AG Neovo FS-24 User manual

FS-24 & FS-27 LED-Backlit Display
User Manual

TABLE OF CONTENTS
2
Contents
SAFETY INFORMATION
WEEE...........................................................................................................................................................4
PRECAUTIONS
Notice ...........................................................................................................................................................5
Cautions When Setting Up ...........................................................................................................................5
Cautions When Using................................................................................................................................... 6
Cleaning and Maintenance........................................................................................................................... 6
Notice for the LCD Display ...........................................................................................................................7
CHAPTER 1: PRODUCT DESCRIPTION
1.1 Package Contents ..................................................................................................................................8
1.2 Installation ..............................................................................................................................................9
1.2.1 Installing the Stand......................................................................................................................9
1.2.2 Adjusting the Viewing Angle and Height.................................................................................... 10
1.2.3 Wall Mounting............................................................................................................................ 11
1.3 Control Buttons..................................................................................................................................... 12
1.4 Overview ..............................................................................................................................................13
1.4.1 Front View .................................................................................................................................13
1.4.2 Rear View..................................................................................................................................14
CHAPTER 2: MAKING CONNECTIONS
2.1 Connecting the AC Power ....................................................................................................................15
2.2 Connecting Input Source Signals ......................................................................................................... 16
2.3 Connecting Audio Devices ................................................................................................................... 17
CHAPTER 3: USING THE LCD DISPLAY
3.1 Turning on the Power ...........................................................................................................................18
3.2 Selecting the Input Source Signal ........................................................................................................ 18
3.3 Adjusting the Volume............................................................................................................................19
3.4 Locking the OSD Menu ........................................................................................................................ 20
3.5 Using Auto Adjustment Function .......................................................................................................... 20
CHAPTER 4: ON SCREEN DISPLAY MENU
4.1 Using the OSD Menu ...........................................................................................................................21
4.2 OSD Menu Tree ................................................................................................................................... 22
CHAPTER 5: ADJUSTING THE LCD DISPLAY
5.1 Luminance Setting................................................................................................................................ 24
5.2 Image Setup Setting.............................................................................................................................25
5.3 Color Temperature Setting ................................................................................................................... 26
5.4 OSD Setup Setting ...............................................................................................................................27
5.5 Extra Setting.........................................................................................................................................28

3
TABLE OF CONTENTS
CHAPTER 6: APPENDIX
6.1 Warning Messages...............................................................................................................................29
6.2 Troubleshooting....................................................................................................................................30
6.3 Transporting the LCD Display .............................................................................................................. 31
CHAPTER 7: SPECIFICATIONS
7.1 Display Specications ..........................................................................................................................33
7.2 Display Dimensions..............................................................................................................................34

SAFETY INFORMATION
4
WEEE
Information for users applicable in European Union countries.
The symbol on the product or its packaging signies that this product has to be
disposed separately from ordinary household wastes at its end of life. Please
kindly be aware that this is your responsibility to dispose electronic equipment at
recycling centers so as to help conserve natural resources. Each country in the
European Union should have its collection centers for electrical and electronic
equipment recycling. For information about your recycling drop off area, please
contact your local related electrical and electronic equipment waste management
authority or the retailer where you bought the product.

5
PRECAUTIONS
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
Symbols used in this manual
This icon indicates the existence of a potential hazard that could result in personal injury
or damage to the product.
This icon indicates important operating and servicing information.
Notice
• Read this User Manual carefully before using the LCD display and keep it for future reference.
• The product specications and other information provided in this User Manual are for reference only. All
information is subject to change without notice. Updated content can be downloaded from our web site at
http://www.agneovo.com.
• To register online, go to http://www.agneovo.com.
• To protect your rights as a consumer, do not remove any stickers from the LCD display. Doing so may
affect the determination of the warranty period.
Cautions When Setting Up
Do not place the LCD display near heat sources, such as a heater, exhaust vent, or in direct
sunlight.
Do not cover or block the ventilation holes in the housing.
Place the LCD display on a stable area. Do not place the LCD display where it may subject
to vibration or shock.
Place the LCD display in a well-ventilated area.
Do not place the LCD display outdoors.
Do not place the LCD display in a dusty or humid environment.
Do not spill liquid or insert sharp objects into the LCD display through the ventilation holes.
Doing so may cause accidental re, electric shock or damage the LCD display.

