AerAtron FR3 Series Installation and operating instructions

FR3 & FQ3 CEILING FAN
FR3
FQ3
Available in: 43”/1070mm 50”/1270mm 60”/1524mm - FR3 model only
LED light kit and ceiling extension kit are oponal for all AeratronTM models
USER MANUAL & INSTALLATION GUIDE
ATTENTION ELECTRICIANS
An isolaon switch per fan is highly recommended
WARNING: If unusual oscilang movement is observed, immediately
stop using the ceiling fan and contact the naonal distributor/retailer

Important information - Please read before attempting installation
1
!
This fan must be installed by a licensed and qualified
electrician according to local authority regulaons.
*DIY installaon allowed in some countries*
1. Please read these instrucons carefully, be mindful of all warnings and safety informaon shown throughout
this manual. Should you have any quesons please call your local agent.
2. Please review the accompanying assembly diagrams before aempng installaon.
3. This fan MUST be installed by a licensed & qualified electrician according to local authority regulaons and in
accordance with current wiring rules of the country/state.
4. A copy of the purchasing receipt and proof of installaon by a licensed and qualified electrician according to
local authority regulaons is required for all warranty claims.
4a. DIY installaon requires proof of purchase only.
5. Where special access equipment is required to service the fan in accordance with local authority regulaons all
associated costs are the responsibility of the owner.
6. Should a warranty claim be required, we reserve the right to charge a service fee for all call outs where the
fan is found not to be defecve and / or where access is not provided.
7. To enable future programming, maintenance, cleaning and troubleshoong an isolaon switch per fan is highly
recommended. Without an isolaon switch per fan, an electrician maybe required to assist with programming,
maintenance, cleaning and troubleshoong. All associated costs are the responsibility of the owner.
8. A Maximum of 8 fans on each RCD / circuit is recommended. The fans are a Class 5 Device with leakage to
Earth.
9. Your warranty will be void if a solid state dimmer or any other brand of wall controller is used.
10. The means for mains power disconnecon must be incorporated in the fixed wiring in accordance with
naonal wiring rules.
11. To avoid possible electric shock during installaon, be sure electricity is turned off at the main power box
before commencing work. Disconnect power by removing fuse or turning off circuit breaker before installing
the fan. Ensure all spliced connecons are adequately insulated.
12. Warning! Do not allow the rotang fan blades to come into contact with any object, this can cause serious
injury or death.
13. Damage caused by incorrect installaon, Force-majeure, lightning, electrical surges & spikes, exposure to
water, pests or moisture is not covered under warranty.
14. This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental
capabilies, or lack of experience and knowledge, unless they have been given supervision or instrucon
concerning use of the appliance by a person responsible for their safety.
15. Suspension System
· the replacement of parts of the safety suspension system device shall be performed by the manufacturer, its
service agent, or suitably qualified persons.
· fixing means for aachment to the ceiling such as hooks, or other devices shall be fixed with a sufficient
strength to withstand 4 mes the weight of the ceiling fan.
· the mounng of the suspension system shall be performed by the manufacturer, its service agent, or suitably
qualified persons
· the model or type reference of a luminaire that may be installed in a fan must be constructed for this purpose
Australia, New Zealand: In accordance with AS/NZS60355-1 & ASNZS60355-2-80: “This appliance is not
intended for use by persons (including children) with reduced physical, sensory or mental capabilies, or lack
of experience and knowledge, unless they have been given supervision or instrucon concerning use of the
appliance by a person responsible for their safety. Children should be supervised to ensure that they do not
play with the appliance.”

