AETNAGROUP ROBOPAC ROBOTAPE 50 ME - LH User manual

ENG
Cardboard box taping machine
Translation of the original instructions
Instructions manual code: 3709302249.0
English Edition: 1116
Serial number
|__|__|__|__|__|__|__|__|__|__|
____________________________________________________________________________________________________
Important
Read and understand these instructions before usin
g
the machine.
Kee
p
this handbook for further consultation.
ROBOPAC S.p.A.

ROBOTAPE 50 ME - LH
Summary
1. GENERAL INFORMATION
1.1. PURPOSE OF THE MANUAL
1.2. MANUFACTURER AND MACHINE IDENTIFICATION
1.3. TERMS AND DEFINITIONS
1.4. MODES OF REQUESTING FOR ASSISTANCE
1.5. ATTACHED DOCUMENTATION
1.6. HOW TO READ THE DIRECTIONS FOR USE
2. SAFETY INFORMATION
2.1. GENERAL SAFETY PRECAUTIONS
2.2. SAFETY WARNINGS FOR HANDLING AND INSTALLATION
2.3. SAFETY WARNINGS FOR USE AND OPERATION
2.4. SAFETY WARNINGS RELATED TO INCORRECT USE
2.4.1. INCORRECT USE THAT CAN BE REASONABLY EXPECTED
2.4.2. EMPLOYER OBLIGATIONS
2.5. SAFETY WARNINGS ON RESIDUAL RISKS
2.6. SAFETY WARNINGS FOR REGULATIONS AND MAINTENANCE
2.7. INFORMATION AND SAFETY SIGNALS
2.8. SURROUNDING AREAS
3. TECHNICAL INFORMATION
3.1. MACHINE GENERAL DESCRIPTION
3.2. DESCRIPTION OF THE OPERATION CYCLE
3.3. SAFETY DEVICE DESCRIPTIONS
3.4. DESCRIPTION OF THE ELECTRICAL DEVICES
3.5. DESCRIPTION OF ACCESSORIES ON REQUEST
3.5.1. DESCRIPTION OF THE TAPING UNIT
3.6. TECHNICAL SPECIFICATIONS
3.7. NOISE LEVEL
3.8. INSTALLATION ENVIRONMENT CHARACTERISTICS
4. INFORMATION ON HANDLING AND INSTALLATION OPERATIONS
4.1. RECOMMENDATIONS FOR HANDLING AND LOADING
4.2. PACKAGING AND UNPACKING
4.3. TRANSPORT AND HANDLING
4.4. MACHINE INSTALLATION
4.5. MOUNTING THE TAPE
4.6. RECOMMENDATIONS FOR CONNECTIONS
4.7. ELECTRICAL CONNECTION
5. INFORMATION ON ADJUSTMENTS
5.1. RECOMMENDATIONS FOR ADJUSTMENTS
5.2. CONVEYOR BELT ADJUSTMENT
5.3. ADJUST THE TRANSPORT UNIT DRIVING CHAIN
5.4. ADJUSTING THE TAPING UNIT
5.4.1. TAPE TENSION REGULATOR
5.4.2. TAPE POSITION ADJUSTMENT
5.4.3. ADJUSTMENT OF TAPE PRESSURE ON THE CASING
6. ABOUT THE USE
6.1. RECOMMENDATIONS FOR OPERATION AND USE
6.2. CONTROL DESCRIPTION
6.3. SWITCHING THE MACHINE ON AND OFF
2/43