6
PRECAUTIONS
Cautions When Using
Use only the power cord supplied with the LCD
display.
The power outlet should be installed near the LCD
display and be easily accessible.
If an extension cord is used with the LCD display,
ensure that the total current consumption plugged
into the power outlet does not exceed the ampere
rating.
Do not allow anything to rest on the power cord. Do
not place the LCD display where the power cord
may be stepped on.
If the LCD display will not be used for an indenite
period of time, unplug the power cord from the
power outlet.
To disconnect the power cord, grasp and pull by the
plug head. Do not tug on the cord; doing so may
cause re or electric shock.
Do not unplug or touch the power cord with wet
hands.
Cleaning and Maintenance
Use a soft cloth lightly moistened with a mild
detergent solution to clean the glass surface and the
housing.
Do not rub or tap the surface of the glass with sharp
or abrasive items such as a pen or screwdriver. This
may result in scratching the surface of the glass.
Do not attempt to service the LCD display yourself,
refer to qualied service personnel. Opening or
removing the covers may expose you to dangerous
voltage or other risks.
Warning:
Unplug the power cord
from the power outlet and
refer to qualied service
personnel under the following
conditions:
♦When the power cord is
damaged.
♦If the LCD display has been
dropped or the housing has
been damaged.
♦If the LCD display emits smoke
or a distinct odor.
Warning:
Ceiling mount or mount
on any other horizontal
surface overhead are not
advisable.
Installation in contravention of
the instructions may result in
undesirable consequences,
particularly hurting people and
damaging property. Users who
have already mounted the
display on the ceiling or any
other horizontal surface overhead
are strongly advised to contact
AG Neovo for consultations and
solutions to help ensure a most
pleasurable and fullling display
experience.

7
PRECAUTIONS
Notice for the LCD Display
In order to maintain the stable luminous performance, it is recommended to use low brightness setting.
Due to the lifespan of the lamp, it is normal that the brightness quality of the LCD display may decrease
with time.
When static images are displayed for long periods of time, the image may cause an imprint on the LCD
display. This is called image retention or burn-in.
To prevent image retention, do any of the following:
• Set the LCD display to turn off after a few minutes of being idle.
• Use a screen saver that has moving graphics or a blank white image.
• Switch desktop backgrounds regularly.
• Adjust the LCD display to low brightness settings.
• Turn off the LCD display when the system is not in use.
Things to do when the LCD display shows image retention:
• Turn off the LCD display for extended periods of time. It can be several hours or several days.
• Use a screen saver and run it for extended periods of time.
• Use a black and white image and run it for extended periods of time.
When the LCD display is moved from one room to another or there is a sudden change from low to high
ambient temperature, dew condensation may form on or inside the glass surface. When this happens, do
not turn on the LCD display until the dew disappears.
Due to humid weather conditions, it is normal for mist to form inside the glass surface of the LCD display.
The mist will disappear after a few days or as soon as the weather stabilizes.
There are millions of micro transistors inside the LCD display. It is normal for a few transistors to be
damaged and to produce spots. This is acceptable and is not considered a failure.

CHAPTER 1: PRODUCT DESCRIPTION
8
1.1 Package Contents
When unpacking, check if the following items are included in the package. If any of them is missing or
damaged, contact your dealer.
LCD display
Stand Stand screws Power cord HDMI cable
FS-24 & FS-27
www.agneovo.com
FS-24/FS-27_Quick Guide_V010
Quick Start Guide
FS-24 & FS-27 LED-Backlit Display
Audio cable Quick start guide Warranty card
Note:
• The pictures are for reference only. Actual items may vary upon shipment.
x 4

9
PRODUCT DESCRIPTION
1.2 Installation
1.2.1 Installing the Stand
1. Place the LCD display with the screen side down on a cushioned surface.
2. Attach the stand to the LCD display.
a. Align and attach the stand to the rear of the LCD display.
b. Use the screws to secure the stand.
3. Rotate the stand 90˚clockwise. Then set the LCD display up in an upright position.

10
PRODUCT DESCRIPTION
1.2.2 Adjusting the Viewing Angle and Height
For optimal viewing, it is recommended to look at the full face of the screen, then adjust the screen of the LCD display
angle and height according to your preference.
Hold the stand so that the screen does not topple when you make the adjustment.
You are able to adjust the screen angle and height as below:
Tilt angle: Pivot angle:
-3°~ 21.5°
90°
0°~ 90°
Note: Before making the adjustment, make sure to
adjust the height to the highest position, and then
tilt the screen 90˚.
Swivel angle: Height adjustment:
150°
±150°
150°
0 ~ 11cm
11cm

11
PRODUCT DESCRIPTION
1.2.3 Wall Mounting
To wall mount the LCD display, do the following steps:
1. Remove the stand.
Please refer to page 36.
2. Wall mount the LCD display.
Screw the mounting bracket to the VESA holes at the rear of the LCD display.
100 mm
100
mm
HDMI D-SUBDP
Note: Take measures to prevent the LCD display from falling down and lessen possible injury and damage
to the display in case of earthquakes or other disasters.
• Use only the 100 x 100 mm wall mount kit recommended by AG Neovo. All
AG Neovo wall mount kits comply with VESA standard.
• Secure the LCD display on a solid wall strong enough to bear its weight.
• It is suggested to wall mount the LCD display without tilting it facing
downward.

