AFO Pool Starry Skies Installation guide

www.afo.es 41
Te hniques and produ ts for the installation of starry skies and spe ial
effe ts in water environments, ba ked by hundreds of sus essful
installations in five ontinents.
Té ni as y produ tos para la instala ión de firmamentos y efe tos
espe iales en entornos suba uáti os, avalados por ientos de
instala iones en in o ontinentes.
UFF401
HCF301
1 - DISTRIBUTE THE POINTS
THROUGH THE POOL FLOOR AND
SECURE THE UFF401 SUPPORTS
WITH A TWO-PART EPOXI
ADHESIVE. WHEN CURED,
FASTEN FIBER WITH CABLE TIES.
FIBER
UFF401
CONCRETE
SLAB
2 - ONCE THE POOL FLOOR IS
SCREEDED AND/OR LEVELED,
TRIM THE SPIKE OF THE UFF401
SUPPORT FLUSH WITH THE
SCREEDED SURFACE.
3 - LAY DOWN THE CERAMIC
CLADDING, TRIMMING THE
PIECES AROUND THE FIBERS
(SEE TRIMMING DETAIL) TO FIT.
4 - WHEN CERAMIC PIECES ARE
GROUTED AND CLEAN, TRIM THE
FIBERS FLUSH WITH THE FINAL
SURFACE.
FIBER INGRESS INTO THE
POOL BASIN WITHOUT
INTERFERING WITH THE
WATERPROOFING SYSTEM.
FIBER TRIMMING DETAIL WITH
CERAMIC MOSAIC. FOR
OTHER FINISHES REQUEST
TECHNICAL DETAILS.
JOINT
TO ILLUMINATOR
FIBER
DISTRIBUTION
HCF201
CODE PRODUCT OUTER Ø PACKING
HCF201 High performan e lad fiber 1,00mm. Polyolefine HFFR ladding 3mm 1000m
HCF301 High performan e lad fiber 1,50mm. Polyolefine HFFR ladding 3,5mm 500m
UFF401 AISI 316 stainless steel fiber support N/A N/A
Pool Starry Skies Installation Details | Detalles de Instala ión de Firmamentos en Pis inas

www.afo.es 42
Starry skies have be ome the highest expression of sophisti ated lighting in pools, both indoor and outdoor.
Swimming or using a pool with a starry sky at night it’s an unforgettable experien e.
Full preparation and installation details available from our te hni al department.

www.afo.es 43
Los firmamentos se han onvertido en la máxima expresión de ilumina ión sofisti ada para pis inas, tanto exteriores omo interiores.
El uso no turno de una pis ina dotada de este sistema es una experien ia inolvidable.
Nuestro departamento té ni o dispone de extensas instru iones para la prepara ión e instala ión de estos sistemas.

www.afo.es 44
Advan ed has pioneered this ex iting new fashionable trend and developed spe ial light ondu tors and a essories to fa ilitate
the installation of starry skies in pools. Sideral effe ts su h as shooting stars, nebulas, omets and s ores of ustom motives
and underwater effe ts are ustom produ ed with spe ial polymer templates manufa tured on request.
Advan ed es pionera en el desarrollo de ondu tores ópti os y a esorios espe iales para fa ilitar la integra ión de firmamentos
en pis inas. Efe tos siderales, tales omo estrellas fuga es, nebulosas, ometas y mu hos otros motivos y efe tos se fabri an
a medida on plantillas de polímero fabri ados bajo pedido.
Advan ed is the foremost World manufa turer of ready-made sets of elements and patterns to in orporate in starry skies and
other de orative installations. In addition, we an ustom produ e any effe t, sign, feature or pattern in any size. All sets are
furnished omplete with ready-made and oded animation harnesses, spe ial illuminators built to reprodu e a given sequen e or
movement and templates for drilling the pattern onto its base. On request, we an manufa ture ready made effe ts on panels
made from any onstru tion material; gypsum board, plywood, metal or polymer, professionally finish to integrate in any s heme.
Advan ed es el mayor produ tor mundial de kits para su in orpora ión en firmamentos y otros elementos de orativos, es enas y
patrones. Fabri amos a medida ualquier rótulo, efe to, patrón o es ena a ualquier tamaño. Todos nuestros kits se suministran
ompletos on mazos de anima ión odifi ados, iluminadores espe iales onstruidos para reprodu ir una se uen ia o efe to
determinado y plantillas de taladrado para trasladar el patrón a la superfi ie de instala ión. Bajo pedido, fabri amos efe tos
terminados en ualquier panel de onstru ión; artón yeso, ontrapla ado, metáli o o de polímero, on a abados profesionales
y listos para in orporar en ualquier entorno.
Kits | Kits

