Agilent Technologies E8364-60105 Installation and operation manual

Agilent Part Number: E8364-90022
Printed in USA December 2007
Supersedes Print Date: April 2007
© Agilent Technologies, Inc. 2003, 2004, 2007
Installation Note
Extended Frequency Range Upgrade Kit (50 GHz to 67 GHz)
Upgrade Kit Number: E8364-60105
For E8364B/C Microwave Network Analyzers WITHOUT the
Configurable Test Set Option (Option 014)

2Installation Note E8364-90022
WARRANTY STATEMENT
THE MATERIAL CONTAINED IN THIS DOCUMENT IS PROVIDED “AS IS,” AND IS SUBJECT TO
BEING CHANGED, WITHOUT NOTICE, IN FUTURE EDITIONS. FURTHER, TO THE MAXIMUM
EXTENT PERMITTED BY APPLICABLE LAW, AGILENT DISCLAIMS ALL WARRANTIES,
EITHER EXPRESS OR IMPLIED WITH REGARD TO THIS MANUAL AND ANY INFORMATION
CONTAINED HEREIN, INCLUDING BUT NOT LIMITED TO THE IMPLIED WARRANTIES OF
MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE. AGILENT SHALL NOT BE
LIABLE FOR ERRORS OR FOR INCIDENTAL OR CONSEQUENTIAL DAMAGES IN
CONNECTION WITH THE FURNISHING, USE, OR PERFORMANCE OF THIS DOCUMENT OR
ANY INFORMATION CONTAINED HEREIN. SHOULD AGILENT AND THE USER HAVE A
SEPARATE WRITTEN AGREEMENT WITH WARRANTY TERMS COVERING THE MATERIAL IN
THIS DOCUMENT THAT CONFLICT WITH THESE TERMS, THE WARRANTY TERMS IN THE
SEPARATE AGREEMENT WILL CONTROL.
DFARS/Restricted Rights Notice
If software is for use in the performance of a U.S. Government prime contract or subcontract,
Software is delivered and licensed as “Commercial computer software” as defined in DFAR
252.227-7014 (June 1995), or as a “commercial item” as defined in FAR 2.101(a) or as
“Restricted computer software” as defined in FAR 52.227-19 (June 1987) or any equivalent
agency regulation or contract clause. Use, duplication or disclosure of Software is subject to
Agilent Technologies’ standard commercial license terms, and non-DOD Departments and
Agencies of the U.S. Government will receive no greater than Restricted Rights as defined in
FAR 52.227-19(c)(1-2) (June 1987). U.S. Government users will receive no greater than
Limited Rights as defined in FAR 52.227-14 (June 1987) or DFAR 252.227-7015 (b)(2)
(November 1995), as applicable in any technical data.
Safety Notes
The following safety notes are used throughout this document. Familiarize yourself with each
of these notes and its meaning before performing any of the procedures in this document.
WARNING Warning denotes a hazard. It calls attention to a procedure which,
if not correctly performed or adhered to, could result in injury or
loss of life. Do not proceed beyond a warning note until the
indicated conditions are fully understood and met.
CAUTION Caution denotes a hazard. It calls attention to a procedure that, if not
correctly performed or adhered to, could result in damage to or destruction
of the instrument. Do not proceed beyond a caution sign until the indicated
conditions are fully understood and met.

Installation Note E8364-90022 3
Contacting Agilent
Assistance with test and measurements needs and information on finding a local Agilent
office are available on the Web at:
www.agilent.com/find/assist
NOTE In any correspondence or telephone conversation, refer to the Agilent
product by its model number and full serial number. With this
information, the Agilent representative can determine whether your
product is still within its warranty period.
If you do not have access to the Internet, please contact your Agilent field engineer.
About the Upgrade Kit
If you need assistance, refer to “Contacting Agilent” on page 3.
Description of the Upgrade
This upgrade kit is used to extend the frequency range of the:
• E8364B/C PNA microwave network analyzer from 50 GHz to 67 GHz
This upgrade applies only to a standard PNA, with no optional hardware.
Products affected. . . . . . . . . . . . . . . . . . . . . . . . . . E8364B/C with no RF hardware options
Installation to be performed by . . . . . . . . . . . . . . Agilent service center or personnel
qualified by Agilent
Estimated installation time . . . . . . . . . . . . . . . . . 2.5 hours
Estimated adjustment time . . . . . . . . . . . . . . . . . 1 hour
Estimated full instrument calibration time . . . . 4.5 hours