ROBOTAPE 50 ME - LH
6.4. EMERGENCY STOP AND RESTART
6.5. FORMAT CHANGE
6.6. CONVEYOR BELT POSITIONING
6.7. POSITIONING OF TOP TAPING UNIT
6.8. POSITIONING OF SIDE PRESSURE UNITS
6.9. HEIGHT SETTING OF WORK TABLE
7. MAINTENANCE INFORMATION
7.1. MAINTENANCE INSTRUCTIONS
7.2. MAINTENANCE PERIOD TABLE
7.3. LUBRICATION POINT DIAGRAM
8. TROUBLESHOOTING
8.1. TROUBLES – CAUSES – REMEDIES
8.2. CORRECTING TAPING ERRORS
9. SPARE PARTS REPLACEMENT INFORMATION
9.1. RECOMMENDATIONS FOR REPLACING PARTS
9.2. REPLACEMENT OF CONVEYOR BELT
9.3. HOW TO REPLACE THE TRANSPORT UNIT DRIVING CHAIN
9.4. HOW TO REPLACE THE DRIVING CHAIN OF THE LIFTING TABLE
9.5. REPLACING THE BLADE
9.6. LIST OF THE RECOMMENDED SPARE PARTS
9.7. MACHINE DISPOSAL AND SCRAPING
10. ENCLOSED DOCUMENTATION
10.1. WARRANTY CONDITIONS
3/43

ROBOTAPE 50 ME - LH
1. GENERAL INFORMATION
1.1. PURPOSE OF THE MANUAL
‒The manual is an integral part of the machine and is aimed to provide the operator the instructions for
use in order to
p
revent and reduce the risks that arise from man-machine interface.
The information have been written by the manufacturer into Italian (the original language)
in full com
p
liance with the
p
rofessional writin
g
p
rinci
p
les and the re
g
ulations in force.
The communication principles were chosen according to the target readers in order to ease
the readin
g
and understandin
g
of the information.
The information may be translated into other languages to satisfy the legal and/or market
re
q
uirements.
The manuals must be translated directly from the ORIGINAL INSTRUCTIONS, without
modification.
Each translation (including that provided by the purchasing agent or by the company that
introduces the machine into the country in question) must specify the message "Translation
of the ori
g
inal instruction".
‒Keep this manual for the entire duration of its useful life in a well known and easy to access place,
available for reference an
y
time the need should arise.
‒In order to easil
y
consult the s
p
ecific to
p
ics of interest, check the table of contents.
‒Some information ma
y
not corres
p
ond com
p
letel
y
to the actual confi
g
uration of the machine delivered.
‒An
y
additional information does not affect the readabilit
y
of the text and the safet
y
level.
‒The manufacturer reserves the right to modify the contents of the manual without prior notice provided
that the safet
y
level is not altered.
‒
T
he s
y
mbols described below are used to hi
g
hli
g
ht the most im
p
ortant information or s
p
ecifications.
iDanger - Warning
Indicates critically dangerous situations that if neglected can result in serious personal safety and health
hazards.
iCaution - Warning
Indicates that suitable actions must be employed in order to avoid personal safety and health hazards and
economic dama
g
es.
|Important
Indicates
p
articularl
y
im
p
ortant technical information that should not be ne
g
lected.
4/43

ROBOTAPE 50 ME - LH
1.2. MANUFACTURER AND
MACHINE IDENTIFICATION
The illustrated identification plate is applied
directly on the machine. It contains references
and indispensable operating safety indications.
A) Machine model.
B) Machine’s serial number.
C) Year of manufacture.
D) Power supply voltage.
E) Power supply frequency.
F) Power supply phases.
G) Electrical power consumption.
H) Total installed power.
L) Air consumption.
M) Max. air supply pressure.
N) Machine weight.
P) Manufacturer’s name.
1.3. TERMS AND DEFINITIONS
Some recurring terms found within the manual are described in order to provide a more complete image of
their meanings.
‒ Routine maintenance
Group of functions necessary to maintain suitable machine operations and efficiency. Normally the
manufacturer, who defines the necessar
y
skills and intervention
p
rocedures,
p
lans these o
p
erations.
‒ Non-routine maintenance
The whole of the operations necessary to keep the operating and efficiency capacity of the machinery.
These operations are not scheduled by the manufacturer and must be carried out by the maintenance
technician.
‒ Qualified technician
a person authorised and chosen from those who have the requirements, skills and information
necessar
y
for installation, use and extraordinar
y
maintenance of the machine.
‒Operator
A person authorised and chosen from those who have the requirements, skills and information
necessar
y
for installation, use and ordinar
y
maintenance of the machine.
‒ Maintenance technician
A person authorised and chosen among those who have the requirements, skills and information
necessary to perform ordinary and extraordinary machine maintenance. He is expected, therefore, to
p
ossess
p
recise information and skills with
p
articular ex
p
ertise in the field of intervention.
‒Format Change
series of operations to carry out on the machine before starting to work with the machine with different
characteristics res
p
ect to the
p
revious ones.
‒ Training
training process aimed to transfer to the operator the knowledge, skills and behaviour required to
o
p
erate the machine autonomousl
y
,
p
ro
p
erl
y
and safel
y
.
‒ Installer
technician chosen, among those that meet the requisites, and authorised by the manufacturer or by its
re
p
resentative, to install and test the machine or the s
y
stem in
q
uestion.
‒ Assistant
em
p
lo
y
ee assi
g
ned to assist the
p
roduction
p
rocesses of the machine or s
y
stem in
q
uestion.
5/43