Contents
2
IMPORTANT
assistance before leaving the site.
Important Informaon ................................................................................................................ 1
Contents ...................................................................................................................................... 2
Unpacking your fan ..................................................................................................................... 3
Installing your Fan ....................................................................................................................... 4
STEP1 Mounng the Hanger Bracket to Ceiling....................................................................... 4
STEP 2 Connecng Mains Power to Terminal Block................................................................. 4
STEP 3 Inserng Fan Motor into Hanger Bracket..................................................................... 5
STEP 4 Installing Receiver into Hanger Bracket ....................................................................... 5
STEP 5 Connecng Receiver..................................................................................................... 6
STEP 6 Pairing the Remote Control ......................................................................................... 7
STEP 7 Aaching the Fan Motor Housing ................................................................................ 8
STEP 8 Assembling the Fan Blades........................................................................................ 8,9
STEP 9 Aaching the Fan Blades ............................................................................................. 9
Opon A - LED Light Kit ............................................................................................................. 10
Opon B - Ceiling Extension Kit................................................................................................. 10
Opon C - Raked Ceiling Kit....................................................................................................... 11
Technical Specificaon .............................................................................................................. 12
Care and Cleaning ..................................................................................................................... 13
Troubleshoong ........................................................................................................................ 13
If the fan is noisy .................................................................................................................... 13
If the fan rotates but does not create much airflow.............................................................. 13
General Informaon.................................................................................................................. 14
Normal Wear and Tear .......................................................................................................... 14
Ceiling Fan Warranty................................................................................................................. 14
Transfer of Warranty ............................................................................................................. 15
The following is NOT covered by warranty. ........................................................................... 15
Aeratron ceiling fan warranty details........................................................................................16

3
Unpacking your fan
Unpack your fan and examine all parts, you should have the following:
CEILING SPACER x 2
HANGER BRACKET
MOTOR ASSEMBLY
CONTROL RECEIVER
MOTOR HOUSING
50” FAN BLADE
X3
43”FAN BLADE
X3 OR 60”FAN BLADE
X3
OR
REMOTE CONTROL
HUB UPPER
HUB LOWER
AAA BATTERIES x2
OR
TIMBER SCREWS X 2
PIVOT LOCK X1
HUB SCREWS X 10
MACHINE SCREWS X 2
WASHER X 2 WASHER X 2
NOTE: Wall control / automaon control & wifi module components are not included;
please contact your local fan supplier for more informaon.

STEP 1 Mounting Hanger Bracket to Ceiling
supply at the main power box. Disconnect power
by removing fuse or turning off circuit breaker.
!
hanger
provided. Ensure ceiling joists are sound and of adequate size and strength to support a 32kg (70lbs) load. If a
between two beams.Proper care must be
and stronger screws.
Ceiling Joist
OPTION A: OPTION B:
Embedded
STEP 2 Connecting Mains Power to Terminal Block
4
WARNING: MOUNT ONLY TO AN OUTLET BOX MARKED ACCEPTABLE FOR FAN SUPPORT.
N
L
CONNECT WITH RECEIVER
3PIN
NEUTRAL
LIVE
L
LIVE
LIVE
GROUND
GREEN
BROWN L
BLUE N
FROM HOUSE
(Mains Power)

!
Inserting an otor into Hanger Bracket
=
Bracket Ensure that lug on Hanger
Ball
STEP 4
is engaged in slot in suspension
Installing Receiver into Hanger Bracket
5
STEP 3
Slide Remote Control Receiver
into Hanger Bracket from the
opposite side of the Terminal block
in the orientaon as shown below.
Oponal
Wifi module
Antenna

X0
6
Connecting the Receiver
STEP 5
Learn Switch
Switch to “O” to pair receiver
with the Remote control and
Switch to “X” to lock the pairing
code with the Remote control
2PIN LED driver connection
(optional for LED light)
3PIN
3PIN
Mains Power
Aerial
4PIN Comms
Connector
(Optional USE ONLY
IF INSTRUCTED)
1.
2.
Connect the 3PIN connector (Mains Power)
between Hanger Bracket and Reciever.
Connect the3PIN
& Earth cable connector
between DC Motor and Receiver.
3PIN
Receiver to
Hanger bracket
3PIN
Receiver
to Motor
Earth Cable

