AGA Legacy 44 Operating instructions

Dual Fuel Range
Service Instructions
F104040-03
This book contains many important safety messages.
Always read and obey all safety messages.

Contents
Servicing Notes 4
1. To Remove the Hand Rail 4
2. To Remove Control Panel 4
3. To Remove the Cooktop 4
4. To Remove a Side Panel 5
5. To Remove Oven Light Switch 5
6. To Remove Electronic Timer 5
7. To Remove A Thermostat 5
8. To Change Broiler Controller 5
9. To Change Cooktop Control Valve 5
10. To Change Cooktop Burner Orifice 6
11. To Change Cooktop Burner Electrode 6
12. To Remove or Change a Cooktop Burner. 6
13. To Remove Broiler Outer Door Panel 7
14. To Remove an Oven Door 7
15. To Change Oven Door Outer Panel 7
16. To Change Oven Door Catch 8
17. To Change Oven Door Seal 8
18. To Adjust Oven Door Catch Keep 8
19. To Change Ignition Generator 8
20. To Remove Oven Inner Back. 8
21. To Replace the Cooling fan 9
22. To Replace an Oven Fan 9
23. To Remove an Oven fan Element 9
24. To Remove Broiler Element. 9
25 To Remove the LH Oven Bottom and Top Elements 10
26. To change oven light bulb. 10
Schematic diagram of the Range 12
Technical Data 14

SERVICING - WARNING
Disconnect from electricity and gas before servicing. Check appliance is safe when you have finished.
4
Servicing Notes
When servicing or replacing gas carrying
components disconnect from gas before
commencing operation and check appliance is
gas sound after completion. When checking for
gas leaks use a liquid leak detector at all joints
and connections to check for leaks in the system.
Use a product specifically manufactured for leak
detection. Leak testing of the appliance shall be
conducted in accordance to the manufacturer’s
instructions.
CAUTION: DO NOT USE A FLAME TO
CHECK FOR GAS LEAKS.
Do not use re-conditioned or unauthorised gas
controls.
Disconnect from electricity supply before
commencing servicing, particularly before
removing any of the following: control panel,
side panels, cooktop tray, or any of the electrical
components or cover boxes. Before electrical
reconnection make sure the range is electrically
safe.
1. To Remove the Handrail
ArtNo.210-0009 - Classic
removing the handles
Remove the handrail plastic blanking plugs and
remove the 2 end bracket fixing screws.
2. To Remove Control Panel
Disconnect from electricity supply.
Pull off all the control knobs. Remove the handrail
(see 2) Remove the 2 cross headed screws that
were hidden by the handrail end brackets.
ArtNo.210-0006 - Fitting the handles 3
Open the broiler door and right-hand oven door
and remove the 2 screws underneath the control
panel.
Pull the control panel forward and support so that
the wires are not strained.
Reassemble in reverse order. When replacing
leads refer to the wiring diagram. Check operation
of timer, ignition, and oven light switches.
3. To Remove the Cooktop
Disconnect from electricity supply.
Remove the grates, cooktop burner caps and tops.
If there are screws holding the cooktop burners to
the cooktop, remove them (not the spark electrode
fixing screws).
A
B
A Cooktop front fixing screws
B Cooktop rear fixing screws
Remove the 2 rear cooktop fixing screws (B) and
the 4 front cooktop fixing screws (A).
Remove the screws holding the flue grille stays
and if the rear extenstion is fitted remove the
screws holding that as well.
Lift the cooktop clear of the appliance. Replace in
reverse order.
Reassemble in reverse order ensuring that the
leads are reconnected. When replacing the
cooktop take care not to damage the ignition
electrodes.
Check for correct burner operation.