ROBOTAPE 50 ME - LH
‒ Production manager
A qualified and skilled technician with experience in the operation and use of machinery in the relevant
manufacturing field.
According to the production needs, the Supervisors may use the machine themselves or give the task to
another O
p
erator.
1.4. MODES OF REQUESTING FOR ASSISTANCE
The distribution network ROBOPAC is at your service for any problem that requires technical support, to order
spare parts, and for whatever new type of need that can help develop your business.
Report the data displayed on the ID plate, the estimated hours you have used the machine, and the type of
flaw
y
ou have uncovered when re
q
uestin
g
technical su
pp
ort.
Contact one of our authorized dealers at the listed address for all your needs.
ROBOPAC SPA
VIA FABRIZIO DA MONTEBELLO, 81
47892 GUALDICCIOLO, REPUBBLICA S.MARINO (RSM)
Phone 0549 (international ++378) 910511
Fax [phone] - 905946
http://www.aetnagroup.com
1.5. ATTACHED DOCUMENTATION
The machine is provided with the documentation listed below, in the absence of a different trade agreement.
‒CE statement of conformity.
‒Warranty conditions (included in this booklet).
‒Instructions for unpacking and installation.
‒Quick start guide.
‒Wiring diagram and list of components.
‒Manuals of installed commercial devices (if necessary for machine use).
‒USB flash drive that contains the information listed.
‒Use and maintenance manual translated into various languages.
‒S
p
are
p
arts catalo
g
ue.
1.6. HOW TO READ THE DIRECTIONS FOR USE
The handbook is divided in chapters, each of which describes a specific category of information.
Each operator who interacts with the machine, apart from reading all the documentation, must read and learn
the information concerning his specific qualification.
Refer to the name preceding the title of the chapters, present in the summary, to search for the subjects to
consult.
These instructions are the result of an automatic system of assembly of text and illustrations, therefore, it is
possible to find, as pages change, some interruptions of the flow of text and charts.
Keep this manual for the entire duration of its useful life in a well known and easy to access place, available
for reference any time the need should arise.
Kee
p
the instructions for use and the attached documentation for future consultation.
6/43

