Aereco VBP+ Instruction Manual

1/36
TF5602_E Aereco S.A.
Installation and maintenance
Download this document on www.aereco.com
MS Management System
VBP+
ENGLISH

2/36
Aereco S.A.
CONTENTS
INTRODUCTION........................................................................................................................................................................ 3
SYSTEM OVERVIEW ................................................................................................................................................................ 4
GENERAL INFORMATION............................................................................................................................................................ 4
Functions of MS management system .............................................................................................................................. 4
Specific components ......................................................................................................................................................... 5
SPECIFIC FUNCTIONS OF EACH SYSTEM COMPONENT .................................................................................................................. 6
Main module (MAIN) ref. VB21119.................................................................................................................................... 6
Fan module (FAN) ref. VB21118 ....................................................................................................................................... 6
Digital temperature sensor ref. AVE1146XX ..................................................................................................................... 6
Operation of the management system with wind gauge.................................................................................................... 7
Operation of the management system with clock .............................................................................................................. 7
TECHNICAL CHARACTERISTICS OF THE COMPONENTS.................................................................................................................. 8
DIMENSIONS ............................................................................................................................................................................ 9
INSTALLATION & ELECTRICAL CONNECTIONS ................................................................................................................ 10
GENERAL ELECTRICAL CONNECTIONS ...................................................................................................................................... 10
SENSOR(S)ELECTRICAL CONNECTIONS.................................................................................................................................... 12
Temperature sensor connection only .............................................................................................................................. 13
Wind gauge connection only ........................................................................................................................................... 14
Clock connection only...................................................................................................................................................... 15
Temperature sensor + wind gauge connection ............................................................................................................... 16
Temperature sensor + clock connection.......................................................................................................................... 17
FAN(S)CONNECTION .............................................................................................................................................................. 18
START-UP ............................................................................................................................................................................... 20
SETTING ................................................................................................................................................................................ 20
General operation............................................................................................................................................................ 22
Reset ............................................................................................................................................................................... 22
Initialisation...................................................................................................................................................................... 24
Configuration procedure .................................................................................................................................................. 25
RUNNING SYSTEM................................................................................................................................................................. 28
DEFECTS AND FAILURES..................................................................................................................................................... 30
Default ‘Temperature’ ...................................................................................................................................................... 30
Default ‘Fan’ .................................................................................................................................................................... 31
Permanent "MAXIMUM LEVEL" mode............................................................................................................................ 32
TECHNICAL MAINTENANCE ................................................................................................................................................. 33
WARRANTY ............................................................................................................................................................................ 34
ENVIRONMENTAL CONCERNS ............................................................................................................................................ 34
VBP + is marketed in France by ACTHYS company under the brand “HELYS 800”.

3/36
Aereco S.A.
INTRODUCTION
Warnings
PLEASE READ THE INSTRUCTION IN THIS MANUAL CAREFULLY BEFORE THE INSTALLATION.
The manufacturer can’t be responsible for damages caused by an installation that is not carried out
according to good engineering practices and does not comply with the installation instructions.
This manual describes how the management modules must be installed and used.
The installation of the complete system must be performed by a qualified technician and in compliance
with the local standards.
Do not use these modules for any applications for which it is not intended.
After unpacking, make sure that they are not damaged. Any functional default must be reported to your
reseller.
Security
The use of electrical appliance implies the following fundamental rules:
Do not touch the appliance with wet or damp body (hands, feet ...), even if it is connected to the ground.
This appliance is not intended for use by persons (including children) with reduced physical, sensory or
mental capabilities, or lack of experience and knowledge, unless they have been given supervision or
instruction concerning use of the appliance by a person responsible for their safety. To avoid any risk, do
not allow them to play with the appliance.
The electrical installation and electrical connections must be carried out by a qualified technician according
to the manufacturer's instructions and in compliance with the characteristics listed on the nameplate of the
unit.
Before carrying out any operation on the appliance, unplug or disconnect it from the power supply, and
ensure it can’t be accidentally restored.
Power cable modification or replacement must only be carried out by qualified personnel or by After-sales
Service in order to avoid any accident.
Children being supervised not to play with appliance.

4/36
Aereco S.A.
SYSTEM OVERVIEW
General information
The MS management system offers advanced fan control features. MS management system requires a specific
configuration of the fan electronic driving box. This configuration can be modified to standard mode (without speed
control = ST mode) by simply moving a jumper on the electronic driving box (please refer to the technical file of the
fan for more information).
MS management system is composed of:
1 circuit-breaker 230 VAC - 2A
1 supply 230 VAC - 5 V DC
1 relay for alarm switching
1 Main module to manage from 1 up to 25 fans
1 Fan module per fan
1 or 2 digital temperature sensors (+ possibility of wind gauge or clock)
These components can be placed in an IP65 electric box (if outside) not included, and clipped on DIN rail. They
are interconnected through RJ11 wires (supplied) of about 25 cm
1
. The connection of Fan modules to the fans is
realised by the mean of four wires standard cable.
Functions of MS management system
Manages the simultaneous operation of inter-connected fans.
Manages powers and operating speeds.
Manages the hybrid operation according to the information received from the connected sensors
(temperature and / or [clock or wind]).
Reports locally defaults.
Returns default information on distant indicator that can be used in particular in the context of BMS.
1
This length allows to comply with the CEM and to limit the lost tension. It allows also to connect 2 modules located
on two appended DIN rail.

