Aero AT-3 R100 User manual

AVIATION TRAINING
Pilot’s Operating Handbook
Aero AT3 R100
HA-VOA

„ „AERO” Sp. z o. o.
03-942 WARSAW, POLAND
UL. WAŁ MIEDZESZYŃSKI 844
WARSAW SEPTEMBER, 2004
AEROPLANE FLIGHT MANUAL
for the AT-3R100
VERY LIGHT AEROPLANE
Aeroplane registration (Call sign): .......................................
Aeroplane Serial No.: .......................................
Registered under No: .......................................
Approved:
CIVIL AVIATION OFFICE
President of the CAO
( Originally signed for President of the CAO by Mr. Z. Mazan)
Date: 2004-09-23
This aeroplane must be operated in accordance with information
and limitations contained in this Manual.
This Manual must be carried in the aeroplane at all times
Doc. No. ATL3.04

„AERO” Sp. z o.o.
AT-3 R100 GENERAL INFORMATION
Page 0-2 SEPTEMBER, 2004
AEROPLANE FLIGHT MANUAL
Editor:
“AERO” Sp. z o.o.
O3-942 WARSAW, POLAND
UL. WAŁ MIEDZESZYŃSKI 844
Approval of translation has been done to the best knowledge and judgment.
In any case, the original Polish language version is authoritive.
English language version of the Polish Document No. ATL3.03 AFM,
translated under delegation of authority CAIB No. 54C.
Jan A.Jasiński, B.S.(Eng.)

„AERO” Sp. z o.o.
GENERAL INFORMATION AT-3 R100
SEPTEMBER, 2004 Page 0-3
AEROPLANE FLIGHT MANUAL
CONTENTS
SECTION
GENERAL 1
LIMITATIONS 2
EMERGENCY PROCEDURES 3
NORMAL PROCEDURES 4
PERFORMANCE 5
WEIGHT AND BALANCE 6
DESCRIPTION OF THE AEROPLANE AND ITS EQUIPMENT 7
SERVICING 8
SUPPLEMENTS 9

„AERO” Sp. z o.o.
AT-3 R100 GENERAL INFORMATION
Page 0-4 AUGUST, 2008
AEROPLANE FLIGHT MANUAL
RECORDING OF REVISIONS
All revisions to this manual, with the exception of actual changes of
weighing data must be recorded in the table below.
The new or corrected text in the corrected pages, is to be marked at the
margin with a vertical line and the number of the revision and the date of
the revision is to be printed at the bottom of the page. For each revision,
the pages specified in the Log of Revisions must be replaced.
6

„AERO” Sp. z o.o.
GENERAL INFORMATION AT-3 R100
JUNE, 2011 Page 0-5
AEROPLANE FLIGHT MANUAL
List of Effective Pages
Section Page Date of issue
0 0-1 SEPTEMBER, 2004
0 0-2 SEPTEMBER, 2004
0 0-3 SEPTEMBER, 2004
0 0-4 AUGUST, 2008
0 0-5 JUNE, 2011
0 0-6 MARCH, 2011
0 0-7 JUNE, 2011
0 0-8 JULY, 2010
0 0-9 JUNE, 2011
0 0-10 JUNE, 2011
1 1-1 SEPTEMBER, 2004
1 1-2 SEPTEMBER, 2004
1 1-3 AUGUST, 2008
1 1-4 SEPTEMBER, 2004
1 1-5 SEPTEMBER, 2004
1 1-6 SEPTEMBER, 2004
1 1-7 SEPTEMBER, 2004
1 1-8 SEPTEMBER, 2004
1 1-9 SEPTEMBER, 2004
1 1-10 SEPTEMBER, 2004
1 1-11 SEPTEMBER, 2004
1 1-12 SEPTEMBER, 2004
1 1-11 SEPTEMBER, 2004
1 1-12 SEPTEMBER, 2004
2 Appvd. 2-1 SEPTEMBER, 2004
2 Appvd. 2-2 SEPTEMBER, 2004
2 Appvd. 2-3 SEPTEMBER, 2004
2 Appvd. 2-4 SEPTEMBER, 2004
2 Appvd. 2-5 AUGUST, 2008
2 Appvd. 2-6 AUGUST, 2008
2 Appvd. 2-7 SEPTEMBER, 2004
2 Appvd. 2-8 JULY, 2010
2 Appvd. 2-9 SEPTEMBER, 2004
2 Appvd. 2-10 SEPTEMBER, 2004
2 Appvd. 2-11 MARCH, 2011