www.afo.es 45

www.afo.es 46
Starry sky effe t sets to over different areas. Complete with illuminator, fiber harness and instru tions. We an design and
supply starry skies of any size and omplexity, su h as the new Amiri Air Terminal with 10,000m2over 2,000Km of fibers, 500,000
points and more than 400 illuminators.
Kits de firmamentos para ubrir áreas de diversa extensión, on iluminador, mazo de fibras e instru iones. Podemos fabri ar y
suministrar firmamentos de ualquier tamaño y omplejidad, omo la Terminal Amiri, on 10.000m2, 2.000Km de fibras, 500.000
puntos y más de 400 iluminadores.
CODE PRODUCT FIBERS FIBER Ø LENGTH AREA ILLUMINATOR
CES851 Starry sky kit 200 Mixed 2m 4m2ASI*
CES852 Starry sky kit 300 Mixed 2 / 3m 6m2ASI*
CES853 Starry sky kit 400 Mixed 2 / 3m 8m2ASI*
CES854 Starry sky kit 450 Mixed 2 / 3 / 4m 9m2ASI*
On request we an manufa ture these patterns or any other from a drawing or photograph.
* Noiseless (no fan).
Cosmi Effe t Sets - Starry Skies | Efe tos Siderales - Firmamentos

www.afo.es 47
Shooting star and starry sky effe t sets with illuminator, fiber harness and instru tions.
Kits de estrellas fuga es y firmamentos on iluminador, mazo de fibras e instru iones.
CODE PRODUCT FIBERS FIBER Ø LENGTH ILLUMINATOR
CES103 Shooting star + starry sky kit 112 + 200 Mixed 3m AHI**
CES104 Shooting star + starry sky kit 112 + 450 Mixed 4m AHI**
CES152 Shooting star + starry sky kit 76 + 200 Mixed 2m ASI*
On request we an manufa ture these patterns or any other from a drawing or photograph.
* Noiseless (no fan). ** Available with low-noise fan.
Cosmi Effe ts - Starry Skies + Shooting Stars | Efe tos Siderales - Firmamentos + Fuga es

www.afo.es 48
Shooting star effe t kit with illuminator, fiber harness, 1:1 drilling template and instru tions.
Kits de estrellas fuga es on iluminador, mazo de fibras, plantilla de taladrado 1:1 e instru iones.
CODE PRODUCT FIBERS FIBER Ø LENGTH ILLUMINATOR
CES101 Shooting star kit 56 1,00mm 2m AHI**
CES102 Shooting star kit 112 1,00mm 3m AHI**
CES151 Shooting star kit 76 0,50mm 2m ASI*
On request we an manufa ture these patterns or any other from a drawing or photograph.
* Noiseless (no fan). ** Available with low-noise fan.
Cosmi Effe t Sets - Shooting Stars | Efe tos Siderales - Estrellas Fuga es

www.afo.es 49
Open or losed omet effe t sets. Complete with illuminator, fiber harness, s ale 1:1 drilling template and installation instru tions.
Kit de ometa abierto o errado, ompleto on iluminador, mazo de fibras, plantilla de taladrado 1:1 e instru iones.
CODE PRODUCT FIBERS FIBER Ø LENGTH ILLUMINATOR
CES201 Open omet kit 750 0,50mm 2m AHI**
CES202 Open omet kit 1500 0,50mm 2m AHI**
CES203 Closed omet kit 750 0,50mm 2m AHI**
CES204 Closed omet kit 1500 0,50mm 2m AHI**
CES251 Open omet kit 648 0,50mm 2m ASI*
CES252 Closed omet kit 648 0,50mm 2m ASI*
On request we an manufa ture these patterns or any other from a drawing or photograph.
* Noiseless (no fan). ** Available with low-noise fan.
Cosmi Effe t Sets - Comets | Efe tos Siderales - Cometas

www.afo.es 50
Aurora kits omplete with illuminator, fiber harness, s ale 1:1 drilling template and instru tions.
Kits de aurora on iluminador, mazo de fibras, plantilla de taladrado a es ala 1:1 e instru iones de montaje.
CODE PRODUCT FIBERS FIBER Ø LENGTH ILLUMINATOR
CES301 Aurora short kit 1800 0,50mm 2m AHI**
CES302 Aurora long kit 3600 0,50mm 2m AHI**
On request we an manufa ture these patterns or any other from a drawing or photograph.
** Available with low-noise fan.
Cosmi Effe t Sets - Auroras | Efe tos Siderales - Auroras