ROBOTAPE 50 ME - LH
2. SAFETY INFORMATION
2.1. GENERAL SAFETY PRECAUTIONS
―Carefully read the “Directions for use”, paying particular attention to the “Residual risks”.
―Pay attention to the safety warnings.
―Use the machine only for the use for which it is designed.
―Sometimes, accidents can be caused by a "careless" use of the machine by the operator.
―Pay maximum attention.
―Preserve the readability of the information signs and observe the indications given.
―Do not tamper with the safety devices and protections.
―
T
he
p
ersonnel authorised to carr
y
out an
y
o
p
eration on the machine has to be ade
q
uatel
y
trained.
2.2. SAFETY WARNINGS FOR HANDLING AND INSTALLATION
―The personnel authorised to handle the machine (loading and unloading) must possess particular
expertise in the field of intervention.
―Carry out handling (loading and discharge) according to the information delivered together with the
product.
―During handling use one or two assistants, if required. This operation may generate unpredictable risks.
―In order to minimise the risks related to assistants' involvement, you must inform them priorily on the
type of work and the behaviour to be used.
―The machine must be handled with the aid of specific means (crane, forklift etc.) by qualified personnel
capable of observing the safety requirements.
―When using the lifting means, insert and/or fasten the devices (hooks, forks etc.) ONLY into the points
provided on the package and/or the machine.
―
T
rans
p
ort the machine suitable means of ade
q
uate ca
p
acit
y
.
―The minimum and maximum temperature (during transport and/or storage) must fall within the range
allowed in order to
p
revent dama
g
in
g
the electrical com
p
onents.
―Install the machine ONLY in s
p
aces free of ex
p
losion and /or fire risks.
―Avoid the s
p
aces ex
p
osed to atmos
p
heric and corrosive a
g
ents.
―Assess, prior to installation, if it is necessary to draw up a "safety plan" in order to protect the safety of
the
p
ersonnel involved.
―Arrange beforehand the adequate safety conditions to operate in safety for working in areas at a height,
those that are not easil
y
accessible or in an
y
case, in dan
g
erous areas.
―Install the machine according to the minimum perimeter indicated by the manufacturer and the
surroundin
g
activities.
―Should the machine interface directly/indirectly with other machines or production lines, draw up the
installation desi
g
n of the machine.
―The design must include all the operating conditions in order to comply with the standards in force on
safet
y
at work
p
lace.
―Check that the installation space is properly ventilated in order to avoid air concentration unhealthy for
the o
p
erators.
―A
pp
l
y
the most suitable solutions for reducin
g
the noise levels and the acoustic
p
ollution to minimum.
―Carry out the electrical connections professionally and in full compliance with the instructions provided
b
y
the manufacturer and the s
p
ecific re
g
ulations in force.
―The electrical connections must be carried out EXCLUSIVELY by operators with particular expertise in
the field of intervention.
―The operator must test the machine and check, through a general test, that the machine can be
commissioned without an
y
risk for the o
p
erator.
―Dismantle all the packaging components in compliance with the standards in force in the country of
installation.
7/43

ROBOTAPE 50 ME - LH
2.3. SAFETY WARNINGS FOR USE AND OPERATION
―The operator must be trained and possess the proper knowledge required to carry out the specific tasks
and must meet the conditions required for the safe use of the machine.
―When using the machine for the first time, the operator must read the manual and identify the controls
and simulate some operations, especially the start-up and shutdown.
―The machine has been designed and built to satisfy all the operating conditions of the Manufacturer,
and those alone.
―Use the machine ONLY with the original safety devices installed by the manufacturer.
―DO NOT tam
p
er with, remove or b
yp
ass the safet
y
devices installed on the machine.
―DO NOT modify the constructive and functional characteristics of the machine.
―ALWAYS wear the individual safety devices indicated in the "Instructions for use" and provided by the
standards in force regarding the safety at workplace.
―ALWAYS keep the surrounding areas in suitable conditions and free of obstacles in order to minimise the
risks, especially near the control station.
―The machine must be used by one operator ONLY, that must be assigned and authorised by the
employer.
―The involvement of one or more assistants when performing some operations or maintenance
interventions may present unpredictable risks.
―In order to minimise the risks related to assistants' involvement, you must inform them priorily on the
t
yp
e of work and the behaviour to be used.
―Make sure that no foreign persons are present within the machine operating area during its production
activity and maintenance.
―Do not use the machine if the scheduled maintenance work has not been regularly carried out.
―DO NOT continue to use the machine if malfunctions have been detected.
―Stop the machine immediately and restart it only after the normal conditions of use have been restored.
―DO NOT carry out interventions different from those indicated in the user manual without the written
consent of the manufacturer.
―Do not carry out interventions with the machine on, but only carry them out after having stopped the
machine and put it in safety conditions.
―DO NOT clean or wash the machine with aggressive products to avoid damaging the components.
―Replace the components ONLY with ORIGINAL PARE PARTS or with SIMILAR design and functional
features.
―Do not abandon the work post or leave the machine unguarded at the end of the work activity without
havin
g
first sto
pp
ed it and
p
ut it in safet
y
conditions.
2.4. SAFETY WARNINGS RELATED TO INCORRECT USE
Read the next warnin
g
s carefull
y
.
2.4.1.INCORRECT USE THAT CAN BE REASONABLY EXPECTED
‒The predictable incorrect use consists of: “the use of the machine different from the indications given in
the manual, that ma
y
stem from the easil
y
p
redictable human behaviour”.
The machine should be used only for sealing with adhesive tape products packed in cardboard boxes of
various sizes.
‒
T
he machine must be used ONLY for the uses intended b
y
the manufacturer.
‒DO NOT allow the machine to be used by operators that are not properly trained, informed and
unauthorised.
‒Packa
g
es that contain li
q
uid or inconsistent
p
roducts must ensure that the
y
do not leak.
‒Do not apply adhesive tape to bulk product with irregular shape and improperly collected to prevent
incorrect
p
acka
g
in
g
.
‒Do not use the machine to wra
p
and stabilise livin
g
bein
g
s (animals and humans).
‒Do not use the machine with adhesive ta
p
e different from that
p
rovided b
y
the Manufacturer.
‒Do not use the machine as a workbench.
‒DO NOT use or let the machine be used for
p
ur
p
oses or in wa
y
s not
p
rovided b
y
the manufacturer.
‒DO NOT use or make use of machines with defective, deactivated and/or not perfectly installed safety
devices.
8/43