The remote control is pre-programmed
No pairing with the receiver required
STEP 6
!
Pairing the Remote Control
NOTE: Blades must be aached prior to tesng the fan
1. On Receiver: Verify that the “Learn” switch is in the “O” posion
2. Slide baery cover to unlock - Locate the LEARN BUTTON &
insert baeries.
3. Switch on the main power to acvate the receiver, indicated
by one beep. (Energise one fan reciever at a ame).
4. Within 60 seconds aer the power is turned on (one beep),
press and hold the LEARN buon on the Remote Control
(min. 3 secs.) unl Fan Receiver issues three ‘beeps’ which
indicates successful pairing.
5. On Receiver: switch the “Learn” switch to “X” (this will
lock the pairing code with the remote)
6. Finish STEP 7, 8 & 9 and press ON/SPEED buon to test
fan funcons.
7. To re-pair, repeat steps 3 to 5
NOTE: Power must be off for 10 seconds min. before repairing.
Pairing a Single Fan per remote control: LEARN MODE
The Remote Control and Fan Receiver will memorise the pairing
code for future use even if mains power is switched off.
LIGHT SWITCH: Select ON/OFF or DIMMING for the light funcon.
(Light will maintain last seng if turned off)
Controlling the Fan
1. Fan OFF
2. Fan ON & Speed 1-6
3. Forward / Reverse
Use Forward mode (counterclockwise) for cooling
Use Reverse mode (clockwise) to circulate warm air
4. Timer 2, 4 & 8hrs
5. Light ON/OFF
To DIM, press and HOLD light buon
to cycle from bright to dark.
(LIGHT SWITCH at DIMMING posion)
6. Breeze/Cycle through speeds randomly
One remote control can control up to 8 fans (within a 7m (23”) radius).On ALL receivers verify
that the “Learn” switch is in the “O” posion. Switch on the mains power to acvate ALL
receivers at the same me, indicated by one ‘beep’. Within 60 seconds, press and hold the
LEARN buon on the remote control (min. 3 seconds) unl fan receiver issues three ‘beeps’.
Pairing mulple fans per remote control.
2
4
5
4 6
4
3
1
O LIGHT DIMMING
‘LEARN’ BUTTONLIGHT SWITCH
| LIGHT ON/OFF
7

8
STEP 7 Attaching the Fan Motor Housing
Align the 3 tabs with the 3 holes on the
Housing and move upwards. Push tabs
inwards slightly before sliding upwards
STEP 8 Assembling the Fan Blades
A B
Place the Hub Upper onto a clean working area.
with the 2 holes in the Hub Upper.
screws for each Blade.
be used.
CLICK!
!
avoid damaging the fan/surface

C
Lock Screw
9
Attaching the Fan Blades
44
STEP Assembling the Fan Blades cont.
C D
Fasten the the Hub Lower from the top side
using the 3 Hub Screws.
Lower) into the recess. With care, turn the fan
over.
No liability is accepted if the Silicone ring is
removed or the Pivot Lock is installed
!
the clearance ‘X’ between
the ceiling and motor
housing is equal all way
round.
Align
Connector and slide fan
blades onto Drive Sha.
D
Hold/push up Fan Blades
and insert Pivot Lock,
sideways. Push Pivot Lock
Tighten Lock Screw
securely using screw driver.
Do not use power tools.
x
A
Pivot Connector
Silicone Ring
B
Pivot Lock
Silicone Ring
Light Hub Lower
(OPTIONAL)
STEP 9
8

10
44
OPTION A LED Light Kit
OPTION B Ceiling Extension Kit
Line up the 2 pins on the LED light with the 2 Holes in the
Safety clip is engaged.
Re-check the correct assembly by gently pulling on the
LED LIGHT
”A“
150mm (6”)
“B”
26.6mm ROD
Suitable for Raked Ceiling up to 17
“B” Extension Rod Length
115mm Rod (4 17/32”)
600mm Rod (23 5/8”)
900mm Rod (35 7/16”)
Accessories Required
Included
Not Included
Not Included
“A” Ceiling to Fan blade
420mm (16 17/32”)
910mm (35 53/64”)
1210mm (47 41/64”)

11
OPTION C Raked Ceiling Kit
CEILING JOIST
“B”
“C”
“a”
“B” Extension Rod Length
115mm Rod (4 17/32”)
600mm Rod (23 5/8”)
900mm Rod (35 7/16”)
Accessories Required
Included
Not Included
Not Included
“C” Clearance
200mm min.
200mm min.
Decoraon ring
not fied
“a” Angle
15° - 17°
17° - 33°
33° - 40°