www.afo.es 51
Cosmi dust sets omplete with illuminator, fiber harness, s ale 1:1 drilling template and instru tions. These sets use 0,25mm
fibers, ex eedingly thin and hallenging to install, but the effe t is breathtaking.
Kits de polvo ósmi o on iluminador, mazo de fibras, plantilla de taladrado a es ala 1:1 e instru iones de montaje. Estos kits
usan fibras de 0,25mm, muy delgadas y omplejas de instalar, pero el efe to es extraordinario.
CODE PRODUCT FIBERS FIBER Ø LENGTH ILLUMINATOR
CES303 Cosmi dust kit 1800 0,25mm 2m AHI**
CES304 Cosmi dust kit 3600 0,25mm 4m AHI**
CES305 Cosmi dust kit 6000 0,25mm 6m AHI**
On request we an manufa ture these patterns or any other from a drawing or photograph.
** Available with low-noise fan.
Cosmi Effe t Sets - Cosmi Dust | Efe tos Siderales - Polvo Cósmi o

www.afo.es 52
Supernovas in round or flat versions. Complete with illuminator, fiber harness, s ale 1:1 drilling template and installation instru tions.
Kits de supernova on iluminador, mazo de fibras, plantilla de taladrado a es ala 1:1 e instru iones.
CODE PRODUCT FIBERS FIBER Ø LENGTH ILLUMINATOR
CES401 Supernova round kit 280 0,50mm 2m AHI**
CES402 Supernova round kit 560 0,50mm 2m AHI**
CES403 Supernova flat kit 1800 0,50mm 3m AHI**
CES404 Supernova flat kit 3600 0,50mm 3m AHI**
CES451 Supernova round kit 570 0,50mm 2m ASI*
On request we an manufa ture these patterns or any other from a drawing or photograph.
* Noiseless (no fan). ** Available with low-noise fan.
Cosmi Effe t Sets - Supernovas | Efe tos Siderales - Supernovas

www.afo.es 53
Nebulas in standard sizes, omplete with illuminator/s, fiber harness/es, s ale 1:1 drilling template and installation instru tions.
Custom made nebulas of any size are also available.
Kits de nebulosas en diferentes tamaños estándar, ompletos on iluminador, mazo/s de fibras, plantilla de taladrado a es ala 1:1
e instru iones. También disponibles en ualquier tamaño a medida.
CODE PRODUCT FIBERS FIBER Ø LENGTH ILLUMINATOR
CES501 Nebula small kit 1800 0,50mm 2m AHI**
CES502 Nebula large kit 3600 0,50mm 2m AHI**
CES551 Nebula miniature kit 648 0,50mm 2m ASI*
On request we an manufa ture these patterns or any other from a drawing or photograph.
* Noiseless (no fan). ** Available with low-noise fan.
Cosmi Effe t Sets - Nebulas | Efe tos Siderales - Nebulosas

www.afo.es 54
These nebula sets are extraordinary, eye- at hing entrepie es bound to delight and awe any observer. We have ustom produ ed
very large nebulas with more than 500,000 individual fibers
Estos monumentales kits onforman efe tos extraordinarios que sorprenden al observador. Hemos fabri ado nebulosas de gran
tamaño on más de 500.000 fibras individuales.
CODE PRODUCT FIBERS FIBER Ø LENGTH ILLUMINATOR
CES503 Nebula super large kit (photo page 45) 11200 0,50mm 6m AHI**
CES504 Nebula super large kit (photo above) 18000 0,50mm 6m AHI**
On request we an manufa ture these patterns or any other from a drawing or photograph.
** Available with low-noise fan.
Cosmi Effe t Sets - Centerpie e Nebulas | Efe tos Siderales - Nebulosas Espe ta ulares

www.afo.es 55
CES601 and CES602 with six bolides. CES603 and CES651, single fireball with “firetails”. Complete with illuminator, fiber
harness 1:1, drilling template and instru tions.
Kits CES601 y CES602; seis bólidos. CES603 y CES651; bola de fuego on estelas. Completos on iluminador, mazo de fibras,
plantilla 1:1 e instru iones.
CODE PRODUCT FIBERS FIBER Ø LENGTH ILLUMINATOR
CES601 Bolide short kit 1200 0,50mm 2m AHI**
CES602 Bolide long kit 2400 0,50mm 3m AHI**
CES603 Fireball large kit 1200 0,50mm 2m AHI**
CES651 Bolide miniature kit 494 0,50mm 2m ASI*
* Noiseless (no fan). ** Available with low-noise fan.
On request we an manufa ture these patterns or any other from a drawing or photograph.
Cosmi Effe t Sets - Bolides and Fireballs | Efe tos Siderales - Bólidos y Bolas de Fuego