ROBOTAPE 50 ME - LH
‒DO NOT continue to use the machine if malfunctions have been detected.
Sto
p
the machine immediatel
y
and restart it onl
y
after the normal conditions of use have been restored.
‒NEVER carry out an intervention with the machine enabled but ONLY after having stopped it properly,
under safet
y
conditions.
‒NEVER use the machine without wearing the Personal Protective Devices indicated by the manufacturer
and re
q
uired b
y
current work
p
lace laws.
‒NEVER use the machine if the scheduled maintenance interventions have not been carried out
accordin
g
l
y
.
‒DO NOT clean or wash the machine with a
gg
ressive
p
roducts to avoid dama
g
in
g
the com
p
onents.
‒DO NOT replace the components with non-original spare parts or with different design and constructive
features.
‒DO NOT leave the machine unattended at the end of the work without shutting it down first in safety
conditions.
2.4.2.EMPLOYER OBLIGATIONS
―The operator must possess the required training and meet the suitable conditions for carrying out the
activities in safety conditions.
―The employer must inform the operator on the INCORRECT USES predictable and on the persistent
Residual risks.
―The operator must be capable of reading and understanding the user manual and must easily identify
the safety signs.
―
T
he em
p
lo
y
er must ade
q
uatel
y
document the trainin
g
obtained b
y
the o
p
erators.
2.5. SAFETY WARNINGS ON RESIDUAL RISKS
‒The purpose of this information is to make the user aware to pay special attention in order to foresee
an
y
risk.
‒When designing and building the machine, the manufacturer has paid particular attention to the
RESIDUAL RISKS that ma
y
affect the safet
y
and health of the o
p
erators.
‒The residual risks are: “all the risks that persists although all safety solutions have been applied and
inte
g
rated durin
g
machine desi
g
n”.
‒The manufacturer has complied with the specific standards in force and applied all the "good
manufacturing regulations".
The list specifies the residual risks specific for this type of machine.
‒Danger of arms cutting: do not put your
hands inside the ta
p
in
g
unit.
9/43

ROBOTAPE 50 ME - LH
‒Danger of arms crushing: do not put your
hands inside the movin
g
or
g
ans.
‒Danger of entanglement: Do not get
close to the conveying belts to avoid
getting entangled with parts of the body
or clothes.
10/43