12
Technical Specifications
180mm (7”) 275mm (10 53/64”)
43” 1070mm / 50” 1260mm / 60” 1524mm
172mm (6 49/64”)
Dimensions for Model:
FR3-43” & FQ3-43”
FR3-50” & FQ3-50”
FR3-60”
Fan Weight:
FR3-43” = 4.7kg (10.4lbs)
FR3-50” = 5.1kg (11.2lbs)
FR3-60” = 5.3kg (11.7lbs)
FQ3-43” = 4.7kg (10.4lbs)
FQ3-50” = 4.9kg (10.8lbs)
Colour Opons:
White/Silver/Black
Dark/Light wood-grain
Remote Control:
Hand held, RF
Standby power 0.49W
Opons:
Wall switch control
Automaon control
Wifi control module
MODEL
FR3-43
FR3-50
FR3-60
FQ3-43
FQ3-50
SPEED 1
60rpm/5.7W
60rpm/5.9W
55rpm/5.9W
60rpm/5.6W
60rpm/5.9W
AIRFLOW/CFM
1149
1682
2411
1111
1483
AIRFLOW/CFM
3400
5010
5935
3290
4521
SPEED 6
180rpm/13.3W
180rpm/23.5W
150rpm/19.2W
180rpm/13.8W
180rpm/19.2W
CFM/WATT
235
227
333
218
236
Operang Voltage = 240V / 50Hz/ Operang speed = rpm (revoluons per minute) / Power usage = W (Wa)
MODEL
FR3-43
FR3-50
FR3-60
FQ3-43
FQ3-50
SPEED 1
61rpm/2.67W
60rpm/2.85W
56rpm/2.83W
61rpm/2.52W
60rpm/2.63W
AIRFLOW/CFM
1149
1682
2411
1111
1483
AIRFLOW/CFM
3400
5010
5935
3290
4521
SPEED 6
181rpm/11.47W
180rpm/21.77W
152rpm/18.61W
181rpm/11.32W
180rpm/17.10W
CFM/WATT
272
245
340
266
265
Operang Voltage = 120V / 60Hz/ Operang speed = rpm (revoluons per minute) / Power usage = W (Wa)

13
Care and Cleaning
Troubleshooting
Regular cleaning of the Aeratron Ceiling fan blades and fan motor housing is the only maintenance needed.
Due to the self-balancing design, a large build up of dust on blades may create an imbalance in extreme cases
only, causing the blades to wobble during use. This is likely to be more apparent on fans with an extension rod.
Regular cleaning of the blade is recommended to prevent dust from building up.
1. When cleaning your fan, only use a so brush or lint free cloth to avoid scratching the finish. DO NOT
use water when cleaning your ceiling fan. It could damage the motor or blades and/or create the
possibility of electric shock.
2. When dusng the blades, they must be supported to prevent bending - no pressure should be applied
to the blade pivot. Aer cleaning the blades, check to ensure that the Drive Sha is vercal, otherwise
the fan may wobble.
3. Occasionally, it may be necessary to re-ghten the fan blades/screws to prevent any clicking or
humming sounds during operaon. This is especially true in climates with broad temperature and
humidity ranges.
4. If you experience any flaw in the operaon of your fan, please check the points in the Trouble Shoong
secon below.
If the fan does not operate properly, or turns on or off at random.
It is normal that the fan is rotang backwards/forwards ll finds the direcon of rotaon.
Make sure that the blades are aached when tesng the fan, the motor is NOT rotang without the
blades aached
2. If applicable, change the baeries in the Remote Control (Handset).
3. Re-pair the remote using steps 3&4 (page 7)
4. Mulple fans: disconnect power to all fans, wait for a minimum of 10 seconds before switching
power back on to all the fans (see page 7)
5. Disconnect and reconnect the 3-pin connector (receiver to motor) to make sure that the
connectors are fully engaged (see page 6)
6. Check the main and branch circuit breakers and/or fuses.
7. Check the wire connecons to the fan.
8. Other RF devices may obstruct the handset to receiver signal.
If the fan is noisy
9. Check to make sure that Suspension Ball is located in the slot correctly, and the one screw
securing the suspension ball is ght (see page 5).
10. Check that Hanger Bracket is solidly mounted, no movement allowed (see page 4)
11. Check that the 2 Hub screws per fan blade are ght and firm (see page 8)
12. Excess wind can li the fan blades and result in some noise.
If the fan rotates but does not create much airflow
13. The room may contain items which obstruct the air-flow.
14. The fan may be too small for the size of the room.
15. The fan might be in reverse funcon (counter clockwise rotaon)
Except for items 1 to 3 below, the following require access to
areas of the fan which carry lethal voltage and must be carried
out by properly qualified personnel. ONLY points 1 to 3 below can
be carried out by the user.
!
Note: In some areas, signals are sent through the power lines by the electricity supplier for the control of
off peak hot water, street lights and so on. These signals may cause an intermient humming in the ceiling
fan. Filters may be available in your country at customer costs. It is not a ceiling fan fault.
1.

