easy to clean, eco-friendly (SGS approved).
5. No electric hazard risk, (no electric wires are used internally), preventing possible injury from
exposure to liquids and chewing.
All maintenance and repairs should be carried out by qualified authorized trained technicians.
All animal care should be supervised by a qualified licensed veterinarian.
If the unit starts to make a continuous noise, please contact an Authorized service centre.
The machine housing can be wiped clean with a mild cleaning agent that is non-abrasive.
Dimension
Noise Level
Filtering and sterilization
Negative ion
Weight
Vent Hose
Suggested filter replacement cycle
Suggested Operation Environment
Relative Humidity
Altitude
Warming time
Temperature Control Tolerance
Storage and Transportation Temperature
30cm×22cm×36cm (12” ×8.65” ×14”)
49dB (high speed)
43dB (low speed)
Three tiered filtering system
0.2μm HEPA filter
254nm ultraviolet sterilization light
6×106Pcs/cm3±10%
6.14kg (13.52lbs)
Food class, flexible, sensor inside.
2 months or over 120 hours
Temperature: -20°C -30°C
35% -80%
≤3200m
2 -8 minutes
±1.0°C
-10°C -45°C
PTC, 800W
45W
110V /95CFM
220V /78CFM
110V /26mmAq
220V /18mmAq
Porcelain Fuse
Heating Element
Fan Motor
Air Volume
Wind Pressure
Fuse
Regulation
Rotational Speed
Rated Current
Rated Fuse
IEC60601
110V /3540RPM
220V /3945RPM
12A (110 -120VAC)
8A (220 -240VAC)
15A (125VAC)
8A (250VAC)

06
Trouble Shooting
Packing List
Warranty
Power Failure
Once temperature exceeds ≥50°C, the red alarm light will flash and the alarm will sound, heating
elements and fans will be shut down automatically, the operation panel is not workable.
Unplug the power plug to allow sufficient cooling time before attempting to restart.
If the problem persists, please contact your KaniStar Authorized service centres.
The yellow light flashing and alarm sounding indicate possible malfunctions with mechanical system,
fans, heater or sensor, etc.
Temperature should be closely monitored until the machine can be turned off and unplugged.
Wait ten minutes and restart, the machine will run self-diagnosis; if the fault light remains on, please
consult your local distributor or service centre.
Check that the power cable is connected.
Check that the Power supply is connected.
Check the fuse.
Overheat
Fault Alarm
Air-conditioning Unit
Instruction Manual
Rubber Tubing Set
Power Cord
12 months limited warranty from the date of purchase.
Warranty does not cover any misuse of the item or any damage caused directly or indirectly by the
user.
An extended warranty can be purchased from the distributor.