„AERO” Sp. z o.o.
AT-3 R100 GENERAL INFORMATION
Page 0-6 MARCH, 2011
AEROPLANE FLIGHT MANUAL
List of Effective Pages (continued)
Section Page Date of issue
2 Appvd. 2-12 MARCH, 2011
2 Appvd. 2-13 AUGUST, 2008
2 Appvd. 2-14 MARCH, 2011
3 Appvd. 3-1 SEPTEMBER, 2004
3 Appvd. 3-2 OCTOBER, 2009
3 Appvd. 3-3 SEPTEMBER, 2004
3 Appvd. 3-4 SEPTEMBER, 2004
3 Appvd. 3-5 SEPTEMBER, 2004
3 Appvd. 3-6 SEPTEMBER, 2004
3 Appvd. 3-7 SEPTEMBER, 2004
3 Appvd. 3-8 SEPTEMBER, 2004
4 Appvd. 4-1 SEPTEMBER, 2004
4 Appvd. 4-2 SEPTEMBER, 2004
4 Appvd. 4-3 SEPTEMBER, 2004
4 Appvd. 4-4 SEPTEMBER, 2004
4 Appvd. 4-5 JULY, 2010
4 Appvd. 4-6 JULY, 2010
4 Appvd. 4-7 JULY, 2010
4 Appvd. 4-8 JULY, 2010
4 Appvd. 4-9 JULY, 2010
4 Appvd. 4-10 JULY, 2010
4 Appvd. 4-11 OCTOBER, 2009
4 Appvd. 4-12 JULY, 2010
4 Appvd. 4-13 OCTOBER, 2009
4 Appvd. 4-14 OCTOBER, 2009
4 Appvd. 4-15 JULY, 2010
4 Appvd. 4-16 SEPTEMBER, 2004
4 Appvd 4-17 SEPTEMBER, 2004
4 Appvd 4 18 SEPTEMBER, 2004
5 Appvd 5-1 MARCH, 2011
5 Appvd 5-2 SEPTEMBER, 2004
5 Appvd 5-3 SEPTEMBER, 2004
5 Appvd 5-4 SEPTEMBER, 2004
5 Appvd 5-5 SEPTEMBER, 2004
5 Appvd 5-6 SEPTEMBER, 2004

„AERO” Sp. z o.o.
GENERAL INFORMATION AT-3 R100
JUNE, 2011 Page 0-7
AEROPLANE FLIGHT MANUAL
List of Effective Pages (continued)
Section Page Date of issue
5 Appvd 5-7 SEPTEMBER, 2004
5 Appvd 5-8 SEPTEMBER, 2004
5 Appvd 5-9 SEPTEMBER, 2004
5 Appvd 5-10 SEPTEMBER, 2004
5 5-11 MARCH, 2011
5 5-12 MARCH, 2011
5 5-13 MARCH, 2011
5 5-14 SEPTEMBER, 2004
5 5-15 SEPTEMBER, 2004
5 5-16 SEPTEMBER, 2004
6 6-1 SEPTEMBER, 2004
6 6-2 SEPTEMBER, 2004
6 6-3 JULY, 2010
6 6-4 SEPTEMBER, 2004
6 6-5 SEPTEMBER, 2004
6 6-6 JULY, 2010
6 6-7 JULY, 2010
6 6-8 JULY, 2010
6 6-9 SEPTEMBER, 2004
6 6-10 MARCH, 2006
6 6-11 JULY, 2010
6 6-12 JUNE, 2011
7 7-1 JULY, 2010
7 7-2 SEPTEMBER, 2004
7 7-3 SEPTEMBER, 2004
7 7-4 SEPTEMBER, 2004
7 7-5 SEPTEMBER, 2004
7 7-6 SEPTEMBER, 2004
7 7-7 SEPTEMBER, 2004
7 7-8 SEPTEMBER, 2004
7 7-9 SEPTEMBER, 2004
7 7-10 SEPTEMBER, 2004
7 7-11 SEPTEMBER, 2004