ROBOTAPE 50 ME - LH
2.6. SAFETY WARNINGS FOR REGULATIONS AND MAINTENANCE
―Keep the machinery in maximum efficiency condition and perform all the scheduled maintenance
operations provided for by the manufacturer.
Proper maintenance will provide the best performance, a longer life span and constant compliance with
safety requirements.
|Important
Maintenance work and adjustments shall be carried out by qualified, authorised personnel.
―Take all necessary precautions (suitably mark the working area and the exits, ensure proper visibility,
provide all necessary supporting equipment, etc.) to ensure safe operation.
―Delimitate the work area to minimise the risks, as per the workplace safety and health regulations.
―Enable all machine safety devices before performing any maintenance and regulation operations.
―Maintenance work in hard to access areas shall be carried out only after having removed any existing
risks.
―DO NOT use products that contain corrosive, toxic and inflammable substances.
―Wear the Individual Protection Devices provided by the laws on workplace safety and indicated in the
"Instructions for use" and/or affixed to the machine.
―Replace the components only with original spare parts or with parts with similar design and functional
characteristics so as to keep the intended safety level unchanged.
―Use lubricants (oils or grease) recommended by the manufacturer or with similar chemical-physical
features.
―Do not dump into the environment polluting liquids, worn parts and maintenance waste.
―Dispose of the same in compliance with current regulations on the matter.
―Select the components according to the chemical and physical features of the material and carry out
the differentiated waste disposal as per the standards in force.
―Follow the procedures in this chapter.
―Non compliance with the instructions given may cause risks for safety and health of the persons and
economic dama
g
es.
2.7. INFORMATION AND SAFETY SIGNALS
T
he fi
g
ure indicates the
p
osition of the safet
y
and information si
g
ns affixed to the machine.
For each sign is specified the relative description.
A) Electrical hazard sign.
Do not access this area: risk of electrical
shock or electrocution.
B) Information sign.
Indicates the points for lifting with a hook
device.
C) Information signal: indicates the
operating direction of the conveying belt.
D) Danger signal: indicates danger of hands
cutting.
E) Information sign: it indentified the power
cut-off switch.
F) Information sign: machine Start symbol.
G) Mandatory sign: it indicates the
obligation to read the entire
documentation before using the
machine.
H) Information sign: it indicates the
connection point for earthing the
machine.
I) Information sign: it indicates the tension
to be applied to the conveyor belt (the
adhesive is located inside the casin
g
).
11/43

ROBOTAPE 50 ME - LH
|Important
Check that the plates are clearly readable, and, if necessary, replace them with new ones that shall be
p
ositioned in the same
p
laces as
p
reviousl
y
.
2.8. SURROUNDING AREAS
The illustration depicts the perimeter work areas of the machine.
A) Operator's working area.
B) Box loading/unloading area.
C) Sorrounding area.
D) Electric
p
ower
p
oint.
12/43

ROBOTAPE 50 ME - LH
3. TECHNICAL INFORMATION
3.1. MACHINE GENERAL DESCRIPTION
‒The semi-automatic manually adjustable taper is a machine designed and built to close products
contained in carton boxes of various formats with adhesive ta
p
e.
‒Use machine only for the purposes set forth by the manufacturer. improper use of machine can cause
risks to safet
y
and health of
p
ersons, further to economical dama
g
e.
‒The machine enables sealing small casings with the dimensions indicated in chapt. 3.6. “Technical
s
p
ecifications”.
‒It can house two taping units T50 - LH that use wide adhesive tape rolls 25÷38 mm, available on the
market.
‒The packs that contain liquids or insubstantial materials must be suitable for the product and must be
p
erfectl
y
closed and ti
g
ht in order to
p
revent an
y
leaks of the content.
‒It is equipped with a series of safety devices designed to avoid anyharm befalling the operator or other
persons who come into contactwith the machine in any way. The machine is produced in a range
ofdifferent models in order to suit market re
q
uirements.
‒This machine is normally installed in workshops or industrial environments protected from the
atmos
p
heric a
g
ents.
Use of this machine in explosive environments or when exposed to the elements is strictly
forbidden.
‒Just one worker is necessary for operation that provides to loading and unloading of the boxes, reel
replacement and to the format change stages.
The figure shows, as a reference only, the machine models and the tablesshow the data and the main
s
p
ecifications.
Main parts
A) Base.
B) Transport unit:
It transports the box during the taping phase
and aligns it in the middle of the taping units.
C) Bottom taping unit:
Accomplishes the taping operation of the
bottom part of the box.
D) Top taping unit:
Accomplishes the taping operation of the top
part of the box.
E) Lifting table:
It places the top taping unit at boxes height.
F) Side pressure units:
Position the box at the centre of the taping unit.
G) Electric
p
anel.
13/43