5
SERVICING - WARNING
Disconnect from electricity and gas before servicing. Check appliance is safe when you have finished.
4. To Remove a Side Panel
Disconnect from electricity supply.
Remove control panel (see 2). Pull the cooker
forward. Remove the 4 retaining screws for each
panel (2 at the front and 2 at the rear). The lower
front retaining screws (one each side) are situated
beneath the lower edge at the front corners of the
side panels
Reassemble in reverse order.
5. To Remove Oven Light Switch
Remove control panel (see 2).
NB The old switch may be destroyed during
removal.
Remove switch button and old switch from its
bezel by gripping the switch body behind the
control panel and twisting sharply.
The switch bezel can then be removed by folding
back its locking wings and pushing forward. Fit
the new bezel to the control panel by first lining
up the raised key on its body with the cutout in
the control panel and pushing it in from the front.
Assemble the new switch to the bezel by lining up
the key sections and pushing home. Fit the new
button by pushing in from the front.
Replace control panel in reverse order and test for
correct operation.
6. To Remove Electronic Timer
Disconnect from electricity supply.
Pull off the timer control buttons and remove
the control panel (See 2). Remove the timer/
mounting bracket assembly from the control panel
by removing the two fixing screws. Remove the
timer from its mounting bracket by depressing the
plastic lugs on the timer case, at the same time
pulling the unit forward.
Reassemble in reverse order. When replacing
leads refer to the wiring diagram. Check operation
of timer.
7. To Remove A Thermostat
Remove control panel (see 2) and cooktop (see
3). Open the appropriate oven door and remove
the oven shelves.
Right-hand oven
Remove oven roof. Remove the two fixings that
secure the thermostat phial cover. Unclip the
thermostat phial from the clips in the oven back
panel & remove from the top rear of the oven.
Left-hand oven
Remove the two screws holding the thermostat
phial to the oven fan cover at the rear of the
oven. Pull the unit forward to access the rear
of the cooker. Remove both rear cover boxes
by removing the fixing screws and lifting clear.
Feed the thermostat capillary clear of the oven.
Disconnect the wires from the thermostat and
undo the two fixings that secure the control to
the mounting plate. Fit the replacement and re-
assemble in reverse order. Ensure that the phial
is clipped to the oven rear, positioned centrally
between the clips. Check that the thermostat
functions correctly.
8. To Change Broiler Controller
Remove the control panel (see 2) and cooktop
(see 3). Disconnect wiring from controller. Remove
2 screws holding switch/controller to mounting
panel. Fit new controller and reassemble in
reverse order. Check for correct operation.
BEFORE SERVICING ANY GAS CARRYING
COMPONENTS TURN OFF GAS SUPPLY.
9. To Change Cooktop Control Valve
Remove the cooktop top, see 3. Undo the nut
at rear of the valve and remove the screw(s)
securing valve to gas rail. Remove old valve,
discard old gasket/seal. Fit new gasket/seal to
new valve.
Reassemble in reverse order. Check valve is
adjusted for correct gas. Check range is gas
sound.