„AERO” Sp. z o.o.
AT-3 R100 GENERAL INFORMATION
Page 0-8 JULY, 2010
AEROPLANE FLIGHT MANUAL
List of Effective Pages (continued)
Section Page Date of issue
7 7-12 SEPTEMBER, 2004
7 7-13 SEPTEMBER, 2004
7 7-14 SEPTEMBER, 2004
7 7-15 JULY, 2010
7 7-16 JULY, 2010
7 7-17 JULY, 2010
7 7-18 JULY, 2010
7 7-19 JULY, 2010
7 7-20 JULY, 2010
7 7-21 JULY, 2010
7 7-22 JULY, 2010
7 7-23 JULY, 2010
7 7-24 JULY, 2010
7 7-25 JULY, 2010
7 7-26 JULY, 2010
7 7-27 JULY, 2010
7 7-28 JULY, 2010
7 7-29 JULY, 2010
7 7-30 JULY, 2010
8 8-1 JULY, 2010
8 8-2 SEPTEMBER, 2004
8 8-3 SEPTEMBER, 2004
8 8-4 JULY, 2010
8 8-5 JULY, 2010
8 8-6 JULY, 2010
8 8-7 JULY, 2010
8 8-8 JULY, 2010
8 8-9 JULY, 2010
8 8-10 JULY, 2010
8 8-11 JULY, 2010
8 8-12 JULY, 2010
9 9-1 SEPTEMBER, 2004

„AERO” Sp. z o.o.
AT-3 R100 GENERAL INFORMATION
JUNE, 2011 Page 0-9
AEROPLANE FLIGHT MANUAL
List of Effective Pages (continued)
Section Page Date of issue
9 9-2 SEPTEMBER, 2004
9 9-3 AUGUST, 2008
9 9-4 JULY, 2009
9 9-5 OCTOBER, 2010
9 9-6 JUNE, 2011

„AERO” Sp. z o.o.
AT-3 R100 GENERAL INFORMATION
Page 0-10 JUNE, 2011
AEROPLANE FLIGHT MANUAL
LOG OF REVISIONS
No. of
Revision Description of Revision Revised Pages Date
1
Introduction of the Supplement
No. 21 0-5, 0-7 to 0-9,
6-11, 9-4 30.06.2005
2
Introduction of the Supplements
No. 22 to 25 0-5, 0-7 to 0-9,
6-11, 9-4 15.07.2005
3
Introduction of the Supplement
No. 26 0-5, 0-7 to 0-9,
6-11, 9-4 10.01.2006
4
Introduction of the Supplement
No. 27, 0-5, 0-7 to 0-9, 6,10,
6-11, 9-4, 9.26-1,
9.26-3, 9.26-5 20.03.2006
5
Introduction of the Supplement
No. 28, 0-5, 0-7 to 0-9,
6-11, 9-4 19.03.2007
6
Introduction of the Supplement
No. 29, removed of the
Supplement No. 17, and text
modifications
0-4 to 0-9, 1-3, 2-5, 2-6,
2-13, 2-14, 4-6, 4-8 to
4-12, 4-15, 6-11, 6-12,
7-15 to 7-30, 9-3, 9-4
29.08.2008
7
Introduction of the Supplement No.
30, changed pages 9.26-3÷9 in
Supplement 26
0-5, 0-7 to 0-9,
6-12, 9-4 10.07.2009
8
Introduction of the Supplement No.
31, 32, 33 and text modifications
0-5 to 0-9, 3-2, 4-5 to
4-7, 4-9 do 4-11, 4-13,
4-14, 6-12, 9-5, 9-6 02.10.2009
9
Changes to parking brake system.
Tow bar. Extending area of
acceptable movement of center of
gravity. Changed pages 9.31-7,
9.31-8, 9.31-12 to 9.31-16 in
Supplement 31
0-5 to 0-10, 2-8, 4-5 to
4-10, 4-12, 4-15, 6-3,
6-6 to 6-8, 6-11, 7-1,
7-15 to 7-32, 8-1, 8-4 to
8-12
12.07.2010
Introduction of the Supplement No.
34 to 45 0-5, 0-7, 0-9, 0-10
6-12, 9-5, 9-6 15.10.2010
Changigng the amount of
consumable fuel.
Introduction of the Supplements
No. 46 to 50
Changed pages 9.21-9, 9.21-10
in Supplement No. 21
0-5 do 0-7, 0-9, 0-10,
2-11 2-12, 2-14, 5-1,
5-11 do 5-13, 6-12, 9-6 07.03.2011
Introduction of the Supplement
No. 51 0-5, 0-7, 0-9, 0-10
6-12, 9-6 20.06.2011