ROBOTAPE 50 ME - LH
3.2. DESCRIPTION OF THE
OPERATION CYCLE
1. Place box (A) at the inlet of machine (B),
between the conve
y
or belts.
2. After start-up, the machine automatically
seals the to
p
and the bottom of the box.
3. The operator picks up the box exiting the
machine.
The cycle ends and the machine is ready to
start a new one.
14/43

ROBOTAPE 50 ME - LH
3.3. SAFETY DEVICE
DESCRIPTIONS
The figure shows the positioning of the devices
on board of the machine.
A) Main electrical knife switch (with
padlock):
to activate and deactivate the power
supply.
It comes with a padlock to prevent
unauthorised personnel from activating
the power supply.
B) Emergency button; the machine stops
immediately when this button is pressed
in emergency situations.
To reset, rotate the button in the
direction indicated b
y
the arrow.
3.4. DESCRIPTION OF THE
ELECTRICAL DEVICES
The figure shows the positioning of the devices
on board of the machine.
A) gear motor: it enables the movement of
the left conveyor belt.
B) gear motor: it enables the movement of
the right conveyor belt.
|Important
For further details see the electrical dia
g
ram.
3.5. DESCRIPTION OF
ACCESSORIES ON
REQUEST
To enhance the performance and to
increase the versatility of the machine,
the manufacturer furnishes the
accessories listed below.
A) Product outfeed roller conveyor.
B) Product infeed roller conveyor.
C) Casters.
D) Product input roller conveyor with
bottom flap closer.
E)
T
a
p
in
g
unit
s
T50 - LH.
15/43

ROBOTAPE 50 ME - LH
3.5.1.DESCRIPTION OF THE TAPING UNIT
T
he ta
p
in
g
unit in
q
uestion serves to ta
p
e cardboard boxes of
p
re-defined sizes.
T
he ta
p
in
g
unit uses ta
p
es with width 25÷38mm.
It can be installed on an
y
cardboard box ta
p
in
g
machine
p
redis
p
osed for such a unit.
It is also
p
ossible to ad
j
ust the len
g
th of the front fla
p
as needed.
DESCRIPTION OF COMPONENTS
1) Roll hub.
2) Spring adjustment screws.
3) Knurled nonreturn roller.
4) Return roller.
5) Tape shaper spring.
6) Small tape stopper roll.
7) Infeed roller.
8) Blade.
9) Blade protection.
10) Outfeed roller.
11) Stop pin.
12) Main s
p
rin
g
.
TECHNICAL FEATURES
Reel dimensions
‒Max reel diameter: 300mm
‒Internal roll holder pipe diamete:
76mm.
‒width: 25÷38mm.
Types of adhesive tape
‒PVC -
p
ol
yp
ro
py
lene (PPL).
16/43

ROBOTAPE 50 ME - LH
3.6. TECHNICAL SPECIFICATIONS
The figure and table specify the dimensional characteristics and technicaldata of the machine.
Table: dimensions of the machine.
A
(mm)
B
(mm)
C
(mm)
D
(mm)
E
(mm)
F
(mm)
G
(mm)
H
(mm)
L
(mm)
M
(mm)
925 960 565 745 670 850 325 775 380 830
Table: Dimensions of product to be taped
Description 50 ME - LH
Lmin. 100mm
Lmax. ∞
Wmin. 80mm
Wmax. 500mm
N25 mm
Hmin. 50mm
H Max with table in
standard position.
500mm
Max weight. 50kg
17/43