SERVICING - WARNING
Disconnect from electricity and gas before servicing. Check appliance is safe when you have finished.
6
10.To Change Cooktop Burner Orifice
ArtNo.102-0014 - Burner details
A
B
C
A orice, B internal orice, C external orice
Remove burner cap and head. Remove old jet. Fit
new orifice. Note the Wok burner has 2 orifices.
Reassemble in reverse order. Check appliance is
gas sound.
11.To Change Cooktop Burner
Electrode
Lift off cooktop grates, remove burner cap.
Remove the screw holding the electrode. Pull
electrode vertically up sufficiently to grip the
lead between thumb and forefinger. Pull off the
electrode, but keep hold of the lead. Fit new
electrode to the lead. Fix electrode in burner with
screw. Replace burner cap. Check the burner
ignition. Replace grates.
12.To Remove or Change a Cooktop
Burner
Remove the cooktop tray (see 3).
Center cooktop burners
Remove the control panel (see 2). The burners
are mounted in 2’s on cross supports. Disconnect
the burner feed pipes at the burners. Remove the
screw at the front holding the cross support. Slide
the support to the right to release in from the rear
location.
Lift the cross support and burners clear. The
burners are fixed to the cross supports with
screws underneath Remove the appropriate
burner and fit the new one. Reassemble in reverse
order. Check burner operation is satisfactory.
Wok burners
Disconnect the burner feed pipes at the burner.
Fit the new one and reassemble in reverse order.
Check burner operation is satisfactory.
13.To Remove Broiler Outer Door
Panel
Open left hand oven door and remove 2 screws
from bottom edge of broiler door. Open broiler
door, support broiler door outer panel and remove
two screws from top inner face of broiler door.
There is a pad of fibre insulation inside the door.
Reassemble in reverse order making sure that the
pad of insulation is in place.
14.To Remove an Oven Door
Open oven door and remove Handyrack (where
fitted) by springing one side out of the bracket on
the door and sliding the other side free. Support
the door and remove the two screws securing
the upper hinge and packing to the cooker front.
Remove the door from the lower hinge by lifting
slightly and moving outwards.
Reassemble in reverse order.
ArtNo.320-0002c
- Oven door side screws (Elan)
15.To Change Oven Door Outer Panel
ArtNo.215-0012 - Fitting the handles - Elan
Remove the two plastic blanking plugs from the
door handles. Remove the 4mm Hex headed
screws holding the handle to the door with the
hexagon key tool. Remove two screws from top
edge and two from bottom edge of the door.

7
SERVICING - WARNING
Disconnect from electricity and gas before servicing. Check appliance is safe when you have finished.
Remove outer door panel. Fit door handle to new
panel. Fit the plastic blanking plugs to the fixing
holes.
ArtNo.210-0005 -
Classic - fitting the handles 1
The handles should be above the fixings.
Fit panel to door. If replacing the outer panel on
the right hand door (with the Thermodial) take
care to make sure the sensor of the Thermodial is
sealed to the door by the rubber grommet.
Reassemble in reverse order.
16.To Change Oven Door Catch
Remove outer door panel (see 15). Remove
screws ‘B’ holding catch assembly to inner door
panel. Fit new catch and reassemble in reverse
order.
Check correct door operation.
ArtNo.320-0003 Oven door latch
B
17.To Change Oven Door Seal
Open oven door. The seal is held in place by small
hooks on the rear face. At the corner pull seal
diagonally away from the door centre until that
hook is released. Proceed to the next hook and
release it in a similar way, and so on.
ArtNo.320-0005 Oven door rubber seal
When fitting new seal, position the seal join at the
bottom. Hook the new seal in one of the corner
holes of the door, and proceed round the door
snapping in each hook in turn.
18.To Adjust Oven Door Catch Keep
Open oven door, slacken off locknut at base
of keep, and screw in or out as required until
required fit is obtained. Retighten locking nut.
19.To Change Ignition Generator
Disconnect from electricity supply.
Pull cooker forward to gain access to the cover
box at the rear of the left hand cooker. Remove
the screws securing the cover and lift clear.
Pull off all the leads to the generator noting
their positions. Slacken the two screws holding
generator to cooker and remove generator.
Fit new generator to cooker and replace leads.
Reassemble in reverse order. Refer to wiring
diagram. Check ignition performance.
20.To Remove Oven Inner Back
Open the oven door. Remove oven furniture. For
the left-hand oven unscrew the 2 thermostat phial
fixing screws.
Remove the fixings that secure the inner back
to the oven rear. Lift the removable panel away.
Re-assemble in reverse order. Ensure that the
retaining fixings are fully tightened. For the left-
hand oven unscrew the 2 thermostat phial fixing