„AERO” Sp. z o.o. SECTION 1
AT-3 R100 GENERAL
SEPTEMBER, 2004 Page 1-1
AEROPLANE FLIGHT MANUAL
Section 1
GENERAL
Page
1.1 Introduction..................................................................................1-2
1.2 Basis of certification.....................................................................1-3
1.3 Warnings, cautions and remarks.................................................1-3
1.4 Descriptive data...........................................................................1-4
1.4.1 Airframe....................................................................................1-4
1.4.2 Engine......................................................................................1-5
1.4.3 Propeller...................................................................................1-5
1.5 View of the aeroplane (three projections)....................................1-6
1.6 List of definitions and abbreviations.............................................1-7

SECTION 1 „AERO” Sp. z o o.
GENERAL AT-3 R100
Page 1-2 SEPTEMBER, 2004
AEROPLANE FLIGHT MANUAL
1.1 Introduction
This Aeroplane Flight Manual is intended to provide pilots and instructors
with information for safe and effective operation of this aeroplane which
belongs to the Very Light Aeroplane category. This manual contains
informative material, which is to be supplied to the pilot according to the
requirements of JAR-VLA. Some supplementary information is also
introduced into the content by the aeroplane manufacturer. It is the pilot’s
responsibility to acquaint him/herself with the contents of this manual, as
well as with any revisions to it.
CAUTION
THIS AEROPLANE FLIGHT MANUAL IS NOT A FLIGHT TRAINING
MANUAL. SEPARATE FLIGHT TRAINING MANUALS EXIST FOR
THAT PURPOSE
Should this manual be lost, the General Inspectorate of Civil Aviation –
Civil Aircraft Inspection Board is to be notified immediately, and if outside
Poland, the local civil aviation authority. Anybody who finds this manual
is requested to deliver it promptly to the manufacturer: Aero Sp. Z o. o.
03-942 Warszawa, Wal Miedzeszyński 844, Poland, email :
[email protected], tel [phone] , fax [phone]
and if outside Poland, to the local civil aviation authority.

„AERO” Sp. z o. o. SECTION 1
AT-3 R100 NORMAL PROCEDURES
AUGUST, 2008 Page 1-3
AEROPLANE FLIGHT MANUAL
1.2 Basis of certification
This aircraft type has been approved by European Aviation Safety
Agency in accordance with JAR-VLA regulations, amended through to
amendment VLA/92/1 and holds a Type Certificate No. A.021.
1.3 Warnings, cautions and remarks
The definitions below concern the following expressions:
warning, caution, note.
WARNING means that if the warnings concerned are not followed, this
will lead to an immediate or significant reduction in flight safety
CAUTION means that if the precautions concerned are not followed this
will lead to an immediate or significant reduction in flight safety
NOTE indicates all special issues, which do not directly affect flight
safety, but are essential or unusual.
6

SECTION 1 „AERO” Sp. z o o.
GENERAL AT-3 R100
Page 1-4 SEPTEMBER, 2004
AEROPLANE FLIGHT MANUAL
1.4 Descriptive data
This AT-3 R100 Very Light Aeroplane is a two-seat, single engine, low
wing, all metal aeroplane, with a three-wheel fixed landing gear with a
nose wheel.
1.4.1. Airframe:
1. Dimensions:
- Span 7.550 m / 24’ 9¼”
- Length 6.150 m / 20’ 6”
- Height 2.230 m / 7’ 3¾”
- Dihedral 3 °
- Lifting area 9.30 m
2
/ 100.1 ft
2
- Mean aerodynamic chord 1.27 m / 4’ 2”
- Wing loading 62.6 kg/m
2
/ 12.8 lb/ft
2
- Wing profile NACA 4415
2. Control surface displacements:
- Slab tail (angles related to the fuselage base – red mark on the
fuselage)
Trailing edge down 10° ±1°
Trailing edge up 12° ±1°
- Trim & balancing tab (angles related to the fuselage
base – red mark at the fuselage)
When the slab tail trailing edge is down,
the tab is displaced downward, i.e. by maximum 26° ±3°
When the slab tail trailing edge is up,
the tab is displaced upwards, i.e. by maximum 44° ±3°