4Installation Note E8364-90022
Items Included in the Upgrade Kit
Check the contents of your kit against the following list. If any item is missing or damaged,
contact Agilent Technologies. Refer to “Contacting Agilent” on page 3.
Table 1 Option 067 Upgrade Kit (E8364-60105) to Extend the E8364B/C to 67 GHz
Ref.
Desig. Description Qty Part Number
N/A Installation note (this document) 1 E8364-90022
N/A License key certificate 1 5964-5136
N/A Model number nameplate (for 67 GHz analyzer E8361A) 1 E8361-80001
N/A Model number nameplate (for 67 GHz analyzer E8361C) 1 E8361-80006
N/A Front panel overlay, no options 1 E8361-80002
A12 A12 source 20 1 E8361-60002
A17 LOMA 12 1 5087-7247
A18 MA 24 1 5087-7248
A22 Switch 1 5087-7238
A23 SOMA 70, port 1
2 5087-7249
A24 SOMA 70, port 2
A25 Test port 1 coupler
2 5087-7225
A26 Test port 2 coupler
A27 Channel A first converter (mixer)
4 5087-7258
A28 Channel R1 first converter (mixer)
A29 Channel R2 first converter (mixer)
A30 Channel B first converter (mixer)
N/A Mixer bias board 1 E8361-63044
N/A SOMA 70 bracket 2 E8361-00002
N/A Machine screw M3.0 x 10 (for attaching A22 switch) 2 0515-0374
N/A Machine screw M3.0 x 6 (for attaching SOMA 70 brackets) 6 0515-0430
N/A Machine screw M3.0 x 25 (for attaching SOMA 70s to brackets) 4 0515-0667

Installation Note E8364-90022 5
N/A Machine screw M3.0 x 27.5 (for attaching E8361-20063 lid
clamps to SOMA 70s)
4 0515-1862
N/A Lid clamp - SOMA 70s 2 E8361-20063
N/A Ribbon cable, A23/A24 SOMA 70s to A16 test set motherboard 2 8121-1001
N/A Cable, stranded wire, A22 switch to A16 test set motherboard 1 8121-0990
W2 A21 SOMA 50 to A22 switch 1 E8361-20002
W3 A22 switch to A23 SOMA 70 1 E8361-20003
W4 A22 switch to A24 SOMA 70 1 E8361-20004
W5 A23 SOMA 70 to A25 test port 1 coupler 1 E8361-20005
W6 A24 SOMA 70 to A26 test port 2 coupler 1 E8361-20006
W7 A23 SOMA 70 to A28 channel R1 mixer 1 E8361-20009
W8 A24 SOMA 70 to A29 channel R2 mixer 1 E8361-20010
W9 A25 test port 1 coupler to A27 channel A mixer 1 E8361-20007
W10 A26 test port 2 coupler to A30 channel B mixer 1 E8361-20008
W20 A8 fractional-N synthesizer J106 to A17 LOMA 12 J2 1 E8361-20045
W21 A8 fractional-N synthesizer J101 to A17 LOMA 12 J3 1 E8361-20046
W38 A23 SOMA 70 to A16 test set motherboard 1 E8361-60124
W39 A24 SOMA 70 to A16 test set motherboard 1 E8361-60123
Table 1 Option 067 Upgrade Kit (E8364-60105) to Extend the E8364B/C to 67 GHz
Ref.
Desig. Description Qty Part Number