ROBOTAPE 50 ME - LH
Table: technical characteristics of the machine
Description 50 ME - LH
Forward speed 22 m/min.
Net weight of standard
machine
(with 2 T50 - LH)
160kg
Supply voltage 230V 1Ph 50Hz + T
Installed power 2 x 0,18kW
Conveyor belts height 30mm
Ambient operating
temperature
0÷40°C
Protection grade
Electrical wiring
IP54
Protection grade
Electric motors
IP 23
3.7. NOISE LEVEL
The noise levels were measured in compliance with the:
- ISO 4871
- ISO 11201 standards.
|Important
The noise level can vary according to the type of adhesive tape used.
Table: Noise level.
Description Lm
dB (A)
Lw
dBw (A)
Lw
mW (A)
Lop
dB (A)
Empty operation 47.0 63.0 0.00 52.7
Functioning in working
conditions.
67.9 83.8 0.24 75.3
Lm - Avera
g
e level of
p
ressure on the measurement surface.
Lw - Acoustic
p
ower out
p
ut.
Lop - Level at the operator's place.
iCaution - Warning
Prolonged exposure over 80dB (A) may cause health problems. The use of appropriate protection systems is
recommended (head
p
hones, ear
p
lu
g
s, etc.).
3.8. INSTALLATION ENVIRONMENT CHARACTERISTICS
Careful consideration must be given to the place where the machine is to be installed, in order to ensure that
it may be easily operated, without creating any unnecessary risks for personnel. Therefore we suggest the
followin
g
p
rere
q
uisites.
‒suitable room tem
p
erature (Se
e
3.6. "technical s
p
ecifications").
‒A suitably aired place so that when the machine is working, the degree of humidity is not unpleasantly
hi
g
h/low from the
p
oint of view of the o
p
erator.
‒A sufficient li
g
htin
g
in order that a
p
leasant, relaxin
g
workin
g
environment is created for the o
p
erator.
18/43

ROBOTAPE 50 ME - LH
‒a boundary area that must be left around the machine for safety rea-sons (See 2.8. "surrounding
areas").
‒a flat surface, steady and without vibrations with adequate weight supporting capacity, also in
consideration of the
p
alletised loads to be wra
pp
ed.
‒
T
he area must be e
q
ui
pp
ed with a
p
ower su
pp
l
y
socket.
iDanger - Warning
Use of this machine in ex
p
losive environments or when ex
p
osed to the elements is strictl
y
forbidden.
19/43

ROBOTAPE 50 ME - LH
4. INFORMATION ON HANDLING AND INSTALLATION
OPERATIONS
4.1. RECOMMENDATIONS FOR HANDLING AND LOADING
|Important
Accomplish handling and loading according to the instructions supplied by the manufacturer to be found on
the machine and in the operating instructions. The person authorized to accomplish these operations must, if
necessar
y
, or
g
anise a "safet
y
p
lan" to
g
uarantee safet
y
to the
p
ersons directl
y
involved.
Use normal lifting equipment and means of transport, in accordance with the instructions to be found on the
p
acka
g
in
g
itself.
Those persons responsible for lifting and transportation operations must decide which are the most suitable
means accordin
g
to the machine’s destination.
Carefully read the "Instructions for use" specified in the manual and those applied directly to the machine
and/or the
p
acka
g
e.
Provide suitable safety conditions in compliance with the regulations on workplace safety to prevent and
minimise the risks.
Pay attention to the SAFETY WARNINGS, do not use the machine for UNSPECIFIED PURPOSES and assess the
p
ossible RESIDUAL RISKS.
4.2. PACKAGING AND UNPACKING
‒The packing is realised, keeping the overall dimensions low, also in consideration of the transport
chosen.
‒To facilitate transport, shipping can be performed with some components disassembled and
a
pp
ro
p
riatel
y
p
rotected and
p
acka
g
ed.
‒Some
p
arts, es
p
eciall
y
electric e
q
ui
p
ment, are
p
rotected with anti-moisture n
y
lon covers.
‒
T
he cases are marked with all necessar
y
information for loadin
g
and unloadin
g
.
‒Durin
g
un
p
ackin
g
, check the inte
g
rit
y
and exact
q
uantit
y
of com
p
onents.
‒Packa
g
in
g
material should be a
pp
ro
p
riatel
y
dis
p
osed accordin
g
to the laws in force.
‒The figure shows the type of package used.
Cardboard box
p
acka
g
in
g
.
20/43