„AERO” Sp. z o.o. SECTION 1
AT-3 R100 GENERAL
SEPTEMBER, 2004 Page 1-5
AEROPLANE FLIGHT MANUAL
- Ailerons (angles related to the wing chord)
- Up 20° ±2°
- Down 15° ±2°
- Rudder (angles related to the chord of the fin)
- Each side 25° ±2°
- Wing flaps (angles related to the wing chord)
- Retracted 0° ±2°
- For takeoff 15° ±2°
- For landing 40°+5/-2°
3. Landing gear
- Wheel track 2.26 m / 7’ 5”
- Main wheel tyre- Type 380 x 150
- Pressure 2.5 bar / 36 psi
- Nose wheel tyre- Type 5.00-4
- Pressure 2.5 bar / 36 psi
- Disc brakes
- Type of shock absorber elastic strut
1.4.2. Engine
Four cylinder, horizontally opposed BOMBARDIER ROTAX, model
912S2 or 912S4 engine. The cylinders are air-cooled, the cylinder heads,
by liquid coolant. Dual ignition. 73.5 kW / 98.5 HP take-off power, 69 kW
/ 92.5 HP continuous power.
1.4.3. Propeller
Wooden, fixed pitch, two-blade GT-2/173/VRR-FW101SRTC propeller
with 1.73 m (5’ 8”) diameter and clockwise direction of rotation

SECTION 1 „AERO” Sp. z o o.
GENERAL AT-3 R100
Page 1-6 SEPTEMBER, 2004
AEROPLANE FLIGHT MANUAL
1.5 View of the aeroplane (three projections)

„AERO” Sp. z o.o. SECTION 1
AT-3 R100 GENERAL
SEPTEMBER, 2004 Page 1-7
AEROPLANE FLIGHT MANUAL
1.6 List of definitions and abbreviations
The following words or expressions have been used or may be helpful in
particular Sections of this manual.
Basic speeds and their denotations:
IAS – “INDICATED AIRSPEED” means the speed of an air vessel
indicated by its airspeed indicator co-operating with a Pitot tube,
which is calibrated for the compressibility of an adiabatic airflow
in the conditions of the standard atmosphere at sea level, without
corrected errors of the airspeed measuring system. All IAS
values in this manual presume the airspeed measuring system
error to be zero.
CAS – “CALIBRATED AIRSPEED” means the speed of an air vessel
after aerodynamic and instrument correction. The calibrated
airspeed is equal to the true airspeed in the conditions of the
standard atmosphere at sea level.
TAS – “TRUE AIRSPEED” means the airspeed of an air vessel,
relative to the undisturbed airflow. It is CAS corrected by the
change of air density depending on altitude and temperature.
TAS = CAS
ρ
ρ
ο
ρ
- air density at the particular altitude

SECTION 1 „AERO” Sp. z o o.
GENERAL AT-3 R100
Page 1-8 SEPTEMBER, 2004
AEROPLANE FLIGHT MANUAL
V
NE
– Maximum never exceed airspeed. This is a limit speed, which
cannot be exceeded in any conditions.
V
NO
– Maximum structural cruising speed. This is a limit speed which
cannot be exceeded except in non-turbulent conditions, and then,
only with care.
V
A
– Manoeuvring speed. Above this speed, rapid or full displacement
of the control surfaces may in certain circumstances result in
exceeding the maximum permissible loads of the structure.
V
FE
–Maximum airspeed with wing flaps extended. This is the maximum
permitted airspeed of the aeroplane with wing flaps extended.
V
S1
– Stalling speed, or minimum airspeed of steady flight, at which the
aeroplane is steerable in any other configuration than the landing
configuration.
V
S0
– Stalling speed, or minimum airspeed of steady flight, at which the
aeroplane is steerable in the landing configuration.
V
X
– Airspeed for the maximum angle of climb. This is the airspeed, at
which the maximum increase of altitude over the shortest distance
may be achieved.
V
Y
– Airspeed for the maximum rate of climb. This is the airspeed at
which the maximum increase of altitude in the shortest time may
be achieved.

„AERO” Sp. z o.o. SECTION 1
AT-3 R100 GENERAL
SEPTEMBER, 2004 Page 1-9
AEROPLANE FLIGHT MANUAL
Meteorological denotations
ISA – International Standard Atmosphere.
ISA assumptions:
- The air is a dry perfect gas
- The temperature at sea level is 15 °C / 59°F,
- The pressure at sea level is 1013.25 hPa,
- The drop in the temperature is 3.25 °C per each 500 m of altitude
(3.564°F for each 1000 ft) in the range from sea l evel up to the
altitude, at which the temperature is
–56.5 °C / -70°F .
OAT – Outside Air Temperature. This is the temperature of the static air,
read from the thermometer, or received from the ground meteorological
service, with instrument error and air compressibility effect corrected.
Pressure altitude – This is the altitude read from the altimeter, preset to
the standard pressure at the average sea level (1013 hPa).
Denotation of power and rating
Take-off power – Maximum power.
Maximum continuous power – Maximum power permitted for the
whole flight.
Engine failure – any engine malfunction, engine stop included.