6Installation Note E8364-90022
Installation Procedure for the Upgrade Kit
The network analyzer must be in proper working condition prior to installing this option. Any
necessary repairs must be made before proceeding with this installation.
WARNING This installation requires the removal of the analyzer’s protective outer
covers. The analyzer must be powered down and disconnected from the
mains supply before performing this procedure.
Electrostatic Discharge Protection
Protection against electrostatic discharge (ESD) is essential while removing or connecting
cables or assemblies within the network analyzer.
Static electricity can build up on your body and can easily damage sensitive internal circuit
elements when discharged. Static discharges too small to be felt can cause permanent
damage. To prevent damage to the instrument:
•always wear a grounded wrist strap having a 1 MΩresistor in series with it when handling
components and assemblies.
•always use a grounded, conductive table mat while working on the instrument.
•always wear a heel strap when working in an area with a conductive floor. If you are
uncertain about the conductivity of your floor, wear a heel strap.
Figure 1 shows a typical ESD protection setup using a grounded mat and wrist strap. Refer to
“Tools Required for the Installation” on page 7 for part numbers.
Figure 1 ESD Protection Setup

Installation Note E8364-90022 7
Overview of the Installation Procedure
Step 1. Verify the Model, Serial, and Option Numbers of the Analyzer
Step 2. Remove the Outer and Inner Covers
Step 3. Replace the A12 Source 20
Step 4. Replace the Top Side to Bottom Side Cables
Step 5. Raise the Receiver Deck
Step 6. Remove the Old Bottom Side Hardware and Cables
Step 7. Install the New Hardware and Cables
Step 8. Lower the Receiver Deck
Step 9. Replace the Front Panel Nameplate and Overlay
Step 10. Reinstall the Inner and Outer Covers
Step 11. Enter the New Model Number
Step 12. Perform Post-Upgrade Adjustments
Tools Required for the Installation
ESD Equipment and Supplies Required for the Installation
Description Agilent Part Number
T-10 TORX driver (set to 9 in-lbs) N/A
T-20 TORX driver (set to 21 in-lbs) N/A
5/16-inch torque wrench (set to 10 in-lbs) N/A
1-inch torque wrench (set to 72 in-lbs) N/A
Description Agilent Part Number
ESD grounding wrist strap 9300-1367
5-ft grounding cord for wrist strap 9300-0980
2 x 4 ft conductive table mat and 15-ft grounding wire 9300-0797
ESD heel strap (for use with conductive floors) 9300-1308

8Installation Note E8364-90022
Test Equipment Required for Post-Upgrade Adjustments
Step 1. Verify the Model, Serial, and Option Numbers of the Analyzer
Refer to the License Key Certificate supplied with the kit:
• Verify that the analyzer’s model and serial numbers match those on the certificate.
• Verify that the option number on the certificate matches the option described by this
installation note.
If the model, serial, or option number do not match the expected results, you will not be able
to install the option. If this is the case, contact Agilent for assistance. Refer to “Contacting
Agilent” on page 3.
Description Agilent Part Number
Power meter E4418B/E4419B
Power sensor, Type-N (100 kHz–4.2 GHz) 8482A
Power sensor, 2.4 mm (4.2 GHz–50 GHz) 8487A
Power sensor, V-Band (50 GHz–67 GHz)a
a. This sensor and adapter must be calibrated together by the Agilent factory. The data supplied
are only valid as long as the sensor and adapter remain connected.
V8486A
Adapter, WR-15 to 1.85 mm (m)aV281B
Adapter, 1.85 mm (f) to 1.85 mm (f)b
b. The 1.85 mm connector has the same ruggedness and is compatible with the 2.4 mm connec-
tor. 1.85 mm and 2.4 mm connectors and adapters may be used interchangeably.
85058-60114
Adapter, 3.5 mm (m) to 2.4 mm (f) 11901D
Adapter, 2.4 mm (f) to 2.4 mm (f)b11900B
Adapter, Type-N (f) to 2.4 mm (f) 11903B
Adapter, SMA (m) to SMA (f), right angle 1250-1249
Test cable, 2.4 mm (f) to 2.4 mm (f)bor
Test cable, 1.85 mm (f) to 1.85 mm (f)b
85133C
N4697E
5/16-inch, open-end torque wrench (set to 10 in-lbs) 8710-1765
1/4-inch, open-end wrench, thin profile 8710-0510