14
General Information
Warranty
1. All electrical motors, including fan motors generate some noise, and may feel hot to the touch. This is
NOT a fault.
2. Ceiling fans tend to move during operaon due to the fact that they are not rigidly mounted. (Rigid
mounngs can generate excessive vibraon and stress on the mounngs).
Movement of a couple of cenmetres is quite OK and does not suggest that the fan will fall down. The
Aeratron fan is mounted securely on a metal Hanger Bracket with rubber cushioning and a ball joint to
allow free movement. Please note that due to manufacturing variaons not all Aeratron ceiling fans
are exactly the same - some may move more than others. Note: Excessive wobble can be caused by the
Drive Sha not being posioned vercally. This can be easily recfied by adjusng the posion of the
Fan Motor Assembly in the Hanger Bracket (see step 9 (D) page 9).
3. Ceiling fans are an environmentally smart choice to help cool you in your home. They work by creang
air flow which causes a cooling sensaon on the skin. Ceiling fans do not cool down air, so for energy
wise use, they should be switched off when leaving a room. The effecveness of ceiling fans is also
dependent on the humidity in the air - they are more effecve in humid environments, and less so in
dry ones.
4. During winter, a reverse (counter clockwise) turning fan helps to reduce heang costs. Warm air rises
to the ceiling, where it cannot be felt by the occupants of a room, especially in areas with high ceilings.
The fan assists to distribute warm air more evenly in the room allowing to set the thermostat several
degrees lower.
Normal Wear and Tear.
Threaded components working slightly loose or parts even slightly damaged or bent during vigorous cleaning
or bumping can cause wobble and noise. This is not covered under warranty, but care during maintenance and
cleaning should prevent this from occurring.
You must have the original purchase receipt or bill of sale to make a warranty claim. No claim will be
accepted unless proof of date of purchase is available at the me of making the warranty claim.
Ceiling Fan Warranty Period.
The ceiling fan itself, excluding the Remote Control Transmier and Receiver, is covered by a 3 year in-home
warranty unless stated otherwise in your jurisdicon (USA –30 year warranty on the motor). For any warranty
claims, please contact your local or regional retailer or distributor. Aeratron Pty Ltd will, at its discreon, only
repair or replace defecve products which have been directly purchased from Aeratron Pty Ltd, all other
product claims must be lodged through your local retailer/distributor. Labour and product delivery costs are
borne by Aeratron Pty Ltd or the retailer during this 3 year period. The cost of obtaining or using special access
equipment (scissor lis, scaffolding etc.) is specifically excluded, and it is the responsibility of the owner to
provide such equipment and have it safely installed and operated.
Remote Control Warranty Period.
In general, Aeratron Pty Ltd Remote Control Receivers and Transmiers (Handsets) are covered by
a 1 year in-home warranty (unless stated otherwise in your jurisdicon) under the same condions as
described above for fans.
Balance of Warranty on Repaired or Replaced Products.
Any replaced or repaired product is covered only by the balance of the warranty remaining on the original
arcle.