12
PRODUCT DESCRIPTION
1.3 Control Buttons
HDMID-SUBDP
1
2
3
4
5
6
1[] AUTO/SOURCE/EXIT
• Call out the Source quick menu. Then
press the button repeatedly to switch
the input source. Refer to page 23.
• For VGA input signal, press and hold the
button to perform auto adjustment.
Refer to page 25.
• During OSD menu, close the OSD menu
or exit a submenu.
• During volume adjustment or Eco mode
selection, close the respective quick
menu.
2[] Up
• Call out the Volume quick menu. Then
press the / button to adjust the
volume level. Refer to page 24.
• For HDMI input signal, you can congure
the audio input source. Refer to page
24.
• During OSD menu, scroll through the
menu options, select an option, and adjust
the settings.
3[] Down
• Call out the Eco Mode quick menu.
Then press the / button to select the
desired setting.
• During OSD menu, scroll through the
menu options, select an option, and adjust
the settings.
4[] MENU/ENTER
• Call out the OSD menu when OSD menu
is off.
• During OSD menu, conrm the selection
or enter a submenu.
5[] Power
Turn the LCD display on. Press it again
to turn the LCD display off. Refer to page
23.
6Power indicator
Indicate the operating status of the LCD
display:
- Lights blue when the LCD display is
turned on.
- Blinks orange when the LCD display is in
standby mode.
- Lights off when the LCD display is turned
off.

13
PRODUCT DESCRIPTION
1.4 Overview
1.4.1 Front View
1
2
1Display screen
2Control buttons
Press the button to perform its function. For more information about each button, refer to page 12.

14
PRODUCT DESCRIPTION
1.4.2 Rear View
1Power Input
Connect the power cord to the power input.
2DP(DisplayPort) connector
Use to connect DP cable for digital input signal.
3HDMI connector
Use to connect an HDMI cable for digital input signal.
4D-SUB (VGA) connector
Use to connect a D-Sub (VGA) cable for analogue input signal.
5Audio port
Use to connect an audio cable for audio input.
6Kensington lock socket
Use to physically lock the system to prevent theft.
The locking device is sold separately. To purchase, contact your retailer.
HDMI D-SUBDP
(AC-IN) HDMI D-SUB
DP
1 2 3 4 5
6

15
CHAPTER 2: MAKING CONNECTIONS
CAUTION:
Make sure that the LCD display is not connected to the power outlet before making any
connections. Connecting cables while the power is ON may cause possible electric shock or
personal injury.
2.1 Connecting the AC Power
1. Connect the power cord to the AC power input at the rear of the LED-backlit display.
2. Connect the plug to a power outlet or power supply.
(AC-IN)
CAUTION:
When unplugging the power cord, hold the power cord by the plug head. Never pull by the
cord.

16
MAKING CONNECTIONS
2.2 Connecting Input Source Signals
Input source signals can be connected with either of the following cables:
HDMI D-SUBDPDP
• DP
Connect one end of an DP cable to the DP connector of
the LCD display and the other end to the DP connector of
the computer.
• VGA
Connect one end of a D-Sub (VGA) cable to the D-SUB
(VGA) connector of the LCD display and the other end to
the VGA connector of the computer.
• HDMI
Connect one end of an HDMI cable to the HDMI connector
of the LCD display and the other end to the HDMI
connector of the computer.

17
MAKING CONNECTIONS
2.3 Connecting Audio Devices
1. Connect one end of an audio cable to the audio port at the rear of the LCD display.
2. Connect the other end of an audio cable to the audio out port of the computer.

CHAPTER 3: USING THE LCD DISPLAY
18
3.1 Turning on the Power
1. Plug the power cord to a power outlet or power supply.
2. Press the button to turn the LCD display on.
Power button
When the LCD display is turned on, press the button to turn off the LCD display.
Note: The LCD display still consumes power as long as the power cord is connected to the power outlet.
Disconnect the power cord to completely cut off power.
3.2 Selecting the Input Source Signal
1. Press the button to call out the Source quick menu.
D-SUB
HDMI
DisplayPort
2. Press the button repeatedly to switch the input source.

19
USING THE LCD DISPLAY
3.3 Adjusting the Volume
1. Press the button to call out the Volume quick menu.
Volume
01
4
2. Press the or button to adjust the volume.
Note:
• During volume or menu setting adjustment, press and hold the / button to change the values
continuously.
• For HDMI input signal, the Audio Source option will appear on the screen when you press the
button.
Volume
01
8
Audio Source Digital
To congure the audio input source, press the button to select Audio Source. Then use the /
button to select the desired setting (Line in/Digital).

20
USING THE LCD DISPLAY
3.4 Locking the OSD Menu
To lock the OSD menu, press and hold the button while the LCD display is off, and then press the
button to turn the LCD display on.
Power button
Menu button
To unlock the OSD menu, press and hold the button while the LCD display is off, and then press the
button to turn the LCD display on.
3.5 Using Auto Adjustment Function
Press and hold the button to perform auto adjustment. This function automatically tunes the LCD display
to its optimal setting, including horizontal position, vertical position, clock, and phase. When auto adjustment is
initiated, the below message is displayed on the screen.
Auto Configure
Please wait
When the message disappears, this indicates the auto adjustment is completed.
Note:
• During auto adjustment, the screen will slightly shake for a few seconds.
• It is recommended to use the auto adjustment function when using the LCD display for the rst time or
after a resolution or frequency change.