Installation Note E8364-90022 9
Step 2. Remove the Outer and Inner Covers
Remove the Outer Cover
CAUTION This procedure is best performed with the analyzer resting on its front
handles in the vertical position. Do not place the analyzer on its front panel
without the handles. This will damage the front panel assemblies.
1. Disconnect the power cord (if it has not already been disconnected).
2. Using a T-20 TORX driver, remove the strap handles (item ①) by loosening the screws
(item ②) on both ends until the handle is free of the analyzer.
3. Using a T-20 TORX driver, remove the four rear panel feet (item ③) by removing the center
screws (item ④).
4. Slide the four bottom feet (item ⑤) off the cover.
5. Slide the cover off of the frame.
Figure 2 Outer Cover Removal
NOTE The figure above shows the E8364B front panel and floppy disk drive. The
E8364C front panel has a slightly different appearance and does not
include a floppy disk drive.

10 Installation Note E8364-90022
Remove the Inner Cover
1. Place the analyzer top-side up on a flat surface.
2. Using a T-10 TORX driver, remove the eleven screws (item ①).
3. Lift off the cover.
Figure 3 Inner Cover Removal
NOTE The figure above shows the E8364B front panel and floppy disk drive. The
E8364C front panel has a slightly different appearance and does not
include a floppy disk drive.

Installation Note E8364-90022 11
Step 3. Replace the A12 Source 20
1. With a 5/16-inch wrench, disconnect semirigid cable (item ①).
2. Disengage the A12 source 20 from the A11 connector and slide it out of the analyzer while
observing the CAUTION below.
CAUTION To avoid damage to the semirigid cable (item ①), pull down on the cable from the
bottom side of the analyzer to move it away while sliding out the A12 source 20.
The cable has some spring to it and the RF pin could be damaged by the A12
source 20.
Figure 4 A12 Source 20 Replacement
NOTE The figure above shows the E8364B front panel and floppy disk drive. The
E8364C front panel has a slightly different appearance and does not
include a floppy disk drive.

12 Installation Note E8364-90022
3. Slide the new A12 source 20 into the analyzer while observing the CAUTION above. Be sure
that the assembly is seated completely into the A11 connector.
4. Reconnect the semirigid cable and tighten with a 5/16-inch torque wrench.

Installation Note E8364-90022 13
Step 4. Replace the Top Side to Bottom Side Cables
1. Place the analyzer on its side as shown.
2. Remove the cable hold-down wire (item ①).
3. Disconnect cables W19 and W20 at both ends; two top side connections and two bottom
side connections.
4. Remove cables W19 and W20 from the analyzer.
5. Position the new cables provided into the analyzer. These cables are now designated as
W20 and W21. Connect these cables to the top side connectors at A8J101 and A8J106 but
do not connect the other ends to the A17 LOMA 10 as the LOMA 10 will be replaced.
6. Reinstall the cable hold-down wire (item ①).
Figure 5 Top Side to Bottom Side Cables Replacement

14 Installation Note E8364-90022
Step 5. Raise the Receiver Deck
1. Place the analyzer bottom-side up on a flat surface.
2. Using a T-10 TORX driver, remove the four screws, (item ①), that secure the receiver deck.
3. Pull the latch pin (item ②) towards the opposite side of the analyzer to release the receiver
deck.
4. Lift the receiver deck to partially raise it, then release the latch pin (item ②). Lift the
receiver deck to its fully raised position and ensure that the latch pin latches in the raised
position.
Figure 6 Receiver Deck Raising

Installation Note E8364-90022 15
Step 6. Remove the Old Bottom Side Hardware and Cables
•Remove the A17 LOMA 10
•Remove the A18 MA 20
•Remove the A22 Switch/Splitter
•Remove the A23 and A24 Detectors
•Remove the A27, A28, A29, and A30 First Converters (Mixers)
•Remove the A25 and A26 Test Port Couplers
Remove the A17 LOMA 10
1. Using a 5/16-inch wrench, disconnect the three semirigid cables (item ①) from the A17
LOMA 10. Two of these cables should already be disconnected (from step 4).
2. Disconnect the ribbon cable (item ②) at the A17 LOMA 10.
3. Using a T-10 TORX driver, remove the four mounting screws (item ③) from the side of the
analyzer. Retain the mounting screws for reinstallation later.
CAUTION Be careful not to damage the center pins of the semirigid cables. Some flexing of
the cables is necessary to remove the assembly. Do not over-bend them.
4. Remove the A17 LOMA 10 from the analyzer. Observe the CAUTION above.
Figure 7 A17 LOMA 10 Removal