SERVICING - WARNING
Disconnect from electricity and gas before servicing. Check appliance is safe when you have finished.
8
ArtNo.320-0020 Oven back fixing screws
screws. Remove the screws that secure the inner
back to the oven rear. Lift the removable panel
away. Re-assemble in reverse order. Ensure that
the retaining fixings are fully tightened.
21.To Replace the Cooling Fan
Disconnect from electricity supply.
Pull cooker forward to gain access to the rear of
the cooker.
Support the fan and remove the screws holding
the cooling fan mounting bracket. Gently lift the
fan and bracket away from the range taking care
not to strain the electrical connection. Disconnect
the leads from the fan noting the orientation.
Remove the fan from the mounting bracket. Fit the
new fan and reassemble in reverse order.
22.To Replace an Oven Fan
Disconnect from electricity supply.
Pull the unit forward to access the cover boxes at
the rear of the appliance. Remove the fixings that
secure the cover and lift it clear. Remove the fan
wiring, noting the connection positions. Remove
the inner back as detailed in Section 20. Hold the
fan blades and undo the centre nut (LH thread),
brass washers, fan blade and Circlip. Undo the
fixings that retain the fan and remove it from the
cavity rear. Fit the replacement and re-assemble
parts in reverse order. Check that the oven
operates satisfactorily.
23.To Remove an Oven fan Element
Disconnect from electricity supply.
Remove the inner back as detailed in Section 20.
Remove the fixings that secure the element
within the oven and lift the element away
carefully. Disconnect the leads and connect to
the replacement element and re-assemble parts
in reverse order. Check that the oven operates
correctly.
24.To Remove Broiler Element
Disconnect from electricity supply.
Remove broiler pan from broiler chamber. From
inside broiler compartment remove enamelled
front shield from broiler roof, 2 screws and
washers. Remove 2 screws and washers securing
the broiler element front support. Remove 1 screw
from each of the broiler elements and withdraw
broiler elements from broiler chamber. Disconnect
the leads and connect to the replacement
elements and re-assemble parts in reverse order.
Check operation of broiler.
25 To Remove the Left-hand Oven
Bottom and Top Elements
Disconnect from the electricity supply.
Bottom Element
Pull the cooker forward to access the cover boxes
at the rear of the unit. Remove the fixings that
secure the cover and lift it clear.

9
SERVICING - WARNING
Disconnect from electricity and gas before servicing. Check appliance is safe when you have finished.
ArtNo.321-0007 - MF oven element 1
A
Remove the 2 screws ‘A’ and allow the plate to
drop down.
ArtNo.321-0008 - MF oven element 2
B
Remove the 2 screws B, holding the element to
the bottom sheet..
Disconnect the leads, noting their positions.
Withdraw bottom element. Fit the new element
and re-assemble parts in reverse order.
Top Element
Open the LH oven door and undo the fixings that
secure the heat shield. Remove the top element
bracket fixings and withdraw element. Replace the
element and re-assemble parts in reverse order.
Check that the oven operates satisfactorily.
26.To Change Oven Light Bulb
Disconnect from the electricity supply.
Remove the oven furniture. Unscrew the bulb.
Fit an Edison screw fitting 15w 125-130v lamp,
FOR OVENS. It must be a special bulb, heat
resistant to 300 °C.

SERVICING - WARNING
Disconnect from electricity and gas before servicing. Check appliance is safe when you have finished.
10
Schematic Diagram of the Range Caution: Label all wires prior to disconnection when servicing controls. Wiring errors can cause improper and dangerous operation. Verify proper operation after servicing.
Code Description BRE Broiler elements BSB Broiler switch block BTC Broiler controller CFM Cooling fan motor IGS Ignition switches ISG Ignition spark generator LOS Left hand oven switch block NLI Neon indicator light OFM Oven fan motor OLS Oven light switch OTL Left hand oven thermostat OTR Right hand oven thermostat OVL Oven light bulb RBE Right hand top outer element RFE Right hand fan element ROE Right hand oven element RSB Right hand oven switch block RTI Right hand fan element RTO Right hand top inner element TCK Timer clock TCO Thermal cut out
Code Color BK Black BL Blue BR Brown GY Grey O Orange R Red V Violet W White Y Yellow