Transfer of Warranty.
If the dwelling where the fan is installed changes hands, the balance of the warranty passes to the new owner,
providing the original bill of sale for the product is retained by the new owner.
Warranty does not cover damage to the fan if it is moved from one dwelling to another during the warranty
period. The warranty is voided in total if the product is sold as second hand goods.
The following is NOT covered by warranty.
1. Any damage incurred aer delivery to the owner that is not caused by a fault in the products materials
or workmanship; damage from lightning or power surges; incorrect installaon; damage due to
incorrect installaon; noise or other influence of ripple control or informaon access systems operated
over power delivery infrastructure; water damage of any kind; installaon or use outdoors; damage
arising from connecon to or use with alternave power systems (e.g. inverters, solar, etc.).
2. Ceiling fans not installed by a licensed electrician.
3. Repair of a ceiling fan used incorrectly, accidentally damaged, modified in any way or not serviced in
accordance with the maintenance instrucons.
4. Travelling costs incurred by Aeratron Pty Ltd personnel or service agents and/or the cost of
transporng and insuring the ceiling fan between the nearest Aeratron Pty Ltd agents' service depot
and its normal locaon. These costs must be met by the purchaser.
5. Subject to any statutory provisions to the contrary, claims for damage to furniture, carpet, walls,
ceilings, foundaons or any other consequenal loss either directly or indirectly resulng from a faulty
ceiling fan.
6. Signals sent through the mains power supply by the electricity supplier for off peak hot water, and
other signals including those for street lights and such. These signals may cause an intermient
humming in the ceiling fan. It is not the fault of the ceiling fan.
7. A service call fee will be charged where; there is nothing wrong with the ceiling fan or; the defecve
operaon of the ceiling fan is due to failure of electricity or; the installaon is not in accordance with
Aeratron Pty Ltd instrucons and/or applicable local regulaons or; the defects have been caused by
incorrect applicaon or abuse of the ceiling fan or; the damage has been caused by unauthorised
persons aempng to repair the fan.
8. When humidity is high and temperature drops moisture condenses on metal surfaces including
ceiling fans. The layer of moisture can be almost microscopic but it will affect the surface by
deposing a ny layer of dissolved salts or airborne acidic compounds and thus eventually leading to
corrosion if the product is not properly and regularly cleaned.
9. Travelling costs incurred by Aeratron personnel or service agents exceeding 50kms between the
nearest agents’ service depot and the customer. These costs must be met by the purchaser.
Making a Claim
You must have the original purchase receipt or bill of sale along with a proof of installaon by a Licensed
Electrician to make a warranty claim. No claim will be accepted without these documents being provided.
Please contact the local agent via the warranty Hotline, web or email.
Please note carefully - If the product is found to be free of defects or the product is not funconing
properly as a result of faulty installaon or lack of maintenance then Aeratron or its service agent reserve the
right to charge a service fee to recfy the reported problem.
15
Warranty Cont.
For any problems found during fan installaon please contact
the naonal distributor/retailer and ask for assistance before
leaving the site.
IMPORTANT

16
WARRANTY PHONE NUMBERS
AUSTRALIA 1300 116 305 (9am to 5pm EAST)
USA – please call [phone]
Please Note: When calling for warranty you will require the following informaon; date of purchase;
model and colour of the fan. The installing electrician’s details may also be required.
16
Warranty Details
Aeratron ceiling fan warranty details
Please File with your Purchase Receipt
Customer Details
Name: ______________________________________________
Address: ____________________________________________
Post Code: ___________________________________________
Phone Number: _______________________________________
Fan Details
Model: ______________________________________________
Colour: ______________________________________________
Date of Purchase: ______________________________________
Electricians Details
Name of Electrician: ____________________________________
Licence Number: _______________________________________
Please scan and send per email to your local or naonal retailer or distributor
For any problems found during fan installaon
please contact the naonal distributor/retailer
and ask for assistance before leaving the site.
IMPORTANT

Thank you. Your Aeratron team.
Internaonal Edion 2022/03
INSPIRED BY THE EXPERTS
If this shape looks familiar - that’s because it is. Your Aeratron fan was painstakingly
developed to mimic nature’s true masters of controlling air. It’s a proven design
that we are confident will work effeciently in your home for years to come.
The FRigatebird has opmised wings with the largest wingspan in relaon to it’s
body of any bird species in the world, so the frigatebird is naturally an adept pilot.
Frigate birds have been known to stay in the air for nearly a whole week.