16 Installation Note E8364-90022
Remove the A18 MA 20
1. Using a 5/16-inch wrench, disconnect the two semirigid cables (item ①) from the A18 MA
20. Remove these cables completely to allow the A18 MA 20 to be removed from the
analyzer. Retain these cables for reinstallation later.
2. Disconnect the ribbon cable (item ②) at the A18 MA 20.
3. Using a T-10 TORX driver, remove the four mounting screws (item ③) from the side of the
analyzer. Retain the mounting screws for reinstallation later.
CAUTION Be careful not to damage the center pins of the semirigid cables. Some flexing of
the cables is necessary to remove the assembly. Do not over-bend them.
4. Remove the A18 MA 20 from the analyzer. Observe the CAUTION above.
Figure 8 A18 MA 20 Removal

Installation Note E8364-90022 17
Remove the A22 Switch/Splitter
1. Disconnect the stranded switch control cable (item ①) from the A22 switch/splitter.
Remove this cable completely from the analyzer and discard it. It will be replaced later.
2. Using a 5/16-inch wrench, remove the five semirigid cables (item ②). Discard these cables,
they will be replaced with new ones.
3. Using a T-10 TORX driver, remove the two mounting screws (item ③). Retain the
mounting screws for reinstallation later.
CAUTION Be careful not to damage the center pins of the semirigid cables. Some flexing of
the cables is necessary to remove the assembly. Do not over-bend them.
4. Remove the A22 switch/splitter from the analyzer. Observe the CAUTION above. Discard this
switch/splitter, it will be replaced with a new one.
Figure 9 A22 Switch/Splitter Removal

18 Installation Note E8364-90022
Remove the A23 and A24 Detectors
1. Disconnect the stranded control cable (item ①) from each detector. Remove and discard
this cable, it will not be used.
2. Using a 5/16-inch wrench, disconnect the remaining semirigid cable (item ②) from each
detector. Remove and discard these cables, they will not be used.
3. Remove the flexible cable (item ③) from each detector and discard them, they will not be
used.
4. Using a T-10 TORX driver, remove the three mounting screws (item ④) from each bracket
to which the detectors are attached.
5. Remove the brackets, with the detectors attached, from the analyzer and discard them,
they will not be used.
Figure 10 A23 and A24 Detectors Removal

Installation Note E8364-90022 19
Remove the A27, A28, A29, and A30 First Converters (Mixers)
1. Using a 5/16-inch wrench, disconnect the six semirigid cables (item ①) and the four
flexible cables (item ②).
2. Using a T-10 TORX driver, remove the four mounting screws (item ③). Retain the
mounting screws for reinstallation later.
CAUTION Be careful not to damage the center pins of the semirigid cables. Some flexing of
the cables is necessary to remove the assembly. Do not over-bend them.
3. Remove the mixer bracket with all four mixers attached and disconnect the ribbon cable
(item ④). Observe the CAUTION above. Set this item aside for modification later.
Figure 11 A27, A28, A29, and A30 First Converters Removal

20 Installation Note E8364-90022
Remove the A25 and A26 Test Port Couplers
1. Using a 5/16-inch wrench, remove the two semirigid cables (item ①) from each of the test
port couplers. Discard these cables, they will be replaced with new ones.
2. Using a 1-inch wrench, remove the test port coupler nuts (item ②) from the front panel.
Retain the test port coupler nuts for reinstallation later.
CAUTION Be careful not to damage the center pins of the semirigid cables. Some flexing of
the cables is necessary to remove the assembly. Do not over-bend them.
3. Remove the A25 and A26 test port couplers from the analyzer. Observe the CAUTION above.
Figure 12 A25 and A26 Test Port Couplers Removal