11
SERVICING - WARNING
Disconnect from electricity and gas before servicing. Check appliance is safe when you have finished.
Schematic Diagram of the Range Caution: Label all wires prior to disconnection when servicing controls. Wiring errors can cause improper and dangerous operation. Verify proper operation after servicing.
c d
12
6 5 4
7 8
2 1
3
P2
P1
P3
P4
P5 P6 P7
P8
12
12
4 P4 3 P3 2 P2 1 P1
P4
4 3P2 2
P1
1
P3
P1
42
4a P2
S2 S1
b
b
b
bk
gy
br
br
v
bk
v
r
or
y
w
r
gy
w
y
r
bk
bk
r
bk
v
v v
br
br
br
or
b
b
b b
b
v
v v v v v v
w
or
y
gy
w
w
or
v
br br br br br
br
br
br
br
r
or
w
y
vw
wv
br
rr
rr r rr
y
bk
r
bk
bk r
bk
bk
bk
gy
gy gy
gy
or or
or
bk
v
br
br
w
w
w
w
bk bk bk
r r r r r
r
y
N
L1 L2
B1
B2
B3 B4
A1
A2
A3
B5
B6
B7
D1 D2 D3
D4
F1
F2
G1 G2 H1 H2
C
J JJ J
K
KK
I

SERVICING - WARNING
Disconnect from electricity and gas before servicing. Check appliance is safe when you have finished.
12
Technical Data
This range is supplied set for Natural gas.
A conversion kit from NG to LP gas is included.
INSTALLER: Please leave these instructions with the User.
DATA BADGE LOCATION: Inside base of drawer cavity - remove drawer. For removal of drawer see
installation instructions.
Country of Destination: USA, Canada.
Gas Electric
Natural Gas 4.0” W.C (10 mbar) 240V 60Hz
Propane 10.0” W.C (25 mbar)
See appliance data badge for test pressures.
Dimensions
Overall height (splash not fitted) minimum 35 3/8” (89.8 cm) maximum 36 7/16” (92.5 cm)
Overall width 43 5/16” (110cm) See ‘Positioning the Range’
Overall depth without spacer 26 3/4” (68cm)
Overall depth with spacer 28 3/4” (73cm)
Space for fixing See ‘Positioning the Range’
Minimum space above cooktop 30” (76cm)
Connections
Gas Electric
1/2”NPT at rear right-hand side 240 V 60 Hz

13
SERVICING - WARNING
Disconnect from electricity and gas before servicing. Check appliance is safe when you have finished.
Ratings
Natural Gas Propane Gas
Orice Orice Screw*
Cooktop
Wok Burner 15,000Btu/hr internal 110 15,000Btu/hr internal 71 49
external 166 external 93
Large Burner 12,000Btu/hr 170 12,000Btu/hr 106 38
Medium Burners 9,200Btu/hr 150 8,000Btu/hr 84 31
Small Burner 5,000Btu/hr 107 4,200Btu/hr 61 22
Gas burner inputs based on Gross Caloric Value.
* The valves in this range are tted with adjustable bypass screws. The range is supplied with the bypass screws set
for Natural gas. For LPG conversion the bypass screws must be screwed all the way down.
Ovens Left-hand Multi-function Oven Right-hand Fan Oven
Fan element 2.5kW 2.5kW
Top element 1.2kW
Browning Element 1.15kW
Bottom element 1.0kW
Broiler 2.3kW
Maximum total electrical load at 240V approximate total including oven lights, oven fan etc: 7.4kW.
Orifices
AA DC CB
A Wok burner
B Large Burner
C Medium Burners
D Small Burner
ArtNo.102-0037 - Soudillon tap bypass screw
Valve bypass screw
ArtNo.102-0014 - Burner details
B, C, D A1 A2

14

15

AGA Marvel
1260 E. VanDeinse St.
Greenville, MI 48838
Business [phone]
Fax: [phone]
Toll Free Telephone [phone]
www.agamarvel.com