5/36
Aereco S.A.
9 speeds are available by default in MS version, corresponding to the curves shown above, and numbered from a
to i.
Specific components
MS management system has 3 specific components, available exclusively at Aereco or its resellers. Other system
components (circuit breaker, power, etc...) can be bought on the market as long as they respect the technical
features mentioned in this document.
1 : Main module (« MAIN ») code VB21119
2 : Fan module (« FAN ») code VB21118
3 : Digital temperature sensor code AVE1146XX
1
2
3

6/36
Aereco S.A.
Specific functions of each system component
Main module (MAIN) ref. VB21119
Allows to define groups with specific numbers of fans (1 to 5 fans per group, 1 to 5 groups per Main
module).
Interprets the 'probe' input and communicates the speed range for each Fan module.
Stops the fans of the same group in case of failure of one fan.
Can communicate the overall working of the system (correct operation or failure) with an output for working
indicator.
Can communicate the detailed operation of the system (current range of temperature for example).
Fan module (FAN) ref. VB21118
Identifies the fan to assign to a group
Determines its base speed according to the characteristics of the building (table provided)
Sends the signal (PWM ) for the fan speed control
Gets information of the fan operation (Motor speed rotation)
Communicates the fan operation (correct operation or failure) to the Main module
Digital temperature sensor ref. AVE1146XX
The digital temperature probe communicates the outside temperature to the Main module. This information is
exploited to manage the operation modes of the fans. The Main module supports several levels of operation
according to the information received from the temperature probe, so as to adapt the speed of the fans.
Available speeds are shown on page 5.
Example of a setting adjusting the fan speed according to temperature:
Instead or in addition of the temperature sensor, it is possible to connect the following inputs, available on the
market, respecting the technical features mentioned in this document.

7/36
Aereco S.A.
Operation of the management system with wind gauge
A specific wind gauge / anemometer may also be used to supplement or replace the temperature sensor. A
switching wind speed “Vb” can be defined:
If [wind speed < Vb] then operation according to the temperature (if sensor) or maximal speed setting (if
no temperature sensor).
If [wind speed ≥ Vb] then minimum speed (= “natural ventilation” mode).
Operation of the management system with clock
A clock can also be used to supplement or replace the temperature sensor. One or several time period for boost
airflow can then be defined and addressed:
During the “boost airflow” period: Maximum speed of the setting.
Out of “boost airflow” periods: Operation according to the temperature (if sensor) or minimum speed (=
“natural ventilation” mode).

8/36
Aereco S.A.
Technical characteristics of the components
MS management system requires the use of the following components:
Component
Characteristics
Supplier / reference
Quantities
Differential circuit
breaker
C2 type
230 VAC –2A
Rail DIN
Not specified
1 per Main
module
230 VAC –5 VDC
Supply
Recommended supply models :
1 per Main
module
A) if from 1 to12 Fan modules:
Linear supply
230 VAC –5 VDC ; 2,5 W
Rail DIN
A) Comatec brand
ref. TBD2/AR.0050.05/F
B ) if from 13 to 25 Fan modules:
Linear switching power supply
230 VAC –5 VDC ; 15 W
Rail DIN
Remark : can also be used from one
module, but then will not be optimised for
sizing and cost.
B ) Siemens brand
ref. 6EP1311-1SH03
5V/3A 2
Relay for side
alarm
Plug relay switching 5 VDC relay, simple
contact 10 A+ Rail DIN
Connection to the electric circuit : 250
V~max and 10A max.
FINDER –ref :
40.519.005.0300 +
FINDER –ref : 95.05
1 per Main
module
Main module
Power supply in 5VDC
3 wires input for probe
Output « alarm relay » 2 wires: 0-5V (max.
current 200 mA), type « open collector
5VDC ».
Connection through RJ11 wire (supplied) to
Fan modules.
Rail DIN
Aereco –ref. VB21119
1 for up to 25
fans
Fan module
Output 4 wires to send the PWM command
to the fan then to get its speed information.
Connection through RJ11 wire (supplied) to
other Fan modules and to the Main module.
Rail DIN
Aereco –ref. VB21118
1 per fan
2