www.afo.es 56
Sets with fast- hasing flaming meteoroids in different onfigurations. Complete with illuminator, fiber harness 1:1, drilling
template and instru tions.
Kits on meteoroides en diversas onfigura iones. Completos on iluminador, mazo de fibras, plantilla 1:1 e instru iones.
CODE PRODUCT FIBERS FIBER Ø LENGTH ILLUMINATOR
CES610 Small meteoroid rain kit 660 0,50mm 3m AHI**
CES611 Large meteoroid rain kit 1620 0,50mm 4m AHI**
On request we an manufa ture these patterns or any other from a drawing or photograph.
** Available with low-noise fan.
Cosmi Effe t Sets - Meteoroide Rain | Efe tos Siderales - Lluvia de Meteoroides

www.afo.es 57
Saturn and moon osmi effe t sets; omplete with illuminator, fiber harness, s ale 1:1 drilling template and installation instru tions.
Kits de efe tos luna y Saturno; ompletos on iluminador, mazo de fibras, plantilla 1:1 e instru iones de instala ión.
CODE PRODUCT FIBERS FIBER Ø LENGTH ILLUMINATOR
CES701 Saturn kit 2000 0,50mm 2m AHI**
CES702 Moon kit 2000 0,50mm 2m AHI**
CES751 Saturn miniature kit 508 0,50mm 2m ASI*
CES752 Moon miniature kit 684 0,50mm 2m ASI*
On request we an manufa ture these patterns or any other from a drawing or photograph.
* Noiseless (no fan). ** Available with low-noise fan.
Cosmi Effe t Sets - Planets 1 | Efe tos Siderales - Planetas 1

www.afo.es 58
Realisti planets sets in diverse sizes and onfigurations omplete with illuminator, fiber harness, s ale 1:1 drilling template and
installation instru tions.
Kits de planetas de gran realismo en varios tamaños y onfigura iones; ompletos on iluminador, mazo de fibras, plantilla 1:1 e
instru iones de instala ión.
CODE PRODUCT FIBERS FIBER Ø LENGTH ILLUMINATOR
CES703 Realisti Saturn kit 2000 0,50mm 2m AHI olor**
CES704 Realisti moon kit 2000 0,50mm 2m AHI olor**
CES705 Realisti meteorite kit 2000 0,50mm 2m AHI olor**
On request we an manufa ture these patterns or any other from a drawing or photograph.
** Available with low-noise fan.
Cosmi Effe t Sets - Planets 2 | Efe tos Siderales - Planetas 2

www.afo.es 59
Multiple planets sets in diverse sizes and onfigurations omplete with illuminator, fiber harness, s ale 1:1 drilling template and
installation instru tions.
Kits de grupos de planetas de gran realismo en varios tamaños y onfigura iones; ompletos on iluminador, mazo de fibras,
plantilla 1:1 e instru iones de instala ión.
CODE PRODUCT FIBERS FIBER Ø LENGTH ILLUMINATOR
CES721 Four-planet kit 1200 0,50mm 3m AHI olor**
CES722 Six-planet kit 1800 0,50mm 4m AHI olor**
CES723 Eight-planet kit 2400 0,50mm 6m AHI olor**
On request we an manufa ture these patterns or any other from a drawing or photograph.
** Available with low-noise fan.
Cosmi Effe t Sets - Planet Sets | Efe tos Siderales - Grupos de Planetas

www.afo.es 60
De orative rystal sets to reate patterns, effe ts or simply add to standard starry skies. Ea h set is omplete with fiber
harness, illuminator and rystal fittings.
Kits de orativos on ristales para la rea ión de efe tos o mez lar on los firmamentos de fibra estándar. Cada kit se suministra
ompleto on mazo de fibras, iluminador y juego de ristales.
CODE PRODUCT LIGHT GUIDES CRYSTALS LENGTH ILLUMINATOR
CES861 Crystal kit 20 x 3mm 20 1,5 / 2m XXX
CES862 Crystal kit 20 x 3mm 20 3 / 4m XXX
CES863 Crystal kit 30 x 3mm 30 2,5 / 4,5m XXX
CES864 Crystal kit 70 x 3mm 70 2,5 / 6,5m XXX
On request we an manufa ture kits with any number of fibers or rystals.
Crystal Sets | Kits de Cristales