9/36
Aereco S.A.
Component
Characteristics
Supplier / reference
Quantities
Temperature
probe
Temperature range = - 55°C to +125°C
Signal type = « 1 wire » (specific)
Aereco –ref.
AVE1146XX
1 per Main
module
Wind gauge
230 VAC supply
Temperature range = -25°C to +50°C
Wind switch level setting = 5 to 55 km/h,
through potentiometer
Reaction time after over passing the switch
level = 3 to 5 seconds
Contact = NO type
HAGER –ref : TG050
1 per Main
module
Relay for Wind
gauge
Modular switch relay, 230 VAC, SPNO type
Rail DIN
FINDER -
ref : 22.21.8.230.4000
1 per wind
gauge
Clock
230 VAC supply
Temperature range = -5°C to 50 °C
Daily program with minimum step of 30
minutes
Contact = NC type
Rail DIN
FINDER –
ref : 12.01.8.230.0000
1 per Main
module
These components must be put inside a modular electric box with DIN rail, IP 65 (if outdoor installation), not
supplied.
Dimensions
Main and Fan modules.
The size of a module corresponds to two standard units.
Dimensions in mm:

10/36
Aereco S.A.
INSTALLATION & ELECTRICAL CONNECTIONS
The installation and electrical connections must be carried out by a professional in
compliance with applicable regulations in force in the country of installation.
General electrical connections
The following components are designed to be installed in a modular electric box unit DIN rail.
The electric box must be minimum IP65 if it is located outside.
RJ11 cables are supplied with the Fan module (FAN) and must connect only one 'R' output to one 'L' input.
Reminder: a Main module (MAIN) can manage from 1 to 5 groups of 1 to 5 fans. A maximum of 25 Fan modules
can therefore be connected to the Main module, the last 'R' output remaining without any connection
Terminal 11-14 : Output “NO”(normally open before setting off)
Terminal 11-12 : Output “NC”(normally closed before setting off)
The scheme next page is showing an overview of the system connections, as recommended by Aereco. Other
installation are possible; please check the compliance with your local regulation.
FINDER
40.519.005.0300

11/36
Aereco S.A.

12/36
Aereco S.A.
Sensor(s) electrical connections
There are 5 possible configurations requiring a specific wiring:
Temperature sensor only
Wind gauge only
Clock only
Temperature sensor + wind gauge
Temperature sensor + clock
The temperature sensor has a standard length of 300 mm. It is possible to shift it by addition of a cable according
to the following characteristics:
The cable is a 3 wire cable, in compliance with applicable regulations in force:
1,5 mm² minimum cross sectional area for each wire,
10 m maximum length,
Ambient condition resistant (including UV resistance)
The cable must not include driver colour "yellow / green", colour used for ground only.
The power in the cables does not exceed 20 mA.

13/36
Aereco S.A.
Temperature sensor connection only

14/36
Aereco S.A.
Wind gauge connection only

15/36
Aereco S.A.
Clock connection only

16/36
Aereco S.A.
Temperature sensor + wind gauge connection

17/36
Aereco S.A.
Temperature sensor + clock connection

18/36
Aereco S.A.
Fan(s) connection
This operation describes how to connect a fan to its modules; it has to be done for each fan connected to the
control unit.
The cable is a 4 wire cable between Ø6 and Ø12 mm diameter in compliance with applicable regulations
in force: 1,5 mm² minimum cross sectional area for each wire, 25 m maximum length between the fan and
its fan module, ambient condition resistant (including UV resistance).
The power in the cables does not exceed 20 mA.
The cable must not include driver colour "yellow /
green", colour used for ground only.
1) Identify and match each fan with its Fan
module
Each fan must have a number for easy installation and
maintenance:
Note a number on the label of the fan and copy it
on the label of the corresponding module (insert "
N. ").
Identify both cable endings using the same
number.

19/36
Aereco S.A.
2) Connect each fan (electronic driving box of the fan - see installation instructions of the fan) to its
module respecting the terminals (observe the colour code):
Fan module terminal '1 ' on terminal '1' of the fan
Fan module terminal '2 ' on terminal '2' of the fan
Fan module terminal '3 ' on terminal '3' of the fan
Fan module terminal '4 ' on terminal '4' of the fan
3) Check that the jumper pin located at the top right of the electronic
driving box of the fan is on pins '1 '& '2' "MS mode".
Electronic driving
box of the fan

20/36
Aereco S.A.
START-UP
Before starting, check the mounting of the fans on their chimney and the non-obstruction of the
duct (any object inside would cause a stress on the turbine)
Do not insert anything through them
Never turn on the fans if the electronic driving box is open
All the following operations must only be carried out once the electrical box is completely finished
(all the electrical connections must be completed)
Setting
Before starting, it is necessary to identify each fan group and to set each fan (that is to say, define its
operating speeds).
As a reminder, usually a fan group corresponds to a stack of dwellings.
1) Identify each fan that you want to group together and note the
group number in the insert "Gr" on each corresponding Fan module.
Important: a maximum of 5 groups are possible having each a
maximum of 5 fans.
